MV810G1 (SP1) Series AC Drive for Solar Pumps
User Manual
Document Version:
Archive Date:
BOM Code:
Shenzhen Megmeet Electrical Co., Ltd. provides comprehensive technical support for
our valued customers. Please contact your nearest Megmeet office or service center,
or connect directly with Megmeet headquarters if any assistance is needed.
Shenzhen Megmeet Electrical Co., Ltd.
All rights reserved. The contents in this document are subject to change without
notice.
Address: 5th Floor, Block B, Unisplendour Information Harbor, Langshan Road,
Nanshan District, Shenzhen, 518057, China
Website: www.megmeet.com
Tel: +86-755-86600500
Fax: +86-755-86600562
Service email: driveservice@megmeet.com
V1.0
2024/07/**
R********

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MV810G1 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Megmeet MV810G1 Series

Summary of Contents for Megmeet MV810G1 Series

  • Page 1 BOM Code: R******** Shenzhen Megmeet Electrical Co., Ltd. provides comprehensive technical support for our valued customers. Please contact your nearest Megmeet office or service center, or connect directly with Megmeet headquarters if any assistance is needed. Shenzhen Megmeet Electrical Co., Ltd.

  • Page 2: Foreword

    Built upon the demonstrated excellence of the control algorithms at the core of Megmeet’s successful MV800 drive series, MV810G1 (SP1) delivers dedicated photovoltaic pumping system control...

  • Page 3: Safety Precautions

    Safety precautions that failure to comply with the notice can result in death or severe Indicates personal injuries. Indicates that failure to comply with the notice may result in moderate or minor personal injuries, or property damages. • Install the product on incombustible materials such as metal. Failure to comply will result in a fire •...
  • Page 4 tapes. Otherwise, electric shock may occur. • When handling the drive product, protect the operating panel and the covers against any stress to avoid falling off. Failure to comply may result in personal injuries or property damage. • Install the product on the place that can bear the weight. Failure to comply will result in personal injuries or equipment damage •...

  • Page 5: Table Of Contents

    Contents Foreword ......................................1 Chapter 1 Introduction of MV810G1 (SP1) ........................8 1.1 Product model ................................8 1.2 Product nameplate ..............................8 1.3 Product series and models .............................9 1.4 Technical specifications ............................9 1.5 Electrical specifications ............................12 1.5.1 Electrical specifications for models with 220 V AC or 310 V DC input ........12 1.5.2 Electrical specifications for models with 380 V AC or 540 V DC input ........
  • Page 6 4.2.2 Control circuit terminal wiring ........................38 4.2.3 Control board layout ..........................49 4.3 Installation method compliant with EMC requirements ................49 4.3.1 Noise suppression ............................49 4.3.2 Field wiring requirements ........................51 4.3.3 Grounding ..............................53 4.3.4 Installation of relay, contactor, and electromagnetic brake ............54 4.3.5 Leakage current and countermeasures .....................
  • Page 7 7.2 P01: Status display parameters ........................163 7.3 P02: Basic function parameters ........................169 7.4 P03: Motor 1 parameters ........................... 174 7.5 P04: Motor 1 encoder parameters ........................178 7.6 P05: Motor 1 vector control parameters ...................... 179 7.7 P06: Motor 1 torque control parameters ......................185 7.8 P07: Motor 1 V/F control parameters ......................
  • Page 8 9.3 Replacement of quick-wear parts ........................273 9.4 Storage ..................................273 Appendix 1 Modbus Communication Protocol ......................275 Appendix 2 Warranty and Service ..........................292 Parameter recording table ..............................293...

  • Page 9: Chapter 1 Introduction Of Mv810G1 (Sp1)

    Chapter 1 Introduction of MV810G1 (SP1) 1.1 Product model The model name on the drive nameplate indicates the product series, the voltage class, the power rating, and the product version. 1.2 Product nameplate...

  • Page 10: Product Series And Models

    1.3 Product series and models Table 1-1 Product series and models Rated input Rated output Rated output Fan air volume Enclosure Model current (A) current (A) power (kW) (m³/min) MV810G1-2S0.4B(SP1) MV810G1-2S0.75B(SP1) 10.4 0.75 MV810G1-2S1.5B(SP1) 16.2 MV810G1-2S2.2B(SP1) 23.0 0.48 MV810G1-4T0.75B(SP1) 0.75 MV810G1-4T1.5B(SP1) MV810G1-4T2.2B(SP1) 0.48...
  • Page 11 input voltage fluctuation ±10%, transient voltage fluctuation -15% to +10% (187 V to 264 V); voltage unbalance rate < 3%, distortion rate compliant with IEC 61800-2; 4T models: three-phase 380 V to 480 V; continuous voltage fluctuation ±10%, transient voltage fluctuation -15% to +10% (323 V to 528 V);...
  • Page 12 Fast tracking, over-torque/under-torque detection, torque limit, multi-speed reference, multiple acceleration/deceleration time switchover, auto-tuning, S curve acceleration/deceleration, slip compensation, fan speed control, frequency hopping, energy saving operation, PID adjustment, hibernation function, power dip ride-through, Modbus, torque control, torque control and speed control switchover, automatic restart, DC braking, dynamic braking, Key functions simple PLC, AVR, switchover between 2 sets of motor parameters,...

  • Page 13: Electrical Specifications

    Indoors with no direct sunlight exposure, dust, corrosive gas, Working conditions combustible gas, oil mist, water vapour/dripping, or salt. ≤ 1000 m: normal use. 1000 m < altitude < 3000 m: derated by 1% Altitude for every 100 m higher. Maximum altitude: 3000 m. Ambient -10℃...

  • Page 14: Electrical Specifications For Models With 380 V Ac Or 540 V Dc Input

    Recommended Voc voltage range 360 to 430 V DC Recommended MPPT voltage range 250 to 350 V DC Startup voltage range 230 to 450 V DC Input from the mains or backup power generator 2S/2T models: single/three-phase 220 V to 240 V, continuous Input voltage AC voltage fluctuation ±10%, transient voltage fluctuation -15% to +10%.
  • Page 15 Recommended solar Max. input DC Output Applicable Model array power (kWp) current (A) current (A) motor (kW) MV810G1-4T30B (SP1) MV810G1-4T37B (SP1) Table 1-6 Input/Output specifications for models with 380 V AC or 540 V DC input Input Solar panel input Max.

  • Page 16: Parts And Components

    1.6 Parts and components 1: Enclosure 2: PG card 3: Keypad 4: Control board 5: Expansion box 6: Rubber plug 7: Upper cover 8: Cable fixation bracket 9: Grounding board 10: Fan cover 11: Fan 12: Dust-proof plate Figure 1-1 Parts diagram (example based on enclosure B) 1.7 Appearance and dimensions There are five enclosure types, each with different dimensions as shown in Figure 1-2, Figure 1-3, Figure 1-4, Figure 1-5, and Figure 1-6.
  • Page 17 (1) Enclosure B: 2S0.4 kW to 2.2 kW; 4T0.75 kW to 4T3.7 kW Figure 1-2 Enclosure B (2) Enclosure C: 2T3.7 kW; 4T5.5 kW / 7.5 kW Figure 1-3 Enclosure C...
  • Page 18 (3) Enclosure D(2T5.5/7.5 kW; 4T11/15 kW) Figure 1-4 Enclosure D (4) Enclosure E: 4T18.5/22 kW Figure 1-5 Enclosure E...
  • Page 19 (5) Enclosure F: 4T30/37 kW Figure 1-6 Enclosure F Table 1-7 Outline dimensions, mounting dimensions, and gross weight Mounting Gross hole Enclosure Drive weight (mm) (mm) (mm) (mm) (mm) (mm) diameter ±0.5 (kg) (mm) MV810G1-2S0.4B (SP1) MV810G1-2S0.75B (SP1) MV810G1-2S1.5B (SP1) MV810G1-2S2.2B (SP1) Enclosure 187.5...

  • Page 20: Operating Panel Dimensions

    Mounting Gross hole Enclosure Drive weight (mm) (mm) (mm) (mm) (mm) (mm) diameter ±0.5 (kg) (mm) MV810G1-2T7.5B (SP1) MV810G1-4T11B (SP1) MV810G1-4T15B (SP1) MV810G1-4T18.5B (SP1) Enclosure 204.8 MV810G1-4T22B (SP1) MV810G1-4T30B (SP1) Enclosure MV810G1-4T37B (SP1) 1.8 Operating panel dimensions Figure 1-7 Operating panel appearance and dimensions The whole MV810 series has a non-detachable keypad as the standard configuration, and reserves an interface for an optional LED/LCD external remote keypad.

  • Page 21: Chapter 2 Options And Accessories

    Chapter 2 Options and Accessories The options and accessories introduced in this chapter, including the installation brackets, protective kits, remote keypads, and other accessories, are all optional. Users can purchase the items by themselves if needed, or consult the local distributor for the applicable configuration. During installation and use, please follow the corresponding steps to avoid damage to the drive.
  • Page 22 Mounting 固定板 plate Mounting bracket Drive 变频器 安装支架 Mount the bracket 安装支架 Mount the drive 安装整机 Hole dimensions 开孔尺寸 Figure 2-2 MV810-EMBB embedded mounting bracket kit Drive component 变频器组件 Through-wall mounting plate Self-tapping 穿墙安装底板 Left bracket screw Right bracket 左安装支架 自攻螺钉...

  • Page 23: Reinforced Metal Base Plate

    Drive component Self-tapping 变频器组件 Left bracket Through-wall mounting plate screw Right bracket 穿墙安装底板 左安装支架 自攻螺钉 右安装支架 M4 combination screw M4组合螺钉 Drive 变频器 M4 combination combination screw M4组合螺钉 screw M4组合螺钉 Rivet nut 铆装螺母 6-M4 6-M4 M4 combination screw M4组合螺钉 Figure 2-4 MV810-EMBD embedded mounting bracket kit 2.3 Reinforced metal base plate MV810-METB, MV810-METC and MV810-METD are reinforced metal base plates respectively corresponding to enclosure B, C, and D.

  • Page 24: Guide Rail Bracket

    the cable shield. It can be fixed to the screws on the grounding plate (marked in green), as shown in the following figure. Figure 2-6 Cable fixation bracket 2.5 Guide rail bracket MV-DIN3563 (for enclosure B only) is a bracket for guide rail installation, with a mounting hole distance of 63 mm, applicable for the standard DIN 35 mm guide rail.

  • Page 25: Remote Led Keypad/Operating Panel (With Shuttle Button)

    Figure 2-8 Keypad mounting base Figure 2-9 Mounting dimensions of the operating panel mounting base 2.7 Remote LED keypad/operating panel (with shuttle button) MV810G1-DP01 is a remote LED operating panel, detachable and supporting expansion, with a shuttle button and the parameter copy function (refer to P00.07). IP rating is IP23. Figure 2-10 Remote LED keypad/Operating panel...

  • Page 26: Remote Lcd Keypad/Operating Panel (Under Development)

    The remote LED keypad/operating panel can be fixed to the cabinet door/plate via a mounting base (see 2.6 for details) or via the two diagonal internal thread holes provided on the back of the remote LED keypad/operating panel, as shown in the following figure. Hole dimension unit: mm. Figure 2-11 Simplified installation of the remote LED keypad/operating panel 2.8 Remote LCD keypad/operating panel (under development) Reserved for the remote LCD operating panel under development.

  • Page 27: Chapter 3 Drive Installation

    Chapter 3 Drive Installation 3.1 Assembly/Disassembly of drive components 1: Cover 2: Dust-proof plate 3: Expansion box Figure 3-1 Assembly/Disassembly of components (example based on enclosure C) (1) Assembly/Disassembly of the cover Disassembly: Press the granulated part of the cover inwards with proper force, pull the cover downwards till the snap-fit joints connecting the cover and the drive are separated, then remove the cover.

  • Page 28: Installation Direction And Spacing

    • Do not install the product in a place with dust or metal powder; • It is strictly forbidden to install the product in a place with corrosive or explosive gases. If there should be any special requirements for installation, please consult Megmeet prior to installation. 3.3 Installation direction and spacing It is recommended to install the product vertically for better ventilation.
  • Page 29 Figure 3-3 Installation using a guide rail If two or more drives are installed close to each other in a vertical line, for better heat dissipation, it is recommended to use a baffle plate to redirect the air flow, minimizing the impact imposed on the upper drive air inlet by the lower drive air outlet, as shown in Figure 3-4.

