Replacement Guide
H&M – OKI MB 492DN
Manual for Field Engineers
user

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MB 492DN and is the answer not in the manual?

Questions and answers

Related Manuals for Oki MB 492DN

Summary of Contents for Oki MB 492DN

  • Page 1 Replacement Guide H&M – OKI MB 492DN Manual for Field Engineers user...

  • Page 2: Table Of Contents

    History ............................2 Appendix ............................. 2 Overview ......................3 On site visit at customer store – Replacement OKI MB 492DN ......3 Prior to arriving onsite to perform work ................3 Prior to commencing your work on site ................3 Replacement and configuration of OKI MB 492DN ............

  • Page 3: Document Management

    Operation Manual Replacement Guide OKI MB 492DN Document management History Version: Date: Author: Changes: 21.10.2015 Bökenheide, Thomas First release 14.03.2016 Thomas McDaniel Added defective printer return and figures Appendix Name Version Patch cable color code GCCC | November 7, 2016 | Partner confidential | ©Wincor Nixdorf International GmbH...

  • Page 4: Overview

    If any information in this manual is missing, please get in contact with Service Desk. 2 On site visit at customer store – Replacement OKI MB 492DN 2.1 Prior to arriving onsite to perform work ...

  • Page 5: Replacement And Configuration Of Oki Mb 492Dn

    Operation Manual Replacement Guide OKI MB 492DN 2.3 Replacement and configuration of OKI MB 492DN 1. Power Down the unit. Hold down the power switch to turn off the power. Figure 1. Power switch 2. Remove printer power, network and phone / fax connections from back panel and set the old printer aside.
  • Page 6 Operation Manual Replacement Guide OKI MB 492DN 5. On the replacement unit, open the access door by pressing the open button and open the top cover. Figure 3. Open the top cover 6. On the original/defective unit remove the image drum/toner. Remove the Drum upward slowly.
  • Page 7 Operation Manual Replacement Guide OKI MB 492DN Figure 5. Install drum/toner 8. IMPORTANT! DO NOT RETURN SHIP PRINTER WITH TONERS/DRUM INSTALLED. Do not package the defective printer for return without first ensuring the toner cartridges/drums have been removed! Failure to remove these will cause costly damage to the unit during shipping. If the replacement printer came with toners already installed you are to leave those toners with the store manager for use later and instead port over the original toners into the replacement printer.
  • Page 8 Operation Manual Replacement Guide OKI MB 492DN 9. Close all covers and connect power, Ethernet and fax lines to the printer. Then power on the printer. 10. Press <Device Settings> on the touch panel Figure 7. Device Settings button 11. Press [Easy Setup ] 12.

  • Page 9: Prior To Leaving Site

    Operation Manual Replacement Guide OKI MB 492DN 22. Enter at the button [Manual] today’s date and time. 23. Move back to the easy setup screen and select [Fax Setting]. Select [Fax Number] on the touch panel. 24. Using the keypad and on screen options, enter the fax number. Ask the Store Manager for the fax number.
  • Page 10 Operation Manual Replacement Guide OKI MB 492DN  Provide the details of your repair and testing via your PDA.  Clean up the work area before leaving store and place everything back neatly. All replaced parts and packaging must be removed from the store.
