Owon XDS2000 Series User Manual

Owon XDS2000 Series User Manual

Dual-channel digital storage oscilloscopes
Hide thumbs

Advertisement

Quick Links

Download this manual
XDS2000 Dual-Channel Series
Digital Storage Oscilloscopes
User Manual
For product support, visit:www.owon.com.hk/download
※：The illustrations, interface, icons and characters in the user manual may be slightly
different from the actual product. Please refer to the actual product.

Advertisement

loading
Need help?

Need help?

Do you have a question about the XDS2000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Owon XDS2000 Series

Summary of Contents for Owon XDS2000 Series

  • Page 1 XDS2000 Dual-Channel Series Digital Storage Oscilloscopes User Manual For product support, visit:www.owon.com.hk/download ※：The illustrations, interface, icons and characters in the user manual may be slightly different from the actual product. Please refer to the actual product.
  • Page 2 LILLIPUT Company. Fujian LILLIPUT Optoelectronics Technology Co., Ltd. No. 19, Heming Road Lantian Industrial Zone, Zhangzhou 363005 P.R. China Tel: +86-596-2130430 Fax: +86-596-2109272 Web: E-mail: www.owon.com info@owon.com.cn...

  • Page 3: General Warranty

    General Warranty We warrant that the product will be free from defects in materials and workmanship for a period of 3 years from the date of purchase of the product by the original purchaser from our company. The warranty period for accessories such as probes. This warranty only applies to the original purchaser and is not transferable to a third party.

  • Page 4: Table Of Contents

    Table of Contents 1. General Safety Requirements ..................1 2. Safety Terms and Symbols ....................2 3. Junior User Guidebook ....................4 Introduction to the Structure of the Oscilloscope ..............5 Front Panel ..............................5 Front Panel Menu Buttons .........................6 Rear Panel ..............................6 Control Area ..............................
  • Page 5 How to Operate the Function Menu ..................52 How to Implement Sampling Setup ......................53 How to Set the Display System ....................... 55 How to Save and Recall a Waveform ......................56 How to Record/Playback Waveforms ..................... 63 How to Clone a waveform ........................66 How to Implement the Auxiliary System Function Setting ..............

  • Page 6: General Safety Requirements

    1.General Safety Requirements 1. General Safety Requirements Before use, please read the following safety precautions to avoid any possible bodily injury and to prevent this product or any other connected products from damage. In order to avoid any contingent danger, ensure this product is only used within the range specified.

  • Page 7: Safety Terms And Symbols

    2.Safety Terms and Symbols 2. Safety Terms and Symbols Safety Terms Terms in this manual. The following terms may appear in this manual: Warning: Warning indicates the conditions or practices that could result in injury or loss of life. Caution: Caution indicates the conditions or practices that could result in damage to this product or other property.
  • Page 8 2.Safety Terms and Symbols It is not allowed to measure AC power when the oscilloscope is AC powered. Warning: To avoid fire or electrical shock, when the oscilloscope input signal connected is more than 42V peak (30Vrms) or on circuits of more than 4800VA, please take note of below items: ...

  • Page 9: Junior User Guidebook

    3.Junior User Guidebook 3. Junior User Guidebook This chapter deals with the following topics mainly:  Introduction to the structure of the oscilloscope  Introduction to the user interface  How to implement the general inspection  How to implement the function inspection ...

  • Page 10: Introduction To The Structure Of The Oscilloscope

    3.Junior User Guidebook Introduction to the Structure of the Oscilloscope This chapter makes a simple description of the operation and function of the front panel of the oscilloscope, enabling you to be familiar with the use of the oscilloscope in the shortest time.

  • Page 11: Front Panel Menu Buttons

    3.Junior User Guidebook 8. Power on/off Backlight of this button: Red light: The oscilloscope is turned off (connects with AC Power); Green light: The oscilloscope is turned on (powered by AC Power). Front Panel Menu Buttons Figure 3- 2 Menu Buttons Rear Panel Figure 3- 3 Rear Panel 1.

  • Page 12: Control Area

    Control Area Figure 3- 4 Control Area Overview 1. Function button area: Total 11 buttons. 2. DAQ: Recorder (This function is not available in XDS2000 series.) P/F: Pass/Fail; W.REC: Waveform Record. 3. Trigger control area with 2 buttons and 1 knob.

  • Page 13: User Interface Introduction

    3.Junior User Guidebook 11. M knob (Multipurpose knob): when a symbol appears in the menu, it indicates you can turn the M knob to select the menu or set the value. You can push it to close the menu on the left and right. User Interface Introduction Figure 3- 5 Illustrative Drawing of Display Interfaces 1.

