- Page 1 Quick Start Guide InSight Series Panoramic Network Camera *Images may differ from actual products. InSight S655I is used for demonstration in this guide.
- Page 2 Contents Chapter 1 Appearance ——————————— 1 Chapter 2 Installation ——————————— 2 Safety First ..............2 Mount the Camera ..........2 Install microSD Card (Optional) .......5 Waterproof (Optional) .........5 Chapter 3 Configuration —————————— 6 Via NVR..............6 Via VIGI App ............6 Via Web ..............7 Appendix FAQ ———————————————...
- Page 3 Chapter 1 Appearance The figure is for demonstration purposes only. Your device may differ in appearance from the depicted. InSight S655I ■ Power Supply Interface RJ45 Network Interface (supports PoE) Reset: Unfasten the two fixed screws to remove the cover. Press for 5 seconds to reset the camera to factory settings.
- Page 4 Chapter 2 Installation Safety First Make sure your power supply matches your camera. The power source ■ should comply with Power Source Class 2 (PS2) or Limited Power Source (LPS) of IEC 62368-1. Make sure that the wall is strong enough to withstand 4 times the ■...
- Page 5 Note: When mounting the camera, avoid strong light sources shining directly into the camera lens. Option 1 Option 2 Option 3 3. Mount the camera according to your desired mounting method. Note: Keep the protective film during installation and remove it before use. •...
- Page 6 • Wall mounting When mounting the camera on a wall, point the microphone upward and the Φ6 mm speaker downward. Optional Φ25 mm Φ3 mm Microphone Speaker • Pendant mounting 1/4-20unc...
- Page 7 Install microSD Card (Optional) microSD Card RESET Button Slot Waterproof (Optional)
- Page 8 Using your cameras with other NVR brands: Step 1: Power on your cameras and connect them to the network. Step 2: Activate the cameras using the TP-Link VIGI app or web management page. Step 3: Refer to the NVR’s User Manual to add cameras.
- Page 9 1. Download and install the latest TP-Link VIGI app. 2. Open the app and log in with your TP-Link ID. If you don’t have an account, sign up first. 3. Tap the + button on the top right and follow the app instructions to add your NVR.
- Page 10 Try to add your camera manually. • For other NVR brands, make sure you have activated the camera by setting a password via TP-Link VIGI app or web management page. Q2. How do I know the camera is powered on? •...
