MV820 High-Performance Vector Control Drive
User Manual
Document Version:
Archive Date:
BOM Code
Shenzhen Megmeet Electrical Co., Ltd. provides professional technical support for our
customers. You can contact the local branch office or customer service center, or
directly contact the company headquarters.
Shenzhen Megmeet Electrical Co., Ltd.
All rights reserved. The contents in this document are subject to change without
notice.
Shenzhen Megmeet Electrical Co., Ltd.
Address: 5th Floor, Block B, Unisplendor Information Harbor, Langshan Road, Nanshan
District, Shenzhen, 518057, China
Zip code: 518057
Website:
https://www.megmeet.com/
Tel: +86-755-86600500
Fax: +86-755-86600562
Service email:
driveservice@megmeet.com
V2.0
2024/01/24
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MV820 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Megmeet MV820

Summary of Contents for Megmeet MV820

  • Page 1 V2.0 Archive Date: 2024/01/24 BOM Code Shenzhen Megmeet Electrical Co., Ltd. provides professional technical support for our customers. You can contact the local branch office or customer service center, or directly contact the company headquarters. Shenzhen Megmeet Electrical Co., Ltd.
  • Page 2 Meanwhile, MV820 has sound anti-trip control and strong adaptation to harsh environments with bad power mains, high temperature, high humidity or filled with dust, largely improving the reliability.
  • Page 3 Safety precautions Indicates that failure to comply with the notice can result in death or severe personal injuries. Indicates that failure to comply with the notice may result in moderate or minor personal injuries or equipment damage.  Install the product on incombustible materials such as metal. Failure to comply will result in a fire. ...
  • Page 4  When carrying the drive, protect the operating panel and the cover against any stress. Failure to comply will result in personal injuries or equipment damage.  Install the product on the place that can bear the weight. Failure to comply will result in personal injuries or equipment damage.

  • Page 5: Table Of Contents

    Contents Chapter 1 Introduction of MV820 Series ............9 1.1 Product model .........................9 1.2 Product nameplate ......................9 1.3 Product series ....................... 10 1.4 Technical specifications ....................10 1.5 Product components ....................14 1.6 Product dimensions ..................... 14 1.7 Operating panel dimensions ..................17 Chapter 2 Options and Accessories ..............
  • Page 6 3.3 Installation direction and gap ...................45 Chapter 4 Drive Wiring ..................47 4.1 Main circuit terminal wiring and description ............50 4.1.1 Main circuit input and output terminal types ..........50 4.1.2 Connection of drive and accessories .............. 53 4.1.3 Basic operation wiring ..................57 4.2 Control circuit terminal wiring and description .............
  • Page 7 6.1 Explanation of terms related to function codes ............ 97 6.2 Function codes of basic menu ................. 97 Chapter 7 Parameter Description ..............181 7.1 P00: System management parameters ..............181 7.2 P01: Status display parameters ................184 7.3 P02: Basic function parameters ................189 7.4 P03: Motor 1 parameters ..................
  • Page 8 8.2 List of operation exceptions ...................284 Chapter 9 Maintenance ..................287 9.1 Daily inspection ......................287 9.2 Periodical maintenance ...................288 9.3 Replacing wearing parts ..................289 9.4 Storage of drive ......................290 Chapter 10 Application of Special Functions ..........291 10.1 Closed-loop application ...................291 10.2 Integrated communication application ...............292 Appendix 1 Modbus Communication Protocol ..........

  • Page 9: Chapter 1 Introduction Of Mv820 Series

    Chapter 1 Introduction of MV820 Series Product model The drive model on the nameplate indicates the product series, voltage class, power rating, product version and so on. Product nameplate...

  • Page 10: Product Series

    Product series Table 1-1 Drive series Rated input Rated output Rated output Enclosure Fan’s air volume Drive model current current power model （m³/min） (kW) MV820G1-2S0.4B MV820G1-2S0.75B 10.4 0.75 MV820G1-2S1.5B 16.2 MV820G1-2S2.2B 23.0 0.48 MV820G1-2D0.4B 5.3/4.1 MV820G1-2D0.75B 10.4/7.5 0.75 MV820G1-2D1.5B 14.0/9.0 MV820G1-2D2.2B 23.0 0.48...
  • Page 11 Rated input Refer to Table 1-1. current (A) Rated 50 Hz/60 Hz, fluctuation range: ±2 Hz frequency (Hz) Rated output power (kW) Refer to Table 1-1. Rated output current (A) Output voltage Three-phase output under rated input conditions, 0 to rated input voltage, deviation less than ±3% Output Output...
  • Page 12 0.1 to 6000.0 (unit: 0.1 s) time Dynamic braking Built-in braking units for the whole MV820 series, braking ratio 0.0 to 100.0% capacity Startup frequency: 0.00 Hz to 599.00 Hz; braking time: 0.1 s to 50.0 s DC braking capacity...
  • Page 13 Cooling Air cooling method Indoors without direct sunlight, dust, corrosive gas, combustible gas, oil mist, water Operating site vapour, drip or salt ≤1000 m: derating not required; 1000 m < altitude < 3000 m: derated by 1% for every Altitude additional 100 m;...

  • Page 14: Product Components

    Product components 1: Enclosure 2: Encoder board 3: Control box 4: Keypad 5: Expansion box 6: Rubber plug 7: Upper cover 8: Wire fixation bracket 9: Grounding board 10: Fan cover 11: Fan 12: Dustproof plate Fig. 1-1 Part of components (taking enclosure B as an example) Product dimensions There are five types of outline dimensions as shown in Fig.
  • Page 15 (2) Enclosure C: 2T3.7 kW; 4T5.5 kW / 7.5 kW Fig. 1-3 Enclosure C (3) Enclosure D: 2T5.5/7.5 kW; 4T11/15 kW Fig. 1-4 Enclosure D...
  • Page 16 (4) Enclosure E: 4T18.5/22 kW Fig. 1-5 Enclosure E (5) Enclosure F: 4T30/37kW Fig. 1-6 Enclosure F Table 1-3 Outline, mounting dimensions and gross weight Mounting Gross Enclosure hole Drive model A (mm) B1 (mm) B2 (mm) H (mm) W (mm) weight±...

  • Page 17: Operating Panel Dimensions

    Mounting Gross Enclosure hole Drive model A (mm) B1 (mm) B2 (mm) H (mm) W (mm) weight± model (mm) diameter 0.5 (kg) (mm) MV820G1-2S0.4B MV820G1-2S0.75B MV820G1-2S1.5B MV820G1-2S2.2B MV820G1-2D0.4B MV820G1-2D0.75B MV820G1-2D1.5B Enclosure B 187.5 158.5 MV820G1-2D2.2B MV820G1-4T0.4B MV820G1-4T0.75B MV820G1-4T1.5B MV820G1-2T2.2B MV820G1-4T2.2B MV820G1-4T3.7B MV820G1-2T3.7B Enclosure C...
  • Page 18 Fig. 1-7 Appearance and mounting dimensions of operating panel (1) A removable LED keypad (with a shuttle button) is the standard configuration for the whole MV820 series, which supports external use. If you want to add a remote LCD keypad, refer to 2.2.8.

  • Page 19: Chapter 2 Options And Accessories

    PCBA boards without an expansion box, such as encoder cards. Accessory cards/options The entire MV820 series supports a wide range of expansions, such as PROFINET, EtherCAT, CANopen, PROFIBUS and other bus expansions, I/O and encoder expansions, capable for scenarios requiring excellent control performance and multi-unit network.
  • Page 20 2.1.1.2 Installation interfaces The electrical interfaces of accessory cards/options connected to the drive are shown in Fig. 2-2. Fig. 2-2 Electrical interfaces...
  • Page 21 2.1.1.3 Installation steps for accessory cards at position 1 Installation method: reverse side mounting for the accessory card (PG card) (1) When the drive is powered off, press the granulated part on the middle-upper of the lower cover, slide it down firmly to take down the cover, as shown in Fig.
  • Page 22 2.1.1.4 Installation steps for options at position 2 Installation method: front side mounting for the option (PN/EtherCAT bus options/IO expansion options) (1) When the drive is powered off, press the granulated part on the middle-upper of the lower cover, slide it down firmly to take down the cover, as shown in Fig.
  • Page 23 Grounding method: connect the B end of the grounding cable to the grounding terminal block (see Fig. 2-7. For grounding terminal blocks of other accessory cards and options, refer to the corresponding sections of 2.1), and you can check the grounding cable diameter and torque by referring to Table 2-1; then connect the A end of the grounding cable to the grounding rack PE (the mark for grounding, circled in Fig.

  • Page 24: Mv810-Pnet01: Profinet Communication Option

    CAT6 Ethernet cable Galvanic isolation 500 V DC Transmission type Cyclic data transmission Module name MV810-PNET01 Communication GSDML file GSDML-V2.32-megmeet-mv800.xml Bus transmission speed 100 Mbps Power voltage 3.3 V DC (provided by the drive) Electrical specifications Insulation voltage 500 V DC...
  • Page 25 Power consumption Weight 25 g ESD (IEC 61800-5-1, IEC 6100-4-2) EFT (IEC 61800-5-1, IEC 6100-4-4) Noise immunity Surge Test (IEC 61800-5-1, IEC 6100-4-5) Conducted Susceptibility Test (IEC 61800-5-1, IEC 6100-4-6) Environment specifications Operating: -10 to 50℃ (temperature), 90% (humidity) Operating/Storage environment Storage: -25 to 70℃...
  • Page 26 communication with the host device; and the LED on the communication port indicates whether the communication status of MV810-PNET01 is normal. Table 2-3 Description of LED on the light guide column of the expansion box LED status Description Action No communication Check whether the PN option is properly connected to the host device between the PN option and the host device...

  • Page 27: Mv810-Ecat01: Ethercat Communication Option

    2.1.3 MV810-ECAT01: EtherCAT communication option 2.1.3.1 Product appearance Fig. 2-8 Components and terminals 2.1.3.2 Function features (1) Supports PDO and SDO services (2) Supports access of drive parameters through SDO (3) Supports 100 Mbps full duplex (4) Supports the speed mode 2.1.3.3 Technical specifications Interface Two RJ45 (IN, OUT)
  • Page 28 XML file MV800_ECAT_CoE_9252_V1.00.xml SDO request, SDO response Variable PDO mapping Power voltage 3.3 V DC (provided by the drive) Insulation voltage 500 V DC Electrical specifications Power consumption Weight 25 g ESD (IEC 61800-5-1, IEC 6100-4-2) EFT (IEC 61800-5-1, IEC 6100-4-4) Noise immunity Surge Test (IEC 61800-5-1, IEC 6100-4-5) Conducted Susceptibility Test (IEC 61800-5-1, IEC...
  • Page 29 NOT CONNECTED 2.1.3.5 Parameter settings for EtherCAT network connection Using MV810-ECAT01 to operate the MV820 drive, you need to set the operation command channel and frequency source of MV820 to the bus communication card, as shown in the following table.
  • Page 30 PCBA indicates the power status and whether the state machine enters the OP mode; and the LED on the communication port indicates whether the communication status of MV810-ECAT01 is normal. Table 2-6 Description of LED on the PCBA of the expansion box LED1 status Description Action...

  • Page 31: Mv810-Ecat02: Ethercat Communication Option

    2.1.4 MV810-ECAT02: EtherCAT communication option 2.1.4.1 Product appearance Fig. 2-10 Components and terminals 2.1.4.2 Function features (1) Supports PDO and SDO services (2) Supports access of drive parameters through SDO (3) Supports 100 Mbps full duplex (4) Supports the speed mode and the torque mode (5) Supports the SM mode and the DC mode with a minimum cycle of 1 ms (6) Supports 4 configurable PDO groups 2.1.4.3 Technical specifications...
  • Page 32 Bus transmission speed 100 Mbps Auto-Defect Module name MV810-ECAT02 XML file MV800_ECAT_CoE_V2.00.xml SDO request, SDO response Variable PDO mapping Power voltage 3.3 V DC (provided by the drive) Insulation voltage 500 V DC Electrical specifications Power consumption Weight 25 g ESD (IEC 61800-5-1, IEC 6100-4-2) EFT (IEC 61800-5-1, IEC 6100-4-4) Noise immunity...
  • Page 33 Name Description NOT CONNECTED NOT CONNECTED Receive Data- NOT CONNECTED NOT CONNECTED 2.1.4.5 Parameter settings for EtherCAT network connection To use MV810-ECAT02 to operate the MV800 series drive, you need to set the operation command channel and frequency source to the bus communication card, as shown in the following table. Table 2-8 Parameter settings for MV810-ECAT02 communication Drive parameter Value...
  • Page 34 Table 2-9 Description of LED on the PCBA of the expansion box Status Description Action Steady on Normal power supply for the ECAT option No need for actions LED1 (Red) Check whether the ECAT option is No power supply for the ECAT option properly connected to the drive Check whether the ECAT option is The state machine is in the Init state...

  • Page 35: Mv810-Io01: Simple Io Option

    2.1.4.8 Installation Accessory list Accessory list Specifications Quantity MV810-ECAT02 75 × 60 × 24 mm User manual A4 × 1 For installation, refer to “2.1.1 Installation of accessory cards/options” for details. 2.1.5 MV810-IO01: simple IO option 2.1.5.1 Product appearance Fig. 2-12 Components and terminals 2.1.5.2 Technical specifications Name Terminal Mark...

  • Page 36: Mv810-Pg01: Simple Incremental Abz Encoder Card

    For installation, refer to “2.1.1 Installation of accessory cards/options” for details. 2.1.6 MV810-PG01: simple incremental ABZ encoder card MV820 supports simple incremental PG card expansions, and you should pay attention to the drive model you ordered; and also, you can order expansion cards individually.
  • Page 37 2.1.6.3 Terminal description The following figure shows the marks of terminals on the MV810-PG01 speed measurement card. Fig. 2-14 Terminal mark Table 2-11 lists the pin definition of terminals on the MV810-PG01 speed measurement card. Table 2-11 PG01 terminal functions Type Mark Name...