  • Page 14: How To Implement The General Inspection

    3.Junior User Guidebook 12. The waveform of CH2. 13. It indicates the measured type and value of the corresponding channel. "T" means period, "F" means frequency, "V" means the average value, "Vp" the peak-peak value, "Vr" the root-mean-square value, "Ma" the maximum amplitude value, "Mi"...

  • Page 15: How To Implement The Function Inspection

    3.Junior User Guidebook If it is found that the packaging carton or the foamed plastic protection cushion has suffered serious damage, do not throw it away first till the complete device and its accessories succeed in the electrical and mechanical property tests. 2.

  • Page 16: How To Implement The Probe Compensation

    3.Junior User Guidebook Figure 3- 6 Auto set Check CH2 by repeating Step 2 and Step 3. How to Implement the Probe Compensation When connect the probe with any input channel for the first time, make this adjustment to match the probe with the input channel. The probe which is not compensated or presents a compensation deviation will result in the measuring error or mistake.

  • Page 17: How To Set The Probe Attenuation Coefficient

    3.Junior User Guidebook Figure 3- 8 Adjust Probe How to Set the Probe Attenuation Coefficient The probe has several attenuation coefficients, which will influence the vertical scale factor of the oscilloscope. To change or check the probe attenuation coefficient in the menu of oscilloscope: (1) Push the function menu button of the used channels (CH1 or CH2 button).

  • Page 18: How To Use The Probe Safely

    3.Junior User Guidebook attach the probe, the oscilloscope set the attenuation automatically on the oscilloscope vertical menu for the channel to match the probe. For example, if you attach a 10:1 probe with the identifying pin, the screen will prompt "The probe attenuation factor is 10X", and set the attenuation to 10X automatically on the oscilloscope vertical menu for the channel.
  • Page 19 3.Junior User Guidebook Figure 3- 11 Vertical Control Zone 1. Use the Vertical Position knob to show the signal in the center of the waveform window. The Vertical Position knob functions the regulating of the vertical display position of the signal. Thus, when the Vertical Position knob is rotated, the pointer of the earth datum point of the channel is directed to move up and down following the waveform.

  • Page 20: Introduction To The Horizontal System

    3.Junior User Guidebook Introduction to the Horizontal System Shown as Figure 3- 12, there are a button and two knobs in the Horizontal Controls. The following practices will gradually direct you to be familiar with the setting of horizontal time base. Figure 3- 12 Horizontal Control Zone 1.

  • Page 21: Touchscreen Controls (Touchscreen Is Optional)

    3.Junior User Guidebook Figure 3- 13 Trigger Control Zone 1. Push the Trigger Menu button and call out the trigger menu. With the operations of the menu selection buttons, the trigger setting can be changed. 2. Use the Trigger Level knob to change the trigger level setting. By turning the Trigger Level knob, the trigger indicator in the screen will move up and down.

  • Page 22: Gestures In Normal Mode

    3.Junior User Guidebook  Touchable menu pane: Click the icon on the left top of the display area, a menu pane will be shown. Clicking the menu item is same as pushing the corresponding button. Gestures in Normal Mode  Select a channel (CH1 or CH2 button): Touch the pointer on the left side of corresponding channel to make it in selected state.
  • Page 23 3.Junior User Guidebook  Set the horizontal position (Horizontal Position knob): Swipe left or right on the display area. Double Zoom and Single Zoom In touchable menu pane, if DoubleZoom is selected, in the display area, pinch and spread horizontally to change the time base; pinch and spread vertically to change the voltage division of current channel.
  • Page 24 3.Junior User Guidebook In touchable menu pane, if SingleZoom is selected, click anywhere on the Display area to show the touching control panel.

  • Page 25: Gestures In Wave Zoom Mode

    3.Junior User Guidebook  Set the voltage division (Vertical Scale knob): Click on the left upper area to increase the voltage division of CH1; click on the left lower area to decrease the voltage division of CH1. Click on the right upper area to increase the voltage division of CH2; click on the right lower area to decrease the voltage division of CH2.
  • Page 26 3.Junior User Guidebook (Double Zoom)

  • Page 27: Other Operations Using Touchscreen

    3.Junior User Guidebook (Single Zoom) Other Operations Using Touchscreen  Measure with Cursors:  Run/Stop: Double tap on the display area, or click the on the left top of the display area to run or stop the waveform sampling.  Touch keyboard: Click to input. ...
  • Page 28 3.Junior User Guidebook...

  • Page 29: Advanced User Guidebook

    4.Advanced User Guidebook 4. Advanced User Guidebook Up till now, you have already been familiar with the basic operations of the function areas, buttons and knobs in the front panel of the oscilloscope. Based the introduction of the previous Chapter, the user should have an initial knowledge of the determination of the change of the oscilloscope setting through observing the status bar.

