  • Page 2 Owner's Manual 2FAST / 4FAST Nipponia S.A.

  • Page 3: Introduction

    INTRODUCTION Thank you for purchasing the NIPPONIA 2FAST/4FAST tricycle scooter. This model is designed for safety, built for comfort and space for daily shopping, the ride to work or other use. The superior vehicle design and built-in technology will meet your expectations for an economical and eco-friendly lifestyle.

  • Page 4: Important Manual Information

    • This booklet is compiled with the latest available information. However, due to constant improvements, modifications or alterations may be made without prior notification. Updated versions can be downloaded from the Nipponia website www.nipponia.com Note: Product and specifications are subject to change without notice.
  • Page 5 IMPORTANT MANUAL INFORMATION Dealer label (stamp) here...

  • Page 6: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION………………………………………….. Pre-operation check list........SERVICE PLAN..........IMPORTANT MANUAL INFORMATION……….. Activating the motor……........WIRING DIAGRAM 2FAST......TABLE OF CONTENTS Braking..............WIRING DIAGRAM 4FAST......SAFETY INFORMATION………………………………. Parking..............SPACE FOR NOTES........PERIODIC MAINTENANCE AND DESCRIPTION OF THE VEHICLE...... MINOR REPAIR..........

  • Page 7: Safety Information

    SAFETY INFORMATION Safe riding 1. Always perform the pre-operation inspection before driving. 2. The scooter should not be used by anyone who does not hold a valid driving license. 3. Many accidents involve motorcycles not seen by other drivers, so please pay attention to the following: •...
  • Page 8 5. Do not hang any load on the handlebars or the suspension. 6. The total weight of the driver, accessories and cargo must not exceed the maximum load limit of the scooter. Maximum load: 90-110 kg (2FAST, depending on battery type) Maximum load: 130-144 kg (4FAST, depending on battery type)
  • Page 9 SAFETY INFORMATION Accessories When installing accessories not approved by Nipponia, attention should be paid to the following points: 1. The installation of the accessories must not affect the suspension travel, the light position and the steering angle. 2. Avoid installing any accessories that could hinder your access to vehicle controls and movement of your hands and feet as it could impair your reaction in an emergency event.

  • Page 10: Description Of The Vehicle

    DESCRIPTION OF THE VEHICLE Frame plate (depending on version)

  • Page 11: Side View

    DESCRIPTION OF THE VEHICLE Side view 1. Mirrors Headlight Front turn signal light Front disc brake 5. Charging socket 6. Seat 7. Top box 8. Rear turn signal light 9. Taillight 10. License plate light 11. Rear reflector 12. Anti-tip wheels 13.

  • Page 12: Controls And Instruments

    DESCRIPTION OF THE VEHICLE Controls and instruments Dashboard unit Left grip Left handlebar switches Parking lever USB socket Bag hook Main switch Right handlebar switches Throttle grip...

  • Page 13: Main Components

    MAIN COMPONENTS MAIN SWITCH / STEERING LOCK The main switch/steering lock controls the ignition and lighting systems and is also used to lock the steering wheel. The switch can be turned to the following positions: “ ” - All electrical circuits are supplied with power and the motor is active. The key cannot be removed.

  • Page 14: Dashboard Unit

    MAIN COMPONENTS DASHBOARD UNIT Left turn signal indicator lamp (1) The left turn signal indicator lamp flashes whenever the turn signal switch is pushed to the left side. High beam indicator (2) Indicates that the high beam switch is in ON position. READY indicator (3) This indicator lights when you press the button on the right switch to release the engine to move forward.
  • Page 15 MAIN COMPONENTS Speedometer (7), odometer (8) and ODO indication (9) The dashboard unit is equipped with a speedometer and an odometer. The speedometer shows the riding speed. The odometer (ODO) shows the total distance traveled. Battery charge indicator (10) This symbol lights when the battery is charging. Battery level gauge (11) The battery level gauge indicates the power remaining before re-charging is required.

  • Page 16: Handlebar Switches - Left

    MAIN COMPONENTS HANDLEBAR SWITCHES - LEFT Low/High beam switch (1) Set the switch to position for the high beam. Set the switch to position for the low beam. Turn signal switch (2) Push this switch to position to signal a left-hand turn or to position to signal a right-hand turn.

  • Page 17: Handlebar Switches - Right

    MAIN COMPONENTS HANDLEBAR SWITCHES - RIGHT 1. Hazard lights switch When you press this switch the taillight is turned on and the operation of the throttle is cut-off. 2. Light switch This switch can be set so that the headlight is always on or it functions as a light switch, depending on the version.

  • Page 18: Power Switch

    MAIN COMPONENTS POWER SWITCH The power switch is installed under the seat area of your vehicle. This switch can shut down the main power supply. It can be activated in ON position, if you want to activate the battery. Power switch If you want to turn off the power switch of the vehicle, set the switch to OFF position.