  • Page 30: Chapter 4 Drive Wiring

    Chapter 4 Drive Wiring This chapter provides the instructions for wiring and connection, and related precautions and warnings for safe operations. • Before opening the drive cover, make sure to completely cut off the power supply and wait for at least 10 minutes.
  • Page 31 The electrical diagram in Figure 4-1 below is for the drive trial use. Figure 4-1 Simplified wiring of the main circuit (for three-phase models) Recommended cables for the drive using Euroblock are shown in the following table: Table 4-1 Recommended cables Type Cable Image...
  • Page 32 Control circuit Recommended pipe-type terminal Main circuit (mm diameter Φ (mm) MV810G1 (SP1) model Input Output Control Input Output Control cable cable terminal cable cable cable terminal cable MV810G1-4T0.75B (SP1) MV810G1-4T1.5B (SP1) MV810G1-4T2.2B (SP1) MV810G1-4T3.7B (SP1) MV810G1-2T3.7B (SP1) MV810G1-4T5.5B(SP1) MV810G1-4T7.5B (SP1) MV810G1-2T5.5B (SP1) MV810G1-2T7.5B (SP1) MV810G1-4T11B (SP1)

  • Page 33: Main Circuit Terminal Description And Wiring

    Control circuit Main circuit terminal terminal Enclosure MV810G1 (SP1) model L1, L2, L3, N U, V, W, +, -, BR 1 to 18 MV810G1-4T3.7B (SP1) MV810G1-2T3.7B (SP1) MV810G1-4T5.5B (SP1) 0.5 N·m 0.5 N·m 0.5 N·m 0.2 N·m MV810G1-4T7.5B (SP1) MV810G1-2T5.5B (SP1) MV810G1-2T7.5B (SP1) 1.5 N·m 1.5 N·m...
  • Page 34 Terminal name Function L1, L3/N 2S/2D models: single-phase 220 V AC input terminals +, BR Terminals for external braking resistor connection +, - DC bus terminals U, V, W Three-phase AC output terminals PE connection terminal, screws used to fix the cable fixation bracket (2) Terminal type 2 Enclosure type: Enclosure C (applicable power: 2T3.7;...
  • Page 35 Terminal name Function PE connection terminal, screws used to fix the cable fixation bracket (4) Terminal type 4 Enclosure type: Enclosure F (applicable power: 4T30/37) Terminal name Function L1、L2、L3 Three-phase 380 V AC, or three-phase 220 V AC input terminals +、...

  • Page 36: Electrical Connection Between Drive And Options

    4.1.2 Electrical connection between drive and options Figure 4-2 Electrical connection between drive and options (example based on three-phase models) (1) A current breaking device, such as an isolation switch, shall be applied between the mains and the drive to ensure safety during maintenance. (2) When using this drive product in North America, a time-delay fuse shall be applied before the drive (rated fuse current shall be 225% of the maximum full-load output current) to limit the extent of influence in case of a downstream device fault.
  • Page 37 MV810G1-2S1.5B (SP1) MV810G1-2S2.2B (SP1) MV810G1-4T0.75B (SP1) MV810G1-4T1.5B (SP1) MV810G1-4T2.2B (SP1) MV810G1-4T3.7B (SP1) MV810G1-2T3.7B (SP1) MV810G1-4T5.5B (SP1) MV810G1-4T7.5B (SP1) MV810G1-2T5.5B(SP1) MV810G1-2T7.5B (SP1) MV810G1-4T11B (SP1) MV810G1-4T15B (SP1) MV810G1-4T18.5B (SP1) MV810G1-4T22B (SP1) MV810G1-4T30B (SP1) MV810G1-4T37B (SP1) Note: Values indicated in the above table are for recommendations only. (3) When the contactor is used for power supply control, do not use it to control the power on/off of the drive.

  • Page 38: Control Circuit Description And Wiring

    (7) Output EMI filter An optional EMI filter can be employed to suppress the noise interference and the leakage current generated at the output side of the drive. (8) Safety grounding cable There is leakage current in the drive. To ensure safety, the drive and the motor must be grounded, and the grounding resistance shall be less than 10 Ω.

  • Page 39: Control Circuit Terminal Wiring

    4.2.2 Control circuit terminal wiring It is recommended to employ wires exceeding 0.5 mm for the connection of the control circuit terminals. The terminal functions are explained in Table 4-6. Table 4-6 Interface board terminal function Type Mark Name Function Specifications 485 differential signal positive (reference...
  • Page 40 Type Mark Name Function Specifications input AI2 voltage/current input via the setting of function code P09.02 (reference ground: GND). Used as the current return terminal during Differential analog current Input current: 0 mA to 20 mA (input input current differential input. If impedance: 10 Ω).
  • Page 41 Type Mark Name Function Specifications P09 terminal input Ox00 parameters). Ox21 HDO2 Multi-function These two terminals serve respectively as the digital inputs DI3 and DI4 only, an can not be set to Multi-function other signal input/output functions via the setting of function codes. This terminal can be used as the Multi-function digital input DI5 via the setting of...
  • Page 42 Type Mark Name Function Specifications terminal Y2; ground: GND). Example: DO2 output For details, refer to the Terminal Terminal P09.00 terminal; input functions of P09.00 to P09.02 in HDO2 pulse Ox21 HDO2 7.10 (Group P09 output terminal input terminal Ox22 HDO2 HDO1 parameters).
  • Page 43 4.2.2.1 AI terminal wiring (1) Terminal 16 receives the single-ended input of analog voltage or current. The type of input can be selected from voltage or current via the setting of the thousands place of P09.01. The wiring method is shown in Figure 4-4. Figure 4-4 Terminal 16 single-ended input wiring (2) Terminal 13 receives the analog current differential input, or analog voltage/current single-ended input.
  • Page 44 Figure 4-7 Terminal 13 current single-ended input wiring 4.2.2.2 AO terminal wiring Analog output terminal AO1 is connected to an external analog meter to indicate multiple physical quantities. The type of output can be selected from analog voltage or current via the setting of P09.02. The terminal wiring method is shown in Figure 4-8.
  • Page 45 (1) Wiring of the connection between the drive and the host with RS485 interface: Figure 4-9 485-RS485 communication wiring (2) Wiring of the connection between the drive and the host with RS232 interface: Figure 4-10 485-(RS485/232)-RS232 communication wiring (3) Wiring of the multi-drive connection in a single RS485 network: Figure 4-11 Recommended wiring method for the connection between the PLC and multiple drives (make sure all the drives and motors are reliably grounded) In case the communication is abnormal when the above recommended wiring method is used, try the...
  • Page 46 significant external interference, isolate its communication cables to protect the PLC (or the host device) from being interfered; (2) Provide dedicated power supply for any RS485/RS232 converter used; (3) Use magnetic rings on the communication cables; (4) Reduce the carrier frequency of the drive properly if the on-site conditions permit. (1) An isolated RS485 converter shall be used in places with significant interference.
  • Page 47 Figure 4-13 Wiring when using the internal power supply and the PNP type external controller ③ Wiring when the external power supply is used and the external controller adopts the PNP common emitter output, as shown in Figure 4-14. Figure 4-14 Wiring when using the external power supply and the PNP type external controller (2) P09.11 = 1 (set the digital terminal open-circuit voltage to 24 V) ①...
  • Page 48 Figure 4-16 Wiring when using the NPN type external controller 4.2.2.5 Multi-function output terminal wiring The multi-function output terminals 4 (DO1), 5 (DO2), and 11 (DO3) can use the internal +24 V power supply of the drive (load capacity no more than 200 mA). The wiring method is shown in Figure 4-17. The inductive load (such as a relay) must be anti-parallel with the fly-wheel diode.
  • Page 49 Figure 4-18 Wiring of the relay outputs RA/RB/RC (1) Do not short the 24 V terminal and the GND terminal. Otherwise, there is a risk of control board damage. (2) For connection of the control terminals, use multi-core shielded cables or twisted cables (1 mm above).

  • Page 50: Control Board Layout

    4.2.3 Control board layout Figure 4-19 Control board layout 4.3 Installation method compliant with EMC requirements Noise is inevitable during the drive operation, which deviates from the EMC requirements. To reduce the interference of the drive to the environment, detailed installation methods are provided in this section, which complies with the EMC requirements in terms of noise suppression, field wiring, grounding, leakage current, and power filter.
  • Page 51 4.3.1.1 Types of noise Figure 4-20 Types of noise 4.3.1.2 Noise transmission path Figure 4-21 Noise transmission path...

  • Page 52: Field Wiring Requirements

    4.3.1.3 Basic measures for noise suppression Table 4-7 Measures for noise suppression Path Measure If the external devices form a closed loop due to the drive wiring, the leakage current of the grounding cable may cause misoperation of relevant devices. The misoperation can ②...
  • Page 53 Figure 4-22 System wiring requirements If the motor cable is too long or its cross sectional area is too large, derated use is required. The larger the cross sectional area is, the larger the ground capacitance and ground leakage current will be. If the cable with larger cross sectional area is used, the output current shall be reduced by about 5% for each level of increase in area.

  • Page 54: Grounding

    4.3.3 Grounding Dedicated grounding pole (optimal) Figure 4-25 Grounding diagram 1 Shared grounding pole (applicable) Figure 4-26 Grounding diagram 2 Shared grounding cable (not recommended) Figure 4-27 Grounding diagram 3 Figure 4-28 Grounding diagram 4 In addition, pay attention to the following notes: •...

  • Page 55: Installation Of Relay, Contactor, And Electromagnetic Brake

    impedance is smaller than that of the round cable with the same cross sectional area. • One end of the 4-core motor cable shall be grounded at the drive side, and the other end shall be connected to the motor grounding end. It is much better if the motor and drive use the dedicated grounding pole.
  • Page 56 Figure 4-30 Leakage current path (1) Grounding leakage current The leakage current not only flows through the drive system, but also invades other equipment and devices through the grounding cables, causing misoperation of the leakage circuit breaker, relay, and other equipment. If the carrier frequency gets higher, or the motor cable gets longer, the leakage current will be larger.

  • Page 57: Drive Installation Compliant With Emc Requirements

    To reliably protect the motor, it is recommended to use a temperature sensor to monitor the motor temperature, and use the overload protection function (electronic thermal relay) of the drive instead of the external thermal relay. 4.3.6 Drive installation compliant with EMC requirements Partition principle In the drive system formed by the drive and motor, the drive, control unit, and sensor are installed in the same cabinet.
  • Page 58 capabilities. Area Ⅲ: The input reactor, drive, braking unit, contactor, and other noise sources. Area Ⅳ: The output noise filter and its wiring. Area Ⅴ: The power supply (including the wiring of the radio noise filter). Area Ⅵ: The motor and its wiring. •...

  • Page 59: Operating Instructions For Power Filter

    The motor cable and control cable should be shielded or armored. The shielding metal mesh shall be connected to both ends of the grounding cable through cable clamps to avoid the twisting of the ends of the metal mesh. Otherwise, the shielding effect will be reduced in the high-frequency conditions. Ensure good conductivity among the mounting plate, mounting screws and the drive’s metal enclosure.

  • Page 60: Radiated Emission Of The Drive

    4.3.8 Radiated emission of the drive Radiated emission is inevitable during the operation of the drive. It has little impact on equipment outside the metal cabinet because the drive is usually installed inside the cabinet. Thus, the main source of radiated emission is the external connection cables. Conduct proper wiring according to the requirements in this section to effectively suppress the radiated emission of the cables.

  • Page 61: Wiring Diagram Of Mv810G1 (Sp1) When Powered By Pv Panel

    4.4.1 Wiring diagram of MV810G1 (SP1) when powered by PV panel Figure 4-34 Basic wiring diagram 1 Notes: (1) The GND terminal of the drive shall be connected to the 0 V of an external device. (2) AI1 and AI2 can be set to the input voltage/current signal via the function codes P09.01 and P09.02. (3) AO1 can be set to the output voltage/current signal via the function code P09.02.

  • Page 62: Commissioning Steps When Powered By Pv Panel

    (5) For instructions on control circuit terminals, please refer to the section 4.2. (6) The above wiring diagram is based on the three-phase model. The actual wiring depends on the specific model. 4.4.2 Commissioning steps when powered by PV panel 1) Check the power specification and the wiring of the drive.

  • Page 63: Mv810G1 (Sp1) Wiring When Powered By The Mains/Generator

    4.4.3 MV810G1 (SP1) wiring when powered by the mains/generator Figure 4-35 Basic wiring diagram 2 Notes: (1) The GND terminal of the drive shall be connected to the 0 V of an external device. (2) AI1 and AI2 can be set to the input voltage/current signal via the function codes P09.01 and P09.02. (3) AO1 can be set to the output voltage/current signal via the function code P09.02.

  • Page 64: Commissioning Steps When Powered By The Mains/Generator

    (5) For instructions on control circuit terminals, please refer to the section 4.2. (6) The above wiring diagram is based on the three-phase model. The actual wiring depends on the specific model. 4.4.4 Commissioning steps when powered by the mains/generator 1) Check and confirm that the connection is correct according to the power supply of the inverter based on the system wiring diagram shown in Figure 4-35.

  • Page 65: Chapter 5 Quick Operation Guide

    Chapter 5 Quick Operation Guide 5.1 Operating panel 5.1.1 Introduction Figure 5-1 Operating panel 5.1.1.1 LED description Table 5-1 LED description Name Description Color Flashing: The value on display is the running frequency; Frequency indicator Yellow On: The value on display is the frequency reference;...
  • Page 66 Name Description Color On during stop: There is a FWD running command for the drive; FWD running On during running: The drive is running Green indicator forward; Flashing: The drive is switching from FWD to REV; On during stop: There is a REV running command for the drive;...
  • Page 67 Button Name Function To select the data bit for change in the editing state, or Shift switch the parameters of status display in other states. Refer to Table 5-3 for instructions on the multi-function Multi-function button; In the operating panel mode, press this button to start the running of the drive;...
  • Page 68 (1) Parameter display in the stop state When the drive is in the stop state, the operating panel displays the stop-state parameters, as shown in Figure 5-2a. The unit LED indicates the unit of the parameter value. When the verification menu is enabled, only the function codes of which the parameter values are different from the factory default settings will be displayed.

