Solar Accessory Cables
REDARC Solar
MODELS:
SRC0001
ƒ
SRC0002
ƒ
SRC0003
ƒ
SRC0006
ƒ
SRC0008
ƒ
SRC0009
ƒ
SRC0010
ƒ
SRC0011
ƒ
REDARC Solar Cables are suitable for use with
REDARC Solar products, including Solar Panels,
Solar Blankets, Solar Regulators and BCDC / BMS
Battery Chargers.
The cables feature UV stabilised PVC insulation
for outdoor applications, and use genuine
Anderson™ to Anderson™ SB™ 50 connectors
with silver plated terminals.
®
SRC0012
ƒ
SRC0016
ƒ
SRC0017
ƒ
SRC0018
ƒ
SRC0019
ƒ
SRPA20-VP
ƒ
SRC0001-CK
ƒ
Advertisement
Related Manuals for Redarc Solar SRC0001
Summary of Contents for Redarc Solar SRC0001
- Page 1 SRC0001-CK ƒ ƒ SRC0011 ƒ REDARC Solar Cables are suitable for use with REDARC Solar products, including Solar Panels, Solar Blankets, Solar Regulators and BCDC / BMS Battery Chargers. The cables feature UV stabilised PVC insulation for outdoor applications, and use genuine Anderson™...
-
Page 2: Warnings And Safety Instructions
SAVE THESE INSTRUCTIONS — this manual contains CAUTION important safety instructions. Do not operate the system unless you have read and understood this manual. REDARC Do NOT use Solar products to charge non– rechargeable recommends that any Solar product is installed by a suitably batteries. - Page 3 SOLAR CABLE SPECIFICATIONS 5 m (16'4") MC4 to Bare-Wire Connector SRC0001 Length 5 m (±100 mm) 16'4" (±3.9") Conductor Tinned Cooper Conductor size AWG 11 (Ø 2.3 mm) Insulation UV Stabilised PVC Connector MC4 to Bare-Wire Current Rating* 30 A Voltage Rating 50 VDC max Colour Coding...
- Page 4 1.5 m (5') MC4 to Bare-Wire Connector SRC0003 Length 1.5 m (±100 mm) / 5' (±3.9") Conductor Tinned Cooper Conductor size AWG 11 (Ø 2.3 mm) Insulation UV Stabilised PVC Connector MC4 to Bare-Wire Current Rating* 30 A Voltage Rating 50 VDC max Colour Coding Sheath: Black...
- Page 5 1.5 m (5') Anderson™ to Anderson™ Cable SRC0008 Length 1.5 m (± 30 mm) / 5' (± 1.2") Conductor Bare Cooper Conductor size AWG 11 (Ø 2.3 mm) Sheath UV Stabilised PVC Connector Anderson™ SB™ 50 Current Rating* 50 A Voltage Rating 50 VDC max Positive Lead: Red...
- Page 6 1.5 m (5') Anderson™ to Battery Terminal Cable SRC0010 Length 1.5 m (± 30 mm) / 5' (± 1.2") Conductor Bare Cooper Conductor size AWG 6 (Ø 4.1 mm) Sheath UV Stabilised PVC Connector Anderson™ SB™ 50 to Battery Terminal Current Rating* 30 A Voltage Rating...
- Page 7 300 mm (11.8") Parallel Anderson™ to Anderson™ Connector SRC0012 Length 300 mm (± 10 mm) / 11.8" (± 0.4") Conductor Bare Cooper Conductor size AWG 11 (Ø 2.3 mm) Sheath UV Stabilised PVC Connector Anderson™ SB™ 50 Current Rating* 40 A Voltage Rating 50 VDC max Positive Lead: Red...
- Page 8 1.5 m (5') Parallel Anderson™ to MC4 Connector SRC0017 Length 1.5 m (± 30 mm) / 5' (± 1.2") Conductor Bare Cooper Conductor size AWG 10 (Ø 2.6 mm) Sheath UV Stabilised PVC Connector Anderson™ SB™ 50 to MC4 Current Rating* 30 A Voltage Rating 50 VDC max...
- Page 9 10 m (32'8") Anderson™ to Anderson™ Cable SRC0019 Length 10 m (± 30 mm) / 32'8" (± 1.2") Conductor Bare Cooper Conductor size AWG 10 (Ø 2.6 mm) Sheath UV Stabilised PVC Connector Anderson™ SB™ 50 Current Rating* 30 A Voltage Rating 50 VDC max Positive Lead: Red...
-
Page 10: System Wiring
Fuse protection is required for wire and component protection in case of short circuit. Fuses must be fitted as close as possible to the battery positive terminal. REDARC recommend using a MIDI style bolt down fuses as they ensure a low resistance connection. The REDARC FK40 and FK60 Fuse Kits are recommended. -
Page 11: Limited Warranty
23 Brodie Road (North), Lonsdale South Australia 5160, Australia Design and specifications are subject to change without notice | Copyright © REDARC Electronics Pty Ltd. All rights reserved REDARC®, THE POWER OF REDARC®, and BCDC® are trademarks of REDARC Electronics Pty Ltd. - Page 12 Tech Support 1300 REDARC (1300-733-272) Australia +61 8 8322 4848 New Zealand +64 9 222 1024 UK & Europe +44 (0)20 3930 8109 +1 (704) 247-5150 Canada +1 (604) 260-5512 Mexico +52 (558) 526-2898 redarcelectronics.com INST142-2...