  • Page 38: Other Accessories

    A4 × 1 For installation, refer to “2.1.1 Installation of accessory cards/options” for details. Other accessories MV820 also has other accessories, including components for protection, installation and maintenance, remote LED and LCD keypads, as shown below: 2.2.1 Dustproof kit MV810-FHJ is a dustproof kit which consists of four covers, large or small, packaged as a whole. It can keep out dust, oil mist and particles in harsh environments.
  • Page 39 Mounting 固定板 plate Mounting Drive 变频器 安装支架 bracket Mount the bracket Mount the drive Hole dimensions 安装支架 安装整机 开孔尺寸 Fig. 2-17 MV810-EMBB embedded mounting bracket kit Drive component 变频器组件 Through-wall mounting plate Self-tapping 穿墙安装底板 Left bracket screw Right bracket 左安装支架 自攻螺钉...

  • Page 40: Reinforced Metal Bottom Plate

    2.2.3 Reinforced metal bottom plate MV810-METB, MV810-METC and MV810-METD are reinforced metal bottom plates corresponding to enclosures of B, C and D. They can reinforce the drive in corrosive environments with high temperature and oil mist. They can be installed through the countersunk head screws included in the accessory package, as shown in the following figure (marked in green).

  • Page 41: Keypad/Operating Panel Mounting Base

    Fig. 2-22 Guide rail bracket 2.2.6 Keypad/Operating panel mounting base Model: MV820-JPT, used to install the remote keypad/operating panel to the cabinet door, as shown in the following figure: Fig. 2-23 Keypad mounting base Fig. 2-24 Mounting dimensions of operating panel fixed base...

  • Page 42: Remote Led Keypad/Operating Panel (With Shuttle)

    2.2.7 Remote LED keypad/operating panel (with shuttle) MV820-DP01, remote LED operating panel, removable, supporting external use, with the shuttle button, parameter copy function (refer to P00.07) and IP23 protection. Fig. 2-25 Remote LED keypad/Operating panel The remote LED keypad/operating panel can be fixed to the cabinet door/plate through a mounting base (see 2.2.6 for details);...

  • Page 43: Remote Lcd Keypad/Operating Panel (In Development)

    2.2.8 Remote LCD keypad/operating panel (in development) MV820 remote LCD panel, IP23 protection. Fig. 2-27 Remote LCD operating panel 2.2.9 Braking unit (see Appendix 2) The series offers built-in braking units for drives of 75 kW or below. You can select the recommended braking resistors...

  • Page 44: Chapter 3 Drive Installation

    Chapter 3 Drive Installation Assembly/Disassembly of drive components Press down 下压 下 推 上 推 1: Cover 2: Operating panel 3: Dustproof plate 4: Expansion box Fig. 3-1 Assembly and disassembly of drive components (taking enclosure C as an example) (1) Assembly/Disassembly of the cover Disassembly: Press down the granulated part of the cover slightly inwards, then pull it downwards until the snap-fit joints of the cover are separated from the drive to remove the cover.

  • Page 45: Installation Environment

    The specific gap distance is shown in Fig. 3-2. Fig. 3-2 Gap distance for vertical installation Besides the installation through screws, MV820 Size A/B also support installation through a guide rail (needs to operate with a guide rail bracket, referring to 2.2.5), as shown in Fig. 3-3.
  • Page 46 Fig. 3-3 Guide rail installation If two or more drives are installed closely up and down, for better heat dissipation, it is recommended to use a baffle plate to redirect the flow, preventing the lower drive from affecting the upper drive, as shown in Fig. 3-4. Fig.

  • Page 47: Chapter 4 Drive Wiring

    Chapter 4 Drive Wiring This chapter explains the wiring and related precautions.  Ensure that the drive’s power supply is completely cut off and wait for at least 10 minutes before you open the cover of the drive.  Ensure that the panel indicator (5-digit LED) of the drive is off and the voltage between + and – of the main circuit is below 36 V DC before you start to wire.
  • Page 48 Recommended pipe-type terminal diameters of the drive using Euroblock are shown in the following table: Table 4-2 Recommended pipe-type terminal diameter Control circuit Recommended pipe-type terminal diameter Main circuit (mm ф (mm) MV820 models Control Output Control Input cable Output cable...
  • Page 49 Control circuit Recommended pipe-type terminal diameter Main circuit (mm ф (mm) MV820 models Control Output Control Input cable Output cable Input cable terminal cable cable terminal cable MV820G1-2D0.75B 1.5/1.0 2.0/1.7 MV820G1-2D1.5B 2.5/1.5 2.6/2.0 MV820G1-2D2.2B 4/2.5 3.2/2.6 MV820G1-4T0.4B MV820G1-4T0.75B MV820G1-4T1.5B MV820G1-2T2.2B MV820G1-4T2.2B...

  • Page 50: Main Circuit Terminal Wiring And Description

    Main circuit terminal wiring and description 4.1.1 Main circuit input and output terminal types The main circuit terminals can be divided into four types depending on the enclosure models and drive models. (1) Terminal type 1 Enclosure type: Enclosure B (applicable power: 2S0.4 to 2.2) Enclosure B (applicable power: 2D0.4 to 2.2) Enclosure B (applicable power: 2T2.2;...
  • Page 51 Terminal name Function description Three-phase 380 V AC or three-phase 220 V AC L1, L2, L3 input terminals +, BR Connect the external braking resistor terminals +, - DC bus terminals U, V, W Three-phase AC output terminals PE connection terminal, screws used to fix the wire fixation bracket (3) Terminal type 3 Enclosure type: Enclosure E (applicable power: 4T18.5/22)
  • Page 52 Terminal name Function description Three-phase 380 V AC or three-phase 220 V AC L1, L2, L3 input terminals +, BR Connect the external braking resistor terminals +, - DC bus terminals U, V, W Three-phase AC output terminals PE connection terminal, screws used to fix the wire fixation bracket (1) For common DC bus applications, the positive and negative poles of the DC input should be connected to + and - separately to achieve power-on buffering of the internal DC bus capacitor of the drive.

  • Page 53: Connection Of Drive And Accessories

    4.1.2 Connection of drive and accessories Fig. 4-2 Connection of drive and accessories (taking three-phase models as the example) (1) A de-energizing device such as an isolation switch must be installed between the power grid and the drive to ensure personal safety during equipment maintenance.
  • Page 54 Table 4-3 Recommended fuse capacity and copper core insulated wire section Control circuit Input line protection Main circuit (mm MV820 models Control terminal Fuse (A) Input cable Output cable cable MV820G1-2S0.4B MV820G1-2S0.75B MV820G1-2S1.5B MV820G1-2S2.2B MV820G1-2D0.4B 1.0/0.75 MV820G1-2D0.75B 1.5/1.0 MV820G1-2D1.5B 2.5/1.5 MV820G1-2D2.2B...
  • Page 55 Control circuit Input line protection Main circuit (mm MV820 models Control terminal Fuse (A) Input cable Output cable cable MV820G1-4T18.5B MV820G1-4T22B MV820G1-4T30B MV820G1-4T37B Note: The parameter values in the table are for recommendation. (3) When the contactor is used for power supply control, do not use the contactor to control power on/off of the drive.
  • Page 56 Table 4-4 Cross sectional area of protective conductors Cross sectional area S (mm ) of phase Minimum cross sectional area Sp (mm ) of conductors protective conductors S ≤ 16 16 ＜ S ≤ 35 35 ＜ S The input/output EMI filter should be installed close to the drive.

  • Page 57: Basic Operation Wiring

    4.1.3 Basic operation wiring Fig. 4-3 Basic wiring diagram 1...

  • Page 58: Control Circuit Terminal Wiring And Description

    Notes: (1) The GND terminal should be connected to the 0 V of an external device. (2) AI1 and AI2 can be set to input voltage signals or current signals through the function codes P09.01 and P09.02. (3) AO1 can be set to output voltage signals or current signals through the function code P09.02. (4) If external braking components are required, an external braking resistor should be connected.
  • Page 59 Type Mark Name Function description Specifications Permissible maximum output current 200 +24 V power +24 V reference power mA (the total current with all digital supply output outputs included) +10 V power +10 V reference power Permissible maximum output current 10 Power supply supply output...
  • Page 60 Type Mark Name Function description Specifications Provides analog voltage/current output, with 28 kinds available. You can Output voltage: 0 to 10 V, ±5% Analog output Analog output choose voltage or current Output current: 0 to 20 mA analog output through the function code P09.02 (reference ground: GND).
  • Page 61 Type Mark Name Function description Specifications The terminal can only be used as digital Multi-function input DI7, and cannot be defined for other signal functions through function codes. The terminal can be used as digital input Multi-function DI8 or analog input AI1 through the function code P09.01.
  • Page 62 “ ”. If the customer orders the closed-loop MV820 drive, a PG card is provided as the standard configuration. The terminal functions of the PG card are shown in Table 4-6. Table 4-6 Terminal functions of PG card...
  • Page 63 4.2.2.1 Analog input terminal wiring (1) Terminal 16 receives the single-ended input of analog voltage or current. The voltage or current input type can be selected through the thousands place of P09.01. The wiring method is shown in Fig. 4-5: Fig.
  • Page 64 Fig. 4-7 Terminal 13 voltage single-ended input wiring Fig. 4-8 Terminal 13 current single-ended input wiring 4.2.2.2 Analog output terminal wiring Analog output terminal AO1 is connected to an external analog meter to indicate a variety of physical quantities. Voltage or current analog output can be selected through P09.02. The terminal wiring method is shown in Fig. 4-9: Fig.
  • Page 65 4.2.2.3 Communication interface wiring MV820 drive provides the RS485 serial communication interface for users. Through the following wiring methods, a control system of single host/single slave or single host/multiple slaves can be created. With the host device (PC or PLC controller) software, multiple functions can be realized such as real-time monitoring, remote control, auto control and complicated running control (for example, infinite multi-stage PLC running).
  • Page 66 4.2.2.4 Multi-function input terminal wiring MV820 multi-function input terminals include 4, 5, 6, 7, 8, 10, 12, 16, which can be defined as digital inputs DI1–DI18 through the function codes P09.00 and P09.01. Besides, there are multiple ways of wiring according to the terminal...
  • Page 67 (1) P09.11=0 (set digital terminal open circuit voltage to 0 V) ① Dry contact mode, shown in Fig. 4-13. Fig. 4-13 Wiring diagram when the internal +24 V power supply of the drive is used ② When the internal power supply of the drive is used and the external controller is the PNP common emitter output, the wiring is shown in Fig.
  • Page 68 ③ When the external power supply is used and the external controller is the PNP common emitter output, the wiring is shown in Fig. 4-15. Fig. 4-15 Wiring diagram with PNP and using the external power supply (2) P09.11=1 (set digital terminal open circuit voltage to 24 V) ①...
  • Page 69 4.2.2.5 Multi-function output terminal wiring The multi-function output terminals 4 (DO1), 5 (DO2) and 11 (DO3) can use the internal +24 V power supply of the drive (load no more than 200 mA). The wiring is shown in Fig. 4-18. Warning: The inductive load (such as a relay) must be anti-parallel with the fly-wheel diode.
  • Page 70 (4) During wiring, the control cables shall be kept away from the main circuit and the strong current lines (including the power cable, motor cable, relay cable, contactor connection cable, etc.) for at least 20 cm, and they shall not be laid in a parallel way.

  • Page 71: Drawing Of Control Board

    (3) When the PG output signal is a differential signal, the wiring with the interface board is as shown in Fig. 4-22: Fig. 4-22 Wiring diagram for differential signal PG 4.2.3 Drawing of control board Fig. 4-23 Drawing of control board...

  • Page 72: Installation Instructions For Emc Requirements

    Installation instructions for EMC requirements Noise is inevitably made during drive operation, which deviates from the EMC requirements. To reduce the interference of the drive to the ambient environment, this section explains the EMC oriented installation method in terms of noise suppression, field wiring, grounding, leakage current, use of power filter and so on.
  • Page 73 4.3.1.2 Noise transmission path Fig. 4-25 Noise transmission path 4.3.1.3 Basic measures for noise suppression Table 4-7 Measures for noise suppression Noise transmission Measures to reduce influence path If the external devices form a closed loop through the drive wiring, the leakage current of the grounding cable may cause misoperation of relevant devices.

  • Page 74: Field Wiring Requirements

    Noise transmission Measures to reduce influence path (1) Devices and signal cables vulnerable to noise should be installed away from the drive. The signal cables should be shielded, with the shield layer grounded. Besides, the shielded cable shall be put into a metal tube, and placed away from the drive and its input/output cables.
  • Page 75 Fig. 4-26 System wiring requirements If the motor cable is too long or its cross sectional area is too large, derating is required. The larger the cross sectional area is, the larger the ground capacitance and ground leakage current will be. If the cable with larger cross sectional area is used, the output current should be reduced by about 5% for each level of area increase.

  • Page 76: Grounding

    4.3.3 Grounding Dedicated grounding pole (the best) Fig. 4-29 Grounding diagram 1 Shared grounding pole (acceptable) Fig. 4-30 Grounding diagram 2 Shared grounding cable (unacceptable) Fig. 4-31 Grounding diagram 3 Fig. 4-32 Grounding diagram 4...

  • Page 77: Installation Of Relay, Contactor And Electromagnetic Brake

    In addition, pay attention to the following notes:  To minimize the impedance of different grounding systems, the standard grounding cable of largest size shall be adopted. The flat cable is preferred, because the high-frequency impedance is smaller than the round cable of the same cross sectional area.

  • Page 78: Leakage Current And Measures

    4.3.5 Leakage current and measures The leakage current passes the line capacitor and motor capacitor at the input and output ends of the drive. Its magnitude depends on the distributed capacitance and carrier frequency. The leakage current includes the grounding leakage current and line-to-line leakage current.