  • Page 69: Reading Of The Led Display

    c: Display in the fault state Figure 5-2 Display in the stop, running, and fault state (3) Display in the fault state When the drive detects a fault signal, it will immediately enter the fault-state display, and display the fault code, as shown in Figure 5-2c. Press the “...

  • Page 70: Example Of Basic Operations

    Display Meaning Display Meaning Display Meaning Display Meaning Examples of LED display: LED display Unit LED Data/Code display Meaning Steady on Flashing Frequency reference Flashing Steady on Output frequency Steady on Flashing Bus voltage Steady on Steady on Bus voltage Overcurrent fault Steady on Steady on...
  • Page 71 5.1.3.1 Password setting To protect the parameters, this drive offers the password protection function. If a user password has been set, the user must input the correct password before entering the function code editing state. To enter the manufacturer parameter groups and the AI/AO correction groups, a manufacturer password is further required.
  • Page 72 (2) Press the “ ” button to enter the level two menu P00.00; (3) Press the “ ” button to change P00.00 to P00.05; (4) Press the “ ” button to enter the level three menu; (5) Press the “ ”...
  • Page 73 Figure 5-5 Set the frequency reference 5.1.3.4 Display of parameters for running status monitoring Select the parameters to be displayed on the operating panel in the running state using the function codes P16.00, P16.01, and P16.02. These parameters include frequency reference, output frequency, bus voltage DI, DO, and AI, etc.;...

  • Page 74: Operation Mode

    Figure 5-7 Example of parameter display switchover 5.2 Operation mode In the following chapters, terms related to the control, operation and status of the drive will be frequently mentioned. Please read this section carefully, which would help to understand and use the functions.

  • Page 75: Operation State

    5.2.2 Operation state The operation state of MV810G1 (SP1) includes the stop state, the running state, and the motor parameter auto-tuning state. (1) Stop state: When the drive is power on and initialized, if there is no operation command input or a stop command is executed during running, the drive will enter the stop state;...
  • Page 76 Figure 5-8 Running mode selection in the speed control mode The five running modes indicate five basic frequency sources. The common running frequency source can be processed with auxiliary frequency superposition and frequency adjustment, while each of “Jog running”, “PLC running”, “multi-speed running” and “process closed-loop running” serves as an independent running channel of the main frequency, among which “PLC running”...

  • Page 77: Initial Power-On

    For the specific frequency reference channels of each running mode in the speed control mode, refer to Chapter 7. (2) Torque reference channel in the torque control mode There are six torque reference channels for the MV810G1 (SP1) torque control mode, including: ①...
  • Page 78 Figure 5-9 Initial power-on process...