  • Page 30: How To Set The Vertical System

    4.Advanced User Guidebook How to Set the Vertical System The VERTICAL CONTROLS includes three menu buttons such as CH1, CH2 and Math, and four knobs such as Vertical Position, Vertical Scale for each channel. Setting of CH1 and CH2 Each channel has an independent vertical menu and each item is set respectively based on the channel.
  • Page 31 4.Advanced User Guidebook 1. To set channel coupling Taking the Channel 1 for example, the measured signal is a square wave signal containing the direct current bias. The operation steps are shown as below: (1) Push the CH1 button to show the CH1 SETUP menu. (2) Select Coupling in the bottom menu.

  • Page 32: Use Mathematical Manipulation Function

    4.Advanced User Guidebook (3) Select Full band in the right menu. The high frequency of the signal will be allowed to pass. (4) Select 20M in the right menu. The bandwidth is limited to 20 M. The frequencies above 20MHz will be rejected. Use Mathematical Manipulation Function The Mathematical Manipulation function is used to show the results of the addition, multiplication, division and subtraction operations between two channels, the FFT...

  • Page 33: Waveform Math

    4.Advanced User Guidebook Switch to select the vertical position or Position value Vertical vertical division of the FFT waveform, Division value/ turn the M knob to adjust it. User Intg, Diff, Sqrt, and user defined function. Function channel Select channel Only the signals whose frequencies are low-pass lower than the current cut-off frequency...

  • Page 34: User Defined Function

    4.Advanced User Guidebook 4. Select Sign as + in the right menu. 5. In the right menu, select Factor2 as CH2. 6. Select Vertical (div) in the right menu, turn the M knob to adjust the vertical position of Math waveform. 7.

  • Page 35: Using Fft Function

    4.Advanced User Guidebook Using FFT function The FFT (fast Fourier transform) math function mathematically converts a time-domain waveform into its frequency components. It is very useful for analyzing the input signal on Oscilloscope. You can match these frequencies with known system frequencies, such as system clocks, oscillators, or power supplies.
  • Page 36 4.Advanced User Guidebook Best solution for frequency, worst for magnitude. Best type for measuring the frequency spectrum of nonrepetitive signals and measuring frequency components near DC. Recommend to use for: Rectangle Transients or bursts, the signal level before and  after the event are nearly equal.

  • Page 37: Use Vertical Position And Scale Knobs

    4.Advanced User Guidebook  DC component or offset can cause incorrect magnitude values of FFT waveform. To minimize the DC component, choose AC Coupling on the source signal.  To reduce random noise and aliased components in repetitive or single-shot events, set the oscilloscope acquisition mode to average.

  • Page 38: Zoom The Waveform

    4.Advanced User Guidebook all channels (include those obtained from the mathematical manipulation), the analytic resolution of which changes with the time base. 2. Horizontal Scale knob: it is used to set the horizontal scale factor for setting the main time base or the window. 3.

  • Page 39: Trigger Control

    4.Advanced User Guidebook signal. Force: Force to create a trigger signal and the function is mainly used in "Normal" and "Single" mode. Trigger Menu: The button that activates the trigger control menu. Trigger Control The oscilloscope provides four trigger types: single trigger, alternate trigger, logic trigger and bus trigger.

  • Page 40: Edge Trigger

    4.Advanced User Guidebook Timeout Trigger: The oscilloscope triggers when the time interval from when the rising edge (or the falling edge) passes through the trigger level to when the neighbouring falling edge (or the rising edge) passes through the trigger level is greater than the timeout time set. Nth Edge Trigger: The oscilloscope triggers on the Nth edge that appears on the specified idle time.
  • Page 41 4.Advanced User Guidebook right corner, after setting, dotted line disappears. 2. Video Trigger Choose video trigger to trigger on fields or lines of NTSC, PAL or SECAM standard video signals. In Video Trigger mode, the trigger setting information is displayed on bottom right of the screen, for example, ,indicates that trigger type is Video, trigger source is CH1, and Sync type is Even.
  • Page 42 4.Advanced User Guidebook Polarity Choose the polarity. When Select pulse width condition and adjust the M knob to set time, press panel button to move cursor to choose which digit to be set. Auto Acquire waveform even no trigger occurred. Normal Acquire waveform when trigger occurred.

  • Page 43: Runt Trigger

    4.Advanced User Guidebook Auto Acquire waveform even no trigger occurred. Normal Acquire waveform when trigger occurred. Single When trigger occurs, acquire one waveform then stop Mode&Hold Holdoff 100 ns – 10 s, turn the M knob to set time interval before another trigger occur, press panel button to move cursor to choose which digit to be set.

