Bobbin Winding

A
B
C
1. Place the thread spool on the spool pin. Slide a
spool cap firmly against the spool.
2. Pull the thread into the thread guide (A) from
front to the back and thread guide (B) from back
to front.
3. Bring the thread around the bobbin winding
tension disc (C), making sure that the thread is
pulled snuggly between the discs.
4. Place the bobbin on the bobbin winding spindle.
Make sure the bobbin is pushed down firmly.
5. Bring the thread clockwise around the bobbin
and place it through the Thread Cutter located
under the bobbin winding spindle (D).
Note: When the bobbin winding spindle is pushed to the right, the machine will not sew. Make sure to push the bobbin
spindle back to the sewing position (left) before sewing.

Inserting the Bobbin

Note: Make sure that the needle is fully raised and the
machine is turned off before inserting or removing the
bobbin.
1. Remove the bobbin cover (A) by pushing the
small button to the right of the cover (B) towards
the right.
2. Insert the bobbin in the bobbin case with the
thread running in a counterclockwise direction.
3. With the tip of your finger on the bobbin, pull the
thread slightly to the right and under the guide
(C) then towards the left.
4. Continue guiding the thread up toward the left
and around the curve (D).
5. Bring it down the channel toward the front and
into the bobbin Thread Cutter(E). Replace the
bobbin cover and pull the thread to the right to
cut off the excess thread.
6. Push the bobbin winding spindle to the right.
When the winding spindle is pushed to the right,
a bobbin winding pop-up is shown on the dis-
play. Press the Start Button to start winding.
7. Press the Start/Stop Button to pause the wind-
ing if needed. When the bobbin is full press the
Start/Stop Button.
Note: You can also start the winding by using the foot
control.
8. Push the bobbin winding spindle to the left. Re-
move the bobbin and cut the thread by using the
Thread Cutter located under the bobbin winding
spindle (D).
1
A
B
3
C
5
E
D
2
4
D