  • Page 79: Chapter 6 Parameter List

    Chapter 6 Parameter List 6.1 Description of table headers Item Explanation Function code Indicates the designation of a function code, such as P00.00; Name Indicates the full name of the function code, which explains its main function; Default Indicates the default value by the factory setting of the function code; Range Indicates the maximum and the minimum values of the function code;...
  • Page 80 Function Modi Name Description Range Default code mode Only parameters different from the factory settings are displayed. 0: No password P00.01 User password 0 to 65535 ○ Others: Password protection P00.02 Reserved 0: Modification available for all data; 1: Modification available for this Parameter protection function code and P02.09 (main P00.03...
  • Page 81 Function Modi Name Description Range Default code factory settings (motor parameters not restored) 0: Disabled Power board P00.06 0, 1 × upgrading command 1: Enabled 0: No action 1: Upload parameters from the drive to the keypad 2: Download parameters from the keypad to the drive (complete) P00.07 Parameter copy...
  • Page 82 Function Modi Name Description Range Default code percentage of the rated current of 300.0% the motor. It monitors the present exciting current of the drive, indicated as a -300.0 to P01.09 Exciting current percentage of the rated current of 300.0% the motor.
  • Page 83 Function Modi Name Description Range Default code Bit5: Running at constant speed Bit6: Pre-excitating Bit7: Tuning Bit8: Overcurrent limited Bit9: Bus overvoltage limited Bit10: Torque limited Bit11: Speed reached (speed mode) / Speed limited (torque mode) Bit12: Drive in fault Bit13: Speed control Bit14: Torque control Bit15: Reserved...
  • Page 84 Function Modi Name Description Range Default code 50.000 kHz 0.000 to P01.28 HDO2 frequency Displays the HDO2 frequency 50.000 kHz -100.0% to P01.29 PID reference -100.0% to 100.0% 100.0% -100.0% to P01.30 PID feedback -100.0% to 100.0% 100.0% -100.0% to P01.31 PID deviation -100.0% to 100.0%...
  • Page 85 Function Modi Name Description Range Default code Displays the present line speed of 0 to 65535 P01.44 Line speed the motor m/min Displays the present output power 0.0 to 6553.5 P01.45 Output power of the drive Inverter bridge -40.0 to P01.46 -40.0 to 150.0℃...
  • Page 86 Function Modi Name Description Range Default code 0: Vector control 1 without PG 1: Vector control 2 without PG (only Control mode P02.00 for asynchronous motors) 0 to 3 × selection 2: VF control (only for asynchronous motors) 0: Motor 1 P02.01 Motor selection 0, 1...
  • Page 87 Function Modi Name Description Range Default code 8: Bus card 0: Digital setting P02.09 1: AI1 setting 2: AI2 setting 3: High-speed pulse HDI reference Auxiliary frequency 4: Simple PLC programming P02.06 0 to 8 × source selection reference 5: Multi-speed running reference 6: PID control 7: Modbus 8: Bus card...
  • Page 88 Function Modi Name Description Range Default code Note: After being restored to the on model default settings, the system will do auto matching based on the actual model (applicable for acceleration/deceleration time 1, 2, 3 and 4) 5.5 kW and below: 10 s 5.5 to 30 kW (included): 20 s Above 30 kW: 40 s 0.0 to 6000.0...
  • Page 89 Function Modi Name Description Range Default code rotor resistance 65.535 Ω on model 0.01 mH to 655.35 mH (drive power ≤ 55 kW) Asynchronous motor Depend on Depend P03.08 × leakage inductance model on model 0.001 mH to 65.535 mH (drive power >...
  • Page 90 Function Modi Name Description Range Default code rated frequency P02.10 on model Number of P03.19 synchronous motor 1 to 128 1 to 128 × pole pairs 0.001 to 65.535 Ω (drive power ≤ 55 kW) Synchronous motor Depend on Depend P03.20 ×...
  • Page 91 Function Modi Name Description Range Default code P04: Motor 1 encoder parameters P04.00 Reserved P04.22 Synchronous P04.23 open-loop Q-axis 0 to 100 0 to 100 ○ correction coefficient Synchronous P04.24 open-loop D-axis 0 to 100 0 to 100 ○ correction coefficient Synchronous P04.25 open-loop speed filter...
  • Page 92 Function Modi Name Description Range Default code Speed loop P05.03 1 to 100 1 to 100 ○ proportional gain 2 Speed loop integral 0.01 to 10.00 P05.04 0.01 to 10.00 s 1.00 s ○ time 2 Switchover frequency 0.00 Hz to P05.05 0.00 Hz to P02.11 10.00 Hz...
  • Page 93 Function Modi Name Description Range Default code limit digital setting 300.0% Excitation regulation P05.13 0 to 60000 0 to 60000 2000 ○ Excitation regulation P05.14 0 to 60000 0 to 60000 1300 ○ P05.15 Torque regulation Kp 0 to 60000 0 to 60000 2000 ○...
  • Page 94 Function Modi Name Description Range Default code acceleration/decelera tion time 0: Digital setting 1: AI1 2: AI2 FWD speed limit P06.04 0 to 5 ○ channel 3: HDI 4: Modbus 5: PROFINET FWD speed limit 0.00 Hz to P06.05 0.00 Hz to P02.11 0.00 Hz ○...
  • Page 95 Function Modi Name Description Range Default code P07.01 Torque boost 0.0 to 50.0 0.0 to 50.0 ○ Cut-off frequency of 0.00 Hz to P07.02 0.00 Hz to P02.11 10.00 Hz × torque boost P02.11 Multi-point V/F 0.00 Hz to P07.03 0.00 Hz to P07.05 0.00 Hz ×...
  • Page 96 Function Modi Name Description Range Default code 8: Modbus 9: PROFINET Digital setting of P07.14 voltage source for V/F 0 to 1000 V 0 to 1000 V ○ separation Voltage rise time of 0.0 to 6000.0 P07.15 0.0 to 6000.0 s 5.0 s ○...
  • Page 97 Function Modi Name Description Range Default code 0: Decelerate to stop P08.06 Stop mode 1: Coast to stop 0 to 2 ○ 2: Emergency stop 0.00 to 3.00 P08.07 Stop frequency 0.00 to 3.00 Hz 0.50 × Stop frequency hold P08.08 0.0 to 600.0 s 0.0 to 600.0 s...
  • Page 98 Function Modi Name Description Range Default code 1: From the maximum frequency Note: Only for asynchronous motors. The larger the parameter is, the faster the tracking speed will be. Speed of speed P08.16 However, an excessively large 1 to 100 ○...
  • Page 99 Function Modi Name Description Range Default code 0: Disabled Restart selection P08.25 0, 1 ○ upon power failure 1: Enabled Waiting time for 0.0 to 3600.0 P08.26 restart upon power 0.0 to 3600.0 s ○ failure 0: Disabled Reverse running P08.27 0, 1 ○...
  • Page 100 Function Modi Name Description Range Default code P08.35 Reserved P09: Terminal input parameters Ones place: 0: Terminal 4 as DI1 1: Terminal 4 as DO1 2: Terminal 4 as HDO1 Tens place: 0: Terminal 5 as DI2 Function selection of P09.00 0 to 0x22 ○...
  • Page 101 Function Modi Name Description Range Default code 1: Terminal 13 as AI2 current input Tens place: 0: Terminal 11 as DO3 1: Terminal 11 as AO1 voltage output 2: Terminal 11 as AO1 current output Hundreds place: Reserved Thousands place: Reserved P09.03 DI1 function selection 0: No function 0 to 72...
  • Page 102 Function Modi Name Description Range Default code 19: Empty-water signal 20: Frequency reference source switchover from A to B 21: Frequency reference source switchover from combination to A 22: External reset (RESET) input 23: Coast to stop input (FRS) 24: Acceleration/Deceleration prohibit 25: DC braking input at stop 26: Simple PLC pause command...
  • Page 103 Function Modi Name Description Range Default code 42: REV prohibit 43: Drive running prohibit 44: External stop command (it is valid for all control modes, and the device will be stopped according to the current stop mode) 45: Auxiliary frequency reference clear 46: Pulse input clear 47: Speed control and torque...
  • Page 104 Function Modi Name Description Range Default code 1: Digital terminal open-circuit voltage 24 V Ones place: 0: DI1 positive logic active 1: DI1 negative logic active Tens place: 0: DI2 positive logic active 1: DI2 negative logic active DI1 to DI4 active P09.12 0 to 0×1111 ○...
  • Page 105 Function Modi Name Description Range Default code Reverse Forward Stop 1: Two-wire mode 2 FWD is the source of running commands, and REV controls the running directions. Command Stop Stop Forward Reverse 2: Three-wire mode 1 Three-wire operation control terminal EN is the enabling terminal, and the rising edges of FWD and REV are the source of the running commands and directions.
  • Page 106 Function Modi Name Description Range Default code and REV controls the running directions. Command Forward 0→1 Reverse Stop Used to set the filter time for DI terminal sampling. It is recommended to increase the 0.000 to P09.15 DI filter time parameter value when there is 0.010 s ○...
  • Page 107 Function Modi Name Description Range Default code DI3 switch-off delay P09.22 0.0 to 600.0 0.0 s ○ time DI4 switch-on delay P09.23 0.0 to 600.0 0.0 s ○ time DI4 switch-off delay P09.24 0.0 to 600.0 0.0 s ○ time 0.00 to P09.25 AI1 lower limit...
  • Page 108 Function Modi Name Description Range Default code P09.34 to P09.36 AI2 upper limit P09.34 to 10.00 V 10.00 V ○ 10.00 V Percentage -100.0 to P09.37 corresponding to AI2 -100.0 to 100.0% 100.0% ○ 100.0% upper limit 0.000 to P09.38 AI2 filter time 0.000 to 10.000 s 0.030 s...
  • Page 109 Function Modi Name Description Range Default code 10: Frequency upper limit (FHL) 11: Frequency lower limit (FLL) 12: Zero-speed running 13: Simple PLC stage completion 14: Simple PLC cycle completion 15: Current running time reach 16: Accumulated running time reach 17: AC drive ready to run (RDY) 18: AC drive fault 19: Host device on/ff signal...
  • Page 110 Function Modi Name Description Range Default code Hundreds place: 0: DO3 positive logic active 1: DO3 negative logic active Thousands place: 0: RO1 positive logic active 1: RO1 negative logic active DO1 switch-on delay P10.05 0.0 to 600.0 0.0 s ○...
  • Page 111 Function Modi Name Description Range Default code 6: Torque current (0 to 3 * Iem) 7: Reserved 8: Output voltage (0 to 1.2 * Ve) 9: Bus voltage (0 to 800 V) 10: AI1 after correction 11: AI2 after correction 12: Reserved 13: Output power (0 to 2 * Pe) 14: Host device percentage (0 to...
  • Page 112 Function Modi Name Description Range Default code limit P10.23 Frequency corresponding to P10.22 0.00 to 50.00 kHz 0.00 to 50.00 0.00 kHz ○ HDO1 output lower limit HDO1 output upper P10.21 to P10.23 P10.21 to 100.00% 100.00% ○ limit 100.00% Frequency 50.00 corresponding to...
  • Page 113 Function Modi Name Description Range Default code 0.0 to 6000.0 Depend P11.02 Deceleration time 2 0.0 to 6000.0 s ○ on model 0.0 to 6000.0 Depend P11.03 Acceleration time 3 0.0 to 6000.0 s ○ on model 0.0 to 6000.0 Depend P11.04 Deceleration time 3...
  • Page 114 Function Modi Name Description Range Default code 0.0 to 6000.0 P11.11 Jog acceleration time 0.0 to 6000.0 s 6.0 s ○ 0.0 to 6000.0 P11.12 Jog deceleration time 0.0 to 6000.0 s 6.0 s ○ P11.13 Reserved Number of decimal P11.14 0 to 2 0 to 2...
  • Page 115 Function Modi Name Description Range Default code output will be at the skip frequency 0.00 Hz to P11.19 Skip frequency 1 band 0.00 Hz ○ boundary to avoid the mechanical P02.10 resonance of the load.. 0.00 Hz to If the skip frequency is set to 0, the P11.20 Skip frequency 2 0.00 Hz...
  • Page 116 Function Modi Name Description Range Default code terminal outputs an ON signal. FDT1 frequency 0.00 Hz to P11.27 0.00 Hz ○ When the running frequency is detection value P02.11 higher than P11.27 or P11.29, the FDT1 frequency multi-function DO terminal outputs P11.28 0.0 to 100.0% 0.0%...
  • Page 117 Function Modi Name Description Range Default code frequency decelerates to stop and enters the P02.10 hibernation state after the delay defined by P11.43. Hibernation delay 0.0 to 6553.5 P11.43 0.0 to 6553.5 s 0.0 s ○ time 0: Auto running (based on the inverter temperature) 1: Continuous running after P11.44...
  • Page 118 Function Modi Name Description Range Default code Voltage P12.05 over-modulation 100 to 110 100 to 110 × coefficient P12.06 Reserved P12.07 SVPWM mode 0, 1 0, 1 × P12.08 Reserved to P12.10 P13: Multi-speed and simple PLC parameters LED ones: PLC running mode 0: Stop after running for one cycle 1: Keep final values after running for one cycle...
  • Page 119 Function Modi Name Description Range Default code required to set the parameters Multi-speed reference -100.0 to P13.04 ○ (P13.01 to P13.32) to determine the 100.0% running frequency and running Multi-speed reference -100.0 to time of each stage. P13.05 ○ 100.0% The running time range from stage 0 to stage 15: 0.0 to 6553.5 s (min).
  • Page 120 Function Modi Name Description Range Default code Multi-speed reference 0.0 to 6553.5 P13.20 ○ 3 running time s(min) Multi-speed reference 0.0 to 6553.5 P13.21 ○ 4 running time s (min) Multi-speed reference 0.0 to 6553.5 P13.22 ○ 5 running time s(min) Multi-speed reference 0.0 to 6553.5...
  • Page 121 Function Modi Name Description Range Default code Hundr Thous ands Acc/ Acc/ Acc/ Acc/ Refe renc time time time time Acceleration/Deceler Ones P13.34 ation time of simple 0 to 0x3333 0x0000 ○ Tens PLC reference 4 to 7 Hundr Thous ands Acc/ Acc/...
  • Page 122 Function Modi Name Description Range Default code Thous ands P14: Process PID parameters 0: P14.02 digital setting 1: AI1 2: AI2 P14.00 PID reference source 3: Reserved 0 to 6 ○ 4: HDI 5: Modbus 6: PROFINET 0: AI1 1: AI2 2: Reserved 3: HDI 4: Modbus...
  • Page 123 Function Modi Name Description Range Default code 0.000 to P14.07 Derivative time Td1 0.000 to 10.000 s 0.000 s ○ 10.000 s 0.00 to P14.08 Derivative limit 0.00 to 100.00% 0.10% ○ 100.00% 0.01 to 10.00 P14.09 Sampling cycle 0.01 to 10.00 s 0.01 s ○...
  • Page 124 Function Modi Name Description Range Default code setting P14.16 0.00 to 60.00 P14.18 Output filter time 0.00 to 60.00 s 0.00 s ○ Ones place: 0: Integral separation disabled 1: Integral separation enabled Tens place: 0: When the PID output is a negative value, the limit is 0;...
  • Page 125 Function Modi Name Description Range Default code limits. When Hz is chosen, the maximum frequency P02.10 cannot exceed 327.67 Hz. PID frequency upper P14.27 to P14.26 P14.27 to 327.67 Hz 50.00 Hz limit 327.67 Hz PID frequency lower -327.67 Hz to P14.27 -327.67 Hz to P14.26 0.00 Hz...
  • Page 126 Function Modi Name Description Range Default code will report a “485 communication error” (CE). Response delay of P15.04 0 to 200 ms 0 to 200 ms 5 ms ○ the drive Ones place: 0: Response to the write operation 1: No response to the write operation Tens place: Reserved Communication...
  • Page 127 Function Modi Name Description Range Default code 8: Torque current 9: Exciting current 10: Reserved 11: Motor power 12: Estimated motor frequency 13: Actual motor frequency 14: HIWORD of the drive’s accumulated power consumption 15: LOWORD of the drive’s accumulated power consumption 0: No display;...
  • Page 128 Function Modi Name Description Range Default code Used to determine the default selection of parameters (displayed as the serial number of each parameter) to be displayed on the zero level keypad menu in the running state after power-on. Each of the values 0 to 31 corresponds Default selection of respectively to the 32 parameters parameters for LED...
  • Page 129 Function Modi Name Description Range Default code 3: DI input status 2 4: DO input status 5: AI1 input voltage 6: AI2 input voltage 7: AO1 output percentage 8: HDI frequency reference 9: HDO1 output 10: HDO2 output 11: Length 12: Simple PLC current step 13: Line speed 14: PID reference...
  • Page 130 Function Modi Name Description Range Default code P18.01 Control data 1 value 0 to 65535 0 to 65535 Control data 2 P18.02 0 to 0xFFFF 0 to 0xFFFF 0x1002 ○ address P18.03 Control data 2 value 0 to 65535 0 to 65535 Control data 3 P18.04 0 to 0xFFFF...
  • Page 131 Function Modi Name Description Range Default code Asynchronous motor 0.8 to 6000.0 Depend P20.03 0.8 to 6000.0 A × rated current on model Asynchronous motor 0.01 Hz to P20.04 0.01 Hz to P02.10 50.00 Hz × rated frequency P02.10 Asynchronous motor 1 to 36000 Depend P20.05...
  • Page 132 Function Modi Name Description Range Default code saturation coefficient Synchronous motor 0.1 to 3000.0 Depend P20.15 0.1 to 3000.0 kW × rated power on model Synchronous motor Depend P20.16 0 to 1200 V 0 to 1200 V × rated voltage on model Synchronous motor 0.8 to 6553.5...
  • Page 133 Function Modi Name Description Range Default code the static state 2: Full parameter auto-tuning in the rotating state Motor overload 0.0 to P20.28 0.0 to 300.0% 100.0% × protection factor 300.0% P20.29 Reserved P21: Motor 2 encoder parameters (reserved) P21.00 Reserved P21.30 P22: Motor 2 vector control parameters...
  • Page 134 Function Modi Name Description Range Default code 2: AI2 3: HDI 4: Modbus 5: PROFINET 6: MIN (AI1,AI2) 7: MAX (AI1,AI2) Drive torque upper 0.0 to P22.10 0.0 to 300.0% 180.0% ○ limit digital setting 300.0% 0: Digital setting (P22.12) 1: AI1 2: AI2 3: HDI...
  • Page 135 Function Modi Name Description Range Default code Field weakening P22.20 auto-tuning 0.0 to 120.0% 0.0 to 120.0% 100.0% ○ coefficient Field weakening 0.000 to P22.21 0.000 to 1.200 1.000 ○ integral multiple 1.200 P23: Motor 2 torque control parameters 0: Disabled P23.00 Torque control enable 0, 1...
  • Page 136 Function Modi Name Description Range Default code 4: Modbus 5: PROFINET REV speed limit digital 0.00 Hz to P23.07 0.00 Hz to P02.11 0.00 Hz ○ setting P02.11 P23.08 Reserved P23.11 P24: Motor 2 V/F control parameters 0: Straight-line V/F 1: Multi-point V/F 2: Square V/F P24.00...
  • Page 137 Function Modi Name Description Range Default code V/F over-excitation P24.10 0.0 to 100.0 0.0 to 100.0 ○ gain Oscillation P24.11 0 to 100 0 to 100 ○ suppression gain Oscillation P24.12 suppression gain 0 to 2 0 to 2 × mode 0: Digital setting 1: AI1...
  • Page 138 Function Modi Name Description Range Default code Commissioning P26.00 0 to 65535 0 to 65535 ○ parameter 1 Commissioning P26.01 0 to 65535 0 to 65535 ○ parameter 2 Commissioning P26.02 0 to 65535 0 to 65535 ○ parameter 3 Commissioning P26.03 0 to 65535...
  • Page 139 Function Modi Name Description Range Default code Commissioning P26.16 0 to 65535 0 to 65535 ○ parameter 17 Commissioning P26.17 0 to 65535 0 to 65535 ○ parameter 18 Commissioning P26.18 0 to 65535 0 to 65535 ○ parameter 19 Commissioning P26.19 0 to 65535...
  • Page 140 Function Modi Name Description Range Default code 2: MPPT Initial voltage in MPPT P30.01 0 to 100.0 0 to 100.0 85.0 × mode (percentage) P30.02 Power filter time 0 to 10.00 0 to 10.00 × P30.03 Bus filter time 0 to 10.00 0 to 10.00 ×...
  • Page 141 Function Modi Name Description Range Default code delay Empty-water level P30.21 0 to 10000 0 to 10000 × wake-up delay Minimum running P30.22 0 to P02.11 0 to P02.11 10.00 × frequency Low sunlight intensity P30.23 0 to 3600.0 0 to 3600.0 100.0 ×...
  • Page 142 Function Modi Name Description Range Default code Reset time at P30.37 0 to 6553.5 0 to 6553.5 60.0 × underload P30.38 PV reference voltage 0 to 600.0 0 to 600.0 × P30.39 PV actual voltage 0 to 600.0 0 to 600.0 ×...
  • Page 143 Function Modi Name Description Range Default code 12: Reserved 13: Frequency up/down setting clear 14: Frequency increase command (UP) 15: Frequency decrease command (DN) 16: External fault NO input 17: External fault NC input 18 to 19: Reserved 20: Frequency reference source switchover from A to B 21: Frequency reference source switchover from combination to A...
  • Page 144 Function Modi Name Description Range Default code source selection 3 37: Reserved 38: Command channel switched to the keypad 39: Command channel switched to the terminal 40: Command channel switched to communication 41: Reserved 42: REV prohibit 43: Drive running prohibit 44: External stop command (it is valid for all control modes, and the device will be stopped according to...
  • Page 145 Function Modi Name Description Range Default code 68: Length reset 69: Switched to V/F control 70: Switched to FVC control 71: Reserved 72: Reserved 0: Digital terminal open-circuit voltage 0 V Terminal open-circuit P41.03 0, 1 ○ voltage selection 1: Digital terminal open-circuit voltage 24 V Ones place: 0: DI9 positive logic active...
  • Page 146 Function Modi Name Description Range Default code DI10 switch-off delay P41.10 0.0 to 600.0 s 0.0 s ○ time DI11 switch-on delay P41.11 0.0 to 600.0 s 0.0 s ○ time DI11 switch-off delay P41.12 0.0 to 600.0 s 0.0 s ○...
  • Page 147 Function Modi Name Description Range Default code 22: Motor overload pre-alarm signal 23 to 25: Reserved 26: Reference count value reach 27: Designated count value reach 28: Length reach 29 to 37: Reserved 38: Motor 1 and 2 indication terminal 39: Bus card switch signal 40 to 45: Reserved 46: PID feedback loss...
  • Page 148 Function Modi Name Description Range Default code P42: PLC card option parameters (reserved) P43: PROFINET communication parameters 0.0 to 60.0 s PROFINET Note: P43.00 communication 0.0 to 60.0 0.0 s ○ The value of 0.0 indicates that timeout there is no detection of communication timeout.
  • Page 149 Function Modi Name Description Range Default code separation) (0 to 1000) 8: Virtual input terminal command (0 to 0×FF corresponding to DI8 to DI1) 9: Output terminal bus command (set the output terminal function to function 39, 0 to 0×F corresponding to RO, DO3, DO2, and DO1) 10: AO1 output reference (0.00 to 100.00%)
  • Page 150 Function Modi Name Description Range Default code 17: AI2 input voltage (-10.00 V to 10.00 V) 18: HDI input frequency (0 to 50.000 kHz) 19: AO output (0.00 to 100.00%) 20: HDO1 output (0 to 50.000 kHz) 21: HDO2 output (0 to 50.000 kHz) 22: PID reference (-100.0% to 100.0%) 23: PID feedback (-100.0% to...
  • Page 151 Function Modi Name Description Range Default code P88: AI/AO correction (manufacturer’s parameters) P97: Fault and protection parameters Ones place: 0: Pulse-by-pulse current limit protection disabled 1: Pulse-by-pulse current limit protection enabled Tens place: 0: Fan fault disabled P97.00 Fault enable 0 to 0x1111 0x1001 ×...
  • Page 152 Function Modi Name Description Range Default code Current limit P97.03 adjustment Range: 0 to 100 0 to 100 × coefficient Overvoltage stall P97.04 protection action 600 to 750 V 600 to 750 V 720 V ○ voltage Voltage regulator proportional Used to define the proportional P97.05 coefficient for...
  • Page 153 Function Modi Name Description Range Default code delay time defined by P97.12. Undervoltage stall When the bus voltage is greater P97.13 protection pause than this value, the drive stops 460 to 500 V 485 V × voltage lowering the frequency. Ones place: 0: Input phase loss protection disabled...
  • Page 154 Function Modi Name Description Range Default code alarm property 2 1: Decelerate to stop 2: Keep running Ones place: EEPROM read/write fault Tens place: Reserved Hundreds place: Reserved Thousands place: 485 communication fault 0: Coast to stop 1: Decelerate to stop 2: Keep running Fault protection and P97.17...
  • Page 155 Function Modi Name Description Range Default code excessive speed deviation Detection time of When it is set to 0.0 s, speed P97.28 excessive speed 0.0 to 10.0 s 1.0 s ○ deviation protection is disabled. deviation When there are faults, the drive starts to reset after the time interval defined by P97.31.
  • Page 156 Function Modi Name Description Range Default code (OV2) 6: Overvoltage during operation at constant speed (OV3) 7: Undervoltage fault (Uv) 8: Input phase loss (SPI) 9: Output phase loss (SPO) 10: Power module protection (drv) 11: Inverter overheat (OH1) 12: Rectifier bridge overheat (OH2) 13: AC drive overload (OL1) 14: Motor overload (OL2) 15: External fault (EF)
  • Page 157 Function Modi Name Description Range Default code 46: Board-level communication error (bCE) 47: Reserved 48: BootLoader failure (bLt) 49: Power board software version mismatching (vEr) 50: Parameter upload/download timeout (UPdnE) 51: AI1 current input overcurrent (AIOC) 52: Reserved 53: Fan locked-rotor (FAn) 54: Pre-overload (POL1) 55: I/O option 24 V overload (IO-OL) Bus voltage upon the...
  • Page 158 Function Modi Name Description Range Default code Running time upon 0.0 to 6553.5 P97.43 0.0 to 6553.5 s 0.0 s the present fault Bus voltage upon the 0.0 to 6553.5 P97.44 0.0 to 6553.5 V 0.0 V previous fault Actual current upon 0.0 to 999.9 P97.45 0.0 to 999.9 A...
  • Page 159 Function Modi Name Description Range Default code penultimate fault Inverter bridge 0.0 to P97.57 temperature upon 0.0 to 150.0℃ 0.0℃ 150.0℃ the penultimate fault P97.58 Reserved Input terminal status P97.59 upon the penultimate 0 to 0xFF 0 to 0xFF fault Output terminal P97.60 status upon the...
  • Page 160 Function Modi Name Description Range Default code Manufacturer’s bar P98.08 0 to 0xFFFF 0 to 0xFFFF code 2 Manufacturer’s bar P98.09 0 to 0xFFFF 0 to 0xFFFF code 3 Manufacturer’s bar P98.10 0 to 0xFFFF 0 to 0xFFFF code 4 Manufacturer’s bar P98.11 0 to 0xFFFF...