  • Page 44: Windows Trigger

    4.Advanced User Guidebook Adjust the M knob to set pulse width, press panel button to move cursor to choose which digit to be set. Trigger when runt pulse is greater than the set pulse width. Trigger when runt pulse equals to the set pulse width. Trigger when runt pulse is lower than the set pulse width.

  • Page 45: Timeout Trigger

    4.Advanced User Guidebook Auto Acquire waveform even no trigger occurred. Normal Acquire waveform when trigger occurred. Single When trigger occurs, acquire one waveform then stop Mode&Hold Holdoff 100 ns - 10 s, adjust M knob to set time interval before another trigger occur, press panel button to move cursor to choose which digit to be set.

  • Page 46: Logic Trigger

    4.Advanced User Guidebook In Nth Edge Trigger mode, the trigger setting information is displayed on bottom right of the screen, for example, ,indicates that trigger type is Nth Edge, trigger source is CH1, -150V is up level or low level threshold. Nth Edge Trigger Nth Edge Trigger menu list: MENU...

  • Page 47: Alternate Trigger (Trigger Mode: Edge)

    4.Advanced User Guidebook trigger type is Logic, logic mode is AND, CH1 high level and trigger level is 0.00mV, CH2 high level and trigger level is 0.00mV. Logic Trigger menu list: MENU SETTING INSTRUCTION Mode Logic Set vertical channel trigger type as Logic trigger. Set logic mode as AND.

  • Page 48: Bus Trigger

    4.Advanced User Guidebook Reject OFF Trigger on rising edge. Slope Trigger on falling edge. Auto Acquire waveform even no trigger occurs 100 ns - 10 s, turn the M knob to set time Holdoff Mode&Hold interval before another trigger occur, press panel button to move cursor to choose which digit to be set.
  • Page 49 4.Advanced User Guidebook Trigger when Chk Error is detected. After Chk Error choosing this condition, press Configure to enter detailed settings. Trigger on the last bit of the preset data. After Data choosing this condition, press Configure to enter detailed settings. Common Baud: adjust M knob to choose common baud.
  • Page 50 4.Advanced User Guidebook I2C Trigger menu list: MENU SETTING INSTRUCTION Bus Type Set vertical channel bus type as I2C trigger. Set CH1 as SCL or SDA. Source Set CH2 as SCL or SDA. Trigger when SDA data transitions from high to low Start while SCL is high.

  • Page 51: Spi Trigger

    4.Advanced User Guidebook Auto Acquire waveform even no trigger occurred. Mode Normal Acquire waveform when trigger occurred. Single When trigger occurs, acquire one waveform then stop. 3. SPI Trigger Trigger on the specified data when the timeout condition is meet. When using SPI trigger, you need to specify the SCL and SDA data sources.
  • Page 52 4.Advanced User Guidebook By using the CAN bus trigger, you can trigger on Start of Frame, Type of Frame, Identifier, Data, ID & Data, End of Frame, Missing Ack, or Bit Stuffing Error. You need to specify the signal source, trigger signal type, sample point, and signal rate of the CAN signal.

  • Page 53: Bus Decoding

    4.Advanced User Guidebook Use the M knob and Direction (Bottom key on the front panel to set. menu) Byte Set the number of bytes with the Length M knob. The range is 1 to 8. Set the data with the M knob and Data Direction key on the front panel.
  • Page 54 4.Advanced User Guidebook Turn the M knob to set the Baud. The range is 50 to 10,000,000. Custom Baud Tip: You can select the nearest value in Common Baud, and then adjust it in this menu. Set the data width of each frame to match the signal. It Data Bits can be set to 5, 6, 7 or 8.
  • Page 55 4.Advanced User Guidebook Note:  Use the Trigger Level knob to adjust the thresholds of bus trigger and bus decoding.  When the ACK (ACKnowledge Character) is not met, two red error marks will be displayed in the corresponding position in the waveform. I2C Decoding menu list: MENU SETTING...
  • Page 56 4.Advanced User Guidebook arrive as the sequence 01001000 in binary representation, will be decoded as the reversed sequence 00010010. SPI Decoding menu list: MENU SETTING INSTRUCTION Bus Type Set bus type of decoding as SPI. Select the clock edge to match the signal, sample the SCLK SDA data on the rising or falling edge of the clock.

  • Page 57: How To Operate The Function Menu

    4.Advanced User Guidebook Decoded information interpretation: Information Abbreviation Background Identifier I, ID, or do not display Green Overload Frame Green Error Frame Green Data Length code L, DLC, or do not display Blue Data D, Data, or do not display Black Valid: Purple Cyclic Redundancy Check...