  • Page 19: Front Brake Lever

    MAIN COMPONENTS FRONT BRAKE LEVER The front brake lever is located on the right handlebar grip. To apply the front brake, pull this lever towards the grip. REAR BRAKE LEVER The rear brake lever is located on the left handlebar grip. To apply the rear brake, pull this lever towards the grip.

  • Page 20: Seat And Seat Adjustment

    MAIN COMPONENTS Seat To open the seat, use the lock at the rear side of the vehicle. Turn the key counterclockwise to open the seat and have access to the luggage compartment. CAUTION Do not press the key down when turning the key. To close the seat, lower the seat and push the rear part of the seat until you hear a clicking sound.

  • Page 21: Luggage Box, Usb Socket

    MAIN COMPONENTS Luggage box The luggage box (1) is located under the seat. Its maximum loading capacity is 5kg. CAUTION The luggage box is heated by the sun. Additionally, it is not entirely waterproof. Do not keep sensitive or valuable items inside the compartment. USB socket The USB socket is located on the left side of the vehicle.

  • Page 22: Front Hook

    MAIN COMPONENTS Front hook Use this hook to hang your helmet or light weight parts. CAUTION Do not exceed the maximum load of 1kg for the front hook. Top case A top case is fitted on your vehicle to store your helmet or other items. CAUTION Do not exceed the maximum load of 5 kg.

  • Page 23: Smart Key

    MAIN COMPONENTS Smart key (depending on the version) 1. LOCK Press this button once to activate the alarm function. You will listen to 2 beeps. If you press twice then the alarm system starts ringing. 2. UNLOCK Press this button once to deactivate the alarm system. 3.

  • Page 24: Battery Information

    BATTERY INFORMATION BATTERY This model can carry a 60V 20AH Li-ion battery or a 60V 20AH lead acid battery (depending on version). Only one battery is provided with the purchase of your scooter. An optional battery can be purchased for extended range. The battery is positioned under the luggage box.

  • Page 25: Battery Storage

    BATTERY INFORMATION • The scooter includes a safe mode: as the battery discharges, the vehicle’s maximum speed drops in order to help the driver reach his destination. With 9% of battery life remaining, the scooter’s maximum speed will be reduced to 20km/h. It is recommended that you charge the battery before it runs into this reserve.

  • Page 26: Operation And Driving Instructions

    • Note: if you need assistance with how to perform any of the above-mentioned tasks, do not hesitate to contact an authorized Nipponia service center. Before riding the vehicle, please make sure that you are fully familiar with all operating controls and their functions. Consult...

  • Page 27: Activating The Motor

    OPERATION AND DRIVING INSTRUCTIONS ACTIVATING THE MOTOR 1. Ensure that the parking brake is off. 2. Set the R-N-D switch to N-mode. 3. Turn the main switch to the ON position to activate the motor. The Meter Display will turn on. 4.
  • Page 28 The following instructions will help you to keep your vehicle in a good condition. • If you are not familiar with the maintenance work, contact your local Nipponia dealer. • Maintenance, replacement or repair may be performed by an authorized Nipponia service point.

  • Page 29: Periodic Maintenance And Minor Repair

    PERIODIC MAINTENANCE AND MINOR REPAIR TYRES To maximize the performance, durability and safe operation of your vehicle, always check the tyre pressure. Cracks, damage and wear on the tyres cause unsteady steering or even tyre blow-out. Note that the tyre pressure is measured with cold tyres, ideally when the temperature of the tyres equals the ambient temperature.

  • Page 30: Tyre Wear Condition

    (2). If you notice this line is in the same level with the top of the tread grooves, you will need to replace the tire. If you are not familiar with this, please ask your local Nipponia dealer to help you. •...

  • Page 31: Rim And Tyre Information

    PERIODIC MAINTENANCE AND MINOR REPAIR Rim and Tyre information Rim and tyre dimensions are shown in the following table: Front -> Rim: 2.15 x10’’ Tyre: 3.00-10’’ Rear -> Rim: 2.15 x10’’ Tyre: 3.00-10’’ Type: tubeless Rims The rims must be checked before each ride. If any damage is observed, then replace the rim immediately. Do not attempt even the minimum repair to the wheel.

  • Page 32: Brakes

    CAUTION There should be no free play at the brake lever end. If there is free play, contact your Nipponia local dealer. A soft or spongy feeling in the brake lever can indicate the presence of air in the hydraulic system. If there is air in the hydraulic system, have a dealer bleed the system before operating the motorcycle.

  • Page 33: Brake Fluid

    PERIODIC MAINTENANCE AND MINOR REPAIR Front brake pads Each front brake pad is provided with wear indicators, which allows you to check the brake pad wear without having to disassemble the brake. To check the brake pad wear, check the position of the wear indicators while applying the brake.
  • Page 34 PERIODIC MAINTENANCE AND MINOR REPAIR CAUTION • It is suggested to use the same type of brake fluid. Mixing fluids may result in harmful chemical reaction and lead to poor braking performance. • Be careful that water does not enter the master cylinder when refilling. Water will significantly lower the boiling point of the fluid and may result in vapor lock.