  • Page 79: Proper Emc Installation Of Drive

    (2) Line-to-line leakage current When the leakage current passes the distributed capacitance among output cables at the output end of the drive, its high-order harmonics may cause misoperation of the external thermal relay. For the drive with small capacity (7.5 kW and below) and long wires (over 50 m), the leakage current will increase, which makes misoperation more likely to happen.
  • Page 80 Fig. 4-36 Recommended partition for drive EMC installation Notes: Area Ⅰ: the control power transformer, control system, sensor, etc. Area Ⅱ: the interface for the signal and control cables, requiring certain degree of anti-interference. Area Ⅲ: the incoming reactor, drive, braking unit, contactor and other noise source. Area Ⅳ: the output noise filter and its wiring.
  • Page 81 Electrical installation diagram for the drive Fig. 4-37 Installation diagram for the drive The grounding cable of the motor shall be grounded at the drive side. The motor and the drive shall be separately grounded. The motor cable and control cable should be shielded or armored. The shielding metal mesh shall be connected to both ends of the grounding cable through cable clamps to avoid the twisting of the ends of the metal mesh.

  • Page 82: Operating Instructions For Power Filter

    4.3.7 Operating instructions for power filter A power filter shall be used for the device generating strong interference and sensitive to external interference. The power line filter is a two-way low-pass filter, which allows DC or 50 Hz industrial frequency current to pass, and does not allow the high-frequency electromagnetic interference current to pass.
  • Page 83 If the drive and other control devices are installed in the same cabinet, isolate each special area and conduct proper wiring, shielding and line crossing by taking into account of the partition principles above mentioned.

  • Page 84: Chapter 5 Quick Operation Guide For Drive

    Chapter 5 Quick Operation Guide for Drive Operating panel 5.1.1 Introduction Fig. 5-1 Operating panel 5.1.1.1 LED description Table 5-1 LED description Name Description Color Flashing: The current parameter is the running frequency Frequency LED Yellow On: The current parameter is the frequency reference Current LED On: The current parameter is the current...
  • Page 85 Name Description Color During stop, there is a forward running command for the drive Forward running LED Green During running, the drive is running forward Flashing: The drive is switching from FWD to REV During stop, there is a reverse running command for the drive Reverse running LED Green...
  • Page 86 5.1.1.3 Status display of operating panel The display status of the MV820 operating panel includes stop status parameter display, run status parameter display, function code parameter editing status display and fault status display. (1) Stop parameter display status When the drive is in stop, the operating panel displays the stop status parameters, as shown in Fig.
  • Page 87 When you choose the verification menu, only the function codes whose parameter values are different from factory settings will be displayed. You can rotate “ ” to browse all such function codes, and check which parameters have been changed. You can press the “ ”...

  • Page 88: Identification Of Led Display Symbols

    (3) Fault display status When the drive detects a fault signal, it will immediately enter the fault display status and display the fault code, as shown in Fig. 5-2c. You can press the “ ” key to view stop parameters and fault codes cyclically. Through the “ ”...

  • Page 89: Basic Operations

    LED panel display example: LED panel display Unit LED Displayed data/code Meaning of data/code Solid on Flashing Frequency reference Flashing Solid on Output frequency Solid on Flashing Bus voltage Solid on Solid on Bus voltage Overcurrent during Solid on Solid on acceleration When the drive is in the stop or standby state, the panel value is flashing;...
  • Page 90 (1) Press the “ ” key in the locked status, and then the LED will enter the password verification status 00000; (2) Change 00000 to 01368; (3) Press the “ ” key to confirm and pass the password verification, then the LED displays P00. The above steps are shown in Fig.
  • Page 91 5.1.3.3 Set frequency For example, set P02.09=25.00 Hz. Example: Change the function code P02.09 from 50.00 Hz to 25.00 Hz. (1) In the stop parameter display status, press the “ ” key to enter the first level menu P00; (2) Rotate “ ”...

  • Page 92: Operation Mode

    Fig. 5-6 Monitoring status parameter display 5.1.3.5 Switching status parameter display Through the function codes P16.03 and P16.04, you can choose the drive parameters to be displayed on the operating panel during stop, such as set frequency, bus voltage DI, DO, AI and so on (for details, refer to Group P16). Then, you can view the chosen parameters through the “...

  • Page 93: Operation Status

    5.2.2 Operation status The operating states of MV820 include the stop status, running status and motor parameter auto-tuning status. (1) Stop status: if there is no operation command after the drive is started and initialized, or the stop command is executed during operation, the drive will enter the stop status immediately.

  • Page 94: Drive Frequency And Torque Channel

    (1) Frequency reference channel under the speed control mode There are five running modes for the MV820 speed control mode, including jog running, process closed-loop running, PLC running, multi-speed running and common running. The running mode is selected through the P02.05 channel. The priority is shown in Fig.

  • Page 95: Initial Power-On

    For the specific frequency reference channels of the running modes under speed control, refer to Chapter 7 Parameter Description. (2) Torque reference channel under the torque control mode There are six torque reference channels for the MV820 torque control mode, including: ① Digital setting; ② AI1 analog reference ③...

  • Page 96: Initial Power-On Operation

    5.3.2 Initial power-on operation When the drive passes the wiring and power supply inspection, turn on the air switch of the AC power supply at the drive input side to supply power for the drive. The operating panel will first display “- - - - -”, and the contactor will be normally engaged.

