Installation Guide
InSight Series Bullet Network Camera
*Images may differ from actual products.
InSight S345ZI is used for demonstration in this guide.
©2024 TP-Link 7106511452 REV1.0.0
2. Mount Camera
Option 1
1
A
Φ6 mm
Optional
B
Φ25 mm
Φ3 mm
2
Refer to 4. Connect Alarm/Audio Device
(Optional) as necessary
Refer to 5. Waterproof Cables as necessary
3
4
1. Get Ready
Box
Option 2
1
A
Φ6 mm
Optional
B
Φ25 mm
Φ3 mm
2
Refer to 4. Connect Alarm/Audio Device
(Optional) as necessary
Refer to 5. Waterproof Cables as necessary
3
4
microSD Card
Nano SIM Card
Waterproof Tape
(optional)
(For 4G Camera)
(optional)
Option 3
1
61.5mm
Φ
Φ
Appropriate drilling size (Φ)
When installing with anchors
Φ = 6 mm (15/64 in.)
When installing with screws only
Φ = 3 mm (1/8 in.)
D=25mm
61.5mm
Φ
Φ
2
Refer to 4. Connect Alarm/Audio Device
(Optional) as necessary
Refer to 5. Waterproof Cables as necessary
3
4
Pole Mouting Brackets
(optional)