  • Page 35: Front Fork

    3: Brake drum 4: Brace indicator FRONT FORK (for 2FAST model) The condition and operation of the front fork must be checked as follows at the intervals specified in the periodic maintenance and lubrication chart.

  • Page 36: Steering

    PERIODIC MAINTENANCE AND MINOR REPAIR STEERING Worn or loose steering bearings may cause danger. Therefore, the operation of the steering must be checked as follows at the intervals specified in the periodic maintenance and lubrication chart. WHEEL BEARINGS The front and rear wheel bearings must be checked at the intervals specified in the periodic maintenance and lubrication chart.

  • Page 37: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING Although the vehicles receive a thorough inspection before shipment from the factory and again prior to delivery to you, trouble may occur during operation. However, should your vehicle require any repair, take it to a dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the vehicle properly.

  • Page 38: Cleaning And Storage

    CLEANING AND STORAGE CLEANING THE VEHICLE Maintaining the vehicle clean, apart from keeping it attractive, will extend its lifespan and optimize performance. Before cleaning Close all caps, covers, electrical connectors that are well installed, so water can be avoided getting into. Remove the battery while you do the cleaning job.
  • Page 39 CLEANING AND STORAGE Cleaning after normal use Remove dirt with warm water, a mild detergent, and a soft, clean sponge, and then rinse thoroughly with clean water. Use a toothbrush or bottlebrush for hard-to-reach areas. Cleaning after riding in the rain, near the sea or on salt-sprayed roads CAUTION Since sea salt or salt sprayed on the roads during winter are extremely corrosive in combination with water, carry out the following steps after each ride:...

  • Page 40: Storage

    CLEANING AND STORAGE STORAGE Short-term (for a few days) • Always store your vehicle in a cool, dry place and protect it against dust with a vehicle cover. Store the vehicle in a will air flow room with dry air if possible. A place with humidity will cause rust. Long-term (for weeks) •...

  • Page 41: Specifications

    SPECIFICATIONS SPECIFICATIONS 2FAST 4FAST Motor 1000W 1000W Max. Range 40 km 40 km Maximum speed (km/h) Maximum Torque 150 Nm @ 270 rpm 150 Nm @ 270 rpm Battery type Lead acid or Li-ion 60V-20Ah Lead acid or Li-ion 60V-20Ah Full Charge Time 6.5 hours...

  • Page 42: Consumer Information

    CONSUMER INFORMATION VEHICLE IDENTIFICATION NUMBER (VIN) Please write down the VIN (vehicle identification number) to order spare parts or in case the vehicle is stolen. VIN is stamped on the main front tube of the frame. To see the VIN, remove the VIN cover. CAUTION VIN is used to identify your motorcycle and may be used to register your vehicle with the licensing authority in your area.

  • Page 43: Warranty Information

    Only strict compliance with the customer specifications stated in the owner’s manual ensures the prolonging of the natural life of your vehicle. For more details regarding the warranty information, you may visit www.nipponia.com.

  • Page 44: Maintenance Schedule

    MAINTENANCE SCHEDULE The Warranty can be granted only if the vehicle has been serviced in accordance with this maintenance schedule. The inspection intervals are required, otherwise, no warranty can be granted. First Every Every 1000 km 3000 km 6000 km PART TO DO Common check before driving (refer to page 27)
  • Page 45 3. Pour about 110ml of new gear oil. 4. Tighten the filling port to prevent the gear oil from flowing out. 5. For a new vehicle replace the gear oil after the first 1000km. This work should only be done at an authorized Nipponia service point.

  • Page 46: Service Plan

    SERVICE PLAN The Warranty can be granted only if the vehicle has been serviced in accordance with this service plan. 1000 km 3000 km Stamp / Signature Stamp / Signature 6000 km 9000 km Stamp / Signature Stamp / Signature VEHICLE IDENTIFICATION NUMBER: NAME OF THE CUSTOMER: ..
  • Page 47 SERVICE PLAN The warranty can be granted only if the vehicle has been serviced in accordance with this service plan. 12000 km 15000 km Stamp / Signature Stamp / Signature 18000 km 21000 km Stamp / Signature Stamp / Signature VEHICLE IDENTIFICATION NUMBER: NAME OF THE CUSTOMER: ..

  • Page 48: Wiring Diagram 2Fast

    WIRING DIAGRAM 2FAST...

  • Page 49: Wiring Diagram 4Fast

    WIRING DIAGRAM 4FAST...

  • Page 50: Space For Notes

    SPACE FOR NOTES...
  • Page 51 12, Agias Fotinis str. TRADE & TRAFFIC PLUS B.V. a: Prins Mauritslaan 5a, 8091 AJ Wezep, The Netherlands Nea Smyrni, 17121 Athens, Greece e: info@trade-traffic.com e: hq@nipponia.com t: +31 (0) 38-4533222 t: +30 210 9328800 www.trade-traffic.com www.nipponia.com Copyright © 2024 Nipponia SA...
