Saxby Lighting Jude CCT Wall Instruction Manual

Wiring
Having correctly identified the wiring from your existing light fitting, pull the mains wire through the hole and connect to the
quick fit connection block inside the product in the following way:
SUPPLY
INSERT CABLE
SWITCHED LIVE
EARTH (GREEN/YELLOW)
NEUTRAL
Technical data
Supply
220-240 V~, 50 Hz
Voltage:
Bulb
8W LED module CCT, 3000/4000/6000K
Type:
Non-replaceable light source
Conformity with all relevant UKCA Directive requirements.
Conformity with all relevant EC Directive requirements.
This product is Class 1, must be connected to earth.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or local store for recycling advice.
This product is not suitable for dimming.
This product is rated at IP44.
44
IP
Care and Safety
We recommend cleaning with a soft dry cloth. Do not use solvents or abrasive cleaners as these could damage the finish.
For your safety, always switch off the power supply before changing lightbulbs, or cleaning.
This bulb is protected by a PC shade. This part must be replaced immediately should the PC
shade become cracked or damaged. This fitting must not be used without the PC shade in place.
Replace Cracked Shade
For further information, please visit https://www.lighting-info.co.uk/113573
V1 25/09/2024
UK Manufacturer: BH17 7BY
EU Manufacturer: Brilliant AG,
Brilliantstrasse 1, D-27442 Gnarrenburg
PUSH DOWN
Check that...
LIGHT FITTING
• You have correctly identified
the wires.
• The connections are tight.
BROWN (L)
• No loose strands have been
GREEN/YELLOW
left out of the connection
BLUE (N)
block.
This product contains a light source of energy efficiency class D.
Non-replaceable control gear
Instruction manual
Jude CCT Wall
113573
www.saxbylighting.com
