jbc FAE1-B Instruction Manual

Fume extractor
Hide thumbs Also See for FAE1-B:

Advertisement

Table of Contents

JBC FAE1-1B
Fume Extractor
A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
• C r i t i c a l a n d e x p e d i t e d s e r v i c e s
• I n s t o c k / R e a d y - t o - s h i p
Artisan Scientific Corporation dba Artisan Technology Group is not an affiliate, representative, or authorized distributor for any manufacturer listed herein.
Limited Availability
Used and in Excellent Condition
Buy Today!
https://www.artisantg.com/63000-1
• We b u y y o u r e x c e s s , u n d e r u t i l i z e d , a n d i d l e e q u i p me n t
• F u l l - s e r v i c e , i n d e p e n d e n t r e p a i r c e n t e r

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FAE1-B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for jbc FAE1-B

Summary of Contents for jbc FAE1-B

  • Page 1 JBC FAE1-1B Fume Extractor Limited Availability Used and in Excellent Condition Buy Today! https://www.artisantg.com/63000-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
  • Page 2 INSTRUCTION MANUAL Fume Extractor Ref. FAE1-B...

  • Page 3: Packing List

    & M5 Pre-filter ........... 1 unit Ref. FAE1-100 *Already assembled Power cable ........... 1 unit Ref. 0009417 (100V / 120V) 0009401 (230V) Manual ..........1 unit Unseal the filter Ref. 0023483 before the first use w w w.jbctools.com INSTRUCTION MANUAL Fume Extractor Ref. FAE1-B...
  • Page 4 w w w.jbctools.com Features Aspiration tubes for workbench and tool stands extraction Quick release levers for filter change Process screen Filter saturation indicator Green: Filter OK Yellow: ≤ 20% carbon lifetime or about to saturate Red: End of carbon lifetime or filter saturated RJ12 station connections (to station...
  • Page 5 Basic Working System Flexible arm Ø50 Stand Ref. FAE070 Aspiration Duct Lenght: 1 m (39.37 in) Ref. FAE050 To be assembled on For modular stands your workbench with (From SD versions the included clamp onwards) Ref. FAE060 Ref. FAE020 For compact stations To be assembled directly (From B versions on your workbench...

  • Page 6: Menu Interface

    w w w.jbctools.com Turning on the fume extractor Once the fume extractor is turned on, the display shows a similar screen as the following one and the filter saturation indicator is green if the carbon lifetime is higher than 20%. F i l t e r F l o w Saturation...
  • Page 7 Menu Interface Main menu parameters Original PIN: 0105 M a i n m e n u Exit 1 Reset 2 Unit 3 Port 4 Filter set 5 Counters 6 Program version U n i t P o r t F i l t e r s e t Continuous mode Program Ctm - 100%...
  • Page 8 w w w.jbctools.com Menu Interface Port menu parameters P o r t Program Ctm - 100% 2 Delay to stop 3 Pedal B a c k D e l a y t o s t o p P e d a l P o r t Work area 5 sec...
  • Page 9 Parameters Important: Power off any Station or Device connected to the fume extractor before modifying any parameter. Unit Parameter Description Enable/disable continuous aspiration. When enabled, fume extractor suction is activated. Aspiration remains active until continuous mode is Continuous mode disabled or the equipment is powered off. By default Continuous mode is OFF.
  • Page 10 w w w.jbctools.com Port Parameter Description It sets the fume extractor aspiration flow. You can select between a Preset and Custom aspiration program. H (High), M (Medium) or L (Low) are the three Preset available options. Use Up and Down keys to switch between them while being on the main Program screen.
  • Page 11 Filter set Parameter Description It shows remaining activated carbon lifetime expressed in %. It is also Carbon life displayed on the main screen. When 0% is reached the system will show pop-up message STOP#1 to replace the filter. It shows saturation status of HEPA + carbon filter set, expressed in %. It is Saturation also displayed on the main screen.
  • Page 12 RJ12 station connections for Excellence range Allows connecting JBC Soldering Stations featuring a Robot port to the fume extractor in order to automatically activate the extraction when the tools are in use. An RJ12 direct cable is required (ref.
  • Page 13 RJ12 station connections for Advanced range Allows connecting JBC Soldering Stations featuring a USB-B port to the fume extractor in order to automatically activate the extraction when the tools are in use. An USB A/B cable (ref. 0021042) and RJ12-USB A adapter (ref. 0023504) are required. (You must not configure anything on the soldering station).

  • Page 14: Filter Replacement

    w w w.jbctools.com Filter replacement - The unit notifies through both the display and the LED when filters need maintenance. - To replace the filters remove the cover by opening the quick release levers of the casing. - If the saturation indicator remains in red after changing the pre-filter, it means that H13 particle filter is already saturated and must be replaced too.
  • Page 15 Filter replacement Connect the filter tube to The filter has a given position. the quick coupling placed Make sure the filter ribs mate on the metal sheet with the corresponding slots. Quick Release Levers Adjustment - Turn clockwise to loosen and counterclockwise to tighten, in order to adjust the filter airtightness. Read safety guidelines to do the equipment maintenance safely.
  • Page 16 w w w.jbctools.com Safety Follow safety guidelines to prevent electric shock, injury, fire or explosion. - The equipment is only designed to filtrate the fumes generated by soldering. - Do not use the units for the filtration of combustible, explosive or corrosive gasses. Incorrect use may cause fire.

  • Page 17: Specifications

    4 RJ12 connectrors Complies with CE standards. ESD protected. Warranty JBC’s two year warranty covers this equipment against all manufacturing defects, including the replacement of defective parts and labour. Warranty does not cover product wear or misuse. In order for the warranty to be valid, equipment must be returned, postage paid, to the dealer where it was purchased.
