Operation
Manual
ATTENTION: Read the instructions before using the machine.
LIMITED WARRANTY
This product is warranted to be free from defects in material and/
or workmanship for a period of One (1) year from date of original
installation (with the exception of pans, lids, and covers). Any
component which proves to be faulty in material and/or
workmanship will be replaced or repaired (at the option of Prince
Castle, Inc.) without cost to the customer for parts or labor.
This warranty is subject to the following exceptions/conditions:
•
Use of any non-genuine Prince Castle parts voids this warranty.
•
All labor shall be performed during regular work hours.
Overtime premium will be charged to the buyer.
•
Damage caused by carelessness, neglect, and/or abuse (e.g.,
dropping, tampering or altering parts, equipment damaged in
shipment, by fire, flood or an act of God) is not covered under
this warranty.
355 EAST KEHOE BLVD
CAROL STREAM, IL 60188
PHONE: 630-462-8800
TOLL FREE: 1-800-PCASTLE
FAX 630-462-1460
WWW.PRINCECASTLE.COM
TABLE OF CONTENTS
MODEL IDENTIFICATION ................................................. 2
SPECIFICATION .............................................................. 2
SAFETY INFORMATION .................................................... 2
IMPORTANT ................................................................... 2
CONFIGURATION ............................................................ 3
PARTS ORDERING .......................................................... 4
PRODUCT IDENTIFICATION .............................................. 5
INSTALLATION : BEFORE ASSEMBLY ................................. 6
INSTALLATION : ADDING MODULES VERTICALLY ................ 7
INSTALLATION : ADDING MODULES HORIZONTALLY ............ 8
OPERATION : POWER UP ................................................. 9
OPERATION : HOLDING AND CANCELLING ITEMS ............. 10
OPERATION : CHANGE DAY PART ................................... 11
OPERATION : DISPLAY TEMPERATURE ............................ 12
OPERATION : PREPARING TO CLEAN .............................. 13
CLEANING .................................................................... 14
TROUBLESHOOTING ...................................................... 15
Certifications
1
Modular Holding Bin
MHB100 Series
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Prince Castle MHB100 Series
Summary of Contents for Prince Castle MHB100 Series
-
Page 1: Table Of Contents
This warranty is subject to the following exceptions/conditions: INSTALLATION : ADDING MODULES VERTICALLY ....7 • Use of any non-genuine Prince Castle parts voids this warranty. INSTALLATION : ADDING MODULES HORIZONTALLY .... 8 • OPERATION : POWER UP ..........9 All labor shall be performed during regular work hours. -
Page 2: Model Identification
WARNING A Indicates information important to the proper operation of Prince Castle reserves the right to change specifications and the unit. Failure to observe may result in damage to the product design without notice. Such revisions do not entitle the equipment and/or severe bodily injury or death. -
Page 3: Configuration
Modular Holding Bin MHB100 Series Configuration Top Cover 850-163S Pan Lid 850-172S Module MHB100HM1 Includes Pan Lid 850-172S Expansion Base MHB100MB Includes End Cap 850-144S Top Cover 850-163S Expansion Base MHB100EB Includes End Cap 850-144S Top Cover 850-155S End Cap 850-144S 850-500-EN-revF Printed in USA ©... -
Page 4: Parts Ordering
Modular Holding Bin MHB100 Series Parts Ordering Top Cover 850-163S Main Base MHB100MB Top Cover 850-163S (included) Module MHB100HM1 (Not Included) End Cap 850-144S (included) Module MHB100HM1 Main Base MHB100MB Top Cover 850-163S (included) Pan Lid 850-172S Module MHB100HM1 (included) -
Page 5: Product Identification
Modular Holding Bin MHB100 Series Product Identification Touchscreen Control Panel+ Display (one per holding bin) USB connector Power ON/OFF Switch Temperature Daypart Button Display Button Clean Mode (Push Both) 850-500-EN-revF Printed in USA © 2019... -
Page 6: Installation : Before Assembly
Notify the carrier within 24 hours of delivery • Save carton and packaging materials for inspection purposes • Contact your local dealer, or if purchased directly, the Prince Castle Sales Department at 800-722-7853 or 1-630-462-8800 to arrange for a replacement unit. Printed in USA © 2019 850-500-EN-revF... -
Page 7: Installation : Adding Modules Vertically
Modular Holding Bin MHB100 Series Installation : Adding Modules Vertically Secure parts using installed screws 850-500-EN-revF Printed in USA © 2019... -
Page 8: Installation : Adding Modules Horizontally
Modular Holding Bin MHB100 Series Installation : Adding Modules Horizontally Unplug main base before installing Assemble column of NOTE: Install columns from or removing any modules modules vertically RIGHT to LEFT Remove rubber screw Remove end cap from cover from module... -
Page 9: Operation : Power Up
Modular Holding Bin MHB100 Series Operation : Power Up Load pans and pan covers (if used) All units will display Prince Heaters are warming to Turn switch to ON Castle Logo operating temperature Allow up to 30 minutes Bin is empty/... -
Page 10: Operation : Holding And Cancelling Items
Modular Holding Bin MHB100 Series Operation : Holding and Cancelling Items Bin is ready. Press anywhere The displayed item is being held. on display to start NOTE: The display will cycle between showing item and remaining holding time To cancel an item, press and hold the screen for 2 seconds. -
Page 11: Operation : Change Day Part
Modular Holding Bin MHB100 Series Operation : Change Day Part Press DAYPART button The daypart value will update for all machines that are not actively holding items. Continue pressing the DAYPART button to toggle through day parts Stop on desired daypart for 2 seconds to select and set daypart... -
Page 12: Operation : Display Temperature
Modular Holding Bin MHB100 Series Operation : Display Temperature Press TEMP button to Temperature will be display temperature. displayed on all units Press again to exit. Temperatures are displayed for 30 seconds, or until TEMP button is pressed again Upper heater temperature Lower heater temperature Printed in USA ©... -
Page 13: Operation : Preparing To Clean
Modular Holding Bin MHB100 Series Operation : Preparing to Clean Press both TEMP and Units are cooling for Units are ready for DAYPART buttons to cleaning cleaning enter cleaning mode WARNING Note: Turn the power switch OFF Before performing any maintenance, turn the... -
Page 14: Cleaning
Modular Holding Bin MHB100 Series Cleaning WARNING WARNING This unit is not watertight. Do not clean with a water jet/jet Before performing any maintenance, turn the power spray. Do not immerse the unit in water. switch to the OFF position and unplug the power cord... -
Page 15: Troubleshooting
Modular Holding Bin MHB100 Series Troubleshooting PROBLEM PROBABLE CAUSE SOLUTION Power switch is turned off. Turn power switch to ON position. Power cord is not plugged in. Ensure power cord is connected to proper receptacle WARNING No Power Cover or endcap is missing or...