  • Page 97: Chapter 6 Parameter List

    Chapter 6 Parameter List Explanation of terms related to function codes Table field Explanation Function code number Represents the number of the function code, such as P00.00 Function code name Represents the name of the function code, explaining its function Default value Represents the factory settings of function codes Value range...
  • Page 98 Function Default Name Description Value range Change code value displayed. 2: Changed memory menu mode Only parameters that are different from factory settings are displayed. 0: No password P00.01 User password 0 to 65535 ○ Others: Password protection P00.02 Reserved 0: All data can be changed.
  • Page 99 Function Default Name Description Value range Change code value 2: Restore to factory settings 3: Restore some parameters to factory settings (motor parameters not restored) 0: Disabled Power board P00.06 0 to 1 × upgrading command 1: Enabled 0: No operation 1: Drive’s parameters uploaded to the keypad 2: Keypad’s parameters downloaded...
  • Page 100 Function Default Name Description Value range Change code value P01.07 Output current Displays the output current. 0.0 to 6553.5 A Displays the drive’s current torque P01.08 Torque current current as a percentage of the -300.0 to 300.0% motor’s rated current. Displays the drive’s current exciting P01.09 Exciting current...
  • Page 101 Function Default Name Description Value range Change code value Bit7: Tuning Bit8: Overcurrent limited Bit9: Bus overvoltage limited Bit10: Torque limited Bit11: Speed reached (speed mode) / Speed limited (torque mode) Bit12: Drive in fault Bit13: Speed control Bit14: Torque control Bit15: Reserved 0: Invalid P01.18...
  • Page 102 Function Default Name Description Value range Change code value P01.31 PID deviation -100.0% to 100.0% -100.0% to 100.0% P01.32 PID output -100.0% to 100.0% -100.0% to 100.0% PID proportional P01.33 -100.0% to 100.0% -100.0% to 100.0% output P01.34 PID integral output -100.0% to 100.0% -100.0% to 100.0% P01.35...
  • Page 103 Function Default Name Description Value range Change code value Accumulated running P01.48 duration of the drive 0 to 65535 h 0 to 65535 h Current running P01.49 duration of the drive 0 to 65535 min 0 to 65535 min (min) Accumulated running P01.50 0 to 65535 h...
  • Page 104 Function Default Name Description Value range Change code value for asynchronous motors) 2: V/F control (only for asynchronous motors) 3: Closed-loop vector control 0: Motor 1 P02.01 Motor selection 0 to 1 × 1: Motor 2 0: Keypad control Operation command P02.02 1: Terminal control 0 to 2...
  • Page 105 Function Default Name Description Value range Change code value 8: Bus card 0: Digital setting P02.09 1: AI1 2: AI2 3: High-speed pulse HDI reference Auxiliary frequency 4: Simple PLC programming P02.06 0 to 8 × source selection reference 5: Multi-speed running reference 6: PID control 7: Modbus 8: Bus card...
  • Page 106 Function Default Name Description Value range Change code value Note: after being restored to default dependent values, the system will do auto matching based on the actual model (applicable for acceleration/deceleration time 1, 2, 3 and 4) 5.5 kW and below: 10 s 5.5 to 30 kW (included): 20 s Above 30 kW: 40 s Model...
  • Page 107 Function Default Name Description Value range Change code value Asynchronous motor Model P03.06 0.001 to 65.535 Ω 0.001 to 65.535 Ω × stator resistance dependent Asynchronous motor Model P03.07 0.001 to 65.535 Ω 0.001 to 65.535Ω × rotor resistance dependent 0.01 mH to 655.35 mH (drive power Asynchronous motor ≤...
  • Page 108 Function Default Name Description Value range Change code value Synchronous motor Model P03.16 0 to 1200 V 0 to 1200 V × rated voltage dependent Synchronous motor Model P03.17 0.8 to 6553.5 A 0.8 to 6553.5 A × rated current dependent Synchronous motor Model...
  • Page 109 Function Default Name Description Value range Change code value rotating status 3: Full parameter auto-tuning in the static status Motor overload P03.28 0.0 to 300.0% 0.0 to 300.0% 100.0% × protection factor 0: Disabled Motor overload P03.29 0 to 1 ×...
  • Page 110 Function Default Name Description Value range Change code value Synchronous P04.25 open-loop speed 0 to 1000 0 to 1000 ○ filter coefficient Synchronous P04.26 open-loop axis-D 0% to 100% 0 to 100 ○ injection current Synchronous open-loop P04.27 1.0 to 6.0 1.0 to 6.0 ○...
  • Page 111 Function Default Name Description Value range Change code value Slip compensation P05.06 50 to 200% 50 to 200% 100% ○ coefficient Speed loop filter time P05.07 0.00 to 20.00 s 0.00 to 20.00 s 0.02 s ○ constant Vector control P05.08 50 to 200% 50 to 200%...
  • Page 112 Function Default Name Description Value range Change code value Excitation regulation P05.14 0 to 60000 0 to 60000 1300 ○ P05.15 Torque regulation Kp 0 to 60000 0 to 60000 2000 ○ P05.16 Torque regulation Ki 0 to 60000 0 to 60000 1300 ○...
  • Page 113 Function Default Name Description Value range Change code value Torque reference P06.03 acceleration/ 0.0 to 6000.0 s 0.0 to 6000.0 s 6.0 s ○ deceleration time 0: Digital setting 1: AI1 2: AI2 FWD speed limit P06.04 0 to 5 ○...
  • Page 114 Function Default Name Description Value range Change code value 2: Square V/F 3: Reserved 4: V/F complete separation 5: V/F half separation P07.01 Torque boost 0.0 to 50.0 0.0 to 50.0 ○ Cut-off frequency of P07.02 0.00 Hz to P02.11 0.00 Hz to P02.11 10.00 Hz ×...
  • Page 115 Function Default Name Description Value range Change code value 0: Digital setting 1: AI1 2: AI2 3: Reserved 4: HDI Voltage source for P07.13 0 to 9 ○ V/F separation 5: Multi-reference 6: Simple PLC 7: PID 8: Modbus 9: PROFINET Digital setting of P07.14 voltage source for...
  • Page 116 Function Default Name Description Value range Change code value The device responds to the operation commands after the delay P08.01 Startup delay time 0.0 to 600.0 s × time. During the delay, the device is in standby. P08.02 Startup frequency 0.00 to 50.00 Hz 0.00 to 50.00 Hz 0.00...
  • Page 117 Function Default Name Description Value range Change code value 0.00 to P02.10 Start frequency of P08.11 0.00 to P02.10 (maximum frequency) (maximum 0.00 ○ braking at stop frequency) P08.12 Braking delay at stop 0.00 to 30.00 s 0.00 to 30.00 s 0.00 ○...
  • Page 118 Function Default Name Description Value range Change code value running duration exceeds the time set by P08.20, the drive automatically resumes operation. Recovery delay from P08.20 0.0 to 3600.0 s 0.0 to 3600.0 s ○ hibernation P08.21 Reserved P08.24 0: Disabled Restart selection P08.25 0 to 1...
  • Page 119 Function Default Name Description Value range Change code value Deceleration time for P08.33 0.0 to 60.0 s 0.0 to 60.0 s ○ emergency stop 0: Enable protection 1: Disable protection It decides, after a power-on or fault reset, whether the terminals need to Terminal running be enabled again before drive P08.34...
  • Page 120 Function Default Name Description Value range Change code value Ones: 0: Terminal 7 as DI5 1: Terminal 7 as thermosensitive signal input Tens: 0: Terminal 10 as DI6 1: Terminal 10 as HDI Function selection of P09.01 0 to 0x2011 ○...
  • Page 121 Function Default Name Description Value range Change code value 6: Multi-reference terminal 1 P09.08 DI6 function selection 0 to 72 ○ 7: Multi-reference terminal 2 P09.09 DI7 function selection 0 to 72 ○ 8: Multi-reference terminal 3 9: Multi-reference terminal 4 10: Acceleration/Deceleration time terminal 1 11: Acceleration/Deceleration time...
  • Page 122 Function Default Name Description Value range Change code value 30: PID clear 31: PID integral hold 32: Reserved 33: PID regulating feature switchover 34: Main reference frequency source selection 1 35: Main reference frequency source selection 2 36: Main reference frequency source selection 3 37: Reserved 38: Command channel switched to...
  • Page 123 Function Default Name Description Value range Change code value terminal 56: Safety terminal input (reserved） 57 to 59: Reserved 60: Emergency stop 61: Wobble pause 62: Wobble reset 63: Counter reset 64: Counter trigger 65: Power consumption clear 66: Power consumption hold 67: Length counter input 68: Length reset 69: Switched to V/F control...
  • Page 124 Function Default Name Description Value range Change code value 0: DI4 positive logic active 1: DI4 negative logic active Ones: 0: DI5 positive logic active 1: DI5 negative logic active Tens: 0: DI6 positive logic active 1: DI6 negative logic active DI5 to DI8 active P09.13 0 to 0×1111...
  • Page 125 Function Default Name Description Value range Change code value Stop Stop Forward Reverse 2: Three-wire mode 1 Three-wire operation control terminal EN is the enabling terminal, and the rising edges of FWD and REV are the source of running commands and directions. Command 0->1 Forward...
  • Page 126 Function Default Name Description Value range Change code value Stop Used to set the filter time for DI terminal sampling. It is P09.15 DI filter time recommended to increase the 0.000 to 1.000 0.010 s ○ parameter when there is strong interference to avoid misoperation.
  • Page 127 Function Default Name Description Value range Change code value DI4 switch-off delay P09.24 0.0 to 600.0 0.0 s ○ time P09.25 AI1 lower limit 0.00 V to P09.27 0.00 to P09.27 0.00 V ○ Percentage P09.26 corresponding to AI1 0.0% to 100.0% 0.0 to 100.0% 0.0% ○...
  • Page 128 Function Default Name Description Value range Change code value HDI frequency lower P09.39 0.000 kHz to P09.41 0.000 kHz to P09.41 0.000 kHz ○ limit Percentage P09.40 corresponding to HDI 0.0 to 100.0% 0.0 to 100.0% 0.0% ○ frequency lower limit HDI frequency upper P09.39 to 50.000 P09.41...
  • Page 129 Function Default Name Description Value range Change code value 16: Accumulated running duration reach 17: AC drive ready to run (RDY) 18: AC drive fault 19: Host device on/ff signal 20: Motor overheat 21: Torque limited Valid when torque command is limited by the torque limit value 1 or 22: Motor overload warning 23 to 25: Reserved...
  • Page 130 Function Default Name Description Value range Change code value Thousands: 0: RO1 positive logic active 1: RO1 negative logic active DO1 switch-on delay P10.05 0.0 to 600.0 0.0 s ○ time DO1 switch-off delay P10.06 0.0 to 600.0 0.0 s ○...
  • Page 131 Function Default Name Description Value range Change code value 6: Torque current (0 to 3*Iem) 7: Reserved 8: Output voltage (0 to 1.2*Ve) 9: Bus voltage (0 to 800 V) 10: AI1 after correction 11: AI2 after correction 12: Reserved 13: Output power (0 to 2*Pe) 14: Host device percentage (0 to 100.0%)
  • Page 132 Function Default Name Description Value range Change code value HDO1 output lower P10.21 0.00% to P10.23 0.00% to P10.23 0.00% ○ limit Frequency corresponding to P10.22 0.00 to 50.00 kHz 0.00 to 50.00 0.00 kHz ○ HDO1 output lower limit HDO1 output upper P10.23 P10.21 to 100.00%...
  • Page 133 Function Default Name Description Value range Change code value Model P11.01 Acceleration time 2 0.0 to 6000.0 s 0.0 to 6000.0 s ○ dependent Model P11.02 Deceleration time 2 0.0 to 6000.0 s 0.0 to 6000.0 s ○ dependent Model P11.03 Acceleration time 3 0.0 to 6000.0 s...
  • Page 134 Function Default Name Description Value range Change code value Switchover frequency of P11.09 acceleration/ 0.00 Hz to P02.10 0.00 Hz to P02.10 0.00 Hz ○ deceleration time 1 and 2 Jog operation P11.10 0.00 Hz to P02.10 0.00 Hz to P02.10 5.00 Hz ○...
  • Page 135 Function Default Name Description Value range Change code value 1: Retain P11.18 Skip frequency 1 If the reference frequency is within 0.00 Hz to P02.10 0.00 Hz ○ the skip frequency, the drive will Skip frequency 1 output according to the skip P11.19 0.00 Hz to P02.10 0.00 Hz...
  • Page 136 Function Default Name Description Value range Change code value FDT1 frequency P11.27 0.00 Hz to P02.11 0.00 Hz ○ detection value When the running frequency is higher than P11.27 or P11.29, the FDT1 frequency multi-function DO terminal outputs P11.28 0.0 to 100.0% 0.0% ○...
  • Page 137 Function Default Name Description Value range Change code value When the frequency reference is lower than P11.42, the drive Hibernation P11.42 decelerates to stop and enters the 0.00 Hz to P02.10 0.00 Hz ○ frequency hibernation state after the delay defined by P11.43.
  • Page 138 Function Default Name Description Value range Change code value LED ones: PLC running mode 0: Stop after running for one cycle 1: Keep final values after running for one cycle 2: Repeat after running for one cycle LED tens: Startup mode 0: Run from the first stage 1: Continue to run from the retained stage and frequency upon a stop or...
  • Page 139 Function Default Name Description Value range Change code value Multi-speed P13.07 -100.0 to 100.0% ○ reference 6 Multi-speed P13.08 -100.0 to 100.0% ○ reference 7 Multi-speed P13.09 -100.0 to 100.0% ○ reference 8 Multi-speed P13.10 -100.0 to 100.0% ○ reference 9 Multi-speed P13.11 -100.0 to 100.0%...
  • Page 140 Function Default Name Description Value range Change code value Multi-speed P13.20 reference 3 running 0.0 to 6553.5 s (min) ○ time Multi-speed P13.21 reference 4 running 0.0 to 6553.5 s (min) ○ time Multi-speed P13.22 reference 5 running 0.0 to 6553.5 s (min) ○...
  • Page 141 Function Default Name Description Value range Change code value Multi-speed P13.31 reference 14 running 0.0 to 6553.5 s (min) ○ time Multi-speed P13.32 reference 15 running 0.0 to 6553.5 s (min) ○ time Acc/ Acc/ Acc/ Acc/ time time time time Ones Acceleration/...
  • Page 142 Function Default Name Description Value range Change code value Acc/ Acc/ Acc/ Acc/ time time time time Ones Acceleration/ Deceleration time of P13.35 Tens 0 to 0x3333 0x0000 ○ simple PLC reference 8 to 11 Hund reds Thou sand Acc/ Acc/ Acc/ Acc/...
  • Page 143 Function Default Name Description Value range Change code value 6: PROFINET 0: AI1 1: AI2 2: Reserved 3: HDI 4: Modbus P14.01 PID feedback source 0 to 9 ○ 5: PROFINET 6: AI1+AI2 7: AI1-AI2 8: MIN (AI1，AI2) 9: MAX (AI1，AI2) P14.02 PID digital setting -100.0% to 100.0%...
  • Page 144 Function Default Name Description Value range Change code value when it is greater than the high-frequency switchover point, the PID parameter is P14.13 to P14.15; when it is between the low-frequency and high-frequency switchover points, the PID parameter is the linear interpolation of these two group parameters.
  • Page 145 Function Default Name Description Value range Change code value frequency reaches the upper/lower limit P14.20 PID preset value 0.0 to 100.0% 0.0 to 100.0% 0.0% ○ PID preset value hold P14.21 0.00 to 650.00 s 0.00 to 650.00 s 0.0 s ○...
  • Page 146 Function Default Name Description Value range Change code value 0: 1-8-2-N format 1: 1-8-1-E format 2: 1-8-1-O format 3: 1-8-1-N format 0: 4800 BPS 1: 9600 BPS 2: 19200 BPS P15.01 Baud rate 3: 38400 BPS 0 to 6 ○ 4: 57600 BPS 5: 115200 BPS 6: 125000 BPS...
  • Page 147 Function Default Name Description Value range Change code value function codes, it is sure to have response. Reserved function 2 P15.06 0 to 65535 0 to 65535 ○ for user P16: Keypad display setting parameters 0: No display; 1: Display Used to set whether a parameter displays on the zero level of the keypad menu during running.
  • Page 148 Function Default Name Description Value range Change code value keypad menu during running. The related bits are listed below: 0: Bus voltage 1: Drive running status 2: DI1 to DI4 state 3: DI5 to DI8 state 4: DO state 5: AI1 voltage 6: AI2 voltage 7: AI1 current 8: AI2 current...
  • Page 149 Function Default Name Description Value range Change code value keypad menu at stop. Bit0 to bit15 correspond to 16 parameters listed in P16.04. Note: If all is set to 0, the reference frequency will be displayed. Used to set the default parameter number displayed on the zero level of the keypad menu at stop after power-on.
  • Page 150 Function Default Name Description Value range Change code value 0.1 to 999.9% Rotation speed Mechanical rotation speed=60× P16.06 0.1 to 999.9% 100.0% ○ display coefficient displayed running frequency× P16.06/number of motor pole pairs 0.0 to 100.0% Frequency display P16.07 0.0 to 100.0% 100.0% ○...
  • Page 151 Function Default Name Description Value range Change code value Function data 2 P18.11 0 to 65535 0 to 65535 value Function data 3 P18.12 0 to 0xFFFF 0 to 0xFFFF 0x1004 ○ address Function data 3 P18.13 0 to 65535 0 to 65535 value Function data 4...
  • Page 152 Function Default Name Description Value range Change code value 0.01 mH to 655.35 mH (drive power Asynchronous motor ≤ 55 kW) Model P20.08 leakage inductive Model dependent × dependent 0.001 mH to 65.535 mH (drive reactance power > 55 kW) 0.1 mH to 6553.5 mH (drive power ≤...
  • Page 153 Function Default Name Description Value range Change code value Synchronous motor Model P20.18 0.01 Hz to P02.10 0.01 Hz to P02.10 × rated frequency dependent Number of P20.19 synchronous motor 1 to 128 1 to 128 × pole pairs 0.001 to 65.535 Ω (drive power ≤ 55kW) Synchronous motor Model...
  • Page 154 Function Default Name Description Value range Change code value P21: Motor 2 encoder parameters P21.00 Encoder PPR 1 to 65535 1 to 65535 1024 × P21.01 Encoder type 0: ABZ incremental encoder × 0: Forward A/B phase sequence 1: Reverse P21.02 of ABZ incremental 0 to 1...
  • Page 155 Function Default Name Description Value range Change code value Slip compensation P22.06 50 to 200% 50 to 200% 100% ○ coefficient Speed loop filter time P22.07 0.00 to 20.00 s 0.00 to 20.00 s 0.50 s ○ constant Vector control P22.08 50 to 200% 50 to 200%...
  • Page 156 Function Default Name Description Value range Change code value Excitation regulation P22.14 0 to 60000 0 to 60000 1300 ○ P22.15 Torque regulation Kp 0 to 60000 0 to 60000 2000 ○ P22.16 Torque regulation Ki 0 to 60000 0 to 60000 1300 ○...
  • Page 157 Function Default Name Description Value range Change code value Torque reference P23.03 acceleration/ 0.0 to 6000.0 s 0.0 to 6000.0 s 6.0 s ○ deceleration time 0: Digital setting 1: AI1 2: AI2 FWD speed limit P23.04 0 to 5 ○...
  • Page 158 Function Default Name Description Value range Change code value P24.01 Torque boost 0.0 to 50.0 0.0 to 50.0 ○ Cut-off frequency of P24.02 0.00 Hz to P02.11 0.00 Hz to P02.11 10.00 Hz × torque boost Multi-point V/F P24.03 0.00 Hz to P24.05 0.00 Hz to P24.05 0.00 Hz ×...
  • Page 159 Function Default Name Description Value range Change code value 5: Multi-reference 6: Simple PLC 7: PID 8: Modbus 9: PROFINET Digital setting of P24.14 voltage source for 0 to 1000 V 0 to 1000 V ○ V/F separation Voltage rise time of P24.15 0.0 to 6000.0 s 0.0 to 6000.0 s...
  • Page 160 Function Default Name Description Value range Change code value Commissioning P26.05 0 to 65535 0 to 65535 ○ parameter 6 Commissioning P26.06 0 to 65535 0 to 65535 ○ parameter 7 Commissioning P26.07 0 to 65535 0 to 65535 ○ parameter 8 Commissioning P26.08...
  • Page 161 Function Default Name Description Value range Change code value Commissioning P26.19 0 to 65535 0 to 65535 ○ parameter 20 Commissioning P26.20 0 to 65535 0 to 65535 ○ parameter 21 Commissioning P26.21 0 to 65535 0 to 65535 ○ parameter 22 Commissioning P26.22...
  • Page 162 Function Default Name Description Value range Change code value 0.0 to 10.0 s Detection time for P40.01 0.0 to 10.0 0.0 s ○ options 0 indicates no timeout detection P40.02 Reserved P40.33 P41: IO option parameters P41.00 DI9 function selection 0: No function 0 to 72 ○...
  • Page 163 Function Default Name Description Value range Change code value 21: Frequency reference source switchover from combination to A 22: External reset (RESET) input 23: Coast to stop input (FRS) 24: Acceleration/Deceleration inhibition 25: DC braking input at stop 26: Simple PLC pause command 27: Frequency reference source switchover from combination to B 28: PLC stop memory clear...
  • Page 164 Function Default Name Description Value range Change code value 44: External stop command (it is valid for all control modes, and the device will be stopped according to the current stop mode) 45: Auxiliary reference frequency clear 46: Reserved 47: Speed control and torque control switchover terminal 48: Torque direction switchover terminal in torque control...
  • Page 165 Function Default Name Description Value range Change code value Ones: 0: DI9 positive logic active 1: DI9 negative logic active Tens: 0: DI10 positive logic active DI9 to DI11 active P41.04 0 to 0x111 ○ mode 1: DI10 negative logic active Hundreds: 0: DI11 positive logic active 1: DI11 negative logic active...
  • Page 166 Function Default Name Description Value range Change code value 1: AC drive in running 2: Forward running 3: Reverse running 4: Frequency reach signal (FAR) 5: Frequency-level detection signal (FDT1) 6: Frequency-level detection signal (FDT2) 7: Overload detection signal (OL) 8: Lockout for undervoltage (LU) 9: External fault stop (EXT) 10: Frequency upper limit (FHL)
  • Page 167 Function Default Name Description Value range Change code value 28: Length reach 29 to 37: Reserved 38: Motor 1 and 2 indication terminal 39: Bus card switch signal 40 to 45: Reserved 46: PID feedback loss 47: Reserved Ones: 0: RO2 positive logic active 1: RO2 negative logic active Tens: Output terminal...
  • Page 168 Function Default Name Description Value range Change code value 0.0 to 60.0 s PROFINET P43.00 communication 0.0 to 60.0 0.0 s ○ Note: No communication timeout timeout time detection when set to 0.0 0: Standard message 1 1: Customized message 1 Note: Only the customized message 1 supports parameter read and PROFINET message...
  • Page 169 Function Default Name Description Value range Change code value 10: AO1 output reference (0.00 to 100.00%) 11: HDO1 output reference (0.00 to 100.00%) 12: HDO2 output reference (0.00 to 100.00%) 13: PID reference (0.0 to 100.0%) 14: PID feedback (0.0 to 100.0%) 15 to 30: Reserved P43.13 PZD2 feedback...
  • Page 170 Function Default Name Description Value range Change code value 20: HDO1 output (0 to 50.000 kHz) 21: HDO2 output (0 to 50.000 kHz) 22: PID reference (-100.0% to 100.0%) 23: PID feedback (-100.0% to 100.0%) 24: PID deviation (-100.0% to 100.0%) 25: PID output (-100.0% to 100.0%) 26 to 30: Reserved P43.24...
  • Page 171 Function Default Name Description Value range Change code value current limiting) protection disabled 1: Pulse-by-pulse current limit (fast current limiting) protection enabled Tens: 0: Fan fault disabled 1: Fan fault enabled Hundreds: 0: Overload prewarning disabled 1: Overload prewarning enabled Thousands: 0: Braking overcurrent disabled 1: Braking overcurrent enabled...
  • Page 172 Function Default Name Description Value range Change code value Overvoltage stall P97.04 suppression action 600 to 750 V 600 to 750 V 720 V ○ voltage Voltage regulator Defines the proportional coefficient proportional P97.05 of the bus voltage regulator upon 0 to 1000 ○...
  • Page 173 Function Default Name Description Value range Change code value Ones: 0: Input phase loss protection disabled 1: Input phase loss protection enabled Tens: 0: Output phase loss protection disabled during running 1: Output phase loss protection enabled during running Phase loss protection P97.14 0 to 0x1111 ○...
  • Page 174 Function Default Name Description Value range Change code value Tens: Reserved Hundreds: Reserved Thousands: 485 communication error 0: Coast to stop 1: Decelerate to stop 2: Keep running Fault protection and P97.17 Ones: Fan locked-rotor 0 to 0x222 0x0002 ○ alarm property 3 Tens: Motor overload Hundreds: Motor overheat...
  • Page 175 Function Default Name Description Value range Change code value Detection time of When it is set to 0.0 s, speed P97.28 excessive speed 0.0 to 10.0 s 1.0 s ○ deviation protection is disabled. deviation When there are faults, the drive starts to reset according to the interval defined by P97.31.
  • Page 176 Function Default Name Description Value range Change code value 8: Input phase loss (SPI) 9: Output phase loss (SPO) 10: Power module protection (drv) 11: Inverter overheat (OH1) 12: Rectifier bridge overheat (OH2) 13: AC drive overload (OL1) 14: Motor overload (OL2) 15: External fault (EF) 16: EEPROM read/write fault (EEP) 17: 485 communication error (CE)
  • Page 177 Function Default Name Description Value range Change code value 47: Reserved 48: BootLoader failure (bLt) 49: Power board software version mismatching (vEr) 50: Parameter upload and download timeout (UPdnE) 51: AI1 current input overcurrent (AIOC) 52: Reserved 53: FAN locked-rotor (FAn) 54: Pre-overload (POL1) 55: IO option 24 V overload (IO-OL) Bus voltage upon the...
  • Page 178 Function Default Name Description Value range Change code value Running duration P97.43 upon the current 0.0 to 6553.5 s 0.0 to 6553.5 s 0.0 s fault Bus voltage upon the P97.44 0.0 to 6553.5 V 0.0 to 6553.5 V 0.0 V latest fault Actual current upon P97.45...
  • Page 179 Function Default Name Description Value range Change code value AC drive status upon P97.56 the second latest 0 to 0xFFFF 0 to 0xFFFF fault Inverter bridge temperature upon P97.57 0.0 to 150.0℃ 0.0 to 150.0℃ 0.0℃ the second latest fault P97.58 Reserved Input terminal state...
  • Page 180 Function Default Name Description Value range Change code value 0 to 999 V Model P98.05 Rate voltage 0 to 999 V (automatically set according to the dependent model) 0 to 999.9A Model P98.06 Rated current 0 to 999.9 A (automatically set according to the dependent model) Manufacturer’s bar...

