- Page 1 SS 550HF Installation Guide Click Image above for High Resolution Diagram LAND ROVER DEFENDER TURBO DIESEL (2.5L) TDI 300 SERIES POST MARCH 1994 Fitment to: Right hand side Fitting time: Approximately 75 minutes Special Tools:...
- Page 2 Unibit Step Drill Remove: Air intake grill from the right hand guard. Radio antenna from the right hand guard. From inside the engine bay, remove the moulded plastic duct and the first section of flexible duct. Bend the lower antenna mount forward at least 90o to allow clearance for the snorkel snout.
- Page 3 810- BODY SNORKEL 133- 000- 3 1/2" AIR RAM - 135- Assembly 810- BRACKET - 032- Upper - Mounting 810- GASKET 435- BOLT - Hex - 000- 6mm x 1.0 x 002- 12mm STUD - 8mm x 000- 1.25 x 25mm - WASHER - Body - 000- 8mm x 30mm...
- Page 4 NUT - Nyloc - 000- 8mm x 1.25 SCREW - S/T - 000- 4.2mm x 13mm 810- GASKET - Foam 016- Body 810- TEMPLATE 017- CUFFED HOSE - 000- 60mm ID x 881- 400mm HOSE - CLAMP - 000- 50/70mm - (SILVER) HOSE - CLAMP - 000-...
