POWERMORE 250 ASSEMBLY INFORMATION
Pivot e-bikes build with the Bosch Smart System are compatible with the PowerMore 250 range extender bat-
tery. This document will guide you through your options for installing the range extender. Refer to
ebike.com
for product manuals and more information on the operation and care of your PowerMore 250.
Note on use:
Depending on the driving situation, the maximum power of the drive unit may be slightly reduced when
the PowerMore 250 is used on its own. For more range and the full power of the drive unit, start your ride
with your PowerTube internal battery fully charged and PowerMore 250 fully charged and connected.
pivotcycles.com

TABLE OF CONTENTS

info@pivotcycles.com
PAGE
1
2
3
4
5
6
1.877.857.4868
www.bosch-

Advertisement

loading
Need help?

Need help?

Do you have a question about the PowerMore 250 and is the answer not in the manual?

Questions and answers

Related Manuals for Bosch PowerMore 250

Summary of Contents for Bosch PowerMore 250

  • Page 1: Table Of Contents

    Depending on the driving situation, the maximum power of the drive unit may be slightly reduced when the PowerMore 250 is used on its own. For more range and the full power of the drive unit, start your ride with your PowerTube internal battery fully charged and PowerMore 250 fully charged and connected.

  • Page 2: Powermore 250 & Mounting Parts

    • If using a shock that is not spec from Pivot, the PowerMore 250 may need to be moved forward for clearance with an additional offset bracket so far that a 150mm cable will not reach. A longer cable will be required.

  • Page 3: Preparing Your Shuttle For Powermore 250

    PREPARING YOUR SHUTTLE FOR THE POWERMORE 250 1.) Check the e-bikes configuration in the Diag- 2.) This needs to be turned on via a configuration nostic Tool or the Flow App. Under "PowerMore request through the Bosch Diagnostic Tool by a Ready:"...

  • Page 4: Powermore 250 Installation

    POWERMORE 250 INSTALLATION Before you begin using your PowerMore 250 Range Extender test the battery and fully charge it. For additional information refer to www.bosch-ebike.com. The Bosch Water Bottle Cage will not clear the shock reservoir if used without an additional offset bracket.

  • Page 5: Powermore 250 Installation With Offset Bracket

    POWERMORE 250 INSTALLATION WITH OFFSET BRACKET Before you begin using your PowerMore 250 Range Extender test the battery and fully charge it. For additional information refer to www.bosch-ebike.com. 1.) Install the offset bracket with the offset portion 2.) Prepare the bracket for installation. Making at the top.

  • Page 6: Bosch Water Bottle Cage Use

    150mm may be needed for some configurations. BOSCH WATER BOTTLE CAGE USE 1.) With the use of an offset bracket the Bosch 4.) Slide the Bosch Water Bottle Cage into the Water Bottle Cage can be used in place of the bracket from the drive side until you hear it click PowerMore 250 Range Extender.

  • Page 7: Powermore 250 Removal

    2.) Press the sides of the cable connector to re- remove it from the charging port. move the cable from the PowerMore 250 battery. 3.) Press down on the bracket's release button 4.) To reinstall the Charging Port Cover you...
  • Page 8 10.) Or reinstall the original water bottle bolts. cage or mount a tool to the frame remove the PowerMore Mounting Bracket. For additional information on the Bosch Smart For additional information on your Shuttle or System please scan the QR Code below.
