Philips 3000 Series Quick Start Manual

Contents
Remote Control
LCD display
and AAA Batteries
Power Cord RS232 Cable RS232 Daisy
Chain Cable
AC Switch USB Cover Cable Clip
Cover x 2PCS
* Differences according to regions.
Display design and accessories may differ from those illustrated above.
X2
3
Input/Output Terminals
RS232 RS232
IN OUT
HDMI 1 IN HDMI 2 IN
DVI-I IN PC LINE IN
1
Unboxing
Signage Display
3000 Series
55BDL3650QE 50BDL3650QE
Quick start guide
IR Sensor Cable
Philips logo
plate
4
Connection
MICRO SD
USB2.0
USB2.0
a
EXPANSION
SLOT
AC IN
IR-IN IR-OUT
AUDIO OUT USB 3.0
RJ45
a
b c d
c
b d
HDMI DVI AUDIO
2
Control Panel
X2
Remote control (IR )
and light sensor
5
Installation
M6 * (10+X) mm
(X=Thickness of Wall mount BKT)
50BDL3650QE: 400mm x 400mm
55BDL3650QE: 400mm x 400mm
