Cisco Aironet 6.5-dBi Diversity Patch Antenna
(AIR-ANT2465P-R)
This document outlines the specifications, describes the AIR-ANT2465P-R 6-dBi patch antenna, and
provides instructions for mounting it. The antenna operates in the 2.4-GHz frequency range and is
designed for use in both indoor and outdoor environments.
The following information is provided in this document.
Technical Specifications, page 2
•
System Requirements, page 3
•
Installation Guidelines, page 4
•
Installing the Antenna, page 5
•
Obtaining Documentation and Submitting a Service Request, page 7
•
Corporate Headquarters:
Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
© 2006 Cisco Systems, Inc. All rights reserved.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cisco Aironet AIR-ANT2465P-R
Summary of Contents for Cisco Aironet AIR-ANT2465P-R
- Page 1 Installation Guidelines, page 4 • Installing the Antenna, page 5 • Obtaining Documentation and Submitting a Service Request, page 7 • Corporate Headquarters: Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA © 2006 Cisco Systems, Inc. All rights reserved.
- Page 2 Operating temperature range –22°F to 158°F (–30°C to 70°C) Storage temperature range –40°F to 185°F (–40°C – 85°C) Environment Indoor/outdoor Left Antenna Azimuth and Elevation Pattern Right Antenna Azimuth and Elevation Pattern Cisco Aironet 6.5-dBi Diversity Patch Antenna (AIR-ANT2465P-R) 78-16942-01...
- Page 3 System Requirements System Requirements This antenna is designed for use with Cisco Aironet access points and bridges but can be used with any 2.4-GHz Cisco Aironet radio device that utilizes an RP-TNC connector. Safety Precautions Translated versions of the following safety warnings are provided in the Safety Warnings for Cisco Aironet Antennas, which is available at http://www.cisco.com.
- Page 4 • cause signal interference because they operate in the same frequency range as the device your antenna is connected to. Install the antenna in a vertical orientation to maximize signal propagation. • Cisco Aironet 6.5-dBi Diversity Patch Antenna (AIR-ANT2465P-R) 78-16942-01...
- Page 5 A Phillips screwdriver • A drill • • A #29 ((0.136-in (3.45 mm)) drill bit (For drywall installation, other surfaces may require a different size) A pencil • • A small mallet or hammer Cisco Aironet 6.5-dBi Diversity Patch Antenna (AIR-ANT2465P-R) 78-16942-01...
- Page 6 After the cable is attached to the antenna, make sure that the connections are sealed (if outdoors) to prevent moisture and other weathering elements from affecting performance. Cisco recommends using a coax seal (such as CoaxSeal) for outdoor connections. Silicon sealant or electrical tape are not recommended for sealing outdoor connections.
- Page 7 Cisco currently supports RSS Version 2.0. Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and other countries. A listing of Cisco's trademarks can be found at www.cisco.com/go/trademarks. Third party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company.
