LevelOne ProCon FSW-1609TFX Brochure page 57

www.level1.com
56
Wireless
WPC-0300
WNC-0300
WNC-0300 / WPC-0300
108 Mbps Wireless PCI/CardBus Adapter
- Auto-switch between the 802.11b/g standards
- Network speeds up to 108 Mbps in Super G mode
- Security protection with 64/128-bit WEP, WPA, WPA2
encryption and 802.1x user authentication
- Auto-select the least crowded channel by dynamic
channel select function
- Detachable 2 dBi antenna (WNC-0300)
- Operates in 2.412 ~ 2.484 GHz frequency
- Ad-Hoc, infrastructure WLAN network wireless roaming
WPC-0600
WNC-0600
WNC-0600 / WPC-0600
N_One Wireless PCI/CardBus Adapter
- Compliant with the current draft-802.11n 2.0 standard
and backward compliant with 802.11b/g standards
- High-speed wireless transmission of up to 300 Mbps
- Provides wireless security with 64/128-bit WEP, WPA-
PSK, WPA2-PSK encoding
- Support Wi-Fi protected setup (WPS)
- Easy to install and configure with the included software
and Windows utility.
- Extended network area connectivity over greater
distances
Wireless Network Adapters Comparison
Model WNC-0300 / WPC-0300
Interface 32-bit PCI / CardBus
Standard Compliant
Wireless Speed 108 Mbps
Antenna Type
2 dBi / Internal
Frequency Range
WPC-0301
WNC-0301
WNC-0301 / WPC-0301
54 Mbps Wireless PCI/CardBus Adapter
- Highly efficient design mechanism to provide unbeatable
performance
- Security protection with 64/128-bit WEP/WPA/WPA2
- Operates in 2.412 ~ 2.484 GHz frequency
- Ad-Hoc, Infrastructure WLAN network wireless roaming
- Built-in diversity patch antenna 2 dBi gain (WPC-0301)
- Data rate auto fall-back under noisy environment or
longer range distance
WPC-0601
WNC-0601
WNC-0601 / WPC-0601
N_Max Wireless PCI/CardBus Adapter
- Comply with IEEE802.11n draft 2.0 standards
- Operation at 2.4 ~ 2.5GHz frequency band to meet
worldwide regulations
- Maximum reliability, throughput and connectivity with
automatic data rate switching and fixed data rate
- Support infrastructure networks via Access Point and
ad-hoc network via peer-to-peer communication
- Support 1T2R Antenna technology
- Support WPA and WPA2 enhanced security
- Support 802.1x attestation and provides WPS
WNC-0301 / WPC-0301
32-bit PCI / CardBus
11b/g 11b/g
54 Mbps
2 dBi / Internal
2.4 GHz 2.4 GHz
one world_one brand_one level_
WNC-0500 / WPC-0500 WNC-0600 / WPC-0600
32-bit PCI / CardBus 32-bit PCI / CardBus
11b/g 11b/g/n Draft 2.0
54 Mbps 300 Mbps
2 dBi / Internal 3 dBi / Internal
2.4 GHz 2.4 GHz
WPC-0500
WNC-0500
WNC-0500 / WPC-0500
54 Mpbs Wireless MIMO PCI/CardBus Adapter
- Backward Compatible with IEEE 802.11b/g standards
- Provides stable throughput improves wireless coverage
- Features MIMO technology for extended operating
range with less blind spots
- Security protection with 64/128-bit WEP, WPA and
WPA2 encryption
WNC-0301USB
WNC-0305USB
WNC-0301USB / WNC-0305USB
54 Mbps Wireless USB Adapter
- Easy plug-and-play setup with installation wizard
- Complies with IEEE 802.11b/g standards for 54 Mbps
wireless connectivity
- Advanced wireless security protection with 64/128-bit
WEP, WPA and WPA2
- Supports USB 2.0/1.1/1.0 interface
- Portable and mini-size design
- Comes bundled with WSK-1000 and WSK-2000 wireless
starter kits (WNC-0305USB)
WNC-0601 / WPC-0601 WNC-0301USB / 0305USB
32-bit PCI / CardBus USB 1.0/1.1/2.0
32-bit PCI / CardBus USB 1.0/1.1/2.0
300 Mbps
Internal
2.4 ~ 2.5GHz 2.4 ~ 2.4835 GHz / 2.4 GHz
54 Mbps
Internal