  • Page 58: How To Implement Sampling Setup

    4.Advanced User Guidebook How to Implement Sampling Setup Push the Acquire button, Acqu Mode, Length, PERF Mode and Intrpl is shown in the bottom menu. The description of the Acqu Mode menu is shown as follows: Function Menu Setting Description Sample Normal sampling mode.
  • Page 59 4.Advanced User Guidebook some points to calculate the whole appearance of the waveform. Select the appropriate interpolation method according to the actual signal. Sine(x)/x interpolation: Connect the sampled points with curved lines. Linear interpolation: Connect the sampled points with straight lines. This method is suitable to rebuild the straight-edged signals, such as square or pulse wave.

  • Page 60: How To Set The Display System

    4.Advanced User Guidebook How to Set the Display System Push the Display button and the Display menu is shown as follows: Function Menu Setting Description Dots Only the sampling points are displayed. Type Vect The space between the adjacent sampling points in the display is filled with the vector form.

  • Page 61: How To Save And Recall A Waveform

    4.Advanced User Guidebook  The Vertical Scale and the Vertical Position knobs of Channel 1 are used to set the horizontal scale and position.  The Vertical Scale and the Vertical Position knobs of Channel 2 are used to set the vertical scale and position continuously.
  • Page 62 4.Advanced User Guidebook When the type is Wave, the menu shows as following: For internal storage, only BIN can be selected. Format Type For external storage, the format can be BIN, (Right menu) Wave TXT or CSV. Choose the waveform to be saved. (If certain channel is off, the corresponding menu item Math will be disabled.)

  • Page 63: Save And Recall The Waveform

    4.Advanced User Guidebook Load Recall the configure from the selected address When the type is Image, the menu shows as following: Ink Saver Select "ON" to open the ink saver. Save the current display screen. The file can be only stored in a USB storage, so a USB Save storage must be connected first.
  • Page 64 4.Advanced User Guidebook the keyboard to confirm. 8. Recalling: The BIN waveform file could be open by waveform analysis software (on the supplied CD). Tip: Whatever the Type of save menu is set, you can save the waveform by just pressing the Copy panel button in any user interface.
  • Page 65 4.Advanced User Guidebook Figure 4- 2: Disk Management of computer 4. Right click 1 or 2 red mark area, choose Format. And system will pop up a warning message, click Yes. Figure 4- 3: Format the USB disk warning 5. Set File System as FAT32, Allocation unit size 4096. Check "Perform a quick format"...
  • Page 66 4.Advanced User Guidebook 6. Formatting process. Figure 4- 5: Formatting the USB disk Check whether the USB disk is FAT32 with allocation unit size 4096 after formatting. Use Minitool Partition Wizard to format Download URL: http://www.partitionwizard.com/free-partition-manager.html Tip: There are many tools for the USB disk formatting on the market, just take Minitool Partition Wizard for example here.
  • Page 67 4.Advanced User Guidebook Figure 4- 6: Reload Disk 4. Right click 1 or 2 red mark area, choose Format. Figure 4- 7: Choose format 5. Set File System FAT32, Cluster size 4096. Click OK. Figure 4- 8: Format setting 6. Click Apply at the top left of the menu. Then click Yes on the pop-up warning to begin formatting.

  • Page 68: How To Record/Playback Waveforms

    4.Advanced User Guidebook Figure 4- 9: Apply setting 7. Formatting process Figure 4- 10: Format process Format the USB disk successfully Figure 4- 11: Format successfully How to Record/Playback Waveforms Wave Record function can record the input current wave. You can set the interval between recorded frames in the range of 10 ms - 10 s.
  • Page 69 4.Advanced User Guidebook Record: To record wave according to the interval until it reaches the end frame set. Record menu (Internal Storage) shows as follows: Menu Setting Instruction Close wave record function. Record Set record menu. Mode Playback Set playback menu. Storage Set storage menu.
  • Page 70 4.Advanced User Guidebook Load Load the waveform record file from the memory. To use wave record function, do as follows: (1) Push Save button. (2) Select Type in the bottom menu, in the left menu, turn the M knob to select Record.

  • Page 71: How To Clone A Waveform

    4.Advanced User Guidebook Record. 3. Select Mode in the bottom menu, select OFF in the right menu. 4. In the bottom menu, select Storage as External. 5. Select Mode in the bottom menu, select Record in the right menu. 6. Select FrameSet in the bottom menu, set End frame and Interval in the right menu.
  • Page 72 4.Advanced User Guidebook Turn the M knob to move line a. Turn the M knob to move line b. Line Two cursors are linked. Turn the M knob to move the pair of cursors. Set the cursors to select the entire screen automatically. Save Save the waveform between two cursors.
  • Page 73 4.Advanced User Guidebook Data format description of OTA waveform file If the source is CH1 or CH2, OTA file consists of two parts: the file header and the data. If the source is CH1&CH2, OTA file consists of three parts: file header, CH1data, and CH2 data.