  • Page 181: Chapter 7 Parameter Description

    Chapter 7 Parameter Description The parameter format is shown below: Function code Function name Value range Default value P00: System management parameters P00.00 Menu mode selection 0 to 2 0: Quick menu mode Only quick commissioning related parameters are displayed. These parameters can be changed to quickly start or stop the drive.
  • Page 182 same as setting a new password, however, you need to input 0000 twice. When the password is successfully cleared, “P.Clr” is displayed. Keep the user password properly. There is no user password by default. P00.02 Reserved P00.03 Parameter protection setting 0 to 2 This function code determines the protection level of drive parameters, including: 0: All data can be changed.
  • Page 183 Table 7-1 Keypad working mode Tens Function Description place Invalid when not in the The STOP key is valid only in the operating panel control channel. panel control mode The STOP key is valid in the panel, terminal and serial port operation command Stop according to the channels.

  • Page 184: P01: Status Display Parameters

    2: Restore to factory settings When it is set to 2, all parameters before P97.32 (excluding P00.01 user password, P01 drive status display parameters and P03+P20 motor parameters) will be restored to factory settings. 3: Restore some parameters to factory settings (motor parameters not restored) When it is set to 3, part of parameters will be restored to factory settings, excluding motor parameters.
  • Page 185 P01.03 Frequency reference 0.00 to P02.10 Monitors the final frequency after the combination of main frequency and auxiliary frequency. A positive value means forward running, and a negative value means reverse running. P01.04 Ramp reference frequency 0.00 to P02.10 Displays the current ramp reference frequency of the drive. P01.05 Output frequency 0.00 to P02.10...
  • Page 186 P01.16 Bus voltage 0.0 to 6553.5 V Displays the current bus voltage of the drive. P01.17 Operation status of the drive 0 to 0xFFFF Fig. 7-2 Operation status of the drive LED ones place Bit0: STOP/RUN When the drive is at stop, Bit0 is 0, otherwise, it is 1. LED ones place Bit1: FWD/REV When the drive is in FWD, Bit0 is 0, otherwise, it is 1.
  • Page 187 Fig. 7-4 DI terminal state Displays the on/off state of DI5 to DI8. “0” means the terminal is off, and “1” means the terminal is on. P01.20 DO state 0 to 0x1111 Fig. 7-5 DO terminal state The function code P01.20 can display the state of the output terminals DO1, DO2, DO3 and RO1. When there is signal output, the corresponding LED place will be set as 1.
  • Page 188 P01.30 PID feedback -100.0% to 100.0% P01.31 PID deviation -100.0% to 100.0% P01.32 PID output -100.0% to 100.0% P01.29–P01.32 display the percentage of the process closed-loop reference, feedback, deviation and output in Group P14 related to the full range. P01.33 PID proportional output -100.0% to 100.0% P01.34...

  • Page 189: P02: Basic Function Parameters

    P01.48 Accumulated running duration of the drive (h) 0 to 65535 h P01.49 Current running duration of the drive (min) 0 to 65535 min P01.50 Accumulated running duration of the fan 0 to 65535 h Display the accumulated running duration, current running duration of the drive and the accumulated running duration of the fan.
  • Page 190 P02.02 Operation command channel selection 0 to 2 MV820 has three operation command channels. 0: Operating panel Use RUN, STOP and the M key (set to JOG function) for control. 1: Terminal Use external control terminals (FWD, REV, FWD JOG, REV JOG) for control.
  • Page 191 1: Opposite direction P02.05 Main frequency source selection 0 to 8 0: Digital setting P02.09 When the drive is powered on, set the value of P02.09 as the current frequency reference. When the drive is running or at stop, you can use the “∧” and “∧” keys on the keypad to change such frequency. 1: AI1 reference 2: AI2 reference AI1 and AI2 are two independent physical channels for analog reference.
  • Page 192 P02.06 Auxiliary frequency source selection 0 to 8 0: Digital setting P02.09 Digital setting P02.09 is used as the source of auxiliary frequency. 1: AI1 reference 2: AI2 reference AI1 and AI2 are used as the source of auxiliary frequency. 3: High-speed pulse HDI reference The auxiliary frequency is determined by the terminal pulse frequency, and it can only be input by the terminal 10.
  • Page 193 P02.08 Frequency reference source calculation 0 to 5 0: Main frequency Only the main frequency reference is used as the frequency reference. 1: Auxiliary frequency Only the auxiliary frequency reference is used as the frequency reference. 2: Main + Auxiliary The sum of the main frequency reference and the auxiliary frequency reference is used as the frequency reference.
  • Page 194 Fb in Fig. 7-6 is the basic operating frequency, defined as the minimum corresponding output frequency when the drive outputs the highest voltage in the V/F mode. Fig. 7-6 Frequency limit parameter definition (1) The maximum output frequency, upper limit frequency and lower limit frequency should be carefully set according to the actual nameplate parameters of the controlled motor and the needs of the operating conditions.

  • Page 195: P03: Motor 1 Parameters

    Table 7-2 Carrier frequency for PWM output of drive Drive power Default carrier frequency 0.4 to 15 kW 4 kHz (1) The carrier frequency affects the noise of the motor during operation, and it is usually set from 3 to 5 kHz. For occasions requiring silent operation, it can be set at 6 to 8 kHz.
  • Page 196 Asynchronous motor P03.07 0.001 to 65.535 Ω Model dependent rotor resistance Asynchronous motor 0.01 mH to 655.35 mH (drive power ≤ 55 kW) P03.08 leakage inductive Model dependent 0.001 mH to 65.535 mH (drive power > 55 kW) reactance Asynchronous motor 0.1 mH to 6553.5 mH (drive power ≤...
  • Page 197 Specify the asynchronous motor iron core magnetic saturation coefficient 1 to 4. P03.15 Synchronous motor rated power 0.1 to 3000.0 kW Model dependent P03.16 Synchronous motor rated voltage 0 to 1200 V Model dependent P03.17 Synchronous motor rated current 0.8 to 6553.5 A Model dependent P03.18 Synchronous motor rated frequency...

  • Page 198: P04: Motor 1 Encoder Parameters

    In order to implement effective overload protection for different types of load motors, it is necessary to adjust the permissible maximum output current of the drive, as shown in Fig. 7-8. Current 电流 100% 200% 电机过载保护系数 Motor overload protection factor 160% 1分...
  • Page 199 encoder 0: Forward, A leads B 1: Reverse, B leads A Local encoder parameter When the motor is running forward, A leads B; and when the motor is running reversely, B leads A. If the wiring sequence direction between the drive’s local PG interface and the PG matches the wiring sequence direction between the drive and the motor, the value should be set to “0”...

  • Page 200: P05: Motor 1 Vector Control Parameters

    P05: Motor 1 vector control parameters P05.00 Speed loop proportional gain 1 1 to 100 P05.01 Speed loop integral time 1 0.01 to 10.00 s 0.50 s P05.02 Switchover frequency 1 0.00 Hz to P02.11 5.00 Hz P05.03 Speed loop proportional gain 2 1 to 100 P05.04 Speed loop integral time 2...
  • Page 201 In the vector control mode, you can set the proportional gain P and integral time I of the speed regulator to change the speed response features of vector control. (1) The composition of speed regulator (ASR) As shown in Fig. 7-10, K is the proportional gain P and T is the integral time I.
  • Page 202 Reducing the integral time I can speed up the dynamic response of the system. However, if I is too small, the system has large overshoots and oscillates easily, as shown in Fig. 7-11. Usually, the proportional gain P is adjusted first to increase P as much as possible without oscillating the system. Then the integral time I is adjusted so that the system has both fast response and small overshoots.
  • Page 203 P05.07 Speed loop filter time constant 0.00 to 20.00 s 0.02 s The speed regulator (ASR) output is passed through a delay filter to get the reference torque current. P05.07 is used to set the time constant of the speed loop output filter of motor 1. Generally, no modification is required. P05.08 Vector control overexcitation gain 50 to 200%...
  • Page 204 P05.15 Torque regulation Kp 0 to 60000 2000 P05.16 Torque regulation Ki 0 to 60000 1300 Used to set the physical channel for the braking torque limit. 0: Digital setting (P05.12) P05.12 is the braking torque limit. 1: AI1 2: AI2 The maximum AI input voltage/current (10 V / 20 mA) can correspond to 300% of the rated torque reference.

  • Page 205: P06: Motor 1 Torque Control Parameters

    Fig. 7-13 Torque control diagram The torque limit value can only be positive. If the reference is negative, the torque limit will become 0 automatically. P05.17 Integral separation 0 to 1 0: Disabled 1: Enabled P05.18 Synchronous motor field weakening coefficient 0 to 100 P05.19 Maximum field weakening current...
  • Page 206 0: Speed control mode In this mode, the motor is controlled by the speed reference, and the internal ASR is effective. The speed control mode shall be used in cooperation with the drive torque limit value and the braking torque limit value. 1: Torque control mode In this mode, the internal ASR is ineffective, and the torque reference amount can be selected according to the function code P06.01.
  • Page 207 For details about the programming method, operation method and communication protocol, see Modbus Communication Protocol. 5: PROFINET The host device sets the current torque reference of the drive through the PROFINET expansion card bus interface. For related use, see Group P40 Fieldbus option parameters. P06.02 Torque digital setting -300.0% to 300.0%...

