- Page 1 VT3500-AI INSTALLATION GUIDE: Hardwired AI Enabled...
-
Page 2: Table Of Contents
VT3500-AI INSTALLATION GUIDE Table of Contents: Foreword Important Instructions Schematic Diagram of System Connection Preparation for Installation List of Installation Materials and Tools Determining the Camera's Mounting Position Installation of the Mounting Bracket & Camera Power Supply Connection, Connection of Signal Cables and Wiring... -
Page 3: Foreword
VisionTrack Ltd. has the right of final interpretation for this document, and reserves the right to make corrections to this document or to make changes to the information and description herein. No prior notice will be given if there is any change. -
Page 4: Schematic Diagram Of System Connection
VT3500-AI INSTALLATION GUIDE Schematic Diagram of System Connection Power Supply via OBD VT3500 OBDII Plug & Common locations for a Play Cable vehicle diagnostic port Note: The colored sensor wires are not used for a plug & play install Power Supply through Internal Vehicle Wiring... -
Page 5: Preparation For Installation
VT3500-AI INSTALLATION GUIDE Preparation for Installation Technical Requirements for Installation Qualified installers should already be familiar with the functions, applications, and the overall principles of the product. They should also be able to understand electrical circuits within a motor vehicle, including common installation methods of in-vehicle equipment. - Page 6 VT3500-AI INSTALLATION GUIDE Preparation for Installation ACC: When the vehicle is in ACC position or ignition state, use a multimeter to measure whether the voltage is about 24V. If the voltage is 0 in shutdown state and about 24V in ACC position or ignition state, select the cable as the ACC power supply connection cable.
- Page 7 VT3500-AI INSTALLATION GUIDE List of Installation Materials and Tools Before installation The following installation accessories and tools should be made available to use: Install Guide Torsion Tighten Screws Common screwdriver socket set Tighten screws; optional Pry open the vehicle panel...
-
Page 8: Determining The Camera's Mounting Position
VT3500-AI INSTALLATION GUIDE Determining the Camera's Mounting Position The installation area is generally selected as shown in the figures below: The DVR must be installed in the middle of the front windshield, generally in the rear view mirror area above the centerline of the front windshield. If this is... -
Page 9: Installation Of The Mounting Bracket & Camera
VT3500-AI INSTALLATION GUIDE Installation of the Mounting Bracket & Camera Clean the interior and exterior of the glass in the installation area with alcohol wipes to ensure that there is no dirt in this area that will affect the view of the external camera lens, and then ensure the glass is dry. -
Page 10: Power Supply Connection, Connection Of Signal Cables And Wiring
VT3500-AI INSTALLATION GUIDE Installation of the Mounting Bracket & Camera Installation of the Mounting Bracket & Camera Run the VT3500 Power Supply Box cable up towards the roof of the vehicle and use the level tool to tuck it in the lining of the ceiling panel and down the pillar of the driver's side. Tighten the mounting bracket screw once happy with the placement. - Page 11 VT3500-AI INSTALLATION GUIDE Power Supply Connection, Connection of Signal Cables and Wiring • Connect POWER to the constant power supply of the vehicle • Connect GND to the ground wire of the vehicle • Connect ACC to the Ignition Positive supply of...
- Page 12 VT3500-AI INSTALLATION GUIDE Power Supply Connection, Connection of Signal Cables and Wiring *Note: If the measured signal is a pulse signal, the source of left steering/right steering/ brake signal should be set as pulse on the setting interface of the main unit; if the...
-
Page 13: Install Verification
VT3500-AI INSTALLATION GUIDE Install Verification Turn the vehicle on and let it run. The camera will boot up with a series of lights and is complete when the green light is solid as pictured below. Light Indicators: Camera is powered on and... - Page 14 VT3500-AI INSTALLATION GUIDE Install Verification The ability to adjust the in-cab view and access the SIM and two Micro SD cards on the bottom of the camera is available. Never remove the SD or SIM cards when the vehicle is in use and the camera's lights are on.
-
Page 15: Vt3500 Ai Calibration Instructions
VT3500-AI INSTALLATION GUIDE VT3500 AI Calibration Instructions Prepare for Calibration: Approved for Firmware Versions V355_T230103.71 and above Ensure the vehicle is parked on level ground. Use a measuring tape, and something to notate the measurements. Download the Veyes Veyes Mobile App for Calibration & Device Settings... - Page 16 VT3500-AI INSTALLATION GUIDE VT3500 AI Calibration Instructions Open the Veyes App once connected to the camera's WIFI: Logging in to the camera’s WIFI To log in use the following details: Username: admin Password: VT2000 Select Preview from the top menu once logged in.
- Page 17 VT3500-AI INSTALLATION GUIDE VT3500 AI Calibration Instructions Channel 1 should be selected in blue, then select calibration: Select the boxes for both questions. Refer to the recommended placement locations outlined in the VT3500 installation guide. Select next:...
- Page 18 VT3500-AI INSTALLATION GUIDE VT3500 AI Calibration Instructions Enter the four measurements taken at the beginning of the calibration process. Select next: Select next: Align the bottom horizontal line to the bottom of the vehicle's windshield as pictured in the image on the next page.
- Page 19 VT3600-AI INSTALLATION GUIDE VT3500 AI Calibration Instructions Align the bottom horizontal line to the bottom of the vehicle's windshield. Check the box for the the question "Did you connect the vehicle left/right turn signal to MDVR" even if lane departure is not being used and the turn signals were not connected to the VT3500. This is a required step to proceed with the app.
- Page 20 VT3600-AI INSTALLATION GUIDE VT3500 AI Calibration Instructions Test the turn signals if using this feature. If not, select complete. Calibration is now complete. Select ‘Preview’ to check the angle of channels 2, 3, and 4 Adjust the angle for channel 2 using the latch found under the camera as pictured below: VT3500 Device Settings The VT3500 AI Enabled camera ships pre-configured for AI features.
