C8051F04x-DK
D
OCUMENT
Revision 0.4 to Revision 0.5
Section 1, added USB Debug Adapter and USB Cable.
Section 2, changed name from "Hardware Setup" to "Hardware Setup using an EC2 Serial Adapter".
Section 2, added 2 Notes bullets.
Section 2, removed Note from bottom of page.
Added Section 3, "Hardware Setup using a USB Debug Adapter".
Section 5.4.2, changed step 2 to include new instructions.
Section 7, J4, changed "Serial Adapter" to "Debug Adapter".
Target Board DEBUG Interface Section, added USB Debug Adapter.
DEBUG Connector Pin Descriptions Table, changed pin 4 to C2D.
Changed "jumper" to "header".
EC2 Serial Adapter section, added EC2 to the section title, table title and figure title.
EC2 Serial Adapter section, changed "JTAG" to "DEBUG".
Added "USB Debug Adapter" section.
Added J8 and J10 to the connector list.
Revision 0.5 to Revision 0.6
Removed EC2 Serial Adapter from Kit Contents.
Removed Section 2. Hardware Setup using an EC2 Serial Adapter. See RS232 Serial Adapter (EC2) User's
Guide.
Removed Section 8. EC2 Serial Adapter. See RS232 Serial Adapter (EC2) User's Guide.
Removed Section 9. USB Debug Adapter. See USB Debug Adapter User's Guide.
14
Downloaded from Elcodis.com electronic components distributor
C L
HANGE IST
Rev. 0.6
