Contents Contents
Before
installation
Installation

Parts list

Parts list
Check that all of the following items are present
①
Speaker X1
④
A llen key (large)
(For securing speaker) X1
Parts list
Safety guidelines
Checklist before use
Speaker installation example
Parts and connections
Adjusting the speaker angle
Installing the speaker grille
Reversing the position of the speaker arm to the base
On a ceiling or wall
Care / Specifications
Warranty and customer service
②
Grille X1
⑤
A llen key (small)
( For securing drop-prevention
wire to speaker)
- 18 -
③
S afety cable
(hole thread diameter 4.5 mm) X1
⑥
Owner's Manual X1
X1
18
19
19
20
21
22
23
24
25
31
32
⑦
Warranty
