Recommended Enclosures
Please Note: Our suggested box volumes are given as internal air requirements
Sealed Enclosure
Box Volume 2.5 cu.ft
* Box is given as internal air volume including driver displacement.
Ported Enclosure
Box Volume 3 cu.ft.
Box Tuning 30 Hz
Port Diameter 7 in.
Port Length 20 in.
* Box is given as internal air volume including port and driver displacement.
PT15D2 / PT15D4
15.6 in. / 39.6 cm
10.12 in. / 25.70 cm
13.8 in. / 35 cm
PT15D2 / PT15D4
15" Subwoofer
Installation Instructions / Owner's Manual
DB Research L.L.P.
302 Hanmore Industrial Parkway // Harlingen, TX 78550
ph: 877.787.0101 // fx: 956.421.4513 // www.dbdrive.net
®
Advertisement
Related Manuals for DB Drive PT15D2
Summary of Contents for DB Drive PT15D2
-
Page 1: Recommended Enclosures
Box Tuning 30 Hz Port Diameter 7 in. Port Length 20 in. * Box is given as internal air volume including port and driver displacement. PT15D2 / PT15D4 15.6 in. / 39.6 cm 10.12 in. / 25.70 cm 13.8 in. / 35 cm PT15D2 / PT15D4 15”... - Page 2 NTRODUCTION Congratulations on your purchase of a DB Drive state-of-the-art subwoofer compo- nent. Your selection of a DB Drive car audio product indicates a true appreciation of fine musical reproduction. Whether adding to an existing system or including a DB Drive subwoofer in a new system, you are certain to notice immediate performance benefits.
