FLEX 5000 Analog 4-channel Isolated Current/Voltage/HART Safety Input Modules
Catalog Numbers 5094-IF4IHS, 5094-IF4IHSXT
Topic
Summary of Changes
This publication contains the following new or updated information. This list includes substantive updates only and is not intended to reflect all changes.
Topic
Updated template
Updated trademarks
Updated UK and European Hazardous Location Approval
Updated IEC Hazardous Location Approval
Updated Special Conditions for Safe Use
Updated Module Specifications
Product Overview
The 5094-IF4IHS and 5094-IF4IHSXT analog 4-channel isolated current/voltage/HART safety input modules offer channel to channel isolated input channels that can connect to
current, voltage, and HART safety input devices. The modules support multiple ranges for each input type.
FLEX 5000® I/O modules use the Producer/Consumer communication model. The Producer/Consumer communication model is an intelligent data exchange between modules and
other system devices in which each module produces data without first being polled.
The 5094-IF4IHS and 5094-IF4IHSXT modules can be used with GuardLogix® 5580 and Compact GuardLogix 5380 Safety controllers. Safety controllers in applications up to SIL 3,
PLe, Cat. 4. The modules are configured with the Studio 5000 Logix Designer® application.
These modules are type-approved and certified for use in safety applications up to and including SIL 3 per IEC 61508, suitable for use in safety applications up to and including
SIL CL 3 per IEC 62061, and suitable for use in safety applications up to and including Performance Level PLe (Category 4) per ISO 13849-1.
For more information about safety application requirements and about which Logix 5000® controllers and Logix Designer application versions are compatible with
FLEX 5000 I/O modules, see the publications that are listed under
Page
4
4
5
6
6
7
8
9
10
10
11
11
11
Page
throughout
Additional Resources on page
11.
1
3
3
3
11
Advertisement
Table of Contents
Related Manuals for Rockwell Automation Allen-Bradley 5094-IF4IHS
Summary of Contents for Rockwell Automation Allen-Bradley 5094-IF4IHS
-
Page 1: Table Of Contents
Installation Instructions Original Instructions FLEX 5000 Analog 4-channel Isolated Current/Voltage/HART Safety Input Modules Catalog Numbers 5094-IF4IHS, 5094-IF4IHSXT Topic Page About the Module Before You Begin Required Components Install the Module Install the End Cap Wire the Terminal Base Disconnect Wires from the Terminal Base Wiring Diagrams Power the System Remove the Module... - Page 2 WARNING: For Class I Division 2 applications, use only Class I Division 2 listed or recognized accessories and modules approved for use within the 5094 platform. When used in a Class I, Division 2, hazardous location, this equipment must be mounted in a suitable enclosure with proper wiring method that complies with the governing electrical codes. Rockwell Automation Publication 5094-IN016B-EN-P - August 2022...
- Page 3 The enclosure must be accessible only by the use of a tool. • This equipment shall be used within its specified ratings defined by Rockwell Automation. • Transient protection shall be provided that is set at a level not exceeding 140% of the peak rated voltage value at the supply terminals to the equipment.
-
Page 4: About The Module
Any illustrations, charts, sample programs, and layout examples shown in this publication are intended solely for the purposes of example. Since there are many variables and requirements associated with any particular installation, Rockwell Automation does not assume responsibility or liability for actual use based upon the examples shown in this publication. -
Page 5: Required Components
The use of other DIN rail materials (for example, aluminum or plastic) that can corrode, oxidize, or are poor conductors can result in improper or intermittent grounding. Secure DIN rail to mounting surface approximately every 200 mm (7.8 in.) and use end-anchors appropriately. Be sure to ground the DIN rail properly. Refer to Industrial Automation Wiring and Grounding Guidelines, Rockwell Automation publication 1770-4.1 for more information. -
Page 6: Install The Module
Once you have installed all your modules for your system, install the end cap on the last terminal base. Make sure that the end cap is unlocked. If the end cap is locked, pull the tab until it clicks. Rockwell Automation Publication 5094-IN016B-EN-P - August 2022... -
Page 7: Wire The Terminal Base
2. Turn the screwdriver to close the terminal on the wire. Torque the screw to 0.4 N•m (3.5 lb•in). Push the wire into the terminal. Spring If the wire is too thin, crimp a wire ferrule on the wire and insert it. Screw-type TB Spring-type TB Rockwell Automation Publication 5094-IN016B-EN-P - August 2022... -
Page 8: Disconnect Wires From The Terminal Base
1. Turn the screwdriver counter-clockwise to open the terminal. Screw 2. Remove the wire. 1. Insert and hold a screwdriver in the right-side terminal. Spring 2. Remove the wire. 3. Pull out the screwdriver. Screw-type TB Spring-type TB Rockwell Automation Publication 5094-IN016B-EN-P - August 2022... -
Page 9: Wiring Diagrams
4-wire current/HART transmitter – SA– SA– DC PSU1 18…32V DC – 3-wire AC/DC PSU2 24V_0 24V_1 24V_2 24V_3 HART transmitter – Do not wire AC power directly to the module. Shield Bar Rockwell Automation Publication 5094-IN016B-EN-P - August 2022... -
Page 10: Power The System
Worn contacts may create electrical resistance that can affect module operation. Press and hold the release lever on the top of the module. Be sure to press the entire lever evenly. Pull the module off the terminal base. Rockwell Automation Publication 5094-IN016B-EN-P - August 2022... -
Page 11: Replace The Module
Provides specifications for the shield bar and jumper accessories. Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1 Provides general guidelines for installing a Rockwell Automation industrial system. Product Certifications website, rok.auto/certifications Provides declarations of conformity, certificates, and other certification details. -
Page 12: Rockwell Automation Support
