VisionPass SP
Quick User Guide
All descriptions illustrations, and specifications in this brochure should be
considered approximate and may relate to optional equipment or feature

Advertisement

loading
Need help?

Need help?

Do you have a question about the VisionPass SP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Idemia VisionPass SP

Summary of Contents for Idemia VisionPass SP

  • Page 1 VisionPass SP Quick User Guide All descriptions illustrations, and specifications in this brochure should be considered approximate and may relate to optional equipment or feature...
  • Page 2 Wall mount Cable kit Cover Plate Documentation package ® ® ® ® Electronic documentation is provided in Adobe Acrobat format (PDF). Adobe Acrobat Reader is available at http://www.adobe.com. IDEMIA - 2023_2000073932 – V2 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...

  • Page 3: Regulatory, Safety And Environmental Notices

    Power Ground. Note that all connections of the VisionPass SP terminal described hereafter are of SELV (Safety Electrical Low Voltage) type. This symbol means do not dispose of your product with your other household waste. Instead, you should protect human health and the environment by handing over your waste equipment to a designated collection point for the recycling of waste electrical and electronic equipment.
  • Page 4 Table of Contents Color Step Content Overview Wiring Three Communications Four SDAC (Single Door Access Control) Five Software Administration Seven Enrollment Eight Optional features IDEMIA - 2023_2000073932 – V2 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...

  • Page 5: Product Overview

    Product Overview Visible camera White leds VisionPass SP provides an innovative and (RGB) effective solution for access control applications using very fast acquisitions of the face. 5" WVGA Access control and Time & Attendance Touchscreen Biometric authentication by face acquisition Simple and ergonomic man-machine interface...
  • Page 6 Please install VisionPass SP terminal vertically at the recommended height, and keep the openings clear to allow air flow. VisionPass SP is designed to operate indoor. To optimize VisionPass SP performance, it is better to follow the rules below: •...
  • Page 7 Terminal Implementation To secure an access, IDEMIA recommends installing the VisionPass SP terminal as a part of a typical Access Control system, which consists of the components described below. The VisionPass SP terminal NON SECURED SECURED AREA AREA Its role is to process the access request from the user. It performs access right...
  • Page 8 “open” command to rights check. the gate controller. Note: One user must be enrolled in the terminal database, in order to be able to perform biometric check. IDEMIA - 2023_2000073932 – V2 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...

  • Page 9: Access Control Modes

    Identifier on the keypad, or a Wiegand frame is received from an external device stored on the contactless card or in the user record in the terminal’s local database (**) IDEMIA - 2023_2000073932 – V2 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 10 General precautions  Do not expose the terminal to extreme temperatures.  When the environment is very dry, avoid synthetic carpeting near the VisionPass SP terminal, to reduce the risk of unwanted electrostatic discharge. Areas containing combustibles  Do not install the terminal in the vicinity of gas stations or any other installation containing flammable or combustible gases or materials.
  • Page 11 User must exit from intention area to allow The facial access control is only initiated when a user is entering the intention area. The user shall walk to the VisionPass SP, looking a next user at the device screen until a green square is displayed on his face. The white LED may light up automatically during the approach in identification case of low light conditions.

  • Page 12: User Guidance

    User Guidance VisionPass SP proposes 3 ways to guide the user to best position his / her face for identification. No User Guidance : terminal acquisition volume is large enough to allow the user to be recognized easily as soon as he / she looks at it.
  • Page 13 Deliberate trigger By default, VisionPass SP will react when a user enters in the intention area, and will start facial acquisition as soon as a user enters in the detection area and looks at the terminal. Note that the video stream is never recorded by VisionPass SP.

  • Page 14: Wiring Overview

    Backup of the Date/Time of the terminal: the volatile settings (such as date/time) of the terminal are protected against power failure, by a dedicated component during 2 hours (at 25°C) without external power supply. IDEMIA - 2023_2000073932 – V2 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...

