SAFARI SS25R Quick Start Manual

SS25R
ITEM DESCRIPTION
1 BODY - SNORKEL
2 3" AIR RAM ASSEMBLY
3 BRACKET - UPPER MOUNTING
4 CLIP - BODY - PLASTIC
5 SCREW - S/T - 4.2 x 13mm
6 BOLT - HEX - 6mm x 1.0 x 12mm
9 STUD - S/S - 8mm x 1.25 x 25mm - O/L
10 WASHER - BODY - 8mm x 30mm
11 NUT - NYLOC - 8mm x 1.25
12 CLAMP - HOSE - 70/90
13 BOLT - HEX - 6mm x 1.0 x 25mm
14 BOLT - HEX - 6mm x 1.0 x 30mm
15 NUT - NYLOC - 6mm x1.0
16 WASHER - FLAT - 6mm
17 ADAPTOR - DUCT
18 HOSE - SILICONE - 75mm ID x 50mm
19 GASKET - ADAPTOR
20 TEMPLATE
21 HOSE CLAMP - SIZE 48 (BLACK)
Copyright Safari Automotive Pty Ltd Melbourne Victoria Australia – www.safarisnorkel.com
Page 1 of 5
01/04/15
QTY PART NO.
1 555-133-000R
1 000-135-050
1 555-032-000
4 000-960
4 000-951
3 000-002-100
6 000-110
6 000-311-300
6 000-205-300
2 000-908
1 000-004
1 000-005
2 000-204
4 000-301
1 555-023-000
1 000-805-225E
1 555-406-000
1 555-017-000
1 000-918/B
