Summary of Contents for Hyundai HY4B26

  • Page 1 PETROL LEAF BLOWER HY4B26 User Manual...
  • Page 2: Table Of Contents

    INDEX CONTENTS PAGE NO.S SAFETY 3 - 8 PART LOCATIONS ASSEMBLY PRE OPERATION CHECKS 10 - 11 STARTING PROCEDURE STOPPING PROCEDURE USING THE MACHINE MAINTENANCE 14 - 17 TROUBLESHOOTING 18 - 19 SPECIFICATION RECYCLING & PRODUCT DISPOSAL DECLARATION OF CONFORMITY CONTACT DETAILS WARRANTY MANUAL UPDATES...
  • Page 3: Safety

    1. SAFETY General Safety Notes. The operator of the machine is responsible for, and has a duty of care in making sure that the machine is operated safely and in accordance with the instructions in this user manual. Keep the manual safe and pass it on if the machine is loaned or sold to another user.
  • Page 4 1.10 Carbon Monoxide (where applicable). 1.11 Carbon monoxide is a colourless and odourless gas. Inhaling this gas can cause death as well as serious long term health problems such as brain damage. 1.12 The symptoms of carbon monoxide poisoning can include but are not limited to the following;...
  • Page 5 1.30 Fueling/De-fueling (where applicable). CAUTION ALL FUELS ARE FLAMABLE 1.31 ALWAYS fuel and defuel in a well ventilated area outside of buildings. 1.32 ALWAYS wear correct, suitable and fit for purpose Personal Protective Equipment (PPE), suggested items are but not limited to safety gloves, overalls. 1.33 When fueling/de-fueling ALWAYS avoid inhaling fumes.
  • Page 6 1.50 Batteries (where present). 1.51 Batteries present a risk if they become damaged by the possible leaking of electrolyte. This electrolyte is an acid and can cause serious burn injuries. Care should be taken when working on or near them. NOTE the electrolyte may be in a liquid or gel form.
  • Page 7: Machine Specific Safety

    1.70 Noise (where applicable). 1.71 The operating noise of the machine can damage your hearing. Wear hearing protection such as earplugs or ear defenders to protect your hearing. Long-term and regular users are advised to have hearing checked regularly. Be especially vigilant and cautious when hearing ear protection because your ability to hear alarm warnings will be reduced.
  • Page 8 1.93 Make sure you keep this manual handy so you may refer to it whenever questions arise and ensure you pass this manual on if the machine is loaned or sold. 1.94 Correct Personal Protective Equipment (PPE) MUST be worn at all times when operating or repairing this machine.
  • Page 9: Part Locations

    2. PART LOCATIONS Fuel Filler Cap Primer Bulb Choke Lever Air Filter Handle Throttle Trigger Ignition Switch Air Tube Exhaust Spark Plug Oil Filler Cap/Dipstick Recoil Starter Handle...
  • Page 10: Assembly

    3. ASSEMBLY WARNING To prevent an accidental start that could cause serious personal injury, always disconnect the engine spark plug HT lead from the spark plug when assembling parts. WARNING DO NOT attempt to modify this product or create accessories not recommended for use with this product.
  • Page 11 To add engine oil, remove the attachment from the power head and place of a flat, level surface. Unscrew the oil filler cap. Slowly pour 60ml of semi-synthetic 4 stroke SAE 10W30 engine oil into the crank case until it reaches the top of the oil fill hole. DO NOT overfill.
  • Page 12: Starting Procedure

    5. STARTING PROCEDURE WARNING This machine is shipped without oil and fuel. You MUST ensure all fluid levels are correct before operation otherwise you may cause serious engine damage that will not be covered by the warranty. FROM COLD Place the machine on flat level ground before starting. Turn the ignition switch to the ‘I’...
  • Page 13: Using The Machine

    7. USING THE MACHINE WARNING NEVER run the unit without the blower tubes installed and the air inlet cover securely closed. Use of an improperly assembled unit may result in serious personal injury. Always hold the blower away from your body with the handle in your right hand. Keep clearance between your body and the machine.
  • Page 14: Maintenance

    8. MAINTENANCE WARNING Before cleaning, inspecting or repairing your unit, you MUST make sure that the engine has stopped and allowed to cool. You MUST disconnect the spark plug HT lead cap to prevent any accidental starting. CAUTION ALWAYS refuel in a well-ventilated area with the engine off and the spark plug HT cap removed.
  • Page 15: Air Filter

    AIR FILTER CAUTION The engine MUST NOT be run without an air filter otherwise piston and/or cylinder damage can occur. This type of damage will NOT be covered under warranty. Maintaining the air filter is very important. If dirt is allowed to get in to the engine through improperly installed, serviced or inadequate filter elements, it can damage and wear out the engine.
  • Page 16 The spark plug gap should be 0.6 – 0.8mm. Check the gap using a feeler gauge and adjust as necessary by carefully bending the side electrode to achieve the correct gap. 0.6 – 0.8mm 7.10 Refit the cleaned and adjusted spark plug by hand to avoid cross-threading. 7.11 After spark plug seats then tighten as necessary but avoid over-tightening.
  • Page 17: Engine Idle Speed

    ENGINE IDLE SPEED 7.18 Start the engine and run at idle speed until operating temperature is reached. Usually around 2 to 3 minutes. 7.19 Use a screwdriver to adjust the engine idle speed to 3000rpm ± 200rpm 7.20 Make small adjustments, turn clockwise to increase the idle speed and anticlockwise to decrease the engine idle speed.
  • Page 18: Troubleshooting

    7.30 Change the engine oil following the procedure 7.13 to 7.17. 7.31 Remove the spark plug and pour a tablespoon of fresh engine oil down the cylinder bore. 7.32 Pull the recoil starter handle three to four times to distribute the oil along the cylinder bore, then refit the spark plug.
  • Page 19: Specification

    Compression ratio is all OK Engine is overheating Stop the engine and let it cool down. When restarting avoid long periods at heavy load and high revs Water in fuel Drain and replace fuel Carbon clogged exhaust Clean exhaust Fuel mixture too lean Adjust the carburetor Engine overheating Cylinder covered with carbon...
  • Page 20: Recycling & Product Disposal

    11. RECYCLING & PRODUCT DISPOSAL We do not offer a takeback scheme for the recovery of Waste Electrical Electronic Equipment (WEEE) & Batteries. Instead the responsibility to dispose of WEEE and or Batteries is passed onto you by So when it becomes necessary to dispose of your machine you must take it to your local Civic Amenity Site.
  • Page 21: Declaration Of Conformity

    12. DECLARATION OF CONFORMITY Genpower Ltd confirms that this Hyundai petrol pressure washer conforms to the following CE directives: 2006/42/EC Machinery Directive 2004/108/EC EMC Directive 2000/14/EC Noise Emissions Directive 97/68/EC NRMM Emissions Directive EC DECLARATION OF CONFORMITY The undersigned. As authorised by:...
  • Page 22: Contact Details

    13. CONTACT DETAILS POSTAL ADDRESS Genpower Ltd, Isaac Way, London Road, Pembroke Dock, Pembrokeshire. SA72 4RW. UK. TELEPHONE +44 (0) 1646 687880 +44 (0) 0164 686198 TECHNICAL EMAIL aftersales@genpower.co.uk WEBSITE www.hyundaipowerequipment.co.uk 14. WARRANTY To register your machine for the manufacturer's warranty, please visit https://www.hyundaipowerequipment.co.uk/warranty 15.
