- Page 1 STRYKER Wheelchair USER MANUAL...
-
Page 3: Table Of Contents
Table of Contents INTRODUCTION ............................. 1 INTENDED USE ............................1 SCHEMATIC AND FEATURES ......................2 SPECIFICATION TABLE ........................3 OPERATIONAL INSTRUCTIONS - USE ..................... 4 SAFETY PRECAUTIONS ........................9 MOUNTING ............................11 CARE and MAINTENANCE ......................... 14 STORAGE .............................. 15 PERIOD OF USE ........................... -
Page 5: Introduction
INTENDED USE The Stryker Wheelchair is intended for indoor or outdoor use with or without an attendant. This foldable wheelchair is designed for carrying a maximum weight capacity up to 135kg with comfort with easy-to-use features. -
Page 6: Schematic And Features
SCHEMATIC AND FEATURES Painted aluminium frame Height adjustable, forward & backward armrest with PU pad Swing away footrest design to reduce accidents Half folding backrest design makes for easy during user transfer. transportation and compact storage. ... -
Page 7: Specification Table
SPECIFICATION TABLE Backrest Height & Inclination 45.5cm Folded Width 34.5cm Gross Weight 17kg Height (Seat to floor) 46cm Overall Dimensions (W x D x H) 67cm x 99cm x 90cm Seat Depth 42cm Seat Width 45cm Weight Capacity 135kg Wheel Measurements – Front (Diameter) 20cm (8”) Wheel Measurements –... -
Page 8: Operational Instructions - Use
OPERATIONAL INSTRUCTIONS - USE For the safe use of your wheelchair, in and out of the house, you need to be confident in the main manoeuvres, such as pushing, braking, going back and forth on flat surfaces (can be done with the help of an assistant). Avoid slopes, uneven surfaces etc. - Page 9 How to get out of the wheelchair alone Avoid bending too far down, or sideways, or backward, as there would be a risk of overturning or losing balance especially if the chair has a reduced seat and / or a high seat height (e.g. cushion). Make sure that the front wheels are in the front and the rear wheels braked when sitting on the wheelchair transferring to another location (e.g.
- Page 10 Upward Slope Do not hang anything above the backrest or above the armrest. This may cause the chair to tip over. To go up hills, install the anti-tippers. To this end insert the anti-tippers into the rear tube and take care that the safety clip protrudes out of the hole in the back tube, locking the anti-tippers into place.
- Page 11 Stairs – Up and Down When stairs are the only option, once the chair is tilted backwards by a person holding the chair by the handles, rest the rear wheels on the steps. The second person must hold a fixed part of the front area of the frame, lift the seat and hold it until the first person stands on the next step and so on.
- Page 12 How To Propel The Chair Yourself Once the user is seated in the chair, take the rings of the rear wheels with both hands, and forcefully push forward so that the chair begins to move. Release the rings. When the chair stops, repeat the action again. Using the Brakes Once the chair is stationary, the user holds the brakes with their hands, activates them, so that the rear wheels...
-
Page 13: Safety Precautions
SAFETY PRECAUTIONS Failure to follow the safety precautions may result in the risk of serious injury. DO NOT exceed the maximum supported weight of 135kg. Make sure that all parts are in good working order. • • Do not use the product on stairs or escalators. •... - Page 14 If any parts are damaged, broken, worn, or missing, contact the dealer. • Stability - The Stryker Wheelchair is designed to ensure safety and stability, provided that you maintain the center of gravity while using it. To preserve the chair's stability, it's important to avoid sudden movements that could lead to a shift in your center of gravity.
-
Page 15: Mounting
TYRE INFLATION – Only if your wheelchair is equipped with pneumatic tyres. If your Stryker Wheelchair is equipped with pneumatic tyres, check the tyre pressure at least once a week. Proper inflation pressures will prolong the life of your tyres and help ensure smooth operation. - Page 16 Adjusting footrests – installation, adjustment and removal The Footrests are folding inward for easy transfer. The footrest is adjustable in degrees of inclination. Note: To remove the footrest, squeeze the trigger toward the chair, rotate the footrests outward or inward and raise them.
- Page 17 Fixing system-adjusting rear wheel The fixing-adjustment system is the most important adjustment for the wheelchair because it determines the center of gravity, the rotation of the chair, the degrees of the wheels and the height of the seat. The center of gravity is determined by the user’s position on the chair. After changing the height of the seat, you may need to adjust the height of the attendant brake handle.
-
Page 18: Care And Maintenance
CARE and MAINTENANCE Failure to care for and monitor your product may result in the risk of serious injury. • Clean the product regularly with warm water and a soft cloth. Do not use abrasive products, detergents or solvents. • Dry with a clean, dry soft cloth. •... -
Page 19: Storage
Modifications We have designed and engineered your Stryker Wheelchair to provide maximum mobility and utility. Under no circumstances should you modify, add, remove, or disable any feature, part, or function of your wheelchair. -
Page 20: Warranty
(or replaced at the Company’s discretion) free of charge. Any unauthorised modifications will invalidate the warranty. 12 MONTH LIMITED WARRANTY Your Top Gun Stryker Wheelchair is fully guaranteed FIVE-YEAR LIMITED WARRANTY for 12-months from the date of purchase against... - Page 21 17 | P a g e...
- Page 22 Copyright Top Gun Mobility Owner’s Manual & Warranty Booklet 2023 18 | P a g e...
