- Page 1 INSTRUCTION MANUAL F3435, F3449, F3450, F6457 Fume Extractor for T210, T245 & T470...
- Page 2 This manual corresponds to the following references: F3450 for T210, tube ø 4 mm F3449 for T245, tube ø 4 mm F3435 for T245, tube ø 6 mm F6457 for T470, tube ø 6 mm Packing list The following items are included: Fume Extractor ......... 1 unit Cleaning Brush ..........
- Page 3 Fume Extractors for Tools are used to extract the smoke produced during soldering near the soldering tip. An extraction pump with filter is required. 100 mm According to purchased reference, they are designed to be used with JBC soldering tools: T245, T210 and T470 Handles. 80 mm...
- Page 4 Assembly For T210 Handles * Place the clamp directly on the handle (1) and slide it forward or backward (2) until the opening of the extractor nozzle is placed near the tip of the cartridge (3). Adjust the position of the extractor to get the nozzle opening near the cartridge tip.
- Page 5 para manuales - color gris 200 mm 130 mm 130 mm For T245 & T470 Handles * Thread the cable into the clamp (1) and slide the clamp onto the handle (2) until the opening of the 100 mm extractor nozzle is placed near the tip of the cartridge (3). 80 mm 60 mm 50 mm...
- Page 6 Notes...
- Page 7 para manuales - color gris 200 mm Notes 130 mm 130 mm 100 mm 80 mm 60 mm 50 mm 40 mm...
- Page 8 9.65 x 7.28 x 1.77 in / 0.33 lb Complies with CE standards. Warranty JBC’s 2 year warranty covers this equipment against all manufacturing defects, including the replacement of defective parts and labour. Warranty does not cover product wear or misuse.