  • Page 15: Power Supply

    Black A battery backup or uninterrupted power supply (UPS) with built-in surge protection is recommended. Maximum distance (meters) IDEMIA recommends using a 24V 1.25A power supply and AWG16 gauge cable. The voltage measured on the product vs power source rating...
  • Page 16 The maximum total cable length is 1200m (4000 ft.) ➢ The cable must be dedicated to this installation and not used for any other purpose *Note: the RS-232 has not been UL evaluated. IDEMIA - 2023_2000073932 – V2 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 17 Use a category 6* shielding cable (120 Ohms) or better. It is strongly recommended to insert a repeater unit every 90 m. Static mode is enabled by default on VisionPass SP terminals (factory setting) : IP=192.168.1.10, Gateway=192.168.1.254, Mask= 255.255.254.0 Terminal Block Ethernet connection ...
  • Page 18 For 18 AWG, the maximum cable distance is (150m) 500 ft. ; for 20 AWG, the maximum is 90m (300 ft.) ; for 22 AWG, the maximum is 60m (200 ft.) All controller outputs shall be open drain or 5 V +/- 5% *Note: GPO0 has not been UL evaluated. IDEMIA - 2023_2000073932 – V2 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 19 White / Red 3 LED1 Blue 4 LED2 Blue / Red Data Clock Out Data 5 OUT0 Green Clock 6 OUT1 White Data Clock In/Out 7 GND Black IDEMIA - 2023_2000073932 – V2 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 20 - Product unmounted of the wall plate (rear connectors accessible): switch disabled (contact open). Warning ➢ This VisionPass SP terminal is part of security system; it is customer’s responsibility to connect the tamper switch (contact) to physical access controller, in order to prevent the access to the connector blocks.
  • Page 21 If door contact is not used, GPI1 (#2) and GPO1 (#7) shall be connected together Power supply from electrical source shall be switched off before starting the installation. IDEMIA - 2023_2000073932 – V2 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 22 1A, an external relay must be used. ➢ The internal relay is designed for 100.000 cycles. If more cycles are needed, an external relay driven by GPO must be used. IDEMIA - 2023_2000073932 – V2 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 23 Software for Remote Administration and Enrollment VisionPass SP Terminals are compatible with MorphoManager application (version 16.3 or higher) IDEMIA - 2023_2000073932 – V2 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 24 Language Settings: user interface language selection, Network Settings: LAN or WLAN parameters Password Settings: terminal administration password modification Boot assistant at next boot: Display this screen on next boot. IDEMIA - 2023_2000073932 – V2 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 25 Configuration with a script hosted on a USB dongle not possible The default configuration is recommended by IDEMIA for operations. To use the features non available by default, the On-demand security state of VisionPass SP can be unlocked with MorphoBioToolBox.
  • Page 26 This Windows application can also be used for the full terminal configuration. Starting from version 16.3, MorphoManager can also configure the TLS communication of a VisionPass SP terminal as soon as the latter has a valid IP address. IDEMIA - 2023_2000073932 – V2...
  • Page 27  User specific access rules definition Optionally, a contactless card can be created. Please refer to the User enrollment section in VisionPass SP Administration Guide. “Local enrollment” shall not be used in a secure system, where it should be performed on an enrolment station (a PC with a dedicated application such as MorphoManager).
  • Page 28 Floor marking is recommended at 60 cm from the • Remove all « non-always on » accessories device to invite the user to stand at the right place, • Remove your glasses before launching the enrollment process. • Remove face masks. IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 29 The PIN code is entered using a numeric keypad to extract and type of card. displayed on the LCD touch screen and validate by clicking on: IDEMIA - 2023_2000073932 – V2 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 30 Time and Attendance feature VisionPass SP terminals support an optional Time and Attendance (T&A) feature. For this, the terminal adds a specific T&A information to each identification or authentication record stored in the embedded event log database. This information is provided by the user through a specific screen displayed during identification or authentication process.
  • Page 31 Date / Time synchronization  The VisionPass SP terminal clock has a +/- 20 ppm typical time deviation at +25°C (roughly +/- 2sec per day). At lower and higher temperature, deviation may be greater (maximum : 8 seconds per 48 hours).
  • Page 32 Release note : for each firmware version, a release note is published describing the new features, the supported products, the potential known issues, the upgrade / downgrade limitations, the recommendations, the potential restrictions… IDEMIA - 2023_2000073932 – V2 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 33 Copyright © 2023, IDEMIA. All rights reserved. www.idemia.com Reproduction in whole or in part in any form or medium without the express written permission of IDEMIA is prohibited. The trademarks identified herein are the trademarks of registered trademarks of IDEMIA, or other third party.
