- Page 1 EWE381RX1G6 EWE451RB-G6 EWE481RX1G6 EWE361RB-G6 EWE601RX1G6 EWE241RX-G6 EWE601RX1G7 UH700 ELECTRIC WATER HEATER INSTALLATION GUIDE & USER MANUAL...
-
Page 2: Parts Identification
1. PARTS IDENTIFICATION Main Product 1. ELCB (Earth Leakage Circuit Breaker) Indicator 2. Power/heater Indicator 3. Earth Indicator 4. Temperature display 5. Temperature knob* 6. Water outlet 7. Water inlet 8. 3 in 1 Stop Valve 9. Stop Valve Lever 10. -
Page 3: Safety Information
2. SAFETY INFORMATION Distinct change in performance. Products manufactured by Electrolux are safe Water leakage from inside. provided they are installed, used and maintained in good working order in... - Page 4 2. SAFETY INFORMATION(Continued) Before using the Electric Water Heater, it is The built-in ELCB (Earth Leakage Circuit advisable to test and adjust the water Breaker) will automatically cut off the power temperature according to your preference. supply in case of current leakage over 15mA. During lightning or thunderstorms, switch off the The thermostat will automatically cut off the power supply to the Electric Water Heater in...
-
Page 5: Installation
3. INSTALLATION 3.1 Product Mounting 5. Use a 6mm diameter drill bit and make the wall plug holes with a depth of 34mm for 1. Select a suitable position in the bathroom. mounting the Electric Water Heater. Note: The bottom of the water heater should 6. - Page 6 3. INSTALLATION(Continued) Select a suitable position for the slider rail Fix the Slider Rail by tightening screw B on Rail shower set then mark 2 screws point (1 on top Bracket, then reinstall the caps as shown and 1 on bottom). It is recommended that the below.
- Page 7 3. INSTALLATION(Continued) Select a suitable position for the slider rail Press the Slider Rail into the Rail Bracket Base shower set then mark 4 screw points (2 on top and reinstall the Rail Bracket Cover. and 2 on bottom). It is recommended that the Top Rail Bracket position at a height of 1950mm to the floor and Bottom Rail Bracket 1300mm to the floor.
- Page 8 3. INSTALLATION(Continued) Install rail shower head, hand shower head, 3.3 Plumbing Procedure and connect PVC hose to the water inlet of the CAUTION! Selector Valve as shown below: This Electric Water Heater is a single-point system, and the “Water Outlet” can only be fitted to the Hose and Hand shower set provided.
- Page 9 3. INSTALLATION(Continued) IMPORTANT! Fuse Distributor Board For Pump Models, it is highly recommended to Miniature Circuit Breaker (MCB) connect the Water Inlet Connection to a Double insulated cable storage supply tank; otherwise, it may cause damage to the Pump Motor. ON/OFF Double Pole Switch WARNING! THE HEATER TANK MUST BE FILLED UP WITH...
- Page 10 3. INSTALLATION(Continued) 4. Reconnect the temperature display cable If earth light still does not light up, please contact electrician to check household earth from front cover to the Main Control PCB. connection. Clamp the cable to the correct position. 6. Install the temperature knob to the front cover.
-
Page 11: Usage Instruction
“E4” during performing testing. If any issue occurs, turn off the mains supply and turn it on again. If the issue persists, contact local Electrolux Service or authorized service technicians. Temperature Control Turn on the Temperature control knob to ‘ON’, The Electric Water Heater might not be hot the 3 LED indicators "Earth,"... - Page 12 4. USAGE INSTRUCTION(Continued) Check the Built-in ELCB Shower Accessory Usage 1. Press the “TEST” Button, the Built-in ELCB 3 spray shower head have 3 spray patterns: (Earth Leakage Circuit Breaker) should trip and cut off the power supply. The "Earth" and "Power/Heater"...
-
Page 13: Maintenance
Turn off the water supply before removing the Circuit Breaker) Test Button, switch OFF the filter. mains supply and contact Electrolux Consumer Clean the Mesh Filter regularly to prevent Care Centre for repair service. Special skill is blockage. Remove the Built-in Filter by turning its required for repairing. -
Page 14: Wiring Diagram
6. WIRING DIAGRAM UH700 series with ELCB (Earth Leakage Circuit UH700 series with ELCB (Earth Leakage Circuit Breaker), with display, no pump models Breaker), with display, with pump models UH700 series with ELCB (Earth Leakage Circuit Breaker), with display, DC pump, EMC models 7. -
Page 15: Consumer Care
WE’RE THINKING OF YOU Thank you for purchasing an Electrolux Office Fax : (+60 3) 7955 5511 appliance. You’ve chosen a product that Consumer Care Center Address: Lot C6, No. brings with it decades of professional 28, Jalan 15/22, Taman Perindustrian Tiong experience and innovation. - Page 16 www.electrolux.com/shop...
