Sealey LED220UV Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
Instruction
Manual
1. SAFETY
1.1. GENERAL
Ensure the lamp is fully charged before initial use.
9
DO NOT turn the lamp on when it is being charged.
8
DO NOT shine directly into your, other person's or an animal's eyes.
8
DO NOT allow children to use the lamp.
8
DO NOT handle or move the lamp whilst it is being charged.
8
DO NOT use the lamp if you suspect that the battery, the lamp casing or the cable is damaged. Consult your Sealey Stockist.
8
DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery,
8
subsequently recharge the battery at least once every six months of non-use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or fire:
‰
DO NOT Attempt to open, dismantle, modify or service the battery pack.
8
DO NOT Crush, puncture, short external contacts or dispose of in fire or water.
8
DO NOT Expose to temperatures above 40°C or below -10°C.
8
DO NOT Expose to direct sunlight for long periods of time.
8
DO NOT Expose to moisture.
8
WARNING! Do not place the lamp face down while in use.
‰
Replace only with the battery pack designated for this product.
9
Recycle or dispose of used battery as stipulated by local regulation.
9
If the electrolyte in the cells gets on your skin, wash thoroughly with soap and water. If it gets in your eyes, rinse thoroughly with
9
cool water and seek immediate medical attention.
2. INTRODUCTION
Powerful 3W COB with 1 x SMD and 2 x UV SMD. USB rechargeable lithium-ion battery with small green/red charging indicator light. Made from
Aluminium, anodized and finished with rubber coating for a more premium feel. A strong magnet in the pocket/belt clip allows for hands-free use
as well as a second strong magnet in the base. Features two longwave UV-A SMDs at 390-400nm.
3. SPECIFICATION
Model no .............................................................. LED220UV
Battery ............................................................3.7V 2200mAh
Charging time.................................................................. 3hrs
LED qty ..................................................................................
1 x 3W COB, 1 x Regular 1W SMD, 2 x UV-A 390-400nm SMD
Length ............................................................................11cm
Lumen output ............................................................... 220lm
4. CHARGING
4.1. The battery fitted to this light is considered to be a consumable item and its ability to accept charge will reduce over time. We will
warranty it against mechanical and electrical defect for a period of one year, this does not cover fair wear and tear. If the battery is not
properly charged before first use, or regularly conditioned, its capacity will diminish. Under these circumstances we will not replace the
battery even if it is less than one year old.
4.2.
Connect the charger into the charge socket on the lamp, see fig.1. Plug into power supply and turn on, the red charge LED on the lamp
next to the charging port will light as the battery charges. When fully charged the LED turns green.
4.3.
When the battery has fully charged (approx 3hrs) Disconnect from mains supply.
Note: The Lithium battery does not suffer from memory effect and once fully charged may be stored for up to six months without another
charge.
5. OPERATION
5.1. Press on/off switch (see fig.1):
First press: lights top 1W SMD, Second press: lights front 3W COB, Third press: switches everything off. UV lights: long press of
switch.
© Jack Sealey Limited
3W COB + 1 SMD RECHARGEABLE ALUMINIUM
POCKET LIGHT WITH UV
LED220UV
MODEL NO:
fig.1
Original Language Version
LED220UV Issue:1 11/06/20
