- Page 1 02/2022 USER MANUAL PIZZA/TORTILLA DOUGH PRESSES 348DPC18NH 348DPC18P 348DPC18T 18" Round 18" Round 18" Round No Heated Platens Top Heated Platen Dual Heated Platens 120V • 1200W 240V • 3300W 348DPC1620T 16" x 20" Rectangular Dual Heated Platens 240V • 3600W...
-
Page 2: Table Of Contents
INDEX Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 Delivery/Setup . - Page 3 SAFETY When using electrical appliances, basic safety precautions should always be followed, including the following: 1 . Keep the work area surrounding the machine clean and organized . 2 . Consider environmental conditions surrounding the machine . Do not use the machine in humid, wet or poorly lit environments .
-
Page 4: Delivery/Setup
. • This manual aims to offer the necessary information to those who are authorized to use the machine . The operators of this machine must read it carefully and apply it strictly . SPECIFICATIONS 348DPC18NH 348DPC18P 348DPC18T 348DPC1620T Press Dimensions 18"... -
Page 5: Controls
CONTROLS Handle Thickness Adjustment Knob Upper Platen Control Panel Power Switch Lower Platen 348DPC18T 348DPC18P 348DPC1620T CONTROL PANEL CONTROL PANEL TEMP + Increases the temperature of upper & lower (if enabled) platens TEMP - Decreases the temperature of upper & lower (if enabled) platens UNIT SWITCH Sets the temperature in Fahrenheit or Celsius... -
Page 6: Operation
OPERATION NO HEATED PLATENS (348DPC18NH) • Diameter and thickness of the finished product is determined through the dough weight, dough temperature, press time and thickness setting . It is recommended to use trial and error to determine the most consistent product . - Page 7 OPERATION UPPER HEATED PLATEN (348DPC18P) • DO NOT touch the heated upper platen . It is hot and can burn the user . • Diameter and thickness of the finished product is determined through the dough weight, dough temperature, press time, thickness setting, & temperature . It is recommended to use trial and error to determine the most consistent product .
- Page 8 OPERATION DUAL HEATED PLATENS (348DPC18T & 348DPC1620T) • DO NOT touch the heated upper & lower platens . They are hot and can burn the user . • Diameter and thickness of the finished product is determined through the dough weight, dough temperature, press time, thickness setting, &...
-
Page 9: Cleaning & Maintenance
OPERATION PROGRAMMING • This unit allows users to save up to 6 temperature and timer programs . 1 . Select the desired temperature unit in Fahrenheit or Celsius by pressing the purple “UNIT SWITCH” button . 2 . Press the program number button where you want the program to be saved . The temperature display and time display will flash . -
Page 10: Circuit Diagrams
CIRCUIT DIAGRAMS 348DPC18P T T i i m m e e r r S S w w i i t t c c h h C C o o n n t t r r o o l l P P a a n n e e l l S S w w i i t t c c h h 3 3 0 0 A A P P o o w w e e r r d d r r i i v v e e b b o o a a r r d d F F u u s s e e 2 2 0 0 A A... - Page 11 CIRCUIT DIAGRAMS 348DPC1620T T T i i m m e e r r S S w w i i t t c c h h S S w w i i t t c c h h 3 3 0 0 A A F F u u s s e e 2 2 0 0 A A P P o o w w e e r r d d r r i i v v e e b b o o a a r r d d C C o o n n t t r r o o l l P P a a n n e e l l...
-
Page 12: Limited Warranty
United States . Estella and Ready Kitchen Warranty will only cover regular rate labor (no overtime or holiday hours) and travel up to 100 miles round trip . - Page 13 Estella shall not be liable, under any legal theory, for loss of use, revenue or profit, or for substitute use or performance, or for incidental, indirect, or special or consequential damages or for any other loss of cost of similar type .
