Setup

SPEAKER SETUP PARAMETERS

SETUP SPEAKERS SET CROSSOVERS
The table below indicates the speaker setup parameters for config-
uring the Main Zone audio output connectors for the desired speaker
setup. These parameters are available on the CUSTOM SETUP and
THX SETUP menus.
Parameter Default Setting
FRONT L/R* 40Hz
CENTER* 60Hz
SIDE L/R* 60Hz
REAR L/R 60Hz
SUBWOOFER* 40Hz
THX ULTRA2 SUB OFF
BGC N/A†
ASA APART
* These parameters cannot be adjusted on the THX SETUP menu.
† When the THX ULTRA2 SUB parameter is set to OFF, the BGC parameter is not available (N/A).
3-26
or
CUSTOM SETUP SETUP
CUSTOM SETUP Menu
Possible Settings
FULL, FULL + SUB, 30 to 120Hz, THX 80Hz
FULL, FULL + SUB, 30 to 120Hz, THX 80Hz, NONE
FULL, FULL + SUB, 30 to 120Hz, THX 80Hz, NONE
FULL, FULL + SUB, 30 to 120Hz, THX 80Hz, NONE
FULL, 30 to 120Hz, THX 80Hz, NONE
ON, OFF
ON, OFF
APART, CLOSE, TOGETHER
SPEAKERS SET CROSSOVERS
Speaker setup parameters perform the same function regardless of
the selected speaker setup. When a parameter setting is adjusted on
one menu, the corresponding parameter setting is automatically
adjusted on the other menu. For example, when a THX speaker setup
is selected, the crossover settings on the CUSTOM SETUP menu are
set to THX 80Hz.
Default Setting
THX 80Hz
THX 80Hz
THX 80Hz
THX 80Hz
THX 80Hz
OFF
N/A†
APART
THX SETUP
THX SETUP Menu
Possible Settings
THX 80Hz
THX 80Hz
THX 80Hz
THX 80Hz, NONE
THX 80Hz
ON, OFF
ON, OFF
APART, CLOSE, TOGETHER