  • Page 208: P07: Motor 1 V/F Control Parameters

    The maximum PULSE input frequency (50 kHz) of the terminal can correspond to 100% of the speed limit reference (maximum output frequency P02.10). For the corresponding relations between the pulse input and output, refer to the description of Group P09. 4: Modbus The host device sets the current speed limit reference of the drive through the standard RS485 communication interface built in the drive.
  • Page 209 Fig. 7-14 V/F curve Fig. 7-15 Multi-point V/F curve P07.00=1: User-defined curve, applicable to segmented constant torque loads, as shown in Fig. 7-14. In Fig. 7-15, F1 < F2 < F3 < Fb, Fb is the basic operating frequency, which is generally the rated frequency of the motor. V1 ≤...
  • Page 210 (1) Improper setting of this parameter can lead to motor overheat or overcurrent protection. (2) fz is defined in the function code P07.02. (3) When driving the synchronous motor, it is recommended to use manual torque boost, and adjust the V/F curve according to the motor parameters and working conditions.

  • Page 211: P08: Startup/Stop Control Parameters

    9: PROFINET Digital setting of voltage source for V/F P07.14 0 to 1000 V separation P07.15 Voltage rise time of V/F separation 0 to 6000.0 s 5.0 s P07.16 Voltage fall time of V/F separation 0 to 6000.0 s 5.0 s P07.17 Stop mode for V/F separation 0 to 1...
  • Page 212 For heavy load startup application, setting a proper startup frequency hold time will facilitate the startup. P08.04 Braking current at startup 0.0 to 100.0% 0.0% P08.05 Braking time at startup 0.00 to 50.00 0.0s P08.04 sets the magnitude of the DC braking current at startup, which is a percentage relative to the drive’s rated current.
  • Page 213 After the P08.08 delay, stop frequency detection starts. During the time defined by P08.10, if P08.09=0, the drive will immediately stop when the ramp reference frequency is equal to or lower than P08.07; if P08.09=1, the drive will stop only when the actual frequency is equal to or lower than P08.07. If no stop frequency is detected after P08.10, the drive will directly stop.
  • Page 214 Only available for asynchronous motors. P08.16 Speed of speed tracking 1 to 100 The larger the parameter is, the faster the tracking speed will be. However, too large parameter may cause the tracking unreliable. P08.17 Speed tracking current 10 to 200% Model dependent Ensure the maximum current during speed tracking is within the range.
  • Page 215 P08.25=1: When you power on the drive after a power failure, the drive will restart automatically after the waiting time defined by P08.26. (1) If there is a stop command, the stop shall prevail. (2) When the restart upon power failure function is effective, if the drive is powered on again while not being completely powered down (the drive LED displays -LU-), the drive will act as though it is powered on again after being completely powered down (the LED on the operating panel is completed extinguished), that is, the drive will restart according to the startup mode defined by P08.00.

  • Page 216: P09: Terminal Input Parameters

    The function is invalid when set to 0. The large the number is, the stronger the braking will be. P08.31 Dynamic braking usage ratio 0 to 100% 100% P08.32 Braking startup voltage 500 to 800 V 700 V The usage ratio of dynamic braking P08.31 and braking startup voltage P08.32 can only be applied to the drive with a built-in braking unit.
  • Page 217 Hundreds: Reserved Thousands: Reserved Terminal 6 can only be set as DI3, and terminal 8 can only be set as DI4. P09.01 Function selection of terminals 7, 10, 12, 16 0 to 0x2011 Ones: 0: Terminal 7 as DI5 1: Terminal 7 as thermosensitive signal input Tens: 0: Terminal 10 as DI6 1: Terminal 10 as HDI...
  • Page 218 P09.03 DI1 function selection 0 to 72 P09.04 DI2 function selection 0 to 72 P09.05 DI3 function selection 0 to 72 P09.06 DI4 function selection 0 to 72 P09.07 DI5 function selection 0 to 72 P09.08 DI6 function selection 0 to 72 P09.09 DI7 function selection 0 to 72...
  • Page 219 57 to 59 Reserved Emergency stop Wobble pause Wobble reset Counter reset Counter trigger Power consumption clear Power consumption hold Length counter input Length reset Switched to V/F control Switched to FVC control Reserved Reserved The settings of multi-function input terminals are mutually exclusive (excluding the No.0 function) 0: No function 1: Terminal forward running input 2: Terminal reverse running input...
  • Page 220 Frequency setting Multi-speed 2 Multi-speed 3 Multi-speed 4 Multi-speed 5 Multi-speed 6 Multi-speed 7 Multi-speed 8 Multi-speed 9 Multi-speed 10 Multi-speed 11 Multi-speed 12 Multi-speed 13 Multi-speed 14 Multi-speed 15 10：Acceleration/Deceleration time terminal 1 11：Acceleration/Deceleration time terminal 2 When you only control one motor (motor 1 or motor 2), the ON/OFF combination of acceleration/deceleration time terminals 1 and 2 enables 1 to 4 selections of acceleration/deceleration.
  • Page 221 acceleration/deceleration time 3 and 4 belong to motor 2. The acceleration/deceleration time terminal 1 controls the switchover between the two groups of acceleration/deceleration time of motor 1 (acceleration/deceleration time 1, 2), while the acceleration/deceleration time terminal 2 controls the switchover between the two groups of acceleration/deceleration time of motor 2 (acceleration/deceleration time 3, 4).
  • Page 222 After the drive receives a stop command, when the running frequency is lower than the start frequency of braking at stop P08.11, the drive starts DC braking. The braking current is set by P08.13. The braking time is the longer one of this terminal’s function hold time and P08.14 (DC braking time at stop).
  • Page 223 Table 7-6 Expression of frequency reference channel selection Main frequency Main frequency Main frequency reference channel reference channel Main frequency reference channel reference channel selection terminal 2 selection terminal 1 selection terminal 3 P02.09 Simple PLC Multi-speed reference Modbus 37: Reserved 38: Command channel switched to keypad When the function terminal is enabled, the operation command channel will be switched to the keypad.
  • Page 224 44: External stop command When the drive is running, if the terminal function is enabled, the drive will stop according to the current stop mode, valid for all control modes. 45: Auxiliary reference frequency clear It is only valid for the digital auxiliary frequency (P02.06=0, 7). When the function terminal is enabled, the auxiliary frequency reference will be cleared, and the frequency reference will be determined by the main frequency reference.
  • Page 225 When this terminal function is enabled, the current wobble output frequency will be reset. 63: Counter reset When this terminal function is enabled, the current count of the reset counter will be cleared. 64: Counter trigger When this terminal function is enabled, the current counter will continue to count. 65: Power consumption clear When this terminal function is enabled, the current count of power consumption will be cleared.
  • Page 226 1: DI2 negative logic active Hundreds: 0: DI3 positive logic active 1: DI3 negative logic active Thousands: 0: DI4 positive logic active 1: DI4 negative logic active P09.13 DI5 to DI8 active mode 0 to 0x1111 Ones: 0: DI5 positive logic active 1: DI5 negative logic active Tens: 0: DI6 positive logic active...
  • Page 227 0: Two-wire mode 1 Command Stop Reverse Forward Stop Fig. 7-19 Two-wire mode 1 1: Two-wire mode 2 Command Stop Stop Forward Reverse Fig. 7-20 Two-wire mode 2 2: Three-wire mode 1 Command 0-＞1 Forward 0-＞1 Reverse Stop Fig. 7-21 Three-wire mode 1 In the above figure: SB1: Stop button SB2: FWD button...
  • Page 228 3: Three-wire mode 2 Command Forward 0-＞1 Reverse Stop Fig. 7-22 Three-wire mode 2 In the above figure: SB1: Stop button SB2: Run button Dli is the input end of DI1 to DI8, so it is required to set the terminal’s function to No.5 function “Three-wire control”. P09.15 DI filter time 0.000 to 1.000...
  • Page 229 Used to set the delay time for level jump upon switch-on/off of digital input terminals. P09.25 AI1 lower limit 0.00 V to P09.27 0.00 V P09.26 Percentage corresponding to AI1 lower limit 0.0% to 100.0% 0.0% P09.27 AI1 upper limit P09.25 to 10.00 10.00 V P09.28...

  • Page 230: P10: Terminal Output Parameters

    Fig. 7-25 Analog input frequency feature curve 7.11 P10: Terminal output parameters P10.00 DO1 function selection 0 to 47 P10.01 DO2 function selection 0 to 47 P10.02 DO3 function selection 0 to 47 P10.03 Relay RO1 output selection 0 to 47 The function of DO terminals are defined in the following table: Table 7-7 Table of digital output terminal functions Item...
  • Page 231 Motor overload warning 23 to 25 Reserved Reference count value reach Designated count value reach Length reach 29 to 37 Reserved Motor 1 and 2 indication terminal Bus card switch signal 40 to 45 Reserved PID feedback loss Reserved 0: Disabled 1: AC drive in running When the drive is running, the indication signal is output.
  • Page 232 When frequency reference ≤ frequency lower limit and the running frequency reaches the frequency lower limit, the relevant indication signal will be output. 12: Zero-speed running When the drive is running at zero speed, the relevant indication signal is output. To make it clear, in the V/F mode, the indication signal is output when the output frequency is 0;...
  • Page 233 26: Reference count value reach The signal is output when the reference count value is reached. 27: Designated count value reach The signal is output when the designated count value is reached. 28: Length reach The signal is output when the set length is reached. 29 to 37: Reserved 38: Motor 1 and 2 indication terminal The output signal indicates the currently selected motor.
  • Page 234 P10.11 RO1 switch-on delay time 0.0 to 600.0 s 0.0 s P10.12 RO1 switch-off delay time 0.0 to 600.0 s 0.0 s Used to set the delay time for level jump upon switch-on/off of output terminals. P10.13 AO1 function 0 to 28 P10.14 HDO1 function 0 to 28...

  • Page 235: P11: Auxiliary Function Parameters

    Frequency corresponding to HDO1 output lower P10.22 0.00 to 50.00 0.00 kHz limit P10.23 HDO1 output upper limit P10.21 to 100.00% 100.00% Frequency corresponding to HDO1 output upper P10.24 0.00 to 50.00 50.00 kHz limit P10.25 HDO1 output filter time 0.000 to 10.000 0.005 s P10.26...
  • Page 236 (P02.10) to 0 Hz, as t shown in Fig. 7-28. The MV820 series drive defines four kinds of acceleration/deceleration time, which can be selected through the different combinations of control terminals during operation, referring to the acceleration/deceleration time terminal function in P09.03 to P09.10.
  • Page 237 Fig. 7-28 Time proportion of S-curve start and end Switchover frequency of P11.09 0.00 Hz to P02.10 0.00 Hz acceleration/deceleration time 1 and 2 Fig. 7-29 Switchover of acceleration/deceleration time 1, 2 As shown in Fig. 7-29, for the motor 1 acceleration, it will run at the acceleration time 1 first as the A curve and the acceleration time is When the output frequency increases to the switching point P11.09, the ...
  • Page 238 Fig. 7-30 Description of jog operation As shown in Fig. 7-30, t is the jog acceleration time (P11.11) and jog deceleration time (P11.12) of actual running; t is the jog time and f is the jog operation frequency (P11.10). The jog acceleration and deceleration time t of actual running is determined by the following equation: ...
  • Page 239 P11.18 Skip frequency 1 0.00 Hz to P02.10 0.00 Hz P11.19 Skip frequency 1 band 0.00 Hz to P02.10 0.00 Hz P11.20 Skip frequency 2 0.00 Hz to P02.10 0.00 Hz P11.21 Skip frequency 2 band 0.00 Hz to P02.10 0.00 Hz If the reference frequency is within the skip frequency, the drive will output according to the skip frequency boundary actually to avoid the mechanical resonance.
  • Page 240 Used to set parameters related to wobble running. P11.26 Frequency reach (FAR) detection range 0.0 to 100.0% 0.0% When the running frequency of the drive is within the P11.26 percentage range of maximum frequency, the multi-function DO terminal outputs an ON signal as shown in Fig. 7-32. Fig.
  • Page 241 Fig. 7-33 Frequency level detection P11.31 Auto start temperature of fan 40.0 to 80.0℃ 55℃ P11.32 Reserved P11.33 Reference length 0 to 60000 m P11.34 Actual length 0 to 60000 m P11.35 Number of pulses per meter 0 to 60000 1000 P11.36 Reference count value...

  • Page 242: P12: Control Optimization Parameters

    The drive automatically starts the internal temperature detection program during operation, and decides the running and stop of the fan according to the temperature condition of the module. 1: Always running after power on The fan is always running after the drive is powered on. 2: Controlled by start/stop commands (On during operation, Off during stop) The fan is running when the drive is in operation, and is stopped after the drive is at stop.
  • Page 243 Fig. 7-34 Simple PLC running In Fig. 7-34, a to a and d to d represent the acceleration and deceleration time of their current stages, and f to f to T represent the frequency reference and stage running time of their current stages. They will be explained in the following function codes.
  • Page 244 0: Stop after running for one cycle As shown in Fig. 7-36, the drive completes one cycle and automatically stops. It starts only after another operation command is given. Fig. 7-36 PLC stops after running for one cycle 1: Keep final values after running for one cycle As shown in Fig.7-37, the drive completes one cycle and automatically keeps the final running frequency and direction.
  • Page 245 Fig. 7-38 PLC repeats after running for one cycle LED tens: Startup mode 0: Run from the first stage If the drive is stopped (due to a stop command, fault or power failure), it will operate from the first stage after restarting. 1: Continue to run from the retained stage and frequency upon a stop or fault If the drive is stopped (due to a stop command or fault), the drive will automatically record the running time of the current stage and the running frequency upon the stop, and continue to run from the remaining stage and frequency...
  • Page 246 Upon power failure, the PLC running status is not retained. The device will run from the first stage after restarting. 1: Retain the stage and frequency upon power failure Upon power failure, the PLC running status including the stage, running frequency and running time, will be retained. The device will run from the startup mode upon interrupted PLC operation defined in the tens place.
  • Page 247 P13.18 Multi-speed reference 1 running time 0.0 to 6553.5 s 0.0 s P13.19 Multi-speed reference 2 running time 0.0 to 6553.5 s 0.0 s P13.20 Multi-speed reference 3 running time 0.0 to 6553.5 s 0.0 s P13.21 Multi-speed reference 4 running time 0.0 to 6553.5 s 0.0 s P13.22...
  • Page 248 Acceleration/Deceleration time of simple PLC P13.34 0 to 0x3333 0x0000 reference 4 to 7 The acceleration/deceleration time selection from stage 4 to stage 7 of the simple PLC is shown in the following figure. Fig. 7-41 Acceleration/Deceleration time selection of simple PLC reference 4 to 7 Acceleration/Deceleration time of simple PLC P13.35 0 to 0x3333...

