PaloAlto Networks PA-410R-5G Quick Start Manual

PA-410R & PA-410R-5G
1
Before You Begin
Use this document to install and begin setting up your Palo Alto Networks PA-410R or PA-410R-5G device. Refer to the product's
hardware reference at https://docs.paloaltonetworks.com/hardware
procedures for installing the firewall.
◼
Verify that the installation site has adequate air circulation and DC power.
◼
Have the following equipment ready:
◼
1/8" flat head screwdriver for terminal block screws.
◼
Crimp tool for #10 ground lug and 8 AWG wire.
◼ Wire strippers for 8 AWG and 16 AWG wire.
◼
Unpack the equipment and verify that you received the following items:
Qty Description
1 PA-410R or PA-410R-5G firewall.
2 DC terminal block and connector.
1 8 AWG Single-Hole or Dual-Hole Ground lug.
1 USB to RJ-45 Console cable.
1 Shielded RJ-45 CAT6 Ethernet cable for management (MGT) port access.
4 (5G only) Multi-band antennas.
1 Sheet, Limited Warranty.
1 China RoHS declaration.
2
Connect the Ethernet Cables
The firewall requires the installation of cable glands and waterproof cabling (purchased separately) to ensure that the device
remains safe in harsh conditions.
You must have purchased PAN-PA-RGD-GLND1 or have access to other standard M12 cable glands to complete this step.
1 Using a flat/Phillips combo screwdriver, unscrew the four screws on the bottom panel of the firewall.
2 On the removed panel, unscrew the stopping plug that lines up with the Ethernet port you are connecting to.
docs.paloaltonetworks.com
for safety information, specifications, and more detailed
(Figure
Figure 1
Figure 2
3 Unpack the Ethernet cable glands. There are four items — an end cap, panel connector, seal, and grommet.
3)
(Figure
If using your own cable glands, ensure that your seal corresponds to the diameter of your Ethernet cable.
4 Install the seal onto the shorter end of the panel connector. Make sure to push the seal until it is flush against the
connector. Screw the shorter end of the panel connector into the hole that corresponds to the Ethernet port being
connected. Make sure that the connector is secure by torquing to 2 Nm.
1)
5 Thread the (unterminated) Ethernet cable through the end cap. This is used to secure the cable gland once the panel is
reattached at the end of
panel connector, terminate the cable end, and gently push it into the Ethernet port until you hear a click.
2)
(Figure
2.2
6 Repeat Steps through
7 Leave the front panel removed and continue to
Page 1 of 5
Quick Start Guide
Figure 3
Cable Diameter Seal
4.8 - 6.2 mm 5.0 mm
7.3 - 9.0 mm 8.5 mm
6.0 - 7.5 mm 6.7 mm
4.8 - 9.0 mm 5.0 / 8.5 / 6.7 mm
4)
(Figure
Figure 4
Step 3
. Feed the Ethernet cable through the gray grommet. Move the Ethernet cable through the
Figure 5
2.5
for any additional Ethernet cables.
Step 3 — Connect the Power Cables
5)
(Figure