  • Page 161: Chapter 7 Parameter Description

    Chapter 7 Parameter Description The parameter is described in the following format: Function code Function name Value range Default value 7.1 P00: System management parameters P00.00 Menu mode selection 0 to 2 0: Quick commissioning menu mode Only parameters related to the quick commissioning are displayed. The user can initiate a quick drive start via the modification of these parameters.
  • Page 162 P00.02 Reserved P00.03 Parameter protection setting 0 to 2 This function code determines the protection level of drive parameters, including: 0: Modification available for all data; 1: Modification available for this function code and P02.09 (main frequency reference digital setting) only;...
  • Page 163 When the STOP/RESET button is used as the fault reset button RESET, it is valid only in the local operating panel control channel. When pressing the RUN and STOP buttons at the same time, the drive will coast to stop. Hundreds place: Function selection of the M button When it is set to 0, the M button is disabled.
  • Page 164 0: Disabled Power board upgrading is prohibited. 1: Enabled Power board upgrading is allowed. P00.07 Parameter copy 0 to 4 0: No action 1: Upload parameters from the drive to the keypad 2: Download parameters from the keypad to the drive (complete) 3: Download parameters from the keypad to the drive (motor parameters not included) 4: Download parameters from the keypad to the drive (motor parameters only) 7.2 P01: Status display parameters...
  • Page 165 P01.06 Output voltage 0 to 65535 V It monitors the present output voltage of the drive. P01.07 Output current 0.0 to 6553.5 A It monitors the present output current of the drive. P01.08 Torque current -300.0 to 300.0% It monitors the present torque current of the drive, indicated as a percentage of the rated current of the motor.
  • Page 166 Figure 7-2 Operation state of the drive LED ones place Bit0: Stop/Run When the drive is in the stop state, Bit0 is 0; otherwise, it is 1. LED ones place Bit1: FWD/REV When the drive is the in the FWD running state, Bit0 is 0; otherwise, it is 1. For other bits, if the condition is met, they will be set to 1.
  • Page 167 Figure 7-4 DI terminal status It displays the status of the four terminals (DI5 to DI8); the value of 0 indicates that the terminal is off, and the value of 1 indicates that the terminal is on. P01.20 DO status 0 to 0x1111 Figure 7-5 DO terminal state It displays the output status of the terminals DO1, DO2, DO3, and relay RO1.
  • Page 168 0.000 to 50.000 P01.27 HDO1 frequency 0.000 to 50.000 P01.28 HDO2 frequency They respectively display the output frequency of HDO1 and HDO2. P01.29 PID reference -100.0% to 100.0% P01.30 PID feedback -100.0% to 100.0% P01.31 PID deviation -100.0% to 100.0% P01.32 PID output -100.0% to 100.0%...
  • Page 169 It displays the present torque reference of the drive, indicated as a percentage of the rated current of the motor. P01.43 Rotation speed of motor 0 to 65535 rpm P01.44 Line speed 0 to 65535 m/min P01.45 Output power 0.0 to 6553.5 kW It displays the present rotation speed, line speed, and the output power of the motor.

  • Page 170: P02: Basic Function Parameters

    P01.57 User-defined frequency display 0.00 to P02.10 7.3 P02: Basic function parameters P02.00 Control mode selection 0 to 3 0: Vector control 1 without PG 1: Vector control 2 without PG (only for asynchronous motors) 2: VF control (only for asynchronous motors) 3: Closed-loop vector control P02.01 Motor selection...
  • Page 171 2: Ethernet channel (reserved) 3: EtherCAT channel / PROFINET channel 4: Programmable card channel (reserved) 5: Radio channel (reserved) Note: A corresponding option must be installed before selecting 1 to 5. P02.04 Running direction 0, 1 This function is valid for the operating panel and serial port channels, and invalid for the terminal channel.
  • Page 172 4: Simple PLC programming reference The simple PLC program is used as the source of the main frequency. The present frequency reference, running time, and cycle method of the drive are determined by Group P13. 5: Multi-speed running reference In this mode, multi-speed terminals are combined to form various multi-speed references. For details, refer to the terminal functions.
  • Page 173 (1) When choosing 1, 2, or 3 as the auxiliary frequency source, the polarity of the auxiliary frequency output is determined by either the analog/pulse value itself or the function code P02.04, which is selected via the setting of Group P09. (2) The source channels for the main frequency and the auxiliary frequency are mutually exclusive.
  • Page 174 P02.09 Frequency digital setting 0.00 Hz to P02.11 50.00 Hz When the main frequency reference channel is digital setting (P02.05=0, 5), this parameter indicates the initial frequency value of the drive’s main frequency reference. P02.11 to 599.00 P02.10 Maximum output frequency 50.00 Hz P02.11 Upper limit frequency...

  • Page 175: P03: Motor 1 Parameters

    (5) The upper and lower frequency limits are used to limit the actual frequency output to the motor. If the frequency reference is higher than the upper limit frequency, the device will run at the upper limit frequency; if the frequency reference is lower than the lower limit frequency, the device will run at the lower limit frequency;...
  • Page 176 1: Synchronous motor P03.01 Asynchronous motor rated power 0.1 to 3000.0 kW Depend on model P03.02 Asynchronous motor rated voltage 0 to 1200 V Depend on model P03.03 Asynchronous motor rated current 0.8 to 6000.0 A Depend on model P03.04 Asynchronous motor rated frequency 0.01 Hz to P02.10 50.00 Hz...
  • Page 177 Figure 7-7 Equivalent circuit diagram for asynchronous motor in steady state In Figure 7-7, R1, X11, R2, X21, Xm, and Io indicate respectively the stator resistance, stator leakage inductance, rotor resistance, rotor leakage inductance, mutual inductance, and no-load current. The value of the function code P03.08 is the sum of the stator leakage inductance and the rotor leakage inductance.
  • Page 178 The above parameters apply to the situation where the motor 1 is a synchronous motor. To enter the motor 1 parameter group, it is required to set both P02.01 and P03.00 to 1. To ensure the control performance, set the values of P03.15 to P03.18 properly according to the nameplate parameters of the motor.

  • Page 179: P04: Motor 1 Encoder Parameters

    In order to implement effective overload protection for different types of load motors, it is necessary to adjust the maximum permissible output current of the drive, as shown in Figure 7-8. Current 电流 100% 200% 电机过载保护系数 Motor overload protection factor 160% 1分...

  • Page 180: P05: Motor 1 Vector Control Parameters

    carrier frequency P04.28 Speed tracking Kp adjustment 10 to 1000 P04.29 Speed tracking Ki adjustment 10 to 1000 P04.30 Speed tracking target current 30% to 200% 100% 7.6 P05: Motor 1 vector control parameters P05.00 Speed loop proportional gain 1 1 to 100 P05.01 Speed loop integral time 1...
  • Page 181 Figure 7-9 PI parameter If the PI value is not properly selected, an overvoltage failure may occur (if there is no external braking resistor or braking unit) when the system accelerates to a high speed after a quick start, which is caused by the energy feedback resulted from the regenerative braking state of the system during the drop process subsequent to the speed overshoot.
  • Page 182 Larger P 比例增益P较大 Reference speed 指令速度 比例增益P较小 Smaller P Smaller I 积分时间I较小 Reference speed 指令速度 积分时间I较大 Larger I Figure 7-11 Relations between the step response and PI parameters Increasing the proportional gain P can accelerate the dynamic response of the system. However, if P is too large, the system is prone to oscillation.
  • Page 183 If the PI value is not properly selected, an overvoltage failure may occur (if there is no external braking resistor or braking unit) when the system accelerates to a high speed after a quick start, which is caused by the energy feedback resulted from the regenerative braking state of the system during the drop process subsequent to the speed overshoot.
  • Page 184 The maximum AI input voltage/current (10 V / 20 mA) corresponds to 300% of the rated torque reference. 3: HDI The maximum pulse input frequency (50 kHz) of the terminal corresponds to 300% of the rated torque reference. For the corresponding relations between the pulse input and output, refer to the description of Group P09.
  • Page 185 The braking torque limit value is set by PROFINET. 6: MIN (AI1, AI2) The braking torque limit value is defined by the minimum between AI1 and AI2. 7: MAX (AI1, AI2) The braking torque limit value is defined by the maximum between AI1 and AI2. Figure 7-13 Torque control diagram The torque limit value shall be positive.

  • Page 186: P06: Motor 1 Torque Control Parameters

    P05.21 Field weakening integral multiple 0.000 to 1.200 7.7 P06: Motor 1 torque control parameters P06.00 Torque control enable 0, 1 0: Disabled 1: Enabled This function code serves as the switchover between the speed control and the torque control. 0: Speed control mode In this mode, the motor is controlled by the speed reference, and the internal ASR is effective.
  • Page 187 3: HDI The maximum pulse input frequency (50 kHz) of the terminal corresponds to 300% of the rated torque reference. For the corresponding relations between the pulse input and output, refer to the description of Group P09. 4: Modbus The host device sets the current torque reference of the drive via the standard RS485 interface built in the drive.

