AFLAMO HONOS 65 Assembly Instructions

Before installation, check the specifications described in the "Important safety instructions" section to determine whether the
Installation of wall-mounted bioethanol fireplaces HONOS 65, 90, 125, 155, 185
The bio-fireplace should be installed on the wall only by a certified installer. Only install the bio-fireplace on a wall made of non-flammable materials.
Before installation, check the specifications described under "Important safety
instructions" to determine whether the room intended for installation is suitable
for
For installation, the position of the mounting holes must be marked on the wall at
the target location.
It is recommended to use a level to obtain the plumb and level of the mounting strips.
When installing a bioethanol fireplace under a TV, a distance of 40-50 cm is
recommended.
If installed under the TV, the bioethanol fireplace should be mounted so that the
heat does not directly affect the TV.
Use plasterboard with
Drill holes and fix the rails with the fasteners to the wall using the mounting
materials provided (the fasteners provided are suitable for stone, brick and
concrete walls). Hang the bioethanol fireplace on the fixing rails and make sure that the
fixing rails and the unit are securely fastened.
Before or after installing the appliance, make sure that the location on which the appliance is
mounted can support its weight.
It is advisable to install a thermal mat behind the bioethanol fireplace (we recommend placing
it on the back of the bioethanol fireplace) to avoid direct heat impact on the surface on which
it is mounted.
Place the bioethanol container in the appliance. Never place a filled biofuel container, as fuel
may be inadvertently spilled on parts of the appliance or its surroundings. For adjustable
containers, place the bioethanol container lid on the container in such a way that the lid can
move freely back and forth when closing or controlling the flame height.
Installation of built-in bioethanol fireplaces JUNO 54, 79, 114, 144, 174
The bioethanol fireplace should be installed on the wall only by a certified
installer. Only install the bioethanol fireplace on a wall made of non-
flammable materials. Before installing the bioethanol fireplace, check the
specifications described in the section "Important safety instructions" to
determine whether the room intended for installation is suitable for use of
the appliance. Bioethanol fireplaces of the type JUNO are built-in
appliances. The assembly
should be carried out according to the steps described below.
Installation consists of attaching the bioethanol fireplace insert to the wall
or to the built-in structure with two holes on the right and left side.
When starting the installation, remove the mounting points closer to the
front frame of the bioethanol fireplace using, for example, a screwdriver or
other tool by pushing in.
For installation, pre-insert the insert and mark the position of the mounting
holes on the wall.
It is advisable to use a level to obtain the plumb and level of the insert.
Drill holes, insert the mounting dowels and fix the insert by screwing in
place (the fasteners supplied are suitable for stone, brick and concrete
walls).
Ensure that the device is securely fixed.
It is advisable to leave a clear ventilation space behind the bioethanol
fireplace and to install a thermal mat on the back to avoid direct heat
exposure to the surface on which it is mounted.
Use plasterboard with increased temperature resistance for plasterboard construction.
ASSEMBLY INSTRUCTIONS
room to be installed is suitable for use of the unit.
the
increased temperature
appliance.
NAZWA HONOS 65
A [cm]
B [cm]
resistance.
C [cm]
D [cm]
HONOS 90 HONOS 125
x x x
45 45 45
x x x
15 15 15
HONOS 155 HONOS 185
x 1350
45 45
90 90
15 15
