- Page 1 Cables & Value Pack SRC0001, SRC0002, SRC0003, SRC0006, SRC0008, SRC0009, SRC0010, SRC0011, SRC0012, SRC0016, SRC0017, SRC0018, SRC0019, SRPA20–VP, SRC0001–CK...
-
Page 2: Redarc Solar Cables And Value Pack
REDARC SOLAR CABLES AND VALUE PACK REDARC Solar Cables are suitable for use with REDARC Solar products. REDARC Solar products include Solar Panels, Solar Blankets, Solar Regulators and REDARC BCDC / BMS Battery chargers. The cables feature UV stabilised PVC insulation for outdoor applications, and use genuine Anderson to Anderson ™... -
Page 3: Table Of Contents
TO MC4 CONNECTOR ���������������������������������������������14 ™ SRC0018 — 5m / 16.4ft ANDERSON TO ANDERSON CABLE ���������������������������������������15 ™ ™ SRC0019 — 10m / 32.8ft ANDERSON TO ANDERSON CABLE �������������������������������������16 ™ ™ SRPA20-VP — VALUE PACK ����������������������������������������������������������������������������������������17 SRC0001-CK — MC4 CONNECTOR KIT �������������������������������������������������������������������������17 SYSTEM WIRING ��������������������������������������������������������������������������������������������������������18 16.1 Wiring Precautions �����������������������������������������������������������������������������������������������18 Fuse Protection ����������������������������������������������������������������������������������������������������18 16.2... -
Page 4: Src0001 - 5M / 16.4Ft Mc4 To Bare-Wire Connector
SRC0001 — 5m / 16.4ft MC4 TO BARE–WIRE CONNECTOR Specifications for MC4 to Bare-Wire Connector Length Part Number 5 m (±100 mm) / SRC0001 16.4 ft (± 3.9") Connector MC4, bare-wire Conductor Current Rating Tinned Cooper 30 A Conductor size AWG 11 (Ø2.3 mm) Voltage Rating 50 VDC max Insulation/Sheath UV Stabilised PVC Colour Coding Sheath —... -
Page 5: Src0002 - 10M / 32.8Ft Mc4 To Bare-Wire Connector
SRC0002 — 10m / 32.8ft MC4 TO BARE–WIRE CONNECTOR Specification for MC4 to Bare-Wire Connector Length Part Number 10 m (±100 mm) / SRC0002 32.8 ft (± 3.9") Connector MC4, bare-wire Conductor Current Rating Tinned Cooper 30 A Conductor size AWG 11 (Ø2.3 mm) Voltage Rating 50 VDC max Insulation/Sheath UV Stabilised PVC Colour Coding Sheath —... -
Page 6: Src0003 - 1.5M / 4.9Ft Mc4 To Bare-Wire Connector
SRC0003 — 1.5m / 4.9ft MC4 TO BARE–WIRE CONNECTOR Specifications for MC4 to Bare-Wire Connector Part Number SRC0003 1.5 m (± 100 mm) / Length 4.9 ft (± 3.9") Connector MC4, bare-wire Conductor Current Rating Tinned Cooper 30 A Conductor size Voltage Rating AWG 11 (Ø2.3 mm) 50 VDC max Insulation/Sheath UV Stabilised PVC Colour Coding Sheath —... -
Page 7: Src0006 - 300Mm / 11.8" Mc4 'Y' Connectors
SRC0006 — 300mm / 11.8" MC4 ‘Y’ CONNECTORS Specifications for MC4 'Y' Connectors Part Number SRC0006 300 mm (±30 mm) / Length 11.8" (±1.2") Connectors MC4 'Y' Conductor Current Rating Tinned Cooper 30 A Conductor size AWG 11 (Ø2.3 mm) Voltage Rating 50 VDC max Insulation/Sheath UV Stabilised PVC Colour Coding Sheath —... -
Page 8: Src0008 - 1.5M / 5Ft Anderson
SRC0008 — 1.5m / 5ft ANDERSON TO ANDERSON CABLE ™ ™ Specifications for Anderson to Anderson Cable ™ ™ Part Number SRC0008 1.5 m (± 30 mm) / Length 5 ft (± 1.2") Connector Anderson ™ ™ Conductor Bare Copper Current Rating 50 A Conductor size Voltage Rating AWG 11 (Ø2.3 mm) 50 VDC max Positive lead —... -
Page 9: Src0009 - 1.5M / 5Ft Anderson
SRC0009 — 1.5m / 5ft ANDERSON TO BATTERY CLIP CABLE ™ Specifications for Anderson to Battery Clip Cable ™ Part Number SRC0009 1.5 m (± 30 mm) / Length Anderson ™ ™ 5 ft (± 1.2") Connector battery clip Conductor Current Rating Bare Copper 30 A Conductor size AWG 11 (Ø2.3 mm) Voltage Rating 50 VDC max Positive lead —... -
Page 10: Src0010 - 1.5M / 5Ft Anderson
SRC0010 — 1.5m / 5ft ANDERSON TO BATTERY TERMINAL CABLE ™ 8 mm / 0.3" Specifications for Anderson to Battery Terminal Cable ™ Part Number SRC0010 1.5 m (± 30 mm) / Length Anderson ™ ™ 5 ft (± 1.2") Connector battery terminal Conductor Bare Copper Current Rating 30 A Conductor size Voltage Rating AWG 6 (Ø4.1 mm) - Page 11 SRC0011 — 300mm / 1ft SERIES ANDERSON ™ TO ANDERSON CONNECTOR ™ Specifications for Series Anderson to Anderson Connector ™ ™ Part Number SRC0011 300 mm (± 10 mm) / Length 1 ft (± 0.4 ") Connector Anderson ™ ™ Conductor Bare Copper Current Rating 40 A Conductor size Voltage Rating AWG 11 (Ø2.3 mm) 50 VDC max Positive lead —...
