Sealey LED201G Quick Start Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS &
CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO
MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR
FUTURE USE.
1. SAFETY
1.1. GENERAL
Ensure the torch is fully charged before initial use.
9
DO NOT turn the torch on when it is being charged.
8
DO NOT shine directly into your, other person's or an animal's eyes.
8
DO NOT allow children to use the torch.
8
DO NOT handle or move the torch whilst it is being charged.
8
DO NOT use the torch if you suspect that the battery, the torch casing or the cable is damaged. Consult your Sealey Stockist.
8
DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery,
8
subsequently recharge the battery at least once every six months of non-use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or fire:
‰
DO NOT attempt to open, dismantle, modify or service the battery pack.
8
DO NOT crush, puncture, short external contacts or dispose of in fire or water.
8
DO NOT expose to temperatures above 40°C or below - 10°C.
8
DO NOT expose to direct sunlight for long periods of time.
8
DO NOT expose to moisture.
8
WARNING! DO NOT place the torch face down while in use.
‰
Replace only with the battery pack designated for this product.
9
Recycle or dispose of used battery as stipulated by local regulation.
9
If the electrolyte in the cells gets on your skin, wash thoroughly with water. If it gets in your eyes, rinse thoroughly with cool water and
9
seek immediate medical attention.
2. INTRODUCTION
Super bright SMD LED top light and SMD LED torch. Light body twists 360° and light arm tilts 180° to provide light at any angle.
Features a magnet on the rear and rubber covered magnet on the base, which allow hands-free operation. Lithium-ion battery for
longer life, no memory effect and a much slower discharge than traditional Ni-MH batteries. Easy to read charge indicator displays the
battery level during use and while charging. Long operating times. Charges via a USB Type-C cable (Supplied).
3. SPECIFICATION
Attribute
Battery 3.7V 0.8Ah Li-ion
Charging Time 2hr
IP Rating IP52
LED Type 1W SMD + 1W SMD
Lumen Output Side(High/Low)/Top - (200/100)/100lm
Nett Weight 0.094kg
Operating time Side(High/Low)/Top - (2/4)/2.5hr
4. OPERATION
4.1. PRESS ON/OFF TO OPERATE (FIG.3)
4.1.1. First press: Low beam
4.1.2. Second press: High beam
4.1.3. Third press: switches on end torch
4.1.4. Fourth press: switches everything off.
4.2. CHARGING (FIG.2)
4.2.1. Open the cover on the side of the mini light.
4.2.2. Plug the USB-C into a 5V USB outlet.
4.2.3. Insert Type-C connector into the charging port on the side,
4.2.4. For a full charge, time is approximately 2 / 2.5hrs. depending on model.
© Jack Sealey Limited
LED TWIST RECHARGEABLE INSPECTION LIGHT
1W & 1W SMD, 200lm / 2W & 1W SMD, 400LM
MODEL NOS.:LED201G / LED401G
LED201G
3.7V 2.0Ah Li-ion
2.5hr
IP52
2W SMD + 1W SMD LED
Side(High/Low)/Top - (400/200)/100lm
0.143kg
Side(High/Low)/Top - (2/4)/6hr
Original Language Version
LED401G
LED201G LED401G
LED201G Shown
Issue 1 10/07/24
