- Page 1 VENEZIA Instructions / Instructions De Montage / Instrucciones N504SWU N509S N511S...
-
Page 2: Necessary Tools
NECESSARY TOOLS - OUTILS NÉCESSAIRES - HERRAMIENTAS NECESARIAS 2 mm 10mm 17mm 25mm 27mm silicon 17mm 19mm 23mm 27mm 30 mm TECHNICAL DETAILS - DONNÉES TECHNIQUES - DATOS TÉCNICOS Minimum pressure Pression minimum Pression mínima 1 BAR Minimum pressure Pression maximum Pression máxima 10 BAR Reccomended working pressure... - Page 3 TECHNICAL DETAILS - DONNÉES TECHNIQUES - DATOS TÉCNICOS If water pressure is above 5 bar, it is advisable to install a flow restrictor upstream of the water supply to avoid vibrations and regulate temperature. Si la pression de l’ e au est supérieure à 5 bar, il est recommandé d’installer un réducteur de pression en amont de l’alimentation afin d’...
-
Page 4: Pre-Installation
PRE-INSTALLATION - PRÉ-INSTALLATION - PREINSTALCIÓN N504SWU 8-1/4" 8-1/4" 3" - 7-7/8" 3" - 7-7/8" 3" - 7-7/8" 3" - 7-7/8" 7-1/4" 7-1/4" 1-3/4" 2-1/2" 1-3/4" 2-1/2" 5-7/8" 5-7/8" 9/16"-24 UNEF 9/16"-24 UNEF 9/16"-24 UNEF 9/16"-24 UNEF R U B I N E T T I R U B I N E T T I These mixers can be used with high-pressure hot water accumulators or with instant water heaters. - Page 5 PRE-INSTALLATION - PRÉ-INSTALLATION - PREINSTALCIÓN N509SWU 6-1/4" 6-1/4" 3"- 7-7/8" 3"- 7-7/8" 3"- 7-7/8" 3"- 7-7/8" 1-3/4" 2-1/2" 1-3/4" 2-1/2" 5-1/8" 5-1/8" 9/16"- 24 UNEF 9/16"- 24 UNEF "- 24 UNEF 9/16"- 24 UNEF R U B I N E T T I R U B I N E T T I These mixers can be used with high-pressure hot water accumulators or with instant water heaters.
-
Page 6: Installation - Instalación
determinare il danneggiamento della treccia ed il INSTALLATION - INSTALLATION - INSTALACIÓN INSTALLAZIONE INSTALLAZIONE INSTALLATION INSTALLATION INSTALLATION INSTALLATION INSTALLATION INSTALACIÓN INSTALAÇÃO INSTALLATION INSTALACIÓN INSTALAÇÃO bile in caso di piccole perdite. ø x 2 Si consiglia l’installazione di rubinetti sottolavabo INSTALLAZIONE DEI FLESSIBILI (FORNI- INSTALLAZIONE DEI FLESSIBILI (FORNI- TI): avvertenze TI): avvertenze... - Page 7 Verwenden Sie nur die mitgelieferten Druckschläuche. Prüfen Sie vor der Montage das Vorhandensein und die Unversehrtheit der Falze auf beiden Seiten der Druckschläuche. Schrauben Sie die Anschlussstücke mit O-Ring von Hand INSTALLATION an (maximaler Anzugsmoment 3 Nm). Ziehen Sie die Anschlusstücke mit Dichtung (Muttern) erst von Hand und dann - INSTALLATION - INSTALACIÓN Schließen Sie die elektrische Erdung auf keinen Fall an den Druckschlauch oder ein anderes Wasserrohr an.
- Page 8 INSTALLATION - INSTALLATION - INSTALACIÓN...
- Page 9 INSTALLATION - INSTALLATION - INSTALACIÓN...
- Page 10 INSTALLATION - INSTALLATION - INSTALACIÓN 27mm...
- Page 11 INSTALLATION - INSTALLATION - INSTALACIÓN 23mm G3/8” G3/8” 19 mm 19 mm...
- Page 12 INSTALLATION - INSTALLATION - INSTALACIÓN G1/2” G1/2”...
- Page 13 - UTILISATION- USO On first use or following prolonged periods of inactivity, do not use the first half-litre of drinking water dispensed. Shut off the plumbing system in the event of a long absence. Check the water-tightness regularly. Lors de la première utilisation ou après une longue période de non utilisation, ne pas consommer le premier demi-litre d’...
-
Page 14: Cartridge Replacement
CARTRIDGE REPLACEMENT - REPLACEMENT DE LA CARTOUCHE - SOSTITUTION DEL CARTUCHO 25mm • Replace following the instructions in reverse order (4-3-2-1). • Re-installer au contraire du procédé (4-3-2-1). • Colocar según el procedimiento inverso (4-3-2-1). - Page 16 PRE-INSTALLATION - PRÉ-INSTALLATION - PREINSTALCIÓN N511SBU+R011AU 1-3/8" 1-3/8" 11-5/8" 11-5/8" 6-1/4" 6-1/4" 5" 5" 5-7/8" 5-7/8" 1-3/4" 1-3/4" 2-1/2" 2-1/2" 2-1/2" 2-1/2" 2-1/2" 2-1/2" 1/2"NPT 1/2"NPT 1/2"NPT 1/2"NPT 1/2"NPT 1/2"NPT 1-1/4" 1-1/4" G1/2" G1/2" These mixers can be used with high-pressure hot water accumulators or with instant water heaters. Ces mitigeurs peuvent être utilisés avec des accumulateurs d’...
- Page 17 INSTALLATION - INSTALLATION - INSTALACIÓN...
- Page 18 INSTALLATION - INSTALLATION - INSTALACIÓN 10mm 17mm...
- Page 19 INSTALLATION - INSTALLATION - INSTALACIÓN...
- Page 20 INSTALLATION - INSTALLATION - INSTALACIÓN METAL...
- Page 21 INSTALLATION - INSTALLATION - INSTALACIÓN...
- Page 22 INSTALLATION - INSTALLATION - INSTALACIÓN...
- Page 23 INSTALLATION - INSTALLATION - INSTALACIÓN 27mm...
- Page 24 INSTALLATION - INSTALLATION - INSTALACIÓN 17mm...
- Page 25 - UTILISATION - USO On first use or following prolonged periods of inactivity, do not use the first half-litre of drinking water dispensed. Shut off the plumbing system in the event of a long absence. Check the water-tightness regularly. Lors de la première utilisation ou après une longue période de non utilisation, ne pas consommer le premier demi-litre d’...
- Page 26 CARTRIDGE REPLACEMENT - REPLACEMENT DE LA CARTOUCHE - SOSTITUTION DEL CARTUCHO 27 mm • Replace following the instructions in reverse order (6-5-4-3-2-1). • Re-installer au contraire du procédé (6-5-4-3-2-1). • Colocar según el procedimiento inverso (6-5-4-3-2-1).
- Page 27 Notes / Notes / Notas...
- Page 28 Fratelli Fantini Spa via Buonarroti, 4 Pella (NO) Italia T +39 0322 918411 r.a. F +39 0322 969530 fantini@fantini.it www.fantini.it...