  • Page 188: P07: Motor 1 V/F Control Parameters

    2: AI2 The AI value is used as the speed limit in torque control. The AI-speed relations are determined by the AI curve in Group P09. 3: HDI The maximum pulse input frequency (50 kHz) of the terminal corresponds to 100% of the speed limit reference (maximum output frequency P02.10).
  • Page 189 Figure 7-14 V/F curve Figure 7-15 Multi-point V/F curve When P07.00 is set to 1, the curve is user-defined and applicable for segmented constant-torque loads, as shown in Figure 7-14. In Figure 7-15, F1 < F2 < F3 < Fb, Fb is the basic operating frequency, which is generally the rated frequency of the motor.
  • Page 190 (4) The maximum output voltage Vmax corresponds to the rated voltage of the motor, so it is necessary to properly set the rated voltage of the motor according to the actual motor selected. P07.03 Multi-point V/F frequency 1 0.00 Hz to P07.05 0.00 Hz P07.04 Multi-point V/F voltage 1...

  • Page 191: P08: Start/Stop Control Parameters

    P07.16 Voltage fall time of V/F separation 0 to 6000.0 s 5.0 s P07.17 Stop mode for V/F separation 0 to 1 0: Frequency and voltage decline to 0 independently; 1: Frequency declines after voltage declines to 0. 7.9 P08: Start/Stop control parameters P08.00 Startup mode 0 to 2...
  • Page 192 P08.04 Braking current at startup 0.0 to 100.0% 0.0% P08.05 Braking time at startup 0.00 to 50.00 s 0.0 s P08.04 sets the magnitude of the DC braking current at startup, which is a percentage relative to the drive’s rated current. P08.05 sets the action time for DC braking at startup.
  • Page 193 P08.13 DC braking current at stop 0.0 to 150.0% 0.0% P08.14 DC braking time at stop 0.0 to 6553.5 s 0.0 s P08.11 sets the start frequency at which the DC braking current begins to be injected during the stop process.
  • Page 194 Make sure that the maximum current during speed tracking is within the range. An excessively small value may impact the effect of the speed tracking. P08.18 Output upon vector 0 Hz 0 to 3 0: Enable voltage output 1: No voltage output 2: Output according to the DC braking current at stop 3: Zero-servo running Running mode when below frequency...
  • Page 195 the operating panel is completely turned off); that is, the drive will restart according to the startup mode defined by P08.00. P08.27 Reverse running prohibit 0, 1 0: Disabled 1: Enabled P08.28 FWD/REV switchover dead-zone time 0.0 to 3600.0 s 0.0 s For some production equipment, reverse running may cause equipment damage.

  • Page 196: P09: Terminal Input Parameters

    When the input of the emergency stop terminal (terminal function 60) is effective, the drive begins to decelerate to stop. The deceleration time is determined by P08.33. When the time is set to 0 s, the drive can be stopped in the shortest deceleration time allowed by the system. P08.34 Terminal running protection selection 0, 1...
  • Page 197 Tens place: 0: Terminal 10 as DI6 1: Terminal 10 as HDI Hundreds place: Reserved Thousands place: 0: Terminal 16 as DI8 1: Terminal 16 as AI1 voltage input 2: Terminal 16 as AI1 current input P09.02 Function selection of terminals 13, 11 0 to 0x21 Ones place: 0: Terminal 13 as AI2 voltage input...
  • Page 198 Item Function Item Function Multi-reference terminal 1 Multi-reference terminal 2 Multi-reference terminal 3 Multi-reference terminal 4 Acceleration/Deceleration time terminal Acceleration/Deceleration time terminal Frequency UP/DOWN setting clear Frequency UP/DOWN setting clear (terminal) (terminal + keypad) Frequency increase command (UP) Frequency decrease command (DN) External fault NO input External fault NC input Full-water signal...
  • Page 199 Item Function Item Function 57 to Reserved Solar voltage reference enable Emergency stop Wobble pause Wobble reset Counter reset Counter trigger Power consumption clear Power consumption hold Length counter input Length reset Switched to V/F control Switched to FVC control Reserved Reserved The settings of the multi-function input terminals are mutually exclusive (excluding the function 0).
  • Page 200 Table 7-4 Multi-speed reference combination table Frequency setting Multi-speed 0 Multi-speed 1 Multi-speed 2 Multi-speed 3 Multi-speed 4 Multi-speed 5 Multi-speed 6 Multi-speed 7 Multi-speed 8 Multi-speed 9 Multi-speed 10 Multi-speed 11 Multi-speed 12 Multi-speed 13 Multi-speed 14 Multi-speed 15 10: Acceleration/Deceleration time terminal 1 11: Acceleration/Deceleration time terminal 2 When only one motor (motor 1 or motor 2) is controlled, the ON/OFF combination of the...
  • Page 201 acceleration/deceleration time terminal 2 controls the switchover between the two groups of acceleration/deceleration time of motor 2 (acceleration/deceleration time 3 and 4). 12: Frequency UP/DOWN setting clear (terminal) 13: Frequency UP/DOWN setting clear (terminal + keypad) 14: Frequency increase command (UP) 15: Frequency decrease command (DN) Instead of the operating panel, the frequency is increased or decreased by the control terminal for remote control .
  • Page 202 It is used to realize the pause control of the PLC process. When the terminal is enabled, the drive runs at zero frequency, and the PLC runs without time counting. When the terminal is disabled, the drive will start in the speed tracking mode, and continue the PLC operation. For details, see the function description of P13.00 to P13.36.
  • Page 203 Main frequency Main frequency Main frequency Main frequency reference reference channel reference channel reference channel channel selection terminal 3 selection terminal 2 selection terminal 1 Simple PLC Multi-speed reference Modbus 37: Reserved 38: Command channel switched to keypad When the function terminal is enabled, the operation command channel will be switched to the keypad. When the function terminal is disabled, the operation command channel will be restored 39: Command channel switched to terminal When the function terminal is enabled, the operation command channel will be switched to the terminal.
  • Page 204 function is disabled, the current mode is speed control; when the terminal function is enabled, the current mode is torque control. When P06.00 is set to 1 and the terminal function is disabled, the current mode is torque control; when the terminal function is enabled, the current mode is speed control. 48: Torque direction switchover terminal in torque control In torque control, if the terminal function is enabled, the torque direction of the torque reference can be changed.
  • Page 205 When this function is enabled, the drive is forced to switch to the V/F control mode. 70: Switched to FVC control When this function is enabled, the drive is forced to switch to the FVC control mode. 71、72: Reserved P09.11 Terminal open-circuit voltage selection 0, 1 0: Digital terminal open-circuit voltage 0 V...
  • Page 206 P09.14 FWD/REV operation mode 0 to 3 This parameter defines four different modes that the external terminals use to control the drive running. 0: Two-wire mode 1 Command Stop Reverse Forward Stop Figure 7-19 Two-wire mode 1 1: Two-wire mode 2 Command Stop Stop...
  • Page 207 3: Three-wire mode 2 Command Forward 0→1 Reverse Stop Figure 7-22 Three-wire mode 2 In the above figure: SB1: Stop button SB2: Run button Dli is the multi-function input end of DI1 to DI8, so it is required to set the terminal to function 5 “Three-wire control.”...
  • Page 208 P09.23 DI4 switch-on delay time 0.0 to 600.0 0.0 s P09.24 DI4 switch-off delay time 0.0 to 600.0 0.0 s The above function codes are used to set the delay time for the level jump upon switch-on and switch-off of the digital input terminals. P09.25 AI1 lower limit 0.00 V to P09.27...
  • Page 209 P09.43 HDI filter time 0.000 to 10.000 s 0.030 s AI1, AI2, and HDI pulse input can be used as different reference channels. The analog input channel function can be set by P09.01 and P09.02, and the pulse input function can be set by P09.01 (terminal 10 input function selection).

  • Page 210: P10: Terminal Output Parameters

    7.11 P10: Terminal output parameters P10.00 DO1 function selection 0 to 47 P10.01 DO2 function selection 0 to 47 P10.02 DO3 function selection 0 to 47 P10.03 Relay RO1 output selection 0 to 47 The functions of the multi-function DO terminals are defined in the following table: Table 7-7 Table of digital output terminal functions Item Function...
  • Page 211 1: AC drive in running When in the running state, the drive outputs the indication signal of the state. 2: Forward running 3: Reverse running The corresponding indication signal is output according to the drive’s actual running direction. 4: Frequency reach signal (FAR) Refer to the function description of P11.26.
  • Page 212 When the current running time (see P11.38) of the drive is reached, the relevant indication signal will be output. 16: Accumulated running time reach When the accumulated running time (see P11.39) of the drive is reached, the relevant indication signal will be output 17: AC drive ready to run (RDY) If the signal output is enabled, it means that the drive does not have any fault, and the bus voltage is...
  • Page 213 47: Reserved P10.04 Output terminal polarity selection 0 to 0x1111 It is used to set the polarity of the digital output terminals, as shown below: P10.05 DO1 switch-on delay time 0.0 to 600.0 s 0.0 s P10.06 DO1 switch-off delay time 0.0 to 600.0 s 0.0 s P10.07...
  • Page 214 Item Function Value range Torque current 0 to 3 * Iem Reserved Output voltage 0 to 1.2 * Ve Bus voltage 0 to 800 V AI1 after correction AI2 after correction Reserved Output power 0 to 2 * Pe Host device percentage 0 to 100.0% Torque limit value 1 0.0 to 300.0%...

  • Page 215: P11: Auxiliary Function Parameters

    P10.26 HDO2 output lower limit 0.00% to P10.28 0.00% Frequency corresponding to HDO2 output P10.27 0.00 to 50.00 0.00 kHz lower limit P10.28 HDO2 output upper limit P10.26 to 100.00% 100.00% Frequency corresponding to HDO2 output P10.29 0.00 to 50.00 50.00 kHz upper limit P10.30...
  • Page 216 Adopt an S curve of speed values between the acceleration start and the reach of speed, as well as between the deceleration start and the reach of speed. In this way, the acceleration and deceleration will be smooth and with less impact. The S curve acceleration/deceleration mode is applicable to the start/stop of load handling, such as elevators and conveyors.
  • Page 217 Figure 7-28 Time proportion of S-curve start and end Switchover frequency of P11.09 0.00 Hz to P02.10 0.00 Hz acceleration/deceleration time 1 and 2 Figure 7-29 Switchover of acceleration/deceleration time 1 and 2 As shown in Figure 7-29, to accelerate motor 1, the motor will firstly run according to the acceleration ...
  • Page 218 Figure 7-30 Description of jog operation As shown in Figure 7-30, t1 is the jog acceleration time (P11.11) and the jog deceleration time (P11.12) in actual running; t2 is the jog time and f is the jog operation frequency (P11.10). The jog acceleration/deceleration time t1 in actual running is determined by the following equation: ...
  • Page 219 P11.18 Skip frequency 1 0.00 Hz to P02.10 0.00 Hz P11.19 Skip frequency 1 band 0.00 Hz to P02.10 0.00 Hz P11.20 Skip frequency 2 0.00 Hz to P02.10 0.00 Hz P11.21 Skip frequency 2 band 0.00 Hz to P02.10 0.00 Hz If the frequency reference is within the jump frequency range, the drive will output at the jump frequency boundary in actual operation to avoid mechanical resonance.
  • Page 220 P11.26 Frequency reach (FAR) detection range 0.0 to 100.0% 0.0% When the running frequency of the drive is within the P11.26 percentage range of maximum frequency, the multi-function DO terminal outputs an ON signal as shown in Figure 7-32 Figure 7-32 Frequency reach (FAR) detection range P11.27 FDT1 frequency detection value 0.00 Hz to P02.11...
  • Page 221 Figure 7-33 Frequency level detection P11.31 Temperature for automatic fan start 40.0 to 80.0℃ 55.0℃ P11.32 Reserved P11.33 Length reference 0 to 60000 m P11.34 Actual length 0 to 60000 m P11.35 Number of pulses per meter 0 to 60000 1000 P11.36 Reference count value...

  • Page 222: P12: Control Optimization Parameters

    P11.44 Fan control 0 to 2 0: Auto running (based on the inverter temperature) The drive automatically starts the internal temperature detection program during operation, and decides the running and stop of the fan according to the temperature of the module. 1: Continuous running after power-on The fan keeps running after the drive is powered on.

