- Page 1 THE NEXT GENERATION OF TELEMATICS AND INTEGRATED CAMERA SOLUTIONS VT2.2 INSTALLATION GUIDE Optional Secondary Camera THE UK'S MOST AWARD-WINNING CAMERA TELEMATICS COMPANY www.visiontrack.com...
-
Page 2: Key Features
VT2.2 INSTALLATION GUIDE Overview VT2.2 is an industry-leading, 2-channel connected full-HD vehicle camera, with GPS/GLONASS, G-shock sensor and built-in Wi-Fi. The super-wide viewing angle provides high-resolution images before, during and after any incident. VT2.2 can be connected to our telematics... -
Page 3: What's In The Box
VT2.2 INSTALLATION GUIDE What’s in the box: VT2.2 Vehicle 2. VT2.2 Power Camera Kit Cable 3M™ Pad (x2) Installation Guide Wire Splice Spare Locking Clips (x2) Screw www.visiontrack.com... - Page 4 VT2.2 INSTALLATION GUIDE VT2.2 Details: Camera Lens Windscreen Bracket (GPS/GLONASS module inside) Power Cable (95cm) 2nd Camera Port (Mini Stereo connector 5V camera, analogue/D1 resolution camera only) PANIC Communication LED button Green LED RS-232C Port (for an external device such as OBD2 or...
-
Page 5: Installation
VT2.2 INSTALLATION GUIDE VT2.2 Installation: Adjust the bracket up or down by removing the screw first (see below), then adjust the angle depending on the specific angle of your windscreen and tighten the screw to lock. Provided is a 3M™ adhesive pad, please attach to the VT2.2... -
Page 6: Rear View Mirror
VT2.2 INSTALLATION GUIDE IMPORTANT: Degrease and clean windscreen before attaching. After the windscreen is clean, secure the VT2.2 behind the rear-view mirror, below the windscreen tint. Place the camera as high on the Windsc windscreen as possible, but still within the windscreen wiper area. - Page 7 VT2.2 INSTALLATION GUIDE VT2.2 Wiring: reen Line up the arrows on the cables to connect the VT2.2 with the power kit cable. Once the arrows are lined up, push together and twist the silver plate to secure connection. After connecting the power kit cable to the VT2.2...
- Page 8 OPTIONAL: VT-PANIC BUTTON In the event of an incident, the VT-PANIC button allows drivers to send alerts to the VisionTrack software platform, VT-PANIC Power Alarm In, NC/ON VT-PANIC BUTTON www.visiontrack.com...
- Page 9 VT2.2 INSTALLATION GUIDE VT2.2 Calibration: On start-up, the GREEN light will flash and the BLUE light will stay solid, once the camera is operational you will hear an audio beep. Record LED Blue LED Communication LED Green LED Park your vehicle on a flat surface and press and hold calibration button for 3 seconds, the camera will beep again.
- Page 10 PLEASE KEEP YOUR COMMISSION NUMBER SAFE. WARNING! On installation please leave camera to boot up completely for approximately 5 minutes and call VisionTrack support team on 01246 223 152 to confirm camera install is complete. If you do not do this it will INVALIDATE the warranty.
- Page 11 VT2.2 INSTALLATION GUIDE Optional Secondary Camera: VT2.2 includes an optional secondary camera offering the ability to monitor and record footage of the driver or passengers. Secondary Camera Secondary Camera Secondary Camera Extensions Cable Mounting Accessories Installation of secondary camera: The camera can be mounted anywhere within the vehicle.
- Page 12 THE UK'S MOST AWARD-WINNING CAMERA TELEMATICS COMPANY www.visiontrack.com VT2.2 INSTALLATION GUIDE 2 Chapman Way High Brooms Industrial Estate Tunbridge Wells Kent TN2 3EF...