  • Page 74: How To Implement The Auxiliary System Function Setting

    4.Advanced User Guidebook 8) CHAN Parameter Meaning Value Comment name CHAN Number of 4 bytes int 1 or 2 channels 9) VOL2 Parameter Meaning Value Comment name VOL2 Voltage division, 4 bytes float The value indicates divided by 400 is voltage (the unit is mV), ADC resolution.
  • Page 75 4.Advanced User Guidebook The description of is shown as the follows: Display Menu Function Menu Setting Description BackLight 0% - 100% Turn the M knob to adjust the backlight. Graticule Select the grid type. Menu Time OFF, 5s - 30s Set the disappear time of menu.
  • Page 76 4.Advanced User Guidebook 4. Select ProbeCh. again to begin probe checking and the checking result will occur after 3s; push any other key to quit. ● Pass/Fail The Pass/Fail function monitors changes of signals and output pass or fail signals by comparing the input signal that is within the pre-defined mask.
  • Page 77 4.Advanced User Guidebook 6. Save rule: Select SaveRule in the bottom menu. Select the save location in the left menu, and then select Save in the right menu to save the rules, which could be called up at once when need. Select Load to call up the rule saved. Note: 1.

  • Page 78: How To Update Your Instrument Firmware

    4.Advanced User Guidebook "Communication with PC" on page 87 for the operation steps. ● Update Use the front-panel USB port to update your instrument firmware using a USB memory device. Refer to "How to Update your Instrument Firmware" on page 73. How to Update your Instrument Firmware Use the front-panel USB port to update your instrument firmware using a USB memory device.

  • Page 79: How To Measure Automatically

    4.Advanced User Guidebook Long press the button to power on the instrument. How to Measure Automatically Push the Measure button to display the menu for the settings of the Automatic Measurements. At most 8 types of measurements could be displayed on the bottom left of the screen.
  • Page 80 4.Advanced User Guidebook Remove Remove the chosen measure type. Remove Remove all the measures. Show Show all the measures of CH1 on the screen. Hide the window of CH1 measures. Show Show all the measures of CH2 on the screen. Hide the window of CH2 measures.

  • Page 81: The Automatic Measurement Of Voltage Parameters

    4.Advanced User Guidebook Figure 4- 13 Automatic measurement The automatic measurement of voltage parameters The oscilloscopes provide automatic voltage measurements including Mean, PK-PK, RMS, Max, Min, Vtop, Vbase, Vamp, OverShoot, PreShoot, Cycle RMS, and Cursor RMS. Figure 4- 14 below shows a pulse with some of the voltage measurement points.

  • Page 82: The Automatic Measurement Of Time Parameters

    4.Advanced User Guidebook Top: Voltage of the waveform's flat top, useful for square/pulse waveforms. Vbase: Voltage of the waveform's flat base, useful for square/pulse waveforms. Amplitude: Voltage between Vtop and Vbase of a waveform. Overshoot: Defined as (Vmax-Vtop)/Vamp, useful for square and pulse waveforms.

  • Page 83: Other Measurements

    4.Advanced User Guidebook Phase: Compare the rising edge of CH1 and CH2, calculate phase difference of two channels. Phase difference=(Delay between channels at the rising edge÷Period)×360°. Note for the following delay measurements: When the Source in menu is set to CH1, the Source 1 is CH1, the Source 2 is CH2.

  • Page 84: How To Customize An Automatic Measurement

    4.Advanced User Guidebook Note: When the waveform on the screen is less than a period, the period area measured is 0. How to customize an automatic measurement You can customize automatic measurements by using gating and statistics. Gating 1. Press the Measure button, and the automatic measurement function menu is displayed at the bottom of the screen;...
  • Page 85 4.Advanced User Guidebook 1. Push Cursor to display the cursor menu. 2. In the bottom menu, select Source as CH1. 3. Select the first menu item in the bottom menu, the Type menu will display at the right of the screen. In the right menu, select Time&Voltage for Type, two blue dotted lines displayed along the horizontal direction of the screen, two blue dotted lines displayed along the vertical direction of the screen.
  • Page 86 4.Advanced User Guidebook Move the cursors by gestures About the gestures for moving cursors, see "Other Operations Using Touchscreen" on P22. The Cursor Measurement for FFT mode In FFT mode, push the Cursor button to turn cursors on and display the cursor menu. The description of the cursor menu in FFT mode is shown as the following table: Function Setting...

  • Page 87: How To Use Autoscale

    4.Advanced User Guidebook Two cursors are linked. Turn the M knob to move the pair of cursors. Display the channel to which the cursor Source Math FFT measurement will be applied. Perform the following operation steps for the amplitude and frequency cursor measurement of math FFT: 1.
  • Page 88 4.Advanced User Guidebook Follow-up and adjust both vertical and horizontal settings. Mode Follow-up and only adjust horizontal scale. Follow-up and only adjust vertical scale. Show Multi-period waveforms. Wave Only show one or two periods. If you want to measure the two-channel signal, you can do as the follows: 1.