  • Page 223: P13: Multi-Speed And Simple Plc Parameters

    P12.07 SVPWM mode 0, 1 P12.08 to P12.10 Reserved 7.14 P13: Multi-speed and simple PLC parameters P13.00 PLC running mode 0 to 0x1112 0x0000 The simple PLC is a multi-speed generator. The drive can automatically change its running frequency and direction according to its running time to meet requirements. This function is previously fulfilled by PLC (programmable logic controller), however, it can be performed by the drive itself now, as shown in Figure 7-34 Figure 7-34 Simple PLC running...
  • Page 224 Figure 7-35 Simple PLC running mode selection LED ones: PLC running mode 0: Stop after one cycle of running As shown in Figure 7-36, the drive completes one cycle and automatically stops. It starts only after another operation command is given. Figure 7-36 PLC stops after running for one cycle 1: Keep final values after one cycle of running As shown in Figure 7-37, the drive completes one cycle and automatically retains the final running...
  • Page 225 Figure 7-37 PLC retains final values after running for one cycle 2: Repeat after running for one cycle As shown in Figure 7-38, the drive will start the next cycle automatically after running for one cycle, and it will not stop until a stop command is given. Figure 7-38 PLC repeats after running for one cycle LED tens: Startup mode 0: Run from the first stage...
  • Page 226 Stopping signal 中断信号 Output frequency Hz 输出频率Hz Time t Stage 1 Running Remaining time 时间t 阶段 阶段2已 阶段2剩余时间 time of 运行时间 of stage 2 stage 2 : Acceleration time of stage 1 : Acceleration time of stage 2 ：阶段1加速时间 ：阶段2加速时间 : Acceleration time of stage 3 : Deceleration time of stage 2 ：阶段3加速时间...
  • Page 227 P13.03 Multi-speed reference 2 -100.0 to 100.0% P13.04 Multi-speed reference 3 -100.0 to 100.0% P13.05 Multi-speed reference 4 -100.0 to 100.0% P13.06 Multi-speed reference 5 -100.0 to 100.0% P13.07 Multi-speed reference 6 -100.0 to 100.0% P13.08 Multi-speed reference 7 -100.0 to 100.0% P13.09 Multi-speed reference 8 -100.0 to 100.0%...
  • Page 228 P13.31 Multi-speed reference 14 running time 0.0 to 6553.5 s 0.0 s P13.32 Multi-speed reference 15 running time 0.0 to 6553.5 s 0.0 s The frequency reference of stage 0 to stage 15 ranges from -100.0 to 100.0%; the 100% value of the frequency reference corresponds to the maximum output frequency P02.10.

  • Page 229: P14: Process Pid Parameters

    The acceleration/deceleration time selection from stage 8 to stage 11 of the simple PLC is shown in the following figure. Figure 7-42 Acceleration/Deceleration time selection of simple PLC stage 8 to 11 Acceleration/Deceleration time of simple P13.36 0 to 0x3333 0x0000 PLC reference 12 to 15 The acceleration/deceleration time selection from stage 12 to stage 15 of the simple PLC is shown in the...
  • Page 230 It defines the adjustment intensity in proportion to the deviation. Solely using P control can not eliminate the steady-state error. Integral control (I) It defines the adjustment intensity in proportion to the deviation integral value, which can eliminate the steady-state error but cannot control sharp changes. Derivative control (D) It defines the adjustment intensity in proportion to the deviation change rate, which can predict the tendency of deviation, quickly respond to sharp changes, and improve the dynamic performance.
  • Page 231 Figure 7-44 PID control diagram...
  • Page 232 P14.00 PID reference source 0 to 6 0: P14.02 digital setting 1: AI1 2: AI2 3: Reserved 4: HDI 5: Modbus 6: PROFINET P14.01 PID feedback source 0 to 9 0: AI1 1: AI2 2: Reserved 3: HDI 4: Modbus 5: PROFINET 6: AI1 + AI2 7: AI1 - AI2...
  • Page 233 A larger Kp indicates quicker response, but an excessively large Kp may easily cause oscillation. The steady-state error can not be eliminated by using Kp control only. P14.06 Integral time Ti1 0.01 to 10.00 2.00 s Ti1 is used to eliminate the steady-state error, so the feedback value would be kept consistent with the target value.
  • Page 234 point When the ramp frequency reference is lower than the low-frequency switchover point, the PID parameters include P14.05 to P14.07. When it is higher than the high-frequency switchover point, the PID parameters include P14.13 to P14.15. When it is between the low-frequency and high-frequency switchover points, the PID parameter is the linear interpolation of the parameters of these two groups.
  • Page 235 P14.21 PID preset value hold time 0.00 to 650.00 0.0 s Proper PID preset value and preset value hold time enable the closed-loop adjustment to quickly enter a stable stage. After the PID operation starts, the frequency will firstly accelerate to the PID preset value according to the acceleration time, and then run continuously at this frequency for the time defined by P14.21 before it runs according to the PID adjustment output, as shown in Figure 7-47.

  • Page 236: P15: Communication Parameters

    P14.27 PID frequency lower limit -327.67 to P14.26 0.00 Hz 7.16 P15: Communication parameters P15.00 Communication format 0 to 0x31 0x30 Ones place: 0: Modbus protocol 1: Expansion card to 485 protocol Tens place: 0: 1-8-2-N format, RTU 1: 1-8-1-E format, RTU 2: 1-8-1-0 format, RTU 3: 1-8-1-N format, RTU P15.01...

  • Page 237: P16: Keypad Display Setting Parameters

    It refers to the delay time between the drive’s receiving and executing of the host command and the returning of the response frame to the host. For the RTU mode, the response delay shall not be less than the transmission time of 3.5 characters. P15.05 Communication action 0, 1...
  • Page 238 Figure 7-49 Parameter selection 2 for LED display in the running state Default selection of parameters for LED P16.02 0 to 31 display in the running state It is used to set the default selection of parameters (displayed as the serial number of each parameter) to be displayed on the zero level keypad menu in the running state after power-on.

  • Page 239: P20: Motor 2 Parameters

    5: AI1 input voltage 6: AI2 input voltage 7: AO1 output percentage 8: HDI frequency reference 9: HDO1 output 10: HDO2 output 11: Length 12: Simple PLC current step 13: Line speed 14: PID reference 15: Torque reference Turn the “ ”...
  • Page 240 Asynchronous motor P20.01 0.1 to 3000.0 kW Depend on model rated power Asynchronous motor P20.02 0 to 1200 V Depend on model rated voltage Asynchronous motor P20.03 0.8 to 6000.0 A Depend on model rated current Asynchronous motor P20.04 0.01 Hz to P02.10 50.00 Hz rated frequency Asynchronous motor...
  • Page 241 coefficient 4 Synchronous motor rated P20.15 0.1 to 3000.0 kW Depend on model power Synchronous motor rated P20.16 0 to 1200 V Depend on model voltage Synchronous motor rated P20.17 0.8 to 6553.5 A Depend on model current Synchronous motor rated P20.18 0.01 Hz to P02.10 Depend on model...

  • Page 242: P21: Motor 2 Encoder Parameters

    7.19 P21: Motor 2 encoder parameters P21.00 to P21.30 Reserved For the parameter description of this parameter group, refer to “7.5 P04: Motor 1 encoder parameters.” 7.20 P22: Motor 2 vector control parameters P22.00 Speed loop proportional gain 1 1 to 100 P22.01 Speed loop integral time 1 0.01 to 10.00...

  • Page 243: P23: Motor 2 Torque Control Parameters

    P22.21 Field weakening integral multiple 0.000 to 1.200 1.000 For the parameter description of this parameter group, refer to “7.6 P05: Motor 1 vector control parameters.” 7.21 P23: Motor 2 torque control parameters P23.00 Torque control enable 0, 1 0: Disabled 1: Enabled P23.01 Torque reference channel...

  • Page 244: P24: Motor 2 V/F Control Parameters

    3: HDI 4: Modbus 5: PROFINET P23.08 to P23.11 Reserved For the parameter description of this parameter group, refer to “7.7 P06: Motor 1 torque control parameters.” 7.22 P24: Motor 2 V/F control parameters P24.00 V/F curve setting 0 to 5 0: Straight-line V/F 1: Multi-point V/F 2: Square V/F...

  • Page 245: P30: Solar Pump Control Parameters

    0: Digital setting 1: AI1 2: AI2 3: Reserved 4: HDI 5: Multi-reference 6: Simple PLC 7: PID 8: Modbus 9: PROFINET Digital setting of voltage source for V/F P24.14 0 to 1000 separation P24.15 Voltage rise time of V/F separation 0.0 to 6000.0 5.0 s P24.16...
  • Page 246 P30.05 MPPT step size for upward search 0 to 200 P30.06 MPPT step size for downward search 0 to 200 P30.11 MPPT power detection refresh time 0 to 65525 P30.12 MPPT internal delay time 0 to 65535 P30.13 MPPT algorithms 0, 1 P30.14 Vmpp keypad setting...
  • Page 247 report an empty-water pre-alarm (A-tL) after the empty-water level delay time (P30.20), and enter the hibernation state. During the empty-water alarm, the empty-water signal is invalid; the system will clear the empty-water alarm after the empty-water level wake-up delay time (P30.21), and enter the running state again.

  • Page 248: P40: Bus Option Parameters

    mode 2: PV input mode P30.26 Time for automatic switchover to PV input 0-65535 P30.27 Automatic switchover delay 0-65535 When the PV input and power line frequency input selection is set to 0, the drive will switch between the power line frequency input and the PV input in an automatic manner, which means the power source of the system will switch between the power grid and the PV automatically.

  • Page 249: P41: I/O Option Parameters

    P40.02 to P40.33 Reserved 7.25 P41: I/O option parameters P41.00 DI9 function selection 0 to 72 P41.01 DI10 function selection 0 to 72 P41.02 DI11 function selection 0 to 72 For the parameter description of this parameter group, refer to 7.10 (P09.03 to P09.10). P41.03 Terminal open-circuit voltage selection 0, 1...

  • Page 250: P43: Profinet Communication Parameters

    P41.11 DI11 switch-on delay time 0.0 to 600.0 0.0 s P41.12 DI11 switch-off delay time 0.0 to 600.0 0.0 s For the parameter description of this parameter group, refer to 7.10 (P09.17 to P09.24). P41.13 Relay RO2 output selection 0 to 47 P41.14 Relay RO3 output selection 0 to 47...
  • Page 251 P43.02 PZD2 receive 0 to 30 P43.03 PZD3 receive 0 to 30 P43.04 PZD4 receive 0 to 30 P43.05 PZD5 receive 0 to 30 P43.06 PZD6 receive 0 to 30 P43.07 PZD7 receive 0 to 30 P43.08 PZD8 receive 0 to 30 P43.09 PZD9 receive 0 to 30...
  • Page 252 P43.16 PZD5 feedback 0 to 30 P43.17 PZD6 feedback 0 to 30 P43.18 PZD7 feedback 0 to 30 P43.19 PZD8 feedback 0 to 30 P43.20 PZD9 feedback 0 to 30 P43.21 PZD10 feedback 0 to 30 P43.22 PZD11 feedback 0 to 30 P43.23 PZD12 feedback 0 to 30...

  • Page 253: P50: Option Status Check Parameters

    24: PID deviation (-100.0% to 100.0%) 25: PID output (-100.0% to 100.0%) 26 to 30: Reserved P43.24 to P43.33 Reserved 7.27 P50: Option status check parameters P50.00 Option type 0 to 3 0: No option 1: PROFINET option 2: EtherCAT option 3: I/O option P50.01 Reserved...
  • Page 254 1: Overload pre-alarm enabled Thousands place: 0: Braking overcurrent disabled 1: Braking overcurrent enabled P97.01 Stall protection enable 0 to 0x111 0x101 Ones place: 0: Overvoltage stall protection disabled 1: Overvoltage stall protection enabled Tens place: 0: Undervoltage stall protection disabled 1: Undervoltage stall protection enabled Hundreds place: 0: Overcurrent stall protection disabled...
  • Page 255 the energy to the drive, resulting in the increase of the DC bus voltage of the drive. If no measures are taken, there will be an overvoltage trip. The function of overvoltage stall protection detects the bus voltage during the deceleration of the drive, and compares it with the overvoltage stall point defined by P97.04.
  • Page 256 Undervoltage stall recovery judgment P97.12 0 to 100.0 s 2.0 s time Undervoltage stall protection pause P97.13 460 to 500 V 485 V voltage It is used to set the voltage point for undervoltage stall protection pause. When the bus voltage is greater than this value, the drive stops lowering the frequency after the delay time set by P97.12 P97.14 Phase loss protection enable...
  • Page 257 Figure 7-54 Fault protection and alarm property 3 P97.18 Fault protection and alarm property 4 0 to 0x20 Figure 7-55 Fault protection and alarm property 4 P97.19 to P97.24 Reserved P97.25 Motor overheat protection threshold 0 to 200℃ 120℃ Compare the analog feedback value of the thermal sensor installed in the motor with the preset motor overheat protection threshold P97.25.
  • Page 258 When the speed deviation (difference between the speed reference and the actual motor speed) exceeds the value set by P97.27, and the hold time of such state exceeds the time set by P97.28, it is defined as excessive speed deviation. Set P97.27 with the maximum output frequency being 100%. When it is set to 0.0 s, speed deviation protection is disabled.
  • Page 259 P97.35 Bus voltage upon the present fault 0.0 to 6553.5 0.0 V P97.36 Actual current upon the present fault 0.0 to 999.9 0.0 A P97.37 Running frequency upon the present fault 0.00 to 655.35 0.00 Hz AC drive operation state upon the present P97.38 0 to 0xFFFF fault...