- Page 12 SRC0012 — 300mm / 1ft PARALLEL ANDERSON TO ANDERSON ™ ™ CONNECTOR Specifications for Parallel Anderson to Anderson Connector ™ ™ Part Number SRC0012 300 mm (± 10 mm) / Length 1 ft (± 0.4 ") Connector Anderson ™ ™ Conductor Bare Copper Current Rating 40 A Conductor size AWG 11 (Ø2.3 mm) Voltage Rating 50 VDC max Positive lead —...
-
Page 13: Src0016 - 1.5M / 5Ft Anderson
SRC0016 — 1.5m / 5ft ANDERSON TO BARE–WIRE CONNECTOR ™ Specifications for Anderson to Bare-Wire Connector ™ Part Number SRC0016 1.5 m (± 30 mm) / Length Anderson ™ ™ 5 ft (± 1.2") Connector bare-wire Conductor Current Rating Bare Copper 40 A Conductor size AWG 10 (Ø2.6 mm) Voltage Rating 50 VDC max Positive lead —... -
Page 14: Src0017 - 1.5M / 5Ft Anderson
SRC0017 — 1.5m / 5ft ANDERSON TO MC4 CONNECTOR ™ Specifications for Anderson to MC4 Connector ™ Part Number SRC0017 1.5 m (±30 mm) / Length 5 ft (± 1.2") Connector Anderson 50, MC4 ™ ™ Conductor Current Rating Bare Copper 30 A Conductor size Voltage Rating AWG 10 (Ø2.6 mm) 50 VDC max Insulation/Sheath UV Stabilised PVC... -
Page 15: Src0018 - 5M / 16.4Ft Anderson
SRC0018 — 5m / 16.4ft ANDERSON TO ANDERSON CABLE ™ ™ Specifications for Anderson to Anderson Cable ™ ™ Part Number SRC0018 5 m (± 30 mm) / Length 16.4 ft (± 1.2") Connector Anderson ™ ™ Conductor Bare Copper Current Rating 40 A Conductor size Voltage Rating AWG 10 (Ø2.6 mm) 50 VDC max Positive —... -
Page 16: Src0019 - 10M / 32.8Ft Anderson
SRC0019 — 10m / 32.8ft ANDERSON TO ANDERSON CABLE ™ ™ Specifications for Anderson to Anderson Cable ™ ™ 10 m (± 30 mm) / Length Connector Anderson ™ ™ 32.8 ft (± 1.2") Conductor Current Rating Bare Copper 30 A Conductor size Voltage Rating AWG 10 (Ø2.6 mm) 50 VDC max Positive —... -
Page 17: Srpa20-Vp - Value Pack
1. SRPA0240 — 20 A Solar Regulator 2. SRC0018 — 5 m Anderson to Anderson cable ™ ™ 3. SRC0009 — 1.5 m Anderson to battery clip cable ™ SRC0001-CK — MC4 CONNECTOR KIT The SRC001-CK includes a male and female MC4 connector. -
Page 18: System Wiring
Fuse protection is required for wire and component protection in case of short circuit. Fuses must be fitted as close as possible to the battery positive terminal. REDARC recommend using MIDI style bolt down fuses as they ensure a low resistance connection. The REDARC FK40 and FK60 fuse kits are recommended. - Page 19 23 Brodie Road (North), c/o Shallco, Inc. Lonsdale SA 5160 308 Component Dr. Australia Smithfield, NC 27577 Australia 1300 REDARC (1300 733 272) +1 (704) 247 5150 New Zealand Canada +64 9 222 1024 +1 (604) 260 5512 UK and Europe...
- Page 20 8:00 a.m. to 5:30 p.m. Australian Central Standard Time, Monday to Friday, or send us an e–mail. Australia (and other Global regions) power@redarc.com.au www.redarc.com.au 1300 REDARC (1300 733 272) New Zealand power@redarcelectronics.co.nz www.redarcelectronics.co.nz +64 9 222 1024 North America power@redarcelectronics.com...