  • Page 249: P14: Process Pid Parameters

    Fig. 7-43 Acceleration/Deceleration time selection of simple PLC reference 12 to 15 When the running direction of the PLC stage is determined by the running command, the motor running direction can be changed in real time by the external direction command. For example, you can use the DI terminal to realize forward and reverse running.
  • Page 250 Fig. 7-44 PID control diagram...
  • Page 251 P14.00 PID reference source 0 to 6 0: P14.02 digital setting 1: AI1 2: AI2 3: Reserved 4: HDI 5: Modbus 6: PROFINET P14.01 PID feedback source 0 to 9 0: AI1 1: AI2 2: Reserved 3: HDI 4: Modbus 5: PROFINET 6: AI1+AI2 7: AI1-AI2...
  • Page 252 1: Negative action, selected when the motor speed needs to decrease upon the increased reference. P14.05 Proportional gain Kp1 0.0 to 1000.0 20.0 A larger Kp indicates quicker response, but too large Kp may easily cause oscillation and the steady-state error can not be eliminated by using Kp control only.
  • Page 253 Fig. 7-45 Deviation limit P14.11 PID parameter low-frequency switchover point 0.00 Hz to P14.12 5.00 Hz When the ramp reference frequency is lower than the low-frequency switchover point, the PID parameter is P14.05 to P14.07; when it is higher than the high-frequency switchover point, the PID parameter is P14.13 to P14.15; when it is between the low-frequency and high-frequency switchover points, the PID parameter is the linear interpolation of these two group parameters.
  • Page 254 P14.19 PID output property 0x000 to 0x111 0x100 Used to set the PID output property, as shown in Fig. 7-46. Fig. 7-46 PID output property P14.20 PID preset value 0.0 to 100.0% 0.0% P14.21 PID preset value hold time 0.00 to 650.00 0.0 s Proper PID preset value and preset value hold time enable the closed-loop adjustment to quickly enter into the stable stage.

  • Page 255: P15: Communication Parameters

    When the feedback signal is smaller than the detection value set by P14.22 and its holding time exceeds the time set by P14.23, the PID feedback is considered as loss. P14.24 PID calculation mode 0 to 1 PID calculation mode selection 0: Calculation disabled at stop 1: Calculation enabled at stop P14.25...
  • Page 256 2: 19200 BPS 3: 38400 BPS 4: 57600 BPS 5: 115200 BPS 6: 125000 BPS P15.02 Local address 0 to 247 Used to identify the address of the drive. Note: 0 is the broadcast address. When set to the broadcast address, the drive can only receive and execute the broadcast command of the host device, but can not respond to the host device.

  • Page 257: P16: Keypad Display Setting Parameters

    7.17 P16: Keypad display setting parameters P16.00 LED display parameter selection 1 during running 0 to 0xFFFF 0xF0 P16.00 and P16.01 define the parameters allowed to be displayed on the LED during drive running, binary setting shown in Fig. 7-48. When a bit is set to 0, the corresponding parameter will not display;...
  • Page 258 When you rotate “ ” clockwise, the function code displays the switched parameter number, only RAM modified and not save to EEPROM. P16.03 LED parameter display selection at stop 0 to 0xFFFF 0: No display 1: Display Used to set whether a parameter is displayed on the zero level of the keypad menu at stop. Bit0 to bit15 correspond to 16 parameters listed in P16.04.

  • Page 259: P20: Motor 2 Parameters

    When you rotate “ ” clockwise, the function code displays the switched parameter number, only RAM modified and not save to EEPROM. P16.05 Line speed display coefficient 0.1 to 999.9% 100.0% This function code is used to correct the line speed display error, and has no influence on the actual speed. P01.42 Line speed...
  • Page 260 0.01 mH to 655.35 mH (drive power ≤ 55 kW) Asynchronous motor leakage P20.08 Model dependent 0.001 mH to 65.535 mH (drive power > 55 inductive reactance 0.1 mH to 6553.5 mH (drive power ≤ 55 Asynchronous motor mutual P20.09 Model dependent 0.01 mH to 655.35 mH (drive power >...

  • Page 261: P21: Motor 2 Encoder Parameters

    0.01 to 655.35 mH (drive power ≤ 55 Synchronous motor axis-Q P20.22 Model dependent 0.001 to 65.535 mH (drive power > 55 inductance Synchronous motor back P20.23 0.0 to 6553.5 V/krpm Model dependent P20.24 to P20.26 Reserved P20.27 Motor auto-tuning 0 to 2 Motor overload protection P20.28...

  • Page 262: P22: Motor 2 Vector Control Parameters

    7.20 P22: Motor 2 vector control parameters P22.00 Speed loop proportional gain 1 1 to 100 P22.01 Speed loop integral time 1 0.01 to 10.00 0.50 s P22.02 Switchover frequency 1 0.00 Hz to P02.11 0.00 Hz P22.03 Speed loop proportional gain 2 1 to 100 P22.04 Speed loop integral time 2...

  • Page 263: P24: Motor 2 V/F Control Parameters

    2: AI2 3: HDI 4: Modbus 5: PROFINET -300.0% to 300.0% 0.0% P23.02 Torque digital setting The digital setting range of torque reference is -300.0% to 300.0%. 0.0 to 6000.0 6.0 s P23.03 Torque reference acceleration/deceleration time Used to set the torque acceleration/deceleration time under torque control. It is invalid under speed control. Specifies the time the system takes to reach the reference torque from the current torque.
  • Page 264 3: Reserved 4: V/F complete separation 5: V/F half separation P24.01 Torque boost 0.0 to 50.0 P24.02 Cut-off frequency of torque boost 0.00 Hz to P02.11 10.00 Hz P24.03 Multi-point V/F frequency 1 0.00 Hz to P24.05 0.00 Hz P24.04 Multi-point V/F voltage 1 0 V to P24.06 P24.05...

  • Page 265: P40: Fieldbus Option Parameters

    P24.17 Stop mode for V/F separation 0 to 1 0: Frequency and voltage decline to 0 independently 1: Frequency declines after voltage declines to 0 P24.18 Reserved P24.19 Reserved For the parameter description, refer to “7.8 P07: Motor 1 V/F control parameters”. 7.23 P40: Fieldbus option parameters 0 to 3 P40.00...
  • Page 266 1: DI9 negative logic active Tens: 0: DI10 positive logic active 1: DI10 negative logic active Hundreds: 0: DI11 positive logic active 1: DI11 negative logic active Thousands: Reserved P41.05 Reserved P41.06 DI filter time 0.000 to 1.000 0.010 s Used to set the filter time for DI terminal sampling.

  • Page 267: P43: Profinet Communication Parameters

    Hundreds: Reserved Thousands: Reserved P41.16 RO2 switch-on delay time 0.0 to 600.0s 0.0 s P41.17 RO2 switch-off delay time 0.0 to 600.0s 0.0 s P41.18 RO3 switch-on delay time 0.0 to 600.0s 0.0 s P41.19 RO3 switch-off delay time 0.0 to 600.0s 0.0 s For the parameter description, refer to “7.11 P10.11 and P10.12”.
  • Page 268 3: Braking torque upper limit reference (0.0 to 300.0%, rated motor current) 4: Torque reference (-300.0 to 300.0%, rated motor current) 5: FWD frequency upper limit reference (0.00 to P02.10) 6: REV frequency upper limit reference (0.00 to P02.10) 7: Voltage reference (VF separation) (0 to 1000) 8: Virtual input terminal command (0 to 0×FF for DI8 to DI1) 9: Output terminal bus command (set the output terminal function to No.

  • Page 269: P50: Option Status Parameters

    5: Output current (0.1 A) 6: Bus voltage (0.1 V) 7: Motor power (0.1%) 8: Reserved 9: Exciting current (0.1 A) 10: Torque current (0.1 A) 11: Status word (0 to 0×FFFF) 12: Fault code (0 to 46) 13: DI1 to DI4 status (0 to 0×FFFF) 14: DI5 to DI8 status 15: Digital output status (0 to 0×F) 16: AI1 input voltage (0 to 10.00 V)

  • Page 270: P97: Fault And Protection Parameters

    1: PROFINET option 2: EtherCAT option 3: IO option P50.01 Reserved P50.02 Reserved P50.03 DI status of the IO option 0 to 0x111 P50.04 DO status of the IO option 0 to 0x11 0: Disabled 1: Enabled P50.05 to P50.14 Reserved 7.27 P97: Fault and protection parameters P97.00...
  • Page 271 1: Overvoltage stall suppression enabled Tens: 0: Undervoltage stall suppression disabled 1: Undervoltage stall suppression enabled Hundreds: 0: Overcurrent stall suppression disabled 1: Overcurrent stall suppression enabled P97.02 Current limit level 20 to 200% 120.0% P97.03 Current limit adjustment coefficient 0 to 100 The current limit function controls load current in real time within the limit set by P97.02 to avoid tripping caused by current overshoot.
  • Page 272 Overvoltage stall point 失速过压点 Time 时间 Output frequency 输出频率 时间 Time Fig. 7-50 Overvoltage stall Voltage regulator proportional coefficient upon P97.05 0 to 1000 overvoltage stall P97.06 Reserved Speed regulator proportional coefficient upon P97.07 0 to 1000 overvoltage stall P97.08 Reserved Used to set the proportional coefficients of the voltage regulator and speed regulator upon overvoltage stall.
  • Page 273 Fig. 7-51 Input and output phase loss protection P97.15 Fault protection and alarm property 1 Fig. 7-52 Fault protection and alarm property 1 P97.16 Fault protection and alarm property 2 0 to 0x2002 Fig. 7-53 Fault protection and alarm property 2 P97.17 Fault protection and alarm property 3 0 to 0x222...
  • Page 274 P97.18 Fault protection and alarm property 4 0 to 0x20 Fig. 7-55 Fault protection and alarm property 4 P97.19 to P97.24 Reserved P97.25 Motor overheat protection threshold 0 to 200℃ 120℃ Compare the analog feedback value of the thermal sensor installed in the motor with the preset motor overheat protection threshold P97.25.
  • Page 275 When the drive is running normally without faults for 600 s, the fault reset count will be cleared. (1) The inverter module protection (OUT), external device fault (EF), the short circuit to ground fault (GdF) cannot be reset (both automatic and manual ways can not reset); undervoltage (Uv), board level communication error (bCE) and power board software version mismatch (vEr) can be automatically reset immediately when the three faults disappear;...

  • Page 276: P98: Drive Parameters

    0.0 to 6553.5 0.0 s MV820 records the latest three fault types (P97.32, P97.33, and P97.34), and records the bus voltage (P97.35), output current (P97.36), running frequency (P97.37), and operation state (P97.38) upon the current fault for users to query. For details about the operation status, see P01.17.
  • Page 277 P98.10 Manufacturer’s bar code 4 0 to 0xFFFF P98.11 Manufacturer’s bar code 5 0 to 0xFFFF P98.12 Manufacturer’s bar code 6 0 to 0xFFFF...

  • Page 278: Chapter 8 Troubleshooting

    List of fault codes All possible fault types of MV820 are summarized in Table 8-1, including 18 fault codes. Before seeking for service, the user can perform self-check according to this table and record the fault symptoms in details. This will help a lot when you contact the sales personnel for technical support.
  • Page 279 Fault code Fault type Possible fault cause Solution Check the encoder and its Encoder fault occurs when PG is running. wiring The drive power is low. Use a drive with higher power Abnormal input voltage Check the input power supply Acceleration Prolong the acceleration time The acceleration time is too short.
  • Page 280 Fault code Fault type Possible fault cause Solution Refer to the overcurrent Instantaneous overcurrent of the drive solutions The duct is blocked or the fan is Unblock the duct or replace damaged. the fan Lower the ambient The ambient temperature is too high. temperature Wires or plug-in units of the control board Check them and rewire...
  • Page 281 Fault code Fault type Possible fault cause Solution The acceleration time is too short. Prolong the acceleration time The grid voltage is too low. Check the grid voltage Adjust the V/F curve and The V/F curve is improper. torque boost The motor overload protection factor Set the overload protection setting is incorrect.
  • Page 282 Fault code Fault type Possible fault cause Solution The Hall device is damaged. Seek for technical support The amplifying circuit is abnormal. Seek for technical support The parameters for feedback loss are set Modify the P14.22 setting improperly. Feedback wire breakage Rewiring PID feedback loss Refer to the P14.01 setting and...
  • Page 283 Fault code Fault type Possible fault cause Solution Check whether the feedback PID feedback The PID feedback exceeds the limited value input voltage is normal. exceeding limit range. If normal, you can seek for technical support Lower the ambient The ambient temperature is too high. temperature The motor duct is blocked.

  • Page 284: List Of Operation Exceptions

    List of operation exceptions Table 8-2 Operation exceptions and solutions Symptom Condition Possible cause Solution The wires of the operating panel Check the wiring and have poor contact. perform hot plug again The operating panel Some keys or all keys has no response.
  • Page 285 Symptom Condition Possible cause Solution Modify the speed Too large speed deviation deviation detection value Check if the P09.12 and The positive/negative logic of the P09.13 settings meet the control terminals changes. requirements Check the fault auto Automatic fault reset reset setting and find out the cause Check the PLC pause...
  • Page 286 Symptom Condition Possible cause Solution The coast-to-stop function terminal Check the coast-to-stop is enabled. terminal The drive running inhibition terminal Check the drive running is enabled. inhibition terminal The external stop function terminal Check the external stop is enabled. function terminal Under the three-wire control mode, Set and close the The drive does not work...