  • Page 260: P98: Drive Parameters

    AC drive operation state upon the P97.56 0 to 0xFFFF penultimate fault Inverter bridge temperature upon the P97.57 0.0 to 150.0 0.0℃ penultimate fault P97.58 Reserved Input terminal status upon the P97.59 0 to 0xFF penultimate fault Output terminal status upon the P97.60 0 to 0xF penultimate fault...
  • Page 261 P98.11 Manufacturer’s bar code 5 0 to 0xFFFF P98.12 Manufacturer’s bar code 6 0 to 0xFFFF...

  • Page 262: Chapter 8 Troubleshooting

    Chapter 8 Troubleshooting 8.1 Diagnosis and solution of faults on display All possible fault types of MV810G1 (SP1) are summarized in Table 8-1, as categorized into 18 fault codes. Before seeking for assistance, the user can perform the fault diagnosis according to this table and record the fault symptoms in details.
  • Page 263 Fault Fault type Possible cause Solution code The drive power is too low. Use a drive with higher power. Abnormal input voltage Check the input power supply. Overvoltage Increase the acceleration time The acceleration time is too short. during appropriately. acceleration When instantaneous stop happens, Set the startup mode P08.00 to startup...
  • Page 264 Fault Fault type Possible cause Solution code The duct is blocked or the fan is Unblock the duct or replace the fan. damaged. The ambient temperature is too Lower the ambient temperature. high. Wires or plug-in units of the control Check them and rewire.
  • Page 265 Fault Fault type Possible cause Solution code When instantaneous stop happens, Set the startup mode P08.00 to startup the rotating motor is restarted. after speed tracking. The acceleration time is too short. Increase the acceleration time. The power grid voltage is too low. Check the power grid voltage.
  • Page 266 Fault Fault type Possible cause Solution code The auxiliary power supply is Seek for technical support. damaged. The Hall device is damaged. Seek for technical support. The amplifying circuit is abnormal. Seek for technical support. The parameters for feedback loss Modify the P14.22 setting are set improperly.
  • Page 267 Fault Fault type Possible cause Solution code (excessively big) The speed deviation detection Modify the speed deviation detection fault value is set too small. setting. Significant load fluctuation Eliminate the load vibration. Check whether the input voltage of the PID feedback The PID feedback value exceeds feedback is normal.

  • Page 268: Operation Exceptions

    Fault Fault type Possible cause Solution code Check whether the fan is blocked Fan locked-rotor Clean the motor fan. by foreign matters. The device will automatically run when low sunlight the light is sufficient. The sunlight is weak or the solar A-LS intensity panel configuration is insufficient.
  • Page 269 Symptom Condition Possible cause Solution The function code The function code does not does not support Modify the function code after support modification in the modification in the the drive stops. running state. running state. The function code P00.03 is Set P00.03 to 0.
  • Page 270 Symptom Condition Possible cause Solution the running Check the external interruption External interruption indicator is on setting and find out the cause (running at zero The frequency reference is 0. Check the frequency reference. frequency). The startup frequency is higher than the frequency Check the startup frequency reference.
  • Page 271 Symptom Condition Possible cause Solution Disable the virtual terminal The virtual terminal function function, or set the function of the host device is set properly via the host device; the improperly. fault can also be cleared by modifying the P09.16 setting. Positive and negative logic of Check the settings of P09.12 and input terminal are not set...

  • Page 272: Chapter 9 Maintenance

    Chapter 9 Maintenance Many factors, such as the extremity in ambient temperature, humidity, dust, and vibration, as well as the aging of the internal components, will give rise to the occurrence of potential faults. Therefore, it is necessary to conduct daily/periodical maintenance for this AC drive product. 9.1 Daily inspection As safety precautions, before inspection and maintenance of the drive, please check the following matters.

  • Page 273: Periodical Maintenance

    2. Noise 2. Listen 2. Low and regular noise 1. Within the rated range, and 1. Output current 1. Current meter three-phase balanced Running 2. Within the rated range, and 2. Output voltage Any time 2. Voltmeter status three-phase balanced 3.

  • Page 274: Replacement Of Quick-Wear Parts

    ① The drive has passed the dielectric strength test before delivery. Thus, the user shall not conduct the test again; otherwise, improper test may damage the drive. ② If it is needed to replace the original components, make sure the models and specifications of new components are the same;...
  • Page 275 (1) The drive should be stored in the place with good ventilation away from high temperature, humidity, dust and metal powder; (2) Long-term storage will cause the deterioration of the electrolytic capacitor. The drive should be powered on for a test at least once (for at least 5 hours) within 2 years. To power on the drive, the input voltage should be raised gradually to the rated value via a regulator.

  • Page 276: Appendix 1 Modbus Communication

    Appendix 1 Modbus Communication Protocol 1. Network The two networking methods for this AC drive include: single-master-multi-slave, and single-master-single-slave. 2. Interface RS485 interface: asynchronous and half-duplex. Default: 1-8-N-1, 9600 bps, RTU. For the parameter setting, refer to Group P15. 3. Communication (1) The drive adopts the Modbus communication protocol, which supports the common reading/writing of the register, and expands part of the commands to manage the function codes.

  • Page 277: Protocol Functions

    Modbus adopts the “Big-Endian” encoding order, which sends the high bytes first and then sends the low bytes. In RTU mode, the larger value between the function code value and the Modbus internal conventional value shall be selected as the idle time between frames. The minimum idle time value between frames under the Modbus internal convention is as follows: the idle time that the frame header and frame tail pass the bus shall not be less than 3.5 characters in order to define the frame.
  • Page 278 Command code Definition Used to rewrite one function code parameter or control parameter (16-bit), and the 0x06 result will be saved at power off. Used to rewrite one function code parameter or control parameter (16-bit), and the 0x07 result will not be saved at power off. Used to rewrite multiple function code parameters or control parameters, and the 0x10 parameter values will be saved at power off.
  • Page 279 0x10 Status parameter group 0x65 0x11 … … For example, the register address of the function code parameter P03.02 is 0x0302, and the register address of the first control parameter (control word 1) is 0x6400. As the format of the whole data frame has been explained in the above text, the following text will describe the format and meanings of the “command code”...
  • Page 280 Exception code Definition 0x03 CRC check error 0x04 Invalid address 0x05 Invalid parameter 0x06 Invalid modification of parameters 0x07 System lock 0x08 Parameter being saved (2) Rewrite one function code parameter or control parameter (16-bit), and the result will be saved at power off.
  • Page 281 Command code 0x07 Register address 0x0000 to 0xFFFF Register content 0x0000 to 0xFFFF If the operation is successful, the response format is as follows: Application-layer protocol data unit Data length (number of bytes) Value or range Command code 0x07 Register address 0x0000 to 0xFFFF Register content 0x0000 to 0xFFFF...
  • Page 282 This command is used to change the content of the continuous data units from the start register address. If the operation fails, an abnormal response frame will return, and its format is described as above. 6. Control parameters and status parameters The control parameters of the drive manage the start, stop, running frequency setting, and other functions alike.
  • Page 283 Register address Parameter name Remarks 0x640C Auxiliary frequency reference Range: 0.00 Hz to P02.10. -3000 to 3000 corresponding to -300.0% to 300.0% 0x640D Torque reference Valid when the torque reference channel is the serial port in the torque control mode. FWD frequency limit under Range: 0.00Hz to P02.11 0x640E...
  • Page 284 Value Function Remarks BIT6 Reserved FWD jog BIT7 No action when FWD and REV jog are Disable FWD jog both enabled; the jog stops when both REV jog are disabled. BIT8 Disable REV jog Enable fault reset The selected bit for the validity of the (valid for all command channels) BIT9 fault reset of the host device...
  • Page 285 Register address Parameter name Remarks 0x6503 Drive serial number Product serial number, such as 810 Software version number of the function 0x6504 Function software version number board 0x6505 Reserved Reserved 0x6506 Output current 0.0 to 6553.5 A 0x6507 Output voltage 0 to 65535 V 0x6508 Output power...
  • Page 286 Register address Parameter name Remarks 0x651B Reserved 0x651C Acceleration time setting 1 0.0 to 6000.0 s 0x651D Deceleration time setting 1 0.0 to 6000.0 s Operation command channel (same as 0x651E Operation command channel P02.02) Refer to the status word 2 definition 0x651F Status word 2 of drive table...
  • Page 287 (2) In the status parameters, the maximum length of “actual running value of current main reference”, “current running frequency”, “running frequency reference”, and “running frequency at the 3rd fault” is 32 bits, and others’ maximum length is 16 bits. The bit definition of status word 1 of the drive is shown in the following table: Value Function Remarks...
  • Page 288 Value Function Remarks BIT0 Reserved Jog running BIT1 Non-jog running Simple PLC running BIT2 Non simple PLC running BIT3 Reserved Process closed-loop running (PID) BIT4 Non process closed-loop running (PID) BIT15 to BIT5 Reserved The bit definition of status word 3 of the drive is shown in the following table. Value Function Remarks...
  • Page 289 BIT14 Torque control BIT15 Reserved 7. Cautions 1. To read multiple parameters, if any one of the function codes is not read successfully (due to invalid parameter address, parameter being password, etc.), only the error information will return, and no read parameter values will return.

  • Page 290: Crc Check

    8. CRC check To improve the speed, CRC-16 generally adopts the table type. The following is the C language source code for realizing CRC-16. Note that the final results have exchanged the high and low bytes, which means the results are the CRC checksum to send. unsigned short CRC16 (unsigned char *msg, unsigned /* The function returns the CRC as a char length)
  • Page 291 0x0028,0xC1E8,0x81E9,0x4029,0x01EB,0xC02B,0x802A,0x41EA,0x01EE,0xC02E,0x802F,0x41EF, 0x002D,0xC1ED,0x81EC,0x402C,0x01E4,0xC024,0x8025,0x41E5,0x0027,0xC1E7,0x81E6,0x4026, 0x0022,0xC1E2,0x81E3,0x4023,0x01E1,0xC021,0x8020,0x41E0,0x01A0,0xC060,0x8061,0x41A1, 0x0063,0xC1A3,0x81A2,0x4062,0x0066,0xC1A6,0x81A7,0x4067,0x01A5,0xC065,0x8064,0x41A4, 0x006C,0xC1AC,0x81AD,0x406D,0x01AF,0xC06F,0x806E,0x41AE,0x01AA,0xC06A,0x806B,0x41AB, 0x0069,0xC1A9,0x81A8,0x4068,0x0078,0xC1B8,0x81B9,0x4079,0x01BB,0xC07B,0x807A,0x41BA, 0x01BE,0xC07E,0x807F,0x41BF,0x007D,0xC1BD,0x81BC,0x407C,0x01B4,0xC074,0x8075,0x41B5, 0x0077,0xC1B7,0x81B6,0x4076,0x0072,0xC1B2,0x81B3,0x4073,0x01B1,0xC071,0x8070,0x41B0, 0x0050,0xC190,0x8191,0x4051,0x0193,0xC053,0x8052,0x4192,0x0196,0xC056,0x8057,0x4197, 0x0055,0xC195,0x8194,0x4054,0x019C,0xC05C,0x805D,0x419D,0x005F,0xC19F,0x819E,0x405E, 0x005A,0xC19A,0x819B,0x405B,0x0199,0xC059,0x8058,0x4198,0x0188,0xC048,0x8049,0x4189, 0x004B,0xC18B,0x818A,0x404A,0x004E,0xC18E,0x818F,0x404F,0x018D,0xC04D,0x804C,0x418C, 0x0044,0xC184,0x8185,0x4045,0x0187,0xC047,0x8046,0x4186,0x0182,0xC042,0x8043,0x4183, 0x0041,0xC181,0x8180,0x4040} If the CRC checksum of each sent byte is computed online, it will take a lot of time, but it can save the program space occupied by the table. The code for computing CRC online is as follows: unsigned int crc_check(unsigned char *data,unsigned char length) int i;...
  • Page 292 return (crc_result=((crc_result&0xff)<<8)|(crc_result>>8)); 9. Scaling of the drive parameters (1) Scaling of frequency is 1: 100 To run the drive at 50 Hz, the main reference should be 0x1388 (5000). (2) Scaling of time is 1: 10 To set the drive’s acceleration time to be 30 s, the function code should be set to 0x012C (300). (3) Scaling of current is 1: 10 If the drive’s feedback current is 0x012C (300), the present current is 30 A.

  • Page 293: Appendix 2 Warranty And Service

    Megmeet. (2) In case of any abnormalities, please seek assistance by contacting the product supplier or Megmeet. (3) During the warranty period, any abnormalities caused by manufacturing and design defects will be repaired free of charge by our company.

  • Page 294: Parameter Recording Table

    Parameter recording table...
  • Page 296 Shenzhen Megmeet Electrical Co., Ltd. Shenzhen Megmeet Electrical Co., Ltd. Drive Warranty Bill Drive Warranty Bill Customer company: Customer company: Detailed address: Detailed address: Zip code: Contact: Zip code: Contact: Tel: Fax: Tel: Fax: Machine model: Machine model: Power: Machine No.: Power: Machine No.:...

This manual is also suitable for:

Mv810g1-2s0.4b(sp1)Mv810g1-2s0.75b(sp1)Mv810g1-2s1.5b(sp1)Mv810g1-2s2.2b(sp1)Mv810g1-4t0.75b(sp1)Mv810g1-4t1.5b(sp1) ... Show all

Table of Contents
