Summary of Contents for BabySense Prisma NVBM50
- Page 1 Prisma 5” HD Split Screen Video Baby Monitor User Manual Wireless Digital Video Baby Monitor Watch, Listen and Talk to Your Baby Models: Prisma - 1 Camera Prisma - 2 Cameras For any product related question please contact us at: support@babysensemonitors.com www.babysensemonitors.com...
- Page 2 02-24 Prisma 5” Split Screen United Kingdom Authorised Representative European Authorised Representative OBELIS UK OBELIS s.a info@obelis.co.uk email@obelis.net Sandford Gate East Point Business Park Oxford OX4 6LB U.K. Boulevard Général Wahis 53, 1030 Brussels, Belgium Tel +44.1491.378012 Tel +(32) 2.732.59.54 Fax +(32) 2.732.60.03...
-
Page 3: Warnings And Safety Instructions
1. Warnings and Safety Instructions Follow these safety precautions to prevent fire, injury or damage to the product. Read and keep instructions: It is very important that you read all the safety and operating instructions before the FirstWatch Video Monitor is operated. - Page 4 • VENTILATION: This product should not be used on a bed, sofa, rug or similar surface that may block the ventilation or speaker openings, or be placed in an enclosed area, such as a bookcase or drawer that may impede air flow. Never cover the product with clothes, towels, blankets or any other item.
- Page 5 Always dispose of your product (with the non removable pre-installed battery) at the end of their life in an environmentally responsible way and in accordance with your local waste disposal requirements. All cardboard and paper packaging materials should be recycled in accordance with your local council waste regulations. Thank you for choosing Babysense Video Monitor from Hisense Ltd.
-
Page 6: Pack Contents
2. Overview 2.1 Pack Contents • Parent Unit x 1 • Baby Unit (Camera) x 1 (x2 in 2 camera model) • AC Power Adapter x 2 (x3 in 2 camera model) • Wall mounting screw set x 1 (x2 in 2 camera model) •... -
Page 7: Baby Unit Overview
2.2 Baby Unit Overview 18. Infrared LEDs 19. Lens 20. Light Sensor (Night Vision) Power LED 22. Microphone 23. Speaker 24. Night Light 25. Temperature Sensor 26. ON/OFF Switch 27. Charging Port 28. PAIR Button (On the Bottom) 3. Getting Started 3.1 Powering the Baby Unit (Camera) •... -
Page 8: Charging The Parent Unit
• Press and hold the Power button (1) on the top left side of the Parent Unit for 5 seconds to turn the unit on. • Once the Parent Unit is turned on, the green power LED (3) will light up and “FirstWatch” logo will display on the LCD. •... - Page 9 • Once both the Baby and Parent Units are switched on, the display on the Parent Unit will show the video captured by the Baby Unit(s). • Baby Unit(s) are paired to the Parent Unit when supplied. There is no need to pair the units again unless the Baby Unit loses its link with the Parent Unit.
- Page 10 4.2 Lullaby & White Noise Setting You can soothe your baby to sleep by playing 5 pre-programmed lullabies from the Baby Unit. The monitor also features White Noise, which is an effective way to soothe a crying infant and lull your newborn to sleep. The Lullaby and White Noise features are controlled remotely from the Parent Unit.
- Page 11 4.3 VOX Mode When using the VOX function, the sound and video transmission will stop (standby mode) if the Baby Unit does not register any sound within 30 seconds. While in standby mode, the LCD screen turns off. Once the Baby Unit registers a sound, louder than the set sensitivity level, it will automatically start transmitting the signal (sound and video) to the Parent Unit and the LCD screen will turn on.
-
Page 12: Brightness Adjustment
4.4 Brightness Adjustment 1. Press to access the menu, choose and press 2. Navigate with to select the desired brightness 3. Press to exit the menu 4.5 Pairing the Baby Unit (Camera) with the Parent Unit The Baby Unit is paired to the Parent Unit when supplied. There is no need to pair the units again unless the Baby Unit loses its link with the Parent Unit. -
Page 13: Temperature Scale Setting
4.6 Deleting the Baby Unit (Camera) 1. Press to access the menu, choose 2. Navigate with to select DELETE option 3. Navigate with to select the camera you want to delete 4. Navigate with to select DELETE and press 5. Press to exit the menu 4.7 Temperature Scale Setting The temperature reading from the temperature sensor (25) at the back of the Baby Unit will be displayed on the top of the screen. -
Page 14: Temperature Alert Setting
4.8 Temperature Alert Setting This function is to alert if the temperature in baby’s room is too low or too high. NOTE: The temperature alert default setting is: <15 °C/59 °F and >31 °C/89 °F. To change the temperature alert levels, please follow the below instructions: 1. -
Page 15: Timer Setting
4.10 Timer Setting 1. Press to access the menu, choose and press 2. Navigate with to select and press 3. Navigate with to select the desired time 4. Press button to confirm 5. Press to exit the menu Power Power Save Save 4.11 Warning Alert Volume Setting... -
Page 16: Frequency Setting
4.12 Frequency Setting This function allows you to choose desired frequency format 60Hz (for US) or 50Hz (for EU). The screen may flicker in some lighting environments and changing the Frequency Setting helps lower the flickering effect. 1. Press to access the menu, choose and press 2. -
Page 17: Volume Adjustments
4.14 Volume Adjustments • Press the VOLUME UP/DOWN buttons (5) to increase/decrease the sound coming out of the parent unit. NOTE: In normal use, it is recommended to set the volume at level 3 and below. Higher volume levels are intended for loud/noisy environments. NOTE: If the volume on the Parent Unit is set too high and the Baby and Parent Units are close to each other, a high-pitched noise may be heard (also known as feedback or static noise). - Page 18 4.16 Zoom Mode This baby monitor features two-zoom levels: x2 and x4. 1. Press the button once to activate “x2” zoom option 2. Press the button twice to activate “x4” zoom option 3. Press the button again to exit zoom option NOTE: This function is not available when SPLIT SCREEN mode is ON.
-
Page 19: Maintenance
4.20 Talk to Baby • Press and hold the Talk Back Button (12) and speak into the Microphone (13) to talk to your baby or partner in the baby’s room via Baby Unit. • Release the button when you are finished talking. NOTE: While the “Talk to Baby”... - Page 20 Problem Possible cause/solution A high-pitched sound is heard from • The Baby Unit and Parent Unit may be too close to each other. Move them further apart. the units (feedback, static) • The volume on the Parent Unit may be set too high. Lower the volume. Cannot hear the baby sounds on •...
-
Page 21: Specifications
7. Specifications Product Model • NVBM50 Frequency • 2.4GHz FHSS Type of Modulation • GFSK Data Rate • 4 Mbps Channel Bandwidth • 3.5 MHz Transmission Range • Up to 980 feet / 300 meters (open space – no obstructions) Input Voltage •... -
Page 22: Fcc Statements
8. FCC Statements This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 23: Warranty Terms
10. Warranty Terms We take quality very seriously. This is why all of our products come with a one-year warranty from the original purchase date against defects in workmanship and materials. If you have warranty or support issues, please contact our customer service. IMPORTANT: Please retain your purchase receipt and attach to the back page of this user manual as you will need to produce this if warranty service is required. - Page 24 Prisma 5” HD Split Screen Video Baby Monitor Made by Hisense Ltd. 27 Shaked St. Hevel Modi’in Industrial Park, 7319900 ISRAEL Tel +972-3-9566604 www.hisense.co.il www.babysensemonitors.com...
