Setup
PERFORMING AUTOMATIC CALIBRATION
CUSTOM SETUP SETTING DISTANCES
FRONT LEFT 0.0ft
CENTER 0.0ft
FRONT RIGHT 0.0ft
SIDE RIGHT 0.0ft
REAR RIGHT 0.0ft
REAR LEFT 0.0ft
SIDE LEFT 0.0ft
SUBWOOFER 0.0ft
STEP DISTANCES
The SETTING DISTANCES menu is displayed when the MC-8 calibrates speaker distances.
• During speaker distance calibration, the MC-8 sends calibration noise signals to the Main Zone
audio output connectors in the order shown on the SETTING DISTANCES menu. The cursor auto-
matically scrolls downward through speaker calibration parameters, highlighting each parameter
while the MC-8 calculates a distance for the corresponding speaker. As it finishes each parameter,
the MC-8 enters the calibrated value or an ERROR message to the right of the parameter label.
3
• Because of the way low-frequency signals propagate in most listening spaces, automatic speaker dis-
tance calibration often produces unreliable results for subwoofers. For this reason, the MC-8 does not
send calibration noise signals to the Subwoofer connector during speaker distance calibration. Instead,
the MC-8 automatically calibrates the subwoofer distance to the shortest distance of the other speak-
ers. These distances can be manually adjusted. See "PERFORMING MANUAL SPEAKER DISTANCE CAL-
IBRATION" on page 3-53.
This step does not occur when the AUTO SPEAKER
SETUP menu DISTANCES option is selected.
4
3-48
(continued)
CUSTOM SETUP SETTING DISTANCES
FRONT LEFT 12.0ft
CENTER 10.5ft
FRONT RIGHT 12.0ft
SIDE RIGHT 4.5ft
REAR RIGHT ERROR
REAR LEFT 6.0ft
SIDE LEFT 4.5ft
SUBWOOFER N/A
DISTANCES & LEVELS
The SETTING LEVELS menu is displayed when the MC-8 calibrates output levels.
• During speaker levels calibration, the MC-8 sends calibration noise signals to the Main Zone
audio output connectors in the order shown on the SETTING LEVELS menu. The cursor auto-
matically scrolls downward through speaker calibration parameters, highlighting each parame-
ter while the MC-8 calculates an output level for the corresponding speaker. As it finishes each
parameter, the MC-8 enters the calibrated value or an ERROR message to the right of the
parameter label.
CUSTOM SETUP SETTING LEVELS
FRONT LEFT 0.0dB
CENTER 0.0dB
FRONT RIGHT 0.0dB
SIDE RIGHT 0.0dB
REAR RIGHT 0.0dB
REAR LEFT 0.0dB
SIDE LEFT 0.0dB
SUBWOOFER 0.0dB
This step does not occur when the AUTO
SPEAKER SETUP menu LEVELS option is
selected.
Lexicon
CUSTOM SETUP SETTING LEVELS
FRONT LEFT -2.0dB
CENTER ERROR
FRONT RIGHT -2.0dB
SIDE RIGHT -4.5dB
REAR RIGHT -3.0dB
REAR LEFT -3.0dB
SIDE LEFT -4.5dB
SUBWOOFER N/A
LEVELS
