BIS-410
Bistable relay
with timer
Do not dispose of this device in the trash along with other waste!
According to the Law on Waste, electro coming from households free of charge and can
give any amount to up to that end point of collec� on, as well as to store the occasion of
the purchase of new equipment (in accordance with the principle of old-for-new, regard-
less of brand). Electro thrown in the trash or abandoned in nature, pose a threat to the
environment and human health.
Purpose
Electronic bistable pulse relay BIS-411 allows switching on or off
the lighting or other device from several different points by pa-
rallel connected, momentary (bell) control switches.
Functioning
The receiver is switched on after a current pulse caused by pres-
sing any momentary (bell) button connected to the relay.
The receiver is turned off after the next impulse or automatically
after the set off time.
A longer pressing of the momentary button (lasting at least 2
seconds) turns on the relay permanently.
The relay will be turned off only after pressing the momentary
button again (or after a power failure).
F&F Filipowski sp. j.
Konstantynowska 79/81, 95-200 Pabianice, POLAND
phone/fax (+48 42) 215 23 83 / (+48 42) 227 09 71
www.fif.com.pl; e-mail: biuro@fif.com.pl
- 1 -
