Summary of Contents for Estella 348EMIX8
- Page 1 U S E R M A N U A L C O U N T E R T O P M I X E R W I T H P R O G R A M M A B L E C O N T R O L S # 3 4 8 E M I X 8 - 8 Q u a r t # 3 4 8 E M I X 1 2 G - 1 2 Q u a r t w w w.
- Page 2 Countdown Timer and Reminder Power Off Memory Mixer Speeds How to Install a Bowl Installing a Bowl Guard How to Install an Attachment Using Your Estella Attachments Maintenance ..........12 Accessories ...........13 Mixing Capacity ...........14 Cleaning & Maintenance ......14 Troubleshooting ...........15 Note: Save these instructions for future reference.
-
Page 3: Safety Precautions
U S E R M A N U A L O V E R V I E W • Professionally designed metal body and countertop style. • Shafts are mounted in ball bearing and 100% steel gears drive. • Electronic 5-speed control allows for non-stop shifting speed. •... -
Page 4: Specifications
20.2" x 16.6" x 24.1" 75 lb. SAFETY GUARD TRANSMISSION ATTACHMENTS (OPTIONAL ON 348EMIX8, INCLUDED ON 348EMIX12G) Stainless Steel Bowl Transmission gears are made of heat-treated Dough Hook Clear guard that easily rotates to open and reveal a alloy steel and are coated with a special micro switch which immediately shuts off power. -
Page 5: Installation
E L E C T R I C A L C O N N E C T I O N S WARNING: The provided electrical cord on this machine is a three-prong grounding cord. It is imperative that the machine is plugged into a properly grounded outlet. 20.5" 8 QUART (348EMIX8) 18" 13.5" 24.1" 12 QUART (348EMIX12G) 20.2"... - Page 6 U S E R M A N U A L C O N T R O L S NOTE: New mixer bowls and agitators (beaters, whip, and dough hook) should be thoroughly washed with hot water and a mild soap solution, rinsed with either a mild soda or vinegar solution, and thoroughly rinsed with clean water BEFORE being used.
-
Page 7: Operation
U S E R M A N U A L O P E R AT I O N P O W E R O N A N D P O W E R O F F After powered on, all of the indicators and the digital display will flash on, and the buzzer will sound for 1 second. -
Page 8: P O W E R O F F M E M O R Y
U S E R M A N U A L The display will show the program number and time duration once it is saved. To choose a saved program, press the corresponding program number and then press the Start/Pause button to begin the program. *Any current program can be reprogrammed by saving over the program number at any time without needing to clear it. - Page 9 U S E R M A N U A L I N S T A L L I N G A B O W L G U A R D Item #348EMIX8: Turn the mixer off and unplug from outlet.
- Page 10 U S E R M A N U A L I N S T A L L I N G A B O W L G U A R D Item #348EMIX12G: Align the Screw Holes: Align the screw holes of the inner and outer nets so that they overlap vertically.
- Page 11 U S E R M A N U A L H O W T O I N S TA L L A N A T T A C H M E N T To install an attachment, the bowl must be installed and fully lowered. Place the attachment in the bowl, push it up on the attachment shaft, and turn it clockwise to seat the shaft pin to the slot of the attachment shank.
-
Page 12: Maintenance
U S E R M A N U A L M A I N T E N A N C E NOTE: ALL MAINTENANCE WORK SHOULD BE DONE ONLY AFTER THE UNIT HAS BEEN DISCONNECTED FROM ELECTRICAL POWER AND GROUNDING. •... - Page 13 U S E R M A N U A L A C C E S S O R I E S 348EMIX8 Item # 348EMIX12G Item # DESCRIPTION 348EMIX8XBL 348EMIX12XBL Stainless Steel Bowl 348EMIX8XDH 348EMIX12XDH Dough Hook 348EMIX8XFB 348EMIX12XFB Flat Beater...
- Page 14 U S E R M A N U A L M I X I N G C A PA C I T Y INGREDIENT TOOL SPEED 348EMIX8 348EMIX12G Bread and roll dough-60% AR -lbs. Dough Hook 1st Speed Only 4 lbs 5 lbs Heavy Bread dough-55% AR-lbs.
-
Page 15: Cleaning And Maintenance
U S E R M A N U A L C L E A N I N G & M A I N T E N A N C E W A R N I N G DISCONNECT THE MACHINE FROM THE POWER SOURCE BEFORE CLEANING •... -
Page 16: Troubleshooting
U S E R M A N U A L T R O U B L E S H O O T I N G PROBLEM POSSIBLE CAUSE SOLUTION Unit unplugged. Ensure the plug is securely set in the outlet. Check that the outlet matches the units power Improper voltage.
