- Page 3 SA400-SA400S-SA400SL Self-powered siren security FEATURES Complies with EN50131 standard Advanced periodic self-diagnosis technology, with ANOMALY output signal ! Internal container entirely made of metal, for high resistance to break-in attempts ! External ABS container with polycarbonate ! LED flasher with high luminous efficiency and low consumption ! Excludable HILTRON logo lighting (SA400SL) ! Tensione nominale di alimentazione: 14Vdc ! Nominal supply voltage: 14Vdc...
- Page 4 SA400-SA400S-SA400SL Self-powered siren security DESCRIPTION OF CONNECTION SIGNALS On the terminal block of the SA400 siren, the following signals are available: SIREN TERMINAL BLOCK DESCRIPTION TAMPER SIREN POWER SUPPLY + 1 (+) SIREN POWER SUPPLY 2 (-) TAMPER OUTPUT_ A NC (TAMP_A) TAMPER OUTPUT_ B NC (TAMP_B)
-
Page 5: Dip Switch Configuration
SA400-SA400S-SA400SL Self-powered siren security LOGO LIGHTING (SA400SL only) It is possible to permanently turn the HILTRON logo on or off, using a specially designed JUMPER. TO TURN ON THE HILTRON LOGO PERMANENTLY: POSITION JP1 TO ON TO PERMANENTLY TURN OFF THE HILTRON LOGO: POSITION JP1 TO OFF ON OFF ON OFF LOGO LIGHTING CIRCUIT... - Page 6 SA400-SA400S-SA400SL Self-powered siren security SW1 DIP SWITCH DESCRIPTION The switches of the SW1 block are identified individually as: SW1–1 / SW1–4 Detailed description follows: SW1 - 1 SW1 - 2 ALARM CYCLE DURATION TIME 3 MINUTS 8 MINUTS 15 MINUTS INFINITE (not compliant with En50131) NOTE1: The configuration with INFINITE alarm cycle duration does not comply with the EN50131 standard.
- Page 7 SA400-SA400S-SA400SL Self-powered siren security SW1 - 4 SYSTEM STATUS POLARITY SELECTION SYSTEM inserted on NEGATIVE front front from POSITIVE to NEGATIVE: SYSTEM INSERTED front from OPEN to NEGATIVE: SYSTEM INSERTED front from NEGATIVE to POSITIVE: SYSTEM DISABLED front from NEGATIVE to OPEN: SYSTEM DISABLED SYSTEM inserted on the front POSITIVE COMMAND front from NEGATIVE to POSITIVE: SYSTEM INSERTED front from OPEN to POSITIVE: SYSTEM ARMED...
- Page 8 SA400-SA400S-SA400SL Self-powered siren security SW2 DIP SWITCH DESCRIPTION The switches of the SW2 block are identified individually as: SW2–1 / SW2–4 Detailed description follows: SW2 - 1 SELECTION OF FLASHES ON ARMING / DISARMING NO Flashes on ARMING event / DISARMING event 2 flashes on system ARMING event 3 flashes on system DISARMING event SW2 - 1...
-
Page 9: Installation Procedure
SA400-SA400S-SA400SL Self-powered siren security INSTALLATION PROCEDURE ATTENTION: During the TEST / INSTALLATION procedure, the alarm cycle is inhibited. For quick installation we recommend operating as follows: 1) Check the following conditions: Turn off the burglar alarm control unit Disconnect all batteries from the anti-theft system Turn off the anti-theft power supplies Disconnect the siren battery 2) Remove the siren's plastic cover... - Page 10 SA400-SA400S-SA400SL Self-powered siren security LED 1 GREEN: FIXED OFF ERRORS ABSENT LED 2 RED: FIXED OFF ANOMALIES ABSENT LED 3 YELLOW: FLASHES: 1 second on + 1 second off Se sono presenti delle anomalie, si potrà osservare: LED 1 GREEN: FIXED OFF ERRORS PRESENT LED 2 RED: FLASHING...
- Page 11 SA400-SA400S-SA400SL Self-powered siren security DESCRIPTION OF CIRCUIT OPERATION FAULT The SA400 siren has been designed to comply with the EN50131 standard. The siren integrates a sophisticated periodic self-diagnosis technology that allows it to verify correct functioning. In the event of a fault, the software classifies the type of fault and applies possible solutions. In all cases of siren failure, the control panel is alerted via the ANOMALIE circuit which changes the output status as described below: Table 2 FAULT output status...
- Page 12 SA400-SA400S-SA400SL Self-powered siren security ERROR RESOLUTION PROCEDURE The siren, during its operation, carries out a series of periodic tests to check that the electronic circuits are in perfect working order, without any type of error / anomaly / fault. If no errors are detected, LED2-RED in Figure 1 (ERROR LED) is permanently off. If errors are detected, LED2-RED in Figure 1 (ERROR LED) starts to flash.
-
Page 13: Flashing Light
SA400-SA400S-SA400SL Self-powered siren security SUMMARY OF OPERATION STATUS OF THE LEDS AND FLASHING LAMP Figure 4 – LED and FLASHING LIGHT arrangement LED 1GREEN LED 1GREEN LED 2 RED LED 2 RED LED 3 YELLOW LED 3 YELLOW 6 LED for FLASHING LIGHT Table 4 –... - Page 14 SA400-SA400S-SA400SL Self-powered siren security 4 WIRE CONNECTION DIAGRAM (2 for TAMPER) (NOT COMPLIANT WITH EN50131) This type of connection is strongly discouraged. Where possible, use the 5-wire connection. The connection diagram of the 4-wire ALARM COMMAND circuit requires the control unit to have an output for the siren of the type: CENTRAL UNIT –...
- Page 15 SA400-SA400S-SA400SL Self-powered siren security CONNECTION DIAGRAM WITH XMR CONTROL UNITS + 12V + Int + SA COM + SIR + OUT + 12V A B IN A B GND 011 012 GND Consolle SA400 On the siren configure SW1-3 OFF ALARM active on negative/OPEN edge Manual always updated on: hiltron.it...
-
Page 16: Central Unit
SA400-SA400S-SA400SL Self-powered siren security 5 WIRE CONNECTION DIAGRAM (MANDATORY FOR EN50131) The connection diagram of the 5-wire ALARM CONTROL circuit is described in the following paragraph. This type of connection complies with the EN50131 standard. This type of connection uses the energy supplied by the power supply to carry out the alarm cycle; the battery is used in back-up mode, i.e. - Page 17 SA400-SA400S-SA400SL Self-powered siren security CONNECTION DIAGRAM FOR FULL EN50131 COMPLIANCE The connection diagram to obtain full compliance with the EN50131 standard is described in the following paragraph. Figure 8 – Connection diagram fully compliant with EN50131 IN SERIES WITH THE 24H PROTECTION LINE OF THE ANTI-THEFT SYSTEM CENTRAL UNIT ALIM +...
-
Page 18: Quick Installation
SA400-SA400S-SA400SL Sirena autoalimentata per esterno security QUICK INSTALLATION INSTALLATION PROCEDURE Carry out the fixing of the container as described in paragraph 3 (see, operations described from point 1 to point 6) Set the dip switches according to the desired configuration Verify that power sources are all disconnected (power supplies and batteries) Carry out the electrical connection, depending on the desired configuration Turn on the siren's power... - Page 20 www.hiltron.it...
