Needle Area; Right Side; Top Of Machine - Pfaff creative expect 350 Manual

Needle Area

1. Buttonhole Lever — Used for buttonhole sew-
ing.
2. Built-in Needle Threader — Thread the needle
quickly and easily.
3. Needle Holder with Needle Clamp Screw —
Secures the needle.
4. Needle Thread Guide — Helps maintain thread
flow when sewing.
5. Presser Foot — Holds fabric against feed teeth
which draw fabric under the presser foot as you
sew.
6. Feed Teeth — Feeds the fabric under the presser
foot when sewing.
7. Presser Foot Ankle — Holds the presser foot.
8. Presser Foot Holder Screw — Loosen the screw
to remove the presser foot holder.

Right Side

1. USB port
2. ON/OFF switch
3. Power cord socket
4. Foot control socket

Top of Machine

1. Bobbin winding tension disc
2. Thread guides
3. Handle
4. Main spool pin
5. Bobbin winder
6. Hole for auxiliary spool pin
7. Bobbin winder lever
8. Thread tension discs
9. Thread take-up lever
2 – I ntroduction
1
2
3
4
5
1
2
3
4
2 3
1
9 8
8
7
6
4 5 6 7
