www.level1.com
Unmanaged Fast Ethernet Switches
FSW-1609TFX
16-Port TP w/ 1 Expansion Slot
Fast Ethernet Switch
- Complies with IEEE802.3 and IEEE802.3u standards
- Supports full/half-duplex on each port
- Utilizes auto-MDI/MDI-X, auto-negotiation and store-
and-forward architecture
- Operating at Max. packet filtering and forwarding rate
- Incorporates both copper and fiber connectivity
- Provide an optional slot for fiber optic module for
network expansion (MDU-0122FXT/0123FXC)
FSW-0822
4-Port PoE + 4-Port TP Fast Ethernet Switch
- Complies with IEEE802.3, 802.3u and 802.3af
- Supports back-pressure and flow control
- Combines PoE and traditional switching power into one
network switch
- Fully compliant with the IEEE802.3af PoE standard
- Provide a maximum power of 15.4W per PoE port
- Max. power consumption w/ PoE PD: 65W
Unmanaged Fast Ethernet Switches Comparison
Model FSW-1609TFX
Ports/Expansion 16 x 10/100TX
1 x Expansion slot
Slots MAC Table
Buffer Memory
Backplane 3.2 Gbps
Power supply
FSW-2409TFX
24-Port TP w/ 1 Expansion Slot
Fast Ethernet Switch
- Complies with IEEE802.3 and IEEE 802.3u standards
- Incorporates copper and fiber connectivity
- Provides a network with fiber connectivity through its 100
Base-FX fiber module slot and optional fiber modules
(MDU-0122FXT/0123FXC)
- Utilizes auto-MDI/MDI-X, auto-negotiation and store-
and-forward architecture
- Operating at maximum packet filtering and
forwarding rate
IFE-0500
4-Port PoE + 1-Port TP Industrial
Fast Ethernet Switch
- Provides auto-sensing for providing power to IEEE
802.3af with 15.4W per PoE port
- Provides surge (EFT) protection (3,000 VDC)
- Supports 4,000 VDC Ethernet ESD protection
- Supports redundant 12 ~ 48 VDC power input
- Case design meets IP-30 protection standard
- DIN-rail and wall mount design
- Provides broadcast storm protection
- Supports operating temperature from -10°C~60°C
FSW-2409TFX
24 x 10/100TX
1 x Expansion slot
8K 8K
160 KB 160 KB
4.8 Gbps
Internal Internal
FSW-0809 FSW-0822
4 x 10/100TX 4 x 10/100TX
4 x 10/100TX-PoE 4 x 10/100TX-PoE
1K 1K
96 KB 96 KB
1.6 Gbps 1.6 Gbps
External Internal
FSW-0809
4-Port PoE + 4-Port TP Fast Ethernet Switch
- Provides 8-port 10/100 Mbps Ethernet Switch with 4
shared PoE ports
- Fully compliant with the IEEE802.3af PoE standard
- Provide a maximum power of 15.4W per PoE port
- Max. power consumption w/ PoE PD: 36.3W (30W PD)
- Supports over current and circuit shorting protection
- Provides a store-and-forward and non blocking switching
architecture
IFE-0501
4-Port PoE + 1-Port Multi-mode SC
Fiber Industrial Fast Ethernet Switch
- Provides multi-mode (2km) SC fiber optic connection
- Provides surge (EFT) protection (3,000 VDC)
- Supports 4,000 VDC Ethernet ESD protection
- Supports redundant 12 ~ 48 VDC power input
- Case design meets IP-30 protection standard
- DIN-rail and wall mount design
- Provides broadcast storm protection
- Supports operating temperature from -10°C~60°C
IFE-0500
1 x 10/100TX 1 x MM 100FX-SC
4 x 10/100TX-PoE 4 x 10/100TX-PoE
1K
512 KB
1 Gbps
Terminal Block Terminal Block
IFE-0501
1K
512 KB
1 Gbps