  • Page 89: How To Use Built-In Help

    4.Advanced User Guidebook triggering. 5. At the mode of Autoscale, if adjust the vertical position, voltage division, trigger level or time scale of CH1 or CH2, the oscilloscope will turn off Autoscale function. To back to Autoscale, Push Autoset. 6. Turn off the submenu at the Autoscale menu, the Autoscale is off and turn on the submenu still enters into the function.
  • Page 90 4.Advanced User Guidebook Help Exit Pass/Fail Inverted Zoom Mode Exit Judge waveform type by Autoset Five kinds of types: Sine, Square, video signal, DC level, Unknown signal. Menu as follow: Sine: ( Multi-period, Single-period, FFT, Cancel Autoset Square: ( Multi-period, Single-period, Rising Edge, Falling Edge, Cancel Autoset Video signal: DC level, Unknown signal: Description for some icons:...

  • Page 91: How To Print The Screen Image

    4.Advanced User Guidebook When the horizontal time base is ≤50ms, the horizontal time base can be expanded for 4 divisions downwards. Single: Push this button you can set the trigger mode as single directly, so when trigger occurs, acquire one waveform then stop. Copy: You can save the waveform by just pushing the Copy panel button in any user interface.

  • Page 92: Communication With Pc

    5.Communication with PC 5. Communication with PC The oscilloscope supports communications with a PC through USB or LAN port. You can use the Oscilloscope communication software to store, analyze, display the data and remote control. For the specific operation method of Oscilloscope host software, please download and view the host help document on our download website.

  • Page 93: Using Lan Port

    5.Communication with PC Using LAN Port Connect directly (1) Connection. Plug in the LAN cable to the LAN port in the back of the oscilloscope; plug the other end into the LAN interface of the computer. (2) Set the network parameters of the computer. Since the oscilloscope can not support obtaining an IP address automatically, you should assign a static IP address.

  • Page 94: Connect Through A Router

    5.Communication with PC (4) Set the network parameters of the oscilloscope. In the oscilloscope, push the Utility button. Select Function in the bottom menu. Select LAN Set in the left menu. In the bottom menu, set the Type item as LAN, and select Set. In the right menu, set IP and Port to the same value as the "Ports-settings"...
  • Page 95 5.Communication with PC Figure 5- 5 Set the network parameters of the computer (3) Set the network parameters of the Oscilloscope Software. Run the software on the computer; choose the "Ports-settings" of the "Communications" menu item. Set "Connect using" to LAN. About the IP, the first three bytes is same as the IP in the step (2), the last byte should be different.
  • Page 96 5.Communication with PC button. Select Function in the bottom menu. Select LAN Set in the left menu. In the bottom menu, set the Type item as LAN, and select Set. In the right menu, set IP and Port to the same value as the "Ports-settings" in the software in step (3). The Netgate and Net mask should be set according to the router.

  • Page 97: Demonstration

    6.Demonstration 6. Demonstration Example 1: Measurement a Simple Signal The purpose of this example is to display an unknown signal in the circuit, and measure the frequency and peak-to-peak voltage of the signal. Carry out the following operation steps for the rapid display of this signal: (1) Set the probe menu attenuation coefficient as 10X and that of the switch in the probe switch as 10X (see "How to Set the Probe Attenuation Coefficient"...

  • Page 98: Example 2: Gain Of A Amplifier In A Metering Circuit

    6.Demonstration Figure 6- 1 Measure period and frequency value for a given signal Example 2: Gain of a Amplifier in a Metering Circuit The purpose of this example is to work out the Gain of an Amplifier in a Metering Circuit.

  • Page 99: Example 3: Capturing A Single Signal

    6.Demonstration Gain = Output Signal / Input signal Gain (db) = 20×log (gain) Figure 6- 2 Waveform of Gain Measurement Example 3: Capturing a Single Signal It's quite easy to use Digital Oscilloscope to capture non-periodic signal, such as a pulse and burr etc.

  • Page 100: Example 4: Analyze The Details Of A Signal

    6.Demonstration (8) Select Source in the bottom menu. Select CH1 in the right menu. (9) Select Coupling in the bottom menu. Select DC in the right menu. (10)In the bottom menu, select Slope as (rising). (11)Turn the Trigger Level knob and adjust the trigger level to the roughly 50% of the signal to be measured.
  • Page 101 6.Demonstration functions acts an important role to help you to find out the details of these noise. Here is how we do it: (1) Push the Acquire button to display the Acquire menu. (2) Select Acqu Mode in the bottom menu. (3) Select Peak Detect in the right menu.

