Cleaning instructions
H-2000-4142-03-A
NC4 Servicing – Cleaning the optics
NC4 정비 - 옵틱 청소
Bảo dưỡng NC4 – Làm sạch ống kính
English
한국어
Tiếng Việt

Advertisement

loading
Need help?

Need help?

Do you have a question about the NC4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Renishaw NC4

  • Page 1 Cleaning instructions H-2000-4142-03-A NC4 Servicing – Cleaning the optics NC4 정비 - 옵틱 청소 Bảo dưỡng NC4 – Làm sạch ống kính English 한국어 Tiếng Việt...
  • Page 2 REGARDING THE CONTENT. RENISHAW EXCLUDES LIABILITY, HOWSOEVER ARISING, FOR ANY INACCURACIES IN THIS DOCUMENT. KO 부인 정보 RENISHAW는 출판일 당시 본 문서에 수록된 정보의 정확성에 만전을 기했지만 내용과 관련하여 어떠한 보증이나 주장도 하지 않습니다. RENISHAW는 어떠한 상황에서도 본 안내서의 부정확성에 대하여 어떠한 책임도 지지 않습니다.
  • Page 3 WARNING - LASER RADIATION Class 3R laser radiation is accessible when the access panel is removed. Switch off power before performing any inspection or maintenance operations. 경고 - 레이저 방출 등급 3R 레이저 방출 장비에는 점검판 제거 시 접근 가능합니다. 검사...
  • Page 4 Cleaning instructions NC4 servicing – cleaning the optics You will need … For further information refer to H-2000-5230 자세한 정보는 H-2000-5230을 참조하십시오 필요한 조치... Bạn sẽ cần … Tham khảo H-2000-5230 để biết thêm thông tin www.renishaw.com www.renishaw.com www.rs-components.com www.rs-components.com www.rs-components.com Optical Cleaner (Solvent Cleaner Plus No. Cleaning tool 132-481) 청소용구...
  • Page 5 Cleaning instructions NC4 servicing – cleaning the optics 0 bar 0 bar This figure shows a typical air filter and is shown for illustrative purposes. The air filter fitted to the machine could be different. 이 그림은 일반적인 공기 필터를 보여주는 것으로, 예시 목...
  • Page 6 Cleaning instructions NC4 servicing – cleaning the optics Remove access panel 점검판을 제거하십시오 Tháo panen công tác...
  • Page 7 Cleaning instructions NC4 servicing – cleaning the optics Insert cleaning tool and rotate 70 to 80 degrees 청소용구를 삽입하고 70-80도 정도 돌리십시오 Lắp dụng cụ làm sạch và xoay 70 đến 80 độ...
  • Page 8 Cleaning instructions NC4 servicing – cleaning the optics Clean with solvent and soaked swab 용제를 적신 면봉으로 청소하십시오 Làm sạch bằng dung môi và tăm bông tẩm...
  • Page 9 Cleaning instructions NC4 servicing – cleaning the optics Clean with dry swab 마른 면봉으로 닦아내십시오 Lau sạch bằng tăm bông khô...
  • Page 10 Cleaning instructions NC4 servicing – cleaning the optics Dry optics with clean air 깨끗한 공기로 옵틱을 건조시키십시오 Sấy khô ống kính bằng khí sạch...
  • Page 11 Cleaning instructions NC4 servicing – cleaning the optics     Clean and inspect 청소하고 검사하십시오 Làm sạch và kiểm tra...
  • Page 12 Cleaning instructions NC4 servicing – cleaning the optics Assemble access panel 점검판을 조립하십시오 Lắp panen công tác...
  • Page 13 Cleaning instructions NC4 servicing – cleaning the optics Repeat 반복하십시오 Lặp lại...
  • Page 14 Cleaning instructions NC4 servicing – cleaning the optics Restore electrical power and air supply 전원 공급 장치와 공기 공급 장치를 다시 켜십시오 Khôi phục nguồn điện và nguồn cấp không khí...
  • Page 15 Cleaning instructions NC4 servicing – cleaning the optics     Check laser beam 레이저 빔을 점검하십시오 Kiểm tra tia laze...
  • Page 16 Renishaw plc +44 (0)1453 524524 +44 (0)1453 524901 New Mills, Wotton-under-Edge, uk@renishaw.com Gloucestershire, GL12 8JR United Kingdom www.renishaw.com For worldwide contact details, please visit our main website at www.renishaw.com/contact *H-2000-4142-03*...
