Safety Information; Product Description - Icon Process Controls truflo UltraFlo UF-500 Series Quick Start Manual

Truflo — UltraFlo
®
Clamp-On Ultrasonic Flow Meter Sensor

Safety Information

■ De-pressurize and vent system prior to installation or removal
■ Confirm chemical compatibility before use
■ DO NOT exceed maximum temperature or pressure specifications
■ ALWAYS wear safety goggles or face-shield during installation and/or service
■ DO NOT alter product construction
Warning | Caution | Danger
Indicates a potential hazard. Failure to follow all warnings
may lead to equipment damage, or failure, injury, or death.
Intended Use
The UltraFlo ultrasonic flow meter should only be used for measuring the flow of pure, homogeneous liquids - it is not intended
®
for use in medical applications!
The volume flow meter UltraFlo
"Safety specifications for electrical measurement, control and laboratory devices").
The manufacturer is not responsible for improper use, losses of work caused by either direct or indirect damage, and for expenses
incurred during installation or use of the flow meter.
The manufacturer is not liable for any injury, damage or harm due to inappropriate or unintended use or modifications of the
flow meter. Conversions and/or changes to the flow meter may only be made, if they are expressly performed in accordance with
the operating instructions in this operating manual.
Personnel for Installation, Commissioning, and Operation
All operations described in this instruction manual (i.e. assembly, electrical installation, commissioning and maintenance of the
flow meter) must be carried out only by trained personnel or an accredited person. The qualified personnel must have read and
understood the operating instructions in this manual and must follow said instructions accordingly.
The installer has to ensure that the flow meter is correctly connected according to the electrical connection diagrams in this
operating manual.
Serious injury or death from electric shock may occur if wiring, installation, disassembly or removal of wires is performed while
electrical power is energized.
Warranty and post warranty service must be exclusively carried out by the manufacturer.

Product Description

The Truflo UF-500 series clamp-on ultrasonic flow meters are easy
®
to install with exceptional long life performance and they require no
alteration to current piping configurations.
The sensor sends over 50 pulses/sec in order to provide accurate
measurement of liquid flow rates in full pipes and can be used in low
pressure systems.
Features
Wide Dynamic Flow Range
?
High Accuracy
?
Pipe Sizes ½ – 10"
?
Lightweight
?
Excellent External Corrosion Resistance
?
24-0498 © Icon Process Controls Ltd.
UF-500
®
is built in accordance with industry standard EN 61010 regulations (corresponds to VDE 0411
®
?
?
?
?
?
Do Not Use Tools
Use of tool(s) may damage produced beyond repair and
potentially void product warranty.
No Contact with Liquid
No Moving Parts
Data Logging (day | month | year)
Suitable for RO | DI Systems
Simple Programming & Installation