  • Page 287: Chapter 9 Maintenance

    Chapter 9 Maintenance The ambient temperature, humidity, dust, vibration as well as the aging of components may cause drive faults. Thus, it is necessary to carry out daily and periodical maintenance. Daily inspection Before inspection and maintenance, check the following matters. Otherwise, electrical shock may occur. ①...

  • Page 288: Periodical Maintenance

    Inspection instructions Inspection item Inspection standard Inspection contents Cycle Inspection means 1. No abnormal heat 1. Heat generation 1. Touch by hand generation Motor Anytime 2. Low and regular 2. Noise 2. Hear noise 1. Within the rated range and 1.

  • Page 289: Replacing Wearing Parts

    the grounding test for a single terminal; otherwise, the drive may be damaged. Please use a 500 V megger during the test. (7) To test the insulating performance of the motor, you need to disconnect the input terminals U, V, W of the motor from the drive, and conduct test independently;...

  • Page 290: Storage Of Drive

    Storage of drive Note the following for the short and long-term storage of the drive: (1) The drive should be stored in the place with good ventilation away from high temperature, humidity, dust and metal powder. (2) Long-term storage will degrade the electrolytic capacitor. The drive should be powered on at least once for 5 hours within 2 years.

  • Page 291: Chapter 10 Application Of Special Functions

    Chapter 10 Application of Special Functions Besides the common functions, the MV820 drive also provides some special functions to lower the cost and improve the convenience for customers. 10.1 Closed-loop application Hardware wiring (1) OC wiring When the encoder’s ABZ signal has only one cable for output, the OC wiring is adopted, as shown in Fig. 10-1.

  • Page 292: Integrated Communication Application

    Parameter setting Confirm the motor encoder’s voltage class P04.04 (currently, the PG card only supports 5 V and 12 V). The default value is 0 (corresponding to 5 V), and if the encoder’s voltage class is 12 V, you can set P04.04 to 1; Confirm the encoder’s PPR P04.00;...
  • Page 293 This mode is the traditional PLC and PN device communication. Every drive shall be installed with a PN option. The function codes can be set as follows: P02.02=2 (communication control) P02.03=3 (PN communication) P02.05=8 (frequency reference channel set to PN) P15.00 ones place=0 (non PN-to-485 function) P40.00=1 (PN function enabled) P40.01=3.0 s (detection for expansion card identification timeout, can be modified to other values)
  • Page 294 P43.13 to P43.23 are used to set the parameters which PLC can read. ② 485 slave P02.02=2 (communication control) P02.03=3 (PN communication) P02.05=8 (frequency reference channel set to PN) P15.00 ones place=1 (PN to 485 function enabled) Set the local 485 station number through P15.02 P40.00=0 (PN to 485 slave function enabled) P40.01=3.0 s (detection for expansion card identification timeout, can be modified to other values) P43.00=3.0 s (detection for PN communication timeout, can be modified to other values)

  • Page 295: Appendix 1 Modbus Communication Protocol

    (4) MV820 provides the RS485 interface only. If the communication interface of external device is RS232, an RS232/485 conversion device is needed.
  • Page 296 For the RTU mode, the actual time of response delay shall not be less than the interval of 3.5 characters. 5. Protocol functions The main function of Modbus is reading/writing parameters. Different command codes control different operation requests. The Modbus protocol of MV820 drive supports the operations as shown in the following table:...
  • Page 297 Command Meaning code Used to read the drive parameters, including function code parameters, control parameters and status 0x03 parameters. Used to change the single 16-bit function code parameter or control parameter of the drive, and 0x06 parameter value will be saved after power off. Used to change the single 16-bit function code parameter or control parameter of the drive, and the 0x07 parameter value will not be saved after power off.
  • Page 298 For example, the register address of the function code parameter P03.02 is 0x0302, and the register address of the first control parameter (control word 1) is 0x6400. As the format of the whole data frame has been explained in the above text, the following text will describe the format and meanings of the “command code”...
  • Page 299 The exception codes and meanings are as follows: Exception Meaning code 0x01 Incorrect password 0x02 Invalid command code 0x03 CRC check error 0x04 Invalid address 0x05 Invalid parameter 0x06 Invalid parameter change 0x07 System lock 0x08 Parameter is being saved (2) Change the single 16-bit function code parameter and control parameter of the drive, and the parameter values will be saved after power off.
  • Page 300 If the operation fails, the abnormal response frame will return, and the format is described as above. (3) Change the single 16-bit function code parameter and control parameter of the drive, and the parameter values will not be saved after power off. When this command is used, the changed parameter value will not be saved upon power on after power off.
  • Page 301 If the operation is successful, the response format is as follows: Application-layer protocol data unit Data length (number of bytes) Value or range Command code 0x10 Start register address 0x0000 to 0xFFFF Number of registers in operation 0x0001 to 0x000A Number of bytes of register content 2 ×...
  • Page 302 Register Parameter name Remarks address 0 to 0xFF 0x6407 DO terminal state setting Bit0 to bit 3 corresponding to DO1 to DO3, RO1 Valid when P10.00 to P10.03=19 0x6408 Reserved 0 to 0xFF 0x6409 Virtual terminal control setting Bit0 to bit 7 corresponding to virtual terminals DI1 to DI8 Valid when the corresponding bit of P09.16 is set 0x640C Auxiliary frequency reference...
  • Page 303 Value Function Remarks 110B Stop in mode 1 Coast to stop Stop according to the deceleration time set 101B Stop in mode 0 (valid when the jog is disabled) Start the drive (valid when the jog is 100B Running command disabled) Others No command...
  • Page 304 (2) The host device processes the faults and alarms as follows: when the drive fault occurs, for control words 1 and 2, only the fault reset command is valid, and any other commands from the host device are invalid. That is, the host shall reset the fault first before sending other commands.
  • Page 305 Register Parameter name Remarks address 0x650B Reserved 0x650C Bus voltage 0.0 to 6553.5 V 0x650D Reserved 0 to 0x1111 0x650E DI terminal state 1 Corresponding to DI1 to DI4 0 to 0x1111 0x650F DI terminal state 2 Corresponding to DI5 to DI8 0 to 0x1111 0x6510 Output terminal state...
  • Page 306 Register Parameter name Remarks address Operation command channel 0x651E Operation command channel (same as P02.02) Refer to the status word 2 0x651F Status word 2 of drive definition table 0x6520 Main frequency source selection Refer to P02.05 0x6521 Reserved 0 to 0xFFF Ones: Control mode 0: SVC1 1: FVC...
  • Page 307 (1) The status parameters can not be written. (2) In the status parameters, the maximum length of “actual running value of current main reference”, “current running frequency”, “running frequency reference” and “running frequency at the 3rd fault” is 32 bits, and others’ length is 16 bits.
  • Page 308 The bit definition of the status word 2 of the drive is shown in the following table. Value Function Remarks BIT0 Reserved Jog running BIT1 Non jog running Simple PLC running BIT2 Non simple PLC running BIT3 Reserved Process closed-loop running (PID) BIT4 Non process closed-loop...
  • Page 309 Speed reached (speed mode)/ BIT11 Speed limited (torque mode) BIT12 Drive fault BIT13 Speed control BIT14 Torque control BIT15 Reserved 7. Cautions 1. To read multiple parameters, if any one of the function codes is not read successfully (due to invalid parameter address, parameter being password, etc.), only the error information will return, and no read parameters will return.
  • Page 310 (7) When the host device has gotten the access (no user password or already being decrypted), if the user password is set or changed through the keypad, the host device still has the current access with no need to decrypt. When the access right becomes invalid, the host device needs to decrypt again (entering the new password) for access.
  • Page 311 0x000 A,0xC1C A,0x81CB,0x400B,0x01C9,0xC009,0x8008,0x41C8,0x01D8,0xC018,0x8019,0x41D9, 0x001B,0xC1DB,0x81D A,0x401 A,0x001E,0xC1DE,0x81DF,0x401F,0x01DD,0xC01D,0x801C,0x41DC, 0x0014,0xC1D4,0x81D5,0x4015,0x01D7,0xC017,0x8016,0x41D6,0x01D2,0xC012,0x8013,0x41D3, 0x0011,0xC1D1,0x81D0,0x4010,0x01F0,0xC030,0x8031,0x41F1,0x0033,0xC1F3,0x81F2,0x4032, 0x0036,0xC1F6,0x81F7,0x4037,0x01F5,0xC035,0x8034,0x41F4,0x003C,0xC1FC,0x81FD,0x403D, 0x01FF,0xC03F,0x803E,0x41FE,0x01F A,0xC03 A,0x803B,0x41FB,0x0039,0xC1F9,0x81F8,0x4038, 0x0028,0xC1E8,0x81E9,0x4029,0x01EB,0xC02B,0x802 A,0x41E A,0x01EE,0xC02E,0x802F,0x41EF, 0x002D,0xC1ED,0x81EC,0x402C,0x01E4,0xC024,0x8025,0x41E5,0x0027,0xC1E7,0x81E6,0x4026, 0x0022,0xC1E2,0x81E3,0x4023,0x01E1,0xC021,0x8020,0x41E0,0x01 A0,0xC060,0x8061,0x41 A1, 0x0063,0xC1 A3,0x81 A2,0x4062,0x0066,0xC1 A6,0x81 A7,0x4067,0x01 A5,0xC065,0x8064,0x41 A4, 0x006C,0xC1 AC,0x81 AD,0x406D,0x01 AF,0xC06F,0x806E,0x41 AE,0x01 A A,0xC06 A,0x806B,0x41 AB, 0x0069,0xC1 A9,0x81 A8,0x4068,0x0078,0xC1B8,0x81B9,0x4079,0x01BB,0xC07B,0x807 A,0x41B A, 0x01BE,0xC07E,0x807F,0x41BF,0x007D,0xC1BD,0x81BC,0x407C,0x01B4,0xC074,0x8075,0x41B5, 0x0077,0xC1B7,0x81B6,0x4076,0x0072,0xC1B2,0x81B3,0x4073,0x01B1,0xC071,0x8070,0x41B0, 0x0050,0xC190,0x8191,0x4051,0x0193,0xC053,0x8052,0x4192,0x0196,0xC056,0x8057,0x4197,...
  • Page 312 int i; unsigned crc_result=0xffff; while（length--） crc_result^=*d At A++; for（i=0;i<8;i++） if（crc_result&0x01） crc_result=（crc_result>>1）^0x A001; else crc_result=crc_result>>1; return （crc_result=（（crc_result&0xff）<<8）|（crc_result>>8））;...
  • Page 313 9. Scaling of drive parameters (1) Scaling of frequency 1:100 To run the drive at 50 Hz, the main reference should be 0x1388 (5000). (2) Scaling of time 1:10 To set the drive’s acceleration time to be 30 s, the function code should be set to 0x012C (300). (3) Scaling of current 1:10 If the drive’s feedback current is 0x012C (300), the present current is 30 A.

  • Page 314: Appendix 2 Braking Components

    Appendix 2 Braking Components 1．External braking unit model definition Appendix Fig. 2-1 Definition of braking unit models ED10% in the above figure means the braking usage ratio is 10%. 2．External braking unit configuration (for conditions with 10% braking usage ratio and 760 V braking action voltage) Appendix Table 2-1 Braking unit configuration Braking unit model and parallel Drive rated power（kW）...
  • Page 315 Braking unit model and parallel Drive rated power（kW） Braking resistor Braking torque (%) number DBU-4220B*1 60kW/3.2Ω*1 DBU-4220B*1 60kW/3.2Ω*1 DBU-4300*1 60kW/2Ω*1 The above recommendations are suitable for working conditions with 10% braking usage ratio and 760 V braking action voltage, capable for most applications. For special working conditions, please consult us. 3．Braking resistor configuration of the built-in braking unit drive Appendix Table 2-2 Braking resistor configuration Minimum braking...
  • Page 316 Minimum braking Drive model Recommended braking resistor Braking torque (%) resistance MV820G1-4T2.2B 440 W/260 Ω 100 Ω MV820G1-4T3.7B 740 W/150 Ω 82 Ω MV820G1-2T3.7B 800 W/33 Ω 22 Ω MV820G1-4T5.5B 1100 W/100 Ω 50 Ω MV820G1-4T7.5B 1500 W/75 Ω 50 Ω MV820G1-2T5.5B 1300 W/22 Ω...
  • Page 317 4．Wiring (1) Wiring of the built-in braking unit of the drive Connect the braking resistors to the + and BR terminals of the drive main circuit. (2) External wiring diagram of external braking unit DBU-4030/4045 Appendix Fig. 2-2 Wiring of the drive and braking unit (3) External wiring diagram of DBU-4220/4300...

  • Page 318: Appendix 3 Warranty And Service

    (such as unsatisfactory performance and function), please contact the distributor or Shenzhen Megmeet Electrical Co., Ltd. (2) In case of any abnormality, contact the distributor or Shenzhen Megmeet Electrical Co., Ltd. immediately for help. (3) During the warranty period, our company will repair any drive abnormality incurred due to the product manufacturing and design free of charge.
  • Page 319 SHENZHEN MEGMEET ELECTRICAL CO., LTD. Address: 5th Floor, Block B, Unisplendor Information Harbor, Langshan Road, Nanshan District, Shenzhen, 518057, China Tel: +86-755-86600500 Fax: +86-755-86600562 Zip code: 518057 Website: https://www.megmeet.com/...

  • Page 320: Parameter Recording Table

    Parameter recording table...

  • Page 322: Wiring Diagram

    Wiring Diagram...
  • Page 323 Shenzhen Megmeet Electrical Co., Ltd. Shenzhen Megmeet Electrical Co., Ltd. Drive Warranty Bill Drive Warranty Bill Customer company: Customer company: Detailed address: Detailed address: Zip code： Contact: Zip code： Contact: Tel: Fax: Tel: Fax: Machine model: Machine model: Power: Machine No.：...

This manual is also suitable for:

Mv810

Table of Contents

Save PDF
