TP-Link VIGI InSight Series Installation Manual
Turret network camera
Hide thumbs
Also See for VIGI InSight Series:
- Quick start manual (16 pages) ,
- Installation manual (2 pages) ,
- Quick start manual (15 pages)
Advertisement
Quick Links
Installation Guide
InSight Series Turret Network Camera
*Images may differ from actual products.
©2024 TP-Link 7106511345 REV1.0.0
2. Mount Camera
Option 1
1
Φ25 mm
2
3
4
Tilt: 0° to 75°
Rotate: 0° to 360°
A
Φ6 mm
B
Φ3 mm
Refer to 4. Connect Alarm/Audio Device
(Optional) as necessary
Refer to 5. Waterproof Cables as necessary
Pan: 0° to 360°
1. Get Ready
Box
Option 2
1
2
3
4
Tilt: 0° to 75°
Rotate: 0° to 360°
Only for certain models
microSD (optional)
Waterproof Tape (optional)
A
Φ6 mm
B
Φ3 mm
Refer to 4. Connect Alarm/Audio Device
(Optional) as necessary
Refer to 5. Waterproof Cables as necessary
Pan: 0° to 360°