  • Page 102: Example 5: Application Of X-Y Function

    6.Demonstration Figure 6- 5 Reduce Noise level by using Average function Example 5: Application of X-Y Function Examine the Phase Difference between Signals of two Channels Example: Test the phase change of the signal after it passes through a circuit network. X-Y mode is a very useful when examining the Phase shift of two related signals.

  • Page 103: Example 6: Video Signal Trigger

    6.Demonstration (7) Turn the Vertical Scale and Vertical Position knobs, optimizing the waveform. (8) With the elliptical oscillogram method adopted, observe and calculate the phase difference (see Figure 6- 6). The signal must be centered and kept in the horizontal direction. Figure 6- 6 Lissajous Graph Based on the expression sin (q) =A/B or C/D, thereinto, q is the phase difference angle, and the definitions of A, B, C, and D are shown as the graph above.
  • Page 104 6.Demonstration (5) Select Modu in the bottom menu. Select NTSC in the right menu. (6) Select Sync in the bottom menu. Select Field in the right menu. (7) Turn the Vertical Scale, Vertical Position and Horizontal Scale knobs to obtain a proper waveform display (see Figure 6- 7).

  • Page 105: Troubleshooting

    7.Troubleshooting 7. Troubleshooting 1. Oscilloscope is powered on but no Display.  Check whether the power connection is connected properly.  Check whether the fuse which is beside the AC power input jack is blew (the cover can be pried open with a straight screwdriver). ...

  • Page 106: Technical Specifications

    8.Technical Specifications 8. Technical Specifications Unless otherwise specified, the technical specifications applied are for XDS2000 dual-channel series only, and Probes attenuation set as 10X. Only if the oscilloscope fulfills the following two conditions at first, these specification standards can be reached.
  • Page 107 9.Appendix Performance Characteristics Instruction 8 bits 0.05 S/s - 1 GS/s mode Single 12 bits 0.05 S/s - 500 MS/s mode XDS2102 0.05 S/s - 1 GS/s XDS2202 Interpolation (Sinx)/x, x XDS2102A 20M. Max Record length XDS2102 40M； XDS2202 80M（Optional） Scanning speed (S/div) 2ns/div - 1000s/div, step by 1 –...

  • Page 108: Trigger

    8.Technical Specifications Performance Characteristics Instruction Delta Volts between any two averages of ≥16 DC accuracy waveforms acquired with the same scope setup and ambient conditions (△V): (average) ±(3% rdg + 0.05 div) Waveform inverted ON/OFF △V, △T, △T&△V between cursors, Cursor auto cursor Max, Min, PK-PK, Top, Base, Amplitude, Mean,...
  • Page 109 8.Technical Specifications Trigger Holdoff 100 ns – 10 s range 50% level setting Input signal frequency ≥ 50 Hz (typical) Edge trigger slope Rising, Falling Support standard NTSC, PAL and Modulation SECAM broadcast systems Video Trigger 1-525 (NTSC) and 1-625 Line number range (PAL/SECAM) Positive pulse：＞, ＜, ＝...
  • Page 110 8.Technical Specifications Data Line Setting H, L, X Signal Type CAN_H, CAN_L, TX, RX Start of Frame, Type of Frame, Trigger Condition Identifier, Data, ID & Data, End of Frame, Missing Ack, Bit Stuffing Error CAN Trigger Baud Rate Common, Custom Sample Point 5% to 95% Frame Type...

  • Page 111: General Technical Specifications

    8.Technical Specifications General Technical Specifications Display Display Type 8" Colored LCD (Liquid Crystal Display) Display Resolution 800 (Horizontal) × 600 (Vertical) Pixels Display Colors 65536 colors, TFT screen Output of the Probe Compensator Output Voltage About 5 V, with the Peak-to-Peak voltage ≥1 MΩ. (Typical ) Frequency (Typical ) Square wave of 1 KHz...

  • Page 112: Appendix

    9.Appendix 9. Appendix Appendix A: Enclosure (The accessories subject to final delivery.) Standard Accessories: Power Cord CD Rom Quick Guide USB Cable Probe Probe Adjust Options: Soft Bag Appendix B: General Care and Cleaning General Care Do not store or leave the instrument where the liquid crystal display will be exposed to direct sunlight for long periods of time.
  • Page 113 9.Appendix 2. Disconnect power before cleaning your Oscilloscope. Clean the instrument with a wet soft cloth not dripping water. It is recommended to scrub with soft detergent or fresh water. To avoid damage to the instrument or probe, do not use any corrosive chemical cleaning agent.

This manual is also suitable for:

Xds seriesXds2102aXds2102Xds2202
