MC-8
STEP
DISTANCES
AUTO DISTANCES
FRONT LEFT 12.0ft
CENTER 10.5ft
FRONT RIGHT 12.0ft
SIDE RIGHT
REAR RIGHT ERROR
REAR LEFT
SIDE LEFT
SUBWOOFER
When the MC-8 is finished calibrating
speaker distances, the AUTO DISTANCES
screen is displayed, indicating the results
for each individual speaker.
• A value indicates that no errors occurred
5
during the calibration procedure.
• An ERROR message indicates that a value
was calculated, but at least one error
occurred during the calibration proce-
dure.
• Press the
light the speaker calibration parameter
you want. Then press the
view more detailed results for the
selected speaker. A message similar to
the one shown above will display.
• Refer to the table on page 3-50 for infor-
mation about all possible speaker calibra-
tion messages.
FRONT LEFT
OK
Refer to the table on page
3-50 for information about
4.5ft
all possible speaker calibra-
tion messages.
6.0ft
4.5ft
N/A
or arrow button to high-
button to
DISTANCES & LEVELS
AUTO SPEAKER SETUP
DISTANCES OK
LEVELS ERROR
AUTO VALUES APPLIED
PRESS TO VIEW
DETAILS
When the MC-8 is finished calibrating
speaker distances and output levels, the
AUTO SPEAKER SETUP screen is displayed,
indicating the results for each calibration
procedure.
• An OK message indicates that no errors
occurred during the calibration proce-
dure.
• An ERROR message indicates that values
were calculated, but at least one error
occurred during calibration.
• Press the or arrow button to high-
light the desired calibration procedure.
DISTANCES displays the AUTO DIS-
TANCES screen shown in the left column
of this table.
LEVELS displays the AUTO LEVELS screen
shown in the right column of this table.
• Press the arrow button to select this
procedure.
• Refer to the instructions in the appropri-
ate column to view more detailed results
for each individual speaker.
LEVELS
AUTO LEVELS
FRONT LEFT
FRONT LEFT -2.0dB
CENTER ERROR
Refer to the table on page
FRONT RIGHT -2.0dB
3-50 for information about
SIDE RIGHT -4.5dB
all possible speaker calibra-
REAR RIGHT -3.0dB tion messages.
REAR LEFT -3.0dB
SIDE LEFT -4.5dB
SUBWOOFER N/A
When the MC-8 is finished calibrating
output levels, the AUTO LEVELS screen is
displayed, indicating the results for each
individual speaker.
• A value indicates that no errors occurred
during the calibration procedure.
• An ERROR message indicates that a value
was calculated, but at least one error
occurred during the calibration proce-
dure.
• Press the or arrow button to high-
light the desired speaker calibration
parameter. Then, press the
button to view more detailed results for
the selected speaker. A message similar
to the one shown above will display.
• Refer to the table on page 3-50 for infor-
mation about all possible speaker calibra-
tion messages.
Setup
OK
arrow
3-49
