- Page 1 Quick Start Guide InSight Series Bullet Network Camera *Images may differ from actual products. InSight S345ZI is used for demonstration in this guide.
- Page 2 Contents Chapter 1 Appearance ——————————— 1 Chapter 2 Installation ——————————— 4 Safety First ..............4 Mount the Camera ..........4 Install microSD Card (Optional) .......7 Connect Alarm/Audio Device (Optional) ..8 Waterproof (Optional) .........9 Chapter 3 Configuration —————————— 10 For Wired Camera ..........10 For 4G Camera ............11 Appendix FAQ ———————————————...
- Page 3 Chapter 1 Appearance The figure is for demonstration purposes only. Your device may differ in appearance from the depicted. InSight S345ZI ■ Built-in Microphone IR LED × 4 Reset: Unfasten the two fixed screws to remove the cover. Press for 5 seconds to reset the camera to factory settings. microSD Card Slot: Unfasten the two fixed screws to remove the cover.
- Page 4 InSight S345-4G ■ Built-in Microphone IR LED × 2 White LED × 2 Status LED Reset: Unfasten the two fixed screws to remove the cover. Press for 5 seconds to reset the camera to factory settings. microSD Card Slot: Unfasten the two fixed screws to remove the cover.
- Page 5 InSight S385PI ■ Built-in Microphone IR LED × 4 Red LED Blue LED Reset: Unfasten the two fixed screws to remove the cover. Press for 5 seconds to reset the camera to factory settings. microSD Card Slot: Unfasten the two fixed screws to remove the cover.
- Page 6 Chapter 2 Installation Safety First Make sure your power supply matches your camera. The power source ■ should comply with Power Source Class 2 (PS2) or Limited Power Source (LPS) of IEC 62368-1. Make sure that the wall is strong enough to withstand 4 times the ■...
- Page 7 2. Choose the mounting method. Option 1 Option 2 Option 3 3. Mount the camera according to your desired mounting method. Option 1 Ceiling Mounting ■ Φ6 mm Optional Φ25 mm Φ3 mm Option 2 Wall Mounting ■...
- Page 8 Φ6 mm Optional Φ25 mm Φ3 mm Option 3 Pole Mounting ■ 61.5mm Φ Φ Appropriate drilling size (Φ) When installing with anchors Φ = 6 mm (15/64 in.) When installing with screws only Φ = 3 mm (1/8 in.) D=25mm 61.5mm Φ...
- Page 9 Install microSD Card (Optional) microSD Card RESET Button Slot B (For 4G Camera) microSD Card Slot RESET Button Nano SIM Card Slot...
- Page 10 Connect Alarm/Audio Device (Optional) Connect Alarm Device Scan for More Details Alarm Out Device (e.g. buzzer) Alarm In Device (e.g. senser) Connect Audio Device Scan for More Details Audio Out Device (e.g. speaker) Audio In Device (e.g. microphone) Note: It is recommended to waterproof the alarm/audio interface even if no alarm/audio equipment is connected.
- Page 11 Waterproof (Optional)
- Page 12 If you are using your cameras with other NVR brands, follow the steps below. 1. Power on your cameras and connect them to the network. 2. Activate the cameras using the TP-Link VIGI app or web management page. 3. Refer to the NVR’s User Manual to add cameras.
- Page 13 1. Download and install the latest TP-Link VIGI app. 2. Open the app and log in with your TP-Link ID. If you don’t have an account, sign up first. 3. Tap the + button on the top right and follow the app instructions to add your NVR.
- Page 14 3. Connect the camera to the power socket via the provided power adapter or the solar panel, and wait until the LED is solid green. 4. Open the app and log in with your TP-Link ID. If you don’t have an account, sign up first.
- Page 15 2. Select your camera and click + to add your camera directly. If you have disabled Plug and Play on your NVR, create a password or use a preset password for your camera. Note: If you are using your cameras with other NVR brands, refer to the NVR’s User Manual to add cameras.
- Page 16 It’s recommended to use a Class 10 microSD card or higher, with storage from 8 GB to 512 GB. • Make sure you have initialized the microSD card via the TP-Link VIGI app or web management page. • If the problem still persists, contact our technical support.
