LevelOne ProCon FSW-1609TFX Brochure page 12

www.level1.com
Unmanaged Gigabit Ethernet
Switches
GSW-5150
48-Port Fast Ethernet TP +
3-Port Gigabit Ethernet TP/SFP Switch
- Fully compliant with IEEE802.3, 3u, 3ab and 802.3x flow
control for full-duplex model
- 48 10/100 Mbps auto-negotiation RJ45 ports
- 2 10/100/1000Mbps auto-negotiation RJ45 ports
- Supports 1 SFP Mini GBIC interface
- Non-blocking switching architecture
- Supports MAC address auto-learning and auto-aging
- LED indicators for monitoring power, link, activity, speed
- Standard 19" rack-mountable steel case
- Internal universal switching power supply
Web Smart Gigabit Ethernet Switches
GSW-0841
8-Port TP w/ 1-Port shared SFP
Web Smart Gigabit Ethernet Switch
- Supports 4 trunk groups and up to 7 trunk members
- Provides QoS for efficient traffic flow
- 802.1Q VLAN, link aggregation and port mirroring
- Supports back-pressure and flow control
- Supports 9K bytes jumbo frame
- Power consumption: 6.24 Watts (Max.)
Unmanaged/Web Smart Fast/Gigabit Ethernet Switches Comparison
Model GSW-5150
Ports/Expansion 48x 10/100TX
3x 1000 FX-SFP
Slots MAC Table
Buffer Memory
Backplane
Management
Web Smart Fast Ethernet Switches
FSW-1670TX
8-Port PoE + 8-Port TP
Web Smart Fast Ethernet Switch
- Manage both PoE and Legacy network devices on the
same LAN
- Auto-detect Powered Device (PD) and power
consumption
- Remote power feeding up to 100 meters for PoE ports
- Tag-based VLAN, QoS, Diffserv and port-based priority
- Features an easy to use web-based user-interface
- Provides MDI/MDI-X, rack-mount, port trunking and port
mirroring
GSW-1641
16-Port TP w/ 1-Port shared SFP
Web Smart Gigabit Ethernet Switch
- Combines 16 Gigabit network ports with a fiber optic
SFP port
- Provides QoS for efficient traffic flow
- 802.1Q VLAN, link aggregation and port mirroring
- Supports back-pressure and flow control
- Supports 9K bytes jumbo frame
- Power consumption: 14.4 Watts (Max.)
FSW-1670TX
8 x 10/100TX-PoE
8 x 10/100TX
8K 4K
1MB 512 KB
20 Gbps 3.2 Gbps
Internal Web browser
FSW-2470 GSW-0841
24 x 10/100TX 8 x 10/100/1000TX
1 x Expansion slot 1 x 1000FX-SFP
4K 8K
160 KB 180 KB
4.8 Gbps 16 Gbps
Web browser Web browser
FSW-2470
24-Port TP w/ 1 Expansion Slot
Web Smart Fast Ethernet Switch
- Able to partition the switch into 24 groups by using port-
based VLAN technology
- Supports IEEE802.1p CoS and 802.1x flow control
- Complies with IEEE 802.3 10 Base-T, IEEE 802.3u 100
Base-TX/100 Base-FX
- Pause frame for 10/100/1000 Mbps full duplex
- Back-pressure for 10/100 Mbps half duplex
- Supports non-blocking full wire speed architecture
- 19", 1U rack-mountable size
GSW-2440
24-Port Web Smart Gigabit Ethernet Switch
- Provides IEEE802.1p QoS for Traffic Prioritization,
IEEE802.1Q VLAN
- Supports link aggregation and port mirroring
- Provides store-and-forward architecture
- Provides NWay auto-negotiation protocol
- Supports 9K bytes jumbo frame
- Easy to use web-based management interface
GSW-1641
16 x 10/100/1000TX 24 x 10/100/1000TX
1 x 1000FX-SFP
8K
340 KB
32 Gbps
Web browser
GSW-2440
8K
500 KB
48 Gbps
Web browser
